Frigidaire FAS186L2A1 User manual

ROOM AIR CONDITIONER
Model No.
FAS186L2A1
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309343701
OWNER’S GUIDE - # 309000825
ENERGY GUIDE - # 309367449
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
PRODUCT NO. BASE MODEL NO. SERIES VOLTS BTU-COOLING
FAS186L2A1 FAS186L2A Gallery 230 17500 BTU
MARKET
USA
Publication No.
5995368478
020316
-EN/SERVICE /BLT
345

03/02 2
Publication No. FAS186L2A1
5995368478
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 03/02
* = Non-Illustrated Parts
FAS186L2A1 Publication No.
5995368478
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309632704 Cabinet,sleeve ,top louvers
* 5303212504 Seal,sleeve/shroud ,23.72" x 1.25" ,bottom
2 309632804 Grille,rear ,with rail
7 309631104 Link,vertical louver ,with handle
8 309633305 Louver Assy,Incl-7,8,9
8 309630804 Louver,horizontal
9 309631004 Louver,vertical
12 309631404 Filter,air ,molded plastic
17 309633205 Front Assembly,w/7,8,9,12,43
19 309341002 Overlay,Frig Gallery
25 309321401 Door,vent ,with actuator
26 309330404 Handle,vent ,gray
26A 309330202 Detent,vent
29 3015312 Screw,8-18AB x 0.500
43 309630904 Panel,cabinet front
70 309342401 Enclosure,elec control mt
78 309350502 Remote Control,transmitter ,with batteries
* 309367449 Energy Guide,FAS186L2A1

03/02 4
Publication No. FAS186L2A1
5995368478
CONTROLS

# = Fast-moving Parts 5 03/02
* = Non-Illustrated Parts
FAS186L2A1 Publication No.
5995368478
CONTROLS
POS. NO PART NO DESCRIPTION
7 309630403 Control Box
* 5303015427 Screw,truss head ,8-18AB x 0.47
10 309623602 Bulkhead,control system
10* 309111201 Grommet,wire protector
12 5304413782 Holder,thermistor ,w/seal
12A 309331801 Clip,sensor retainer ,(2)
13 # 5303306706 Capacitor,370 V ,6+30 mfd
14 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,grounding
15 5303303077 Strap,capacitor mtg.
17 # 309343112 Cord-electric power,type C ,16 AWG
61 5304414095 Thermistor,defrost sensor
70 309342401 Enclosure,elec control mt
71 # 309350401 PC Board,power ,w/temp sensor
72 # 309350403 PC Board,input
72* 5304417643 Ribbon Protector
74 5303301590 Screw,6-20AB x 0.38
75 5304413781 Support,PC board
76 309111602 Transformer,240/12 Volt
76* 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs

03/02 6
Publication No. FAS186L2A1
5995368478
AIR HANDLING PARTS

# = Fast-moving Parts 7 03/02
* = Non-Illustrated Parts
FAS186L2A1 Publication No.
5995368478
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 5303311048 Fan Blade,with clamp
2 3202975 Screw,10-16AB x 0.72 ,square drive
3 309623201 Shroud,cond fan motor
4 5303212504 Seal,sleeve/shroud ,23.72" x 1.25" ,bottom
5 5303015311 Seal,fan housing ,19.56" x 0.50" ,lower
7 5303015427 Screw,truss head ,8-18AB x 0.47
8 # 309630607 Motor,fan
10 309623401 Bulkhead,air system
11 309633001 Blower Wheel,plastic ,with clamp
13 309630302 Cover,blower wheel ,top
15 309630101 Housing,blower scroll
20 309630201 Plate,scroll cover

03/02 8
Publication No. FAS186L2A1
5995368478
COMPRESSOR PARTS

03/02 9
FAS186L2A1 Publication No.
5995368478
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 309603112 Compressor
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 5303291330 Gasket,terminal cover
7 5304416126 Cover,elec terminal ,compressor
8 5304414111 Overload Protector,MRA 12044-386
9 5303294292 Nut,terminal cover
11 # 309634201 Evaporator
12 # 5303306719 Condenser
13 309623501 Tray,evap drip
14 309632910 Base,compressor mtg. ,with studs
16 # 5303209547 Capillary Tube,50 inch long
17 # 5300265301 Drier-filter,service kit
19 5303002664 Washer,compressor mtg
19* 309112501 Washer,metallic
21 5303293809 Washer,terminal cover

03/02 10
Publication No. FAS186L2A1
5995368478
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 03/02
* = Non-Illustrated Parts
FAS186L2A1 Publication No.
5995368478
POS. NO PART NO DESCRIPTION
1 5304407729 Seal,window stuffer
2 5303211056 Bracket,sash lock
4 5304419163 Extension,sliding frame ,LH cab front ,w/closure panel
5 5304409250 Seal,top rail/cab
6 5304414933 Retainer,accordian
7 5304414105 Bracket,support ,RH
8 3001815 Bracket,sill/unit sprt.
9 3007756 Screw,1/4-20 x 0.750
10 3007759 Nut,lock ,1/4-20 ,support bracket
11 5304414106 Bracket,support ,LH
12 3017023 Nut,hex ,10-32 ,2
13 5303281649 Screw,10-32 x 0.500 ,support
14 5304419162 Extension,sliding frame ,RH cab front ,w/closure panel
15 5304414930 Closure,accordian type ,window mount
16 5304414116 Rail,top
17 3002803 Screw,wood, type 17 ,10-12 x 0.750
18 5308012680 Screw,rail
21 5303212504 Seal,sleeve/shroud ,23.72" x 1.25" ,bottom
24 3002801 Screw,8-18B x 0.500
* 309313303 Window Mounting Kit,heavy duty
* 309313204 Mounting Support Kit,heavy duty
* 5304409248 Hardware Kit,window mount ,heavy duty
* 5304409249 Seal,ship screw hole
WINDOW MOUNTING PARTS

03/02 12
Publication No. FAS186L2A1
5995368478 WIRING DIAGRAM
