Frigidaire FAS25EP2A User manual

Product No. FAS25EP2A1
Series heavy duty
Volts 230/208
BTU-Cooling 25000/24700 BTU
BTU-Heating 16000/13000 BTU
Wiring Diagram 81902547
Owner's Guide frig819042060en
Installation Instructions 819042102en
Market North America
M40L0004.eps M40C0010.eps M40M0010.eps 81902547.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995437893
05/05/26
(EN/SERVICE/KC)
099
ROOM AIR
CONDITIONER
Model No.
FAS25EP2A
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995437893 FAS25EP2A1
05/05 2
CABINET, FRONT, CONTROLS

FAS25EP2A1 Publication No: 5995437893
# Functional Parts 3 05/05
* Non-Illustrated Parts
CABINET, FRONT, CONTROLS
POS. NO PART NO. DESCRIPTION
5 5304447944 Vent, fresh air, with lever
7 # 5304447947 Remote Control, transmitter
8A 5304448484 Front Assembly, complete panel, includes 8, 9, 10, 11, 12, 13, 14
8 5304447783 •Panel, front grille
9 5304447784 •Filter, air, plastic frame
10 5304447785 •Louver, horizontal
11 5304447786 •Clip, air vent
12 5304447787 •Frame, front assembly
13 5304447788 •Louver, vertical
14 5304447789 •Dial, louver adjuster
15 5304447790 Frame, shutter panel, LH
16 5304447792 Retainer, shutter lock
17 5304447793 Shutter, accordion panel, RH/LH
18 5304447794 Retainer, shutter mount, cabinet sides
19 5304447795 Rail, shutter track, top
20 5304447796 Cabinet, wrapper/sleeve
21 5304447797 Bracket, cab mounting
22 5304447798 Screw, cab leveling
23 5304447799 Bracket, angle, cab support
24 5304447791 Frame, shutter panel, RH
25 5304447800 Console, control cover
26 # 5304447948 PC Board, display/input
27 5304447949 Clip, cable clamp
28 5304447803 Cover, front plate, control box
29 # 5304447950 PC Board, control/power
30 5304447805 Control Box
31 # 5304447924 Capacitor, fan motor
32 # 5304447807 Sensor, temperature, evap/indoor
33 5304447808 Strap, capacitor mtg.
34 # 5304447964 Capacitor, run
35 # 5304447937 Transformer
36 # 5304447951 Power Cord, LCDI, with test/reset

Publication No: 5995437893 FAS25EP2A1
05/05 4
COOLING & AIR FLOW SYSTEMS

FAS25EP2A1 Publication No: 5995437893
# Functional Parts 5 05/05
* Non-Illustrated Parts
COOLING & AIR FLOW SYSTEMS
POS. NO PART NO. DESCRIPTION
1 5304447971 Base, unit chassis
2 # 5304447943 Valve, water drain, temp sensor
3 5304447963 Plug, drain
6 5304447946 Frame, heater cover, steel
6 # 5304447945 Heater
41 5304447813 Bulkhead, panel, left side
42 # 5304447814 Blower Wheel, centrifugal fan
43 5304447952 Scroll, blower housing, top
44 5304447816 Cover, blower scroll, top plate
45 # 5304447817 Shroud, fan housing
46 # 5304447818 Fan Blade, axial flow
47 # 5304447938 Motor, fan
48 5304447820 Bracket, fan motor mount
49 5304447953 Scroll, blower housing, bottom
50 5304447954 Bulkhead, panel, right side
51 # 5304447965 Evaporator
52 # 5304447966 Capillary Tube
53 # 5304447967 Compressor Assembly, w/electricals, drier, grommets
54 # 5304447968 Condenser
55 # 5304447969 Discharge Tube
56 # 5304447970 Suction Tube

Publication No: 5995437893 FAS25EP2A1
05/05 6
WIRING DIAGRAM
81902547
