Frigidaire FEC30S6H User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEC30S6HSB 3805422359012 WHITE U.S.A.
FEC30S6HBB 3805422359062 BLACK U.S.A.
ELECTRIC - COOKTOP
Model No.
FEC30S6H
©2001 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC COOKTOP
WIRING DIAGRAM # - 318047022
OWNER’S GUIDE # - 318200612
INSTALLATION INSTR. # - 318201410
Publication No.
5995348678
010119
-EN/SERVICE
377
ELECTROLUX HOME PRODUCTS NORTH AMERICA
802, BOUL. L’ANGE-GARDIEN
L’ASSOMPTION, QC
CANADA, J5W 1T6
TEL.: [phone] (ENGLISH)
[phone] (FRANÇAIS)

Publication No. FEC30S6H
5995348678
01/01 2
CONTROL PANEL
69A
69
36
36
36A
74
74
51
16
54
54 54A
LA01CP80223-1

FEC30S6H Publication No.
5995348678
# = Functional Part 301/01
* = Non-Illustrated Part
POS. NO PART NO DESCRIPTION
16 318096310 A B Box, instrument mtg
36 318164500 AKnob white
36 318164505 BKnob black
36A 318164509 AKnob white
36A 318164511 BKnob black
51# 5303297484 A B Light-indicator
54 # 318120505 A B Switch-surface unit
54A# 318191000 A B Switch surface duo
69 5303323134 A B Screw (8-32x3/16),switch mtg
69A 5303305528 A B Screw, 8-32 X 1/4
74 5303321205 A B Bushing,switch
*5303300265 AB Screw, 8-18 X ½
*5303323130 A B Screw, 8 X ¼
CONTROL PANEL
A = FEC30S6H (FEC30S6HSB)
B = FEC30S6H (FEC30S6HBB)

FEC30S6H Publication No.
5995348678
01/01 4
MAINTOP/SURFACE UNITS
46
163
163
163
163
163
23
20
20
159
162
164
15A
52
52
52B
52B
15B
15B
15
16
LA01CT80223-1

FEC30S6H Publication No.
5995348678
# = Functional Part 501/01
* = Non-Illustrated Part
POS. NO PART NO DESCRIPTION
15 318178101 A B Element-surface,2100W
15A# 318178002 A B Element-surface,1000/2000W
15B# 318178100 A B Element-surface 1200W
16 318079311 A Glass Main Top & frame white
16 318079310 BGlass Main Top & frame black
20 318121902 A B Bracket
23 5303297401 A B Panel-access
46 318077211 A B Burner Box
52 318122007 AB Spring element mtg
52B 318122006 A B Spring element mtg
159 318125111 A B Deflector
162 318125200 A B Heat deflector
163 08007817 A B Spacer
164 318125301 A B Shield
*# 5303323364 A B Bx & wires assy
*08016432 A B Screw, 8-18 X 3/8
*5303323129 A B Screw, 8 X ¾
*5303300265 A B Screw, 8-18 X ½
*5303323131 A BScrew, 8-32 X 7/16
MAINTOP/SURFACE UNITS
A = FEC30S6H (FEC30S6HSB)
B = FEC30S6H (FEC30S6HBB)

FEC30S6H Publication No.
5995348678
01/01 6
WIRING DIAGRAM
