Frigidaire FAC082M7A1 User manual

PRODUCT NO. BASE MODEL NO. SERIES VOLTS BTU-COOLING
FAC082M7A1 FAC082M7A Compact 115 8000 BTU
MARKET
USA
Publication No.
5995382966
021217
-EN/SERVICE /KC
345
ROOM AIR CONDITIONER
Model No.
FAC082M7A1
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309107703
OWNER’S GUIDE - # 309000823
ENERGY GUIDE - # 309369924
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917

12/02 2
Publication No. FAC082M7A1
5995382966
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 12/02
* = Non-Illustrated Parts
FAC082M7A1 Publication No.
5995382966
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309643602 Cabinet,wrapper
* 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
6 309640206 Louver Assy,Includes 7,8,9
7 309638002 * Link,vertical louver ,with handle
8 309639302 * Louver,horizontal
9 309342001 * Louver,vertical ,(6)
12 309343501 Filter,air ,7.12 x 17.31 ,no frame
17 309640104 Front Assembly,cabinet ,w/8,9,12,38,43
* 3015312 Screw,8-18AB x 0.500
19 309342909 Dial Plate
20 309364102 Knob,rotary control
22 5303001775 Spacer,dial plate
25 309328603 Door,fresh air vent
26 309638201 Handle,vent door
26A 309330201 Detent,vent
38 309646301 Panel,cabinet front
43 309646401 Frame,cabinet front
* 309369924 Energy Guide,FAC082M7A1

12/02 4
Publication No. FAC082M7A1
5995382966
CONTROLS

# = Fast-moving Parts 5 12/02
* = Non-Illustrated Parts
FAC082M7A1 Publication No.
5995382966
CONTROLS
POS. NO PART NO DESCRIPTION
7 309643802 Control Box
8 # 5303323284 Switch,selector ,7 posn,3 speed
9 # 5304402838 Control,temperature
10 309643702 Bulkhead
10* 309111201 Grommet,wire protector
12 309101202 Clip,retainer ,temp sensor ,(2)
13 # 5304426450 Capacitor,250 V ,40+10 mfd
14 3015312 Screw,8-18AB x 0.500
15 309351901 Strap,capacitor mtg.
17 # 309343122 Cord-electric power,18 AWG ,115 V
* 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,grounding
18 5303007754 Screw,6-32 x 0.188
20 5304417582 Sleeve,temp sensor ,6 in.

12/02 6
Publication No. FAC082M7A1
5995382966
AIR HANDLING PARTS

# = Fast-moving Parts 7 12/02
* = Non-Illustrated Parts
FAC082M7A1 Publication No.
5995382966
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 309645702 Fan Blade,with clamp
2 3202975 Screw,10-16AB x 0.72 ,square drive
3 309643901 Housing,fan shroud
4 5304421913 Seal,top
5 5303303759 Seal,bottom
6 08007481 Nut,Keps ,motor mtg ,(4)
8 # 309644302 Motor,fan
10 309643702 Bulkhead
11 # 309631701 Blower Wheel
12 309112101 Clamp,blower wheel mt ,compression
15 309642901 Housing,blower scroll ,Extended
16 309100201 Clip,evap/bulkhead
20 309643002 Plate,scroll cover

12/02 8
Publication No. FAC082M7A1
5995382966
COMPRESSOR PARTS

# = Fast-moving Parts 9 12/02
* = Non-Illustrated Parts
FAC082M7A1 Publication No.
5995382966
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 309616918 Compressor
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 3201668 Gasket,terminal cover
7 5304405245 Cover,compr terminal
8 # 5304402840 Overload Protector
9 3201670 Nut,terminal cover
10 # 5303317601 Start Assist Kit,compressor
11 # 309619311 Evaporator
12 # 309645305 Condenser
13 309642801 Tray,evap drip
14 309644003 Base,compressor mt. ,with studs
16 # 5303303064 Capillary Tube,30 inch long
17 # 5300265301 Drier-filter,service kit
19 309112501 Washer,metallic

12/02 10
Publication No. FAC082M7A1
5995382966
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 12/02
* = Non-Illustrated Parts
FAC082M7A1 Publication No.
5995382966
POS. NO PART NO DESCRIPTION
1 5304407729 Seal,window stuffer
2 5303211056 Bracket,sash lock
4 309644902 Frame Extension Kit,accordian ,LH & RH ,incl. 4,14,15
4 5304423372 Extension,sliding frame ,LH cab front ,w/closure panel
5 08016226 Seal,top rail/cab
14 5304423373 Extension,sliding frame ,RH cab front ,w/closure panel
15 309645501 Panel,accordian ,RH/LH ,window closure
16 5304417362 Rail,retainer ,top
17 3002803 Screw,wood, type 17 ,10-12 x 0.750
18 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs
20 5304411997 Screw,8-18 x 0.750
22 5304403252 Rail,retainer ,bottom
23 3001806 Screw,23(T) ,10-32 x 0.310
24 5308002974 Screw,wood,type 17 ,8-15 x 0.500
WINDOW MOUNTING PARTS

12/02 12
Publication No. FAC082M7A1
5995382966 WIRING DIAGRAM
