Frigidaire FHTC103WA1 Owner's manual

Frigidaire.com USA 1-800-944-9044 Frigidaire.ca Canada 1-800-265-8352
use &care
Room Air Conditioner
(DY)16120300A20672 (July 2019)
Introduction...................................................... 2
Important Safety Instructions.................... 3
Normal Sounds................................................ 7
Air Conditioner Features............................. 8
Operating Instructions................................ 9
Energy Saving Ideas................................... 15
Before You Call............................................. 16
Major Appliance Limited Warranty....... 18
Care And Cleaning....................................... 15

2INTRODUCTION
Welcome to our family
Model Number
Serial Number
Purchase Date
Thank you for bringing Frigidaire into your
home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use and
care of your product. Please read it before
using your appliance. Keep it handy for
quick reference. If something doesn’t seem
right, the troubleshooting section will help
you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at www.frigidaire.com.
We are here for you! Visit our website, chat
with an agent, or call us if you need help. We
may be able to help you avoid a service visit.
If you do need service, we can get that
started for you.
Let’s make it ocial! Be sure to register your
product.
Keep your product info here so it’s easy to
find.

3
For Your Safety
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance. Read product
labels for flammability and other warnings.
Prevent Accidents
WARNING
To reduce the risk of fire, electrical shock, or
injury to persons when using your air
conditioner, follow basic precautions,
including the following:
•Be sure the electrical service is adequate
for the model you have chosen. This
information can be found on the serial
plate, which is located on the side of the
cabinet and behind the grille.
•If the air conditioner is to be installed in a
window, you will probably want to clean
both sides of the glass first. If the window
is a triple-track type with a screen panel
included, remove the screen completely
before installation.
•Be sure the air conditioner has been
securely and correctly installed according
to the separate installation instructions
provided with this manual. Save this
manual and the installation instructions for
possible future use in removing or
reinstalling this unit.
•When handling the air conditioner, be
careful to avoid cuts from sharp metal fins
on front and rear coils.
Electrical Information
WARNING
The complete electrical rating of your new
room air conditioner is stated on the serial
plate. Refer to the rating when checking the
electrical requirements.
•Be sure the air conditioner is properly
grounded. To minimize shock and fire
hazards, proper grounding is important.
The power cord is equipped with a
three-prong grounding plug for protection
against shock hazards.
•Your air conditioner must be used in a
properly grounded wall receptacle. If the
wall receptacle you intend to use is not
adequately grounded or protected by a
time delay fuse or circuit breaker, have a
qualified electrician install the proper
receptacle.
•Do not run air conditioner without outside
protective cover in place. This could result
in mechanical damage within the air
conditioner.
•Do not use an extension cord or an
adapter plug.
WARNING
Avoid fire hazard or electric shock. Do not
use an extension cord or an adaptor plug.
Do not remove any prong from the power
cord.
115V
15A 230V
15A
230V
20A
230V
30A
Do not, under any
circumstances, cut,
remove or bypass the
grounding prong.
Grounding Prong

4IMPORTANT SAFETY INSTRUCTIONS
NOTE
The power supply cord with this air
conditioner contains a current detection
device designed to reduce the risk of fire.
Please refer to the section ‘Operation of
Current Device’ for details.
In the event that the power supply cord is
damaged, it cannot be repaired. It must be
replaced with a cord from the product
manufacturer.
SAFETY PRECAUTIONS
DANGER! Avoid Serious Injury or Death
•This air conditioner contains no
user-serviceable parts. Always call an
authorized Electrolux servicer for repairs.
•Do not insert or place fingers or objects
into the air discharge area in the front of
the unit.
•Do not start or stop the air conditioner by
unplugging the power cord or turning o
the power at the electrical box.
•Do not cut or damage the power cord.
•If the power cord is damaged, it should
only be replaced by an authorized
Electrolux servicer.
•In the event of a malfunction (sparks,
burning smell, etc.), immediately stop the
operation, disconnect the power cord, and
call an authorized Electrolux servicer.
•Do not operate the air conditioner with
wet hands.
•Do not pull on the power cord.
•Do not drink any water that is drained
from the air conditioner.
SAFETY PRECAUTIONS
CAUTION! Avoid Injury or damage to the
unit or other property
•Provide ventilation per installation
instructions.
•Do not direct airflow at fireplaces or other
heat related sources as this could cause
flare ups or make units run excessively.
•Do not climb on or place objects on
outdoor part of the unit.
•Do not hang objects off the unit.
•Do not place containers with liquids on
the unit.
•Turn off the air conditioner at the power
source when it will not be used for an
extended period of time.
•Periodically check the condition of the
unit’s installation accessories for any
damage.
•Do not apply heavy pressure to the
radiator fins of the unit.
•Operate the unit with air filter in place.
•Do not block or cover the intake grille,
discharge area and outlet ports.
•Ensure that any electrical/electronic
equipment is one yard away from the unit.
•Do not use or store flammable gases near
the unit.
•Do not touch the metal parts of the unit
when removing the filter. Injuries can
occur when handling sharp metal edges.
•Do not use water to clean inside the air
conditioner. Exposure to water can
destroy the insulation, leading to possible
electric shock.
•When cleaning the unit, first make sure
that the power and circuit breaker are
turned off.
WARNING
FOR FLAMMABLE REFRIGERANT
• Do not use means to accelerate the
defrosting process or to clean, other than
those recommended by the manufacturer.
• Do not pierce or burn.
• Be aware that the refrigerants may not
contain an odour.
• Compliance with national gas regulations
shall be observed.
• Keep ventilation openings clear of
obstruction.

5IMPORTANT SAFETY INSTRUCTIONS
• The appliance shall be stored in a room
without continuously operating ignition
sources (for example: open flames, an
operating gas appliance) and ignition
sourcesor (for example:an operating
electric heater) close to the appliance.
• The appliance shall be stored so as to
prevent mechanical damage from
occurring.
• A warning that the appliance shall be
stored in a well-ventilated area where the
room size corresponds to the room area
as specified for operation.
• Any person who is involved with working
on or breaking into a refrigerant circuit
should hold a current valid certificate from
an industry-accredited assessment
authority, which authorises their
competence to handle refrigerants safely
in accordance with an industry recognised
assessment specification.
• Servicing shall only be performed as
recommended by the equipment
manufacturer. Maintenance and repair
requiring the assistance of other skilled
personnel shall be carried out under the
supervision of the person competent in
the use of flammable refrigerants.
• DO NOT modify the length of the power
cord or use an extension cord to power
the unit.
• DO NOT share a single outlet with other
electrical appliances. Improper power
supply can cause fire or electrical shock.
• Please follow the instruction carefully to
handle, install, clear, service the air
conditioner to avoid any damage or
hazard. Flammable Refrigerant R32 is used
within air conditioner. When maintaining
or disposing the air conditioner, the
refrigerant (R32 or R290) shall be
recovered properly, shall not discharge to
air directly.
• No any open fire or device like switch
which may generate spark/arcing shall be
around air conditioner to avoid causing
ignition of the flammable refrigerant used.
Please follow the instruction carefully to
store or maintain the air conditioner to
prevent mechanical damage from
occurring.
• Flammable refrigerant - R32 is used in air
conditioner. Please follow the instruction
carefully to avoid any hazard.
• The refrigerating system should not
receive maintenance, service, or repair by
any person.
• Ensure that the area is in the open or that
it is adequately ventilated before breaking
into the system or conducting any hot
work. A degree of ventilation shall
continue during the period that the work
is carried out. The ventilation should safely
disperse any released refrigerant and
preferably expel it externally into the
atmosphere.
• Check that cabling will not be subject to
wear, corrosion, excessive pressure,
vibration, sharp edges or any other
adverse environmental effects. The check
shall also take into account the effects of
aging or continual vibration from sources
such as compressors or fans.
• Under no circumstances shall potential
sources of ignition be used in the
searching for or detection of refrigerant
leaks. A halide torch (or any other
detector using a naked flame) shall not be
used. The following leak detection
methods are deemed acceptable for all
refrigerant systems. Electronic leak
detectors may be used to detect
refrigerant leaks but, in the case of
FLAMMABLE REFRIGERANTS, the
sensitivity may not be adequate, or may
need re-calibration. (Detection equipment
shall be calibrated in a refrigerant-free
area.) Ensure that the detector is not a
potential source of ignition and is suitable
for the refrigerant used. Leak detection
equipment shall be set at a percentage of

6IMPORTANT SAFETY INSTRUCTIONS
NOTE
• Do not use this device to turn the unit on
or off.
• Always make sure the RESET button is
pushed in for correct operation.
• The power supply cord must be replaced
if it fails to reset when either the TEST
button is pushed, or it cannot be reset. A
new one can be obtained from the
product manufacturer.
• If power supply cord is damaged, it
CANNOT be repaired. It MUST be replaced
by one obtained from the product
manufacturer.
Plug in & press RESET
1. Plug in the Air Conditioner.
2. The power supply cord will have TWO
buttons on the plug head. Press the TEST
button. You will notice a click as the
RESET button pops out.
3. Press the RESET button. Again you will
notice a click as the button engages.
4. The power supply cord is now supplying
electricity to the unit. (This is also
indicated by a light on the plug head).
READ THIS SECTION BEFORE ATTEMPTING
TO OPERATE AIR CONDITIONER.
Unit must be upright for one hour prior to
operating.
The power supply cord contains a current
device that senses damage to the power
cord. To test your power supply cord do the
following:
Operation of Current Device
CAUTION
• This appliance is not intended for use by
persons (including children) with reduced
physical ,sensory or mental capabilities or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for their
safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.
• The appliance shall be installed in
accordance with national wiring
regulations.
the LFL of the refrigerant and shall be
calibrated to the refrigerant employed,
and the appropriate percentage of gas (25
% maximum) is confirmed. Leak detection
fluids are also suitable for use with most
refrigerants but the use of detergents
containing chlorine shall be avoided as the
chlorine may react with the refrigerant
and corrode the copper pipe-work.
NOTE Examples of leak detection fluids
are
– bubble method,
– fluorescent method agents.
If a leak is suspected, all naked flames
shall be removed/extinguished.
If a leakage of refrigerant is found contact
local manufacter to replace unit.

7NORMAL SOUNDS
5
Gurgle/Hiss
“Gurgling or hissing” noise may be
heard due to refrigerant passing
through evaporator during normal
operation.
1
Sound of Rushing Air
At the front of the unit, you may hear
the sound of rushing air being moved
by the fan.
2
Normal Sounds
1
2
34
5
High pitched Chatter
Today’s high eciency compressors
may have a high pitched chatter during
the cooling cycle.
3
4Vibration
Unit may vibrate and make noise
because of poor wall or window
construction or incorrect installation.
Pinging or Swishing
Droplets of water hitting condenser
during normal operation may cause
“pinging or swishing” sounds.
Note: Don’t try to drill any holes on
the base pan to eliminate the normal
sounds, otherwise it will void the
warranty.
Explanation of symbols displayed on the unit
WARNING
This symbol shows that this appliance used a flammable
refrigerant. If the refrigerant is leaked and exposed to an
external ignition source, there is a risk of fire.
This symbol shows that the operation manual should be read
carefully.
This symbol shows that a service personnel should be
handling this equipment with reference to the installation
manual.
This symbol shows that information is available such as the
operating manual or installation manual.
CAUTION
CAUTION
CAUTION

8AIR CONDITIONER FEATURES
ELECTRONIC CONTROL
Before you begin, thoroughly familiarize yourself with the control panel and remote control
and all its functions (as shown below). The unit can be controlled by the touch pad alone,
with the remote control.
Air Conditioner Features
A
B
Turns Unit On Or O
C
Ionizer Feature
D
Eco Feature
Sleep Feature
GSets Fan Speed
HCheck Filter Reset Button
IActivates Timer
JRemote Temp Sensing Indicator
(Some Models)
ESets Mode
KAdjusts Temperature Or Time
FDisplays Temperature/Time
REMOTE CONTROL
Light Feature:
The display and all LED indicators on the
control panel of the unit can be turned o
by pressing the "Light" button on the
remote control. If any other button of the
control panel and remote control is pressed
after that, the unit will beep to indicate it
works as the corresponding direction of
pressing specific button, and the display and
LED indicators will illuminate accordingly,
but they will turn o again in 5 seconds if no
further operation.
Press the "Light" button again or unplug the
unit to cancel this setting.
Battery Size: AAA
Warning: Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc),
or rechargeable (nickel-cadmium) batteries.
Caution for ingestion. Keep out of the reach
of children.
WITH DISPLAY &
REMOTE
SENSING BUTTON
STANDARD REMOTE
A B C D E GF H I J
K

9OPERATING INSTRUCTIONS
PRESS MODE BUTTON
CHOOSE COOL
DO THIS:
NOTE: The unit will run in Cool mode with
Eco feature and Auto fan speed setting
when used for the first time. With the Eco
feature, when the room temperature is below
the set temperature, the fan will continue to
run for 3 minutes after the compressor shuts
o. The fan then cycles on for 2 minutes at 10
minute intervals until the room temperature
is above the set temperature, at which time
the compressor turns back on. Eco feature
can be activated or deactivated by pressing
Eco button, but it is invalid in fan only mode.
AUTO FEATURE:
Note: This mode is a fixed combination of
Cool mode and Auto fan speed setting. In
this mode, the fan speed can not be selected
manually.
Note: In this mode, the fan remains on all the
time with the compressor cycling on and o
when room temperature is reached.
YOU WILL SEE:
NOTE
The following instructions represent the
touch pad. The same instructions can be
used for the remote control.
TO TURN UNIT ON:
PRESS ON/OFF BUTTON
DO THIS:
YOU WILL SEE:
YOU WILL SEE:
COOL FEATURE:
TO CHANGE TEMPERATURE SETTlNG:
PRESS MODE BUTTON
CHOOSE AUTO
DO THIS:
PRESS TO LOWER
PRESS TO RAISE
DO THIS:

10 OPERATING INSTRUCTIONS
Note: The fan speed can be selected among
four settings: Auto, Lo(Low), Med(Medium)
and Hi(High), unless the unit runs in "Auto"
or "Dry" mode, or the Sleep feature is
activated.
Note: Tap or hold either up ( ) or down ( )
button until the desired temperature is seen
on the display. This temperature will be
automatically maintained anywhere between
62 °F (17 °C) and 86 °F (30 °C). If you want
the display to read the actual room
temperature. See "To Operate on Fan Only"
section.
YOU WILL SEE:
Note: Fan starts at Low Speed and adjusts
to a proper speed according to the room
temperature dictates. For example, if the
room doesn't get too warm, it will stay at
the slowest speed. If the room temperature
rises quickly, such as a door being opened, it
will automatically go to the highest speed.
The fan speeds will re-adjust back to the
slowest speed as the room returns to the
original set temperature.
YOU WILL SEE:
TO ADJUST FAN SPEEDS:
YOU WILL SEE:
PRESS TO SELECT
DO THIS:
TO USE AUTO FAN FEATURE:
PRESS FAN BUTTON,
CHOOSE AUTO
DO THIS:
TO OPERATE ON FAN ONLY:
PRESS MODE BUTTON
CHOOSE FAN ONLY
DO THIS:
