Frigidaire FPGC3087MS Installation instructions

frigidaire.com
Signature Features
Built-In Cooktop
FPGC3087M S 30" Gas
Product Dimensions
Width 30"
Depth 21-3/4"
Height 4-1/4"
More Easy-To-Use Features
PowerPlus® FullRange Burner
Go from a 500-BTU simmer to a
17,000-BTU boil quickly
Continuous Grates
Continuous grates make it easy to move
heavy pots and pans between burners
without lifting.
Pro-Select® Controls
Precise control at your fingertips.
Stainless Steel
Recessed Cooktop
Electronic Pilotless Ignition
LP Gas Conversion Option
A.D.A. Compliant1
Available in:
Stainless
(S)
Burners
Right Front
Right Rear
Left Front
Left Rear
Center
BTU
12,000
5,000
9,500
7,500
500 to 17,000
Fits-More™ Cooktop
The Fits-More™ cooktop features five
burners so you can cook more at once.
PowerPlus® Boil
Boil water fast.
Approved Over Frigidaire®
Electric Wall Ovens
Cooktops are approved for installation
above any of our Single Electric Wall
Ovens.
Low Simmer Burner
Perfect for delicate foods and sauces.
1
When properly installed, meets the appliance
standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility
Guidelines as published by the United States
Access Board on June 23, 2004, as amended
August 5, 2005.

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
Drop-In Gas Cooktops
Frigidaire Baseline
AB
C
NOTE: For planning purposes only. Always consult local and national electric and gas codes.
Refer to Product Installation Guide for detailed installation instructions on the web
at frigidaire.com.
Product Dimensions
A - Width
B - Depth
C - Height
30"
21-3/4"
4-1/4"
Cutout Dimensions
Width (Min.) / (Max.)
Depth (Min.) / (Max.)
Height
27-1/4” / 28-1/2”
19-1/8" / 19-3/4"
8"
Granite Countertop
Installation Kit available.
1
When properly installed, meets the appliance standards in the
Americans with Disabilities Act and the Architectural Barriers Act
Accessibility Guidelines as published by the United States
Access Board on June 23, 2004, as amended August 5, 2005.
2For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.
3Cooktops are approved for installation above any of our Electric Single
Wall Ovens.
Features
Controls
Surface Type
Sealed Gas Burners
Grates
Right Front Burner (BTU)
Right Rear Burner (BTU)
Left Front Burner (BTU)
Left Rear Burner (BTU)
Center Burner (BTU)
Control Location
Knob Color
Knob Type
Certifications
A.D.A. Compliant1
Specifications
Power Supply Connection Location
Gas Supply Connection Location
LP Gas Conversion Kit
Voltage Rating
Amps @ 120 Volts2
Minimum Circuit Required (Amps)
Approved for Electric Single
Wall Oven Combination Installation3
Shipping Weight (Approx.)
Pro-Select®
Stainless Steel Recessed
Yes
Continuous Cast Iron
w/Black Matte Finish
12,000
5,000
9,500
7,500
500 to 17,000
Center Front
Stainless
Cast Metal
Yes
Right Rear
Right Rear
Included
120V / 60 Hz / 15A
1.0
15
Yes
55 Lbs.
Built-In Cooktop
FPGC3087M S 30" Gas
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPGC3087M 05/12 © 2012 Electrolux Home Products, Inc.

Accessories information available
on the web at frigidaire.com
Drop-In Gas Cooktops (Version 2)
(Callouts MUST be charted per individual model).
Professional / Gallery / Baseline
BASED ON INSTALL GUIDE
VERBIAGE (VERSION 2)
(G) min. between rear
edge of cutout and adjacent
combustible surface
(or backsplash)
BASED ON INSTALL GUIDE
VERBIAGE (VERSION 2)
(G) min. between rear
edge of cutout and adjacent
combustible surface
(or backsplash)
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE •frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPGC3087M 05/12 © 2012 Electrolux Home Products, Inc.
Specifications
subject to change.
Built-In Cooktop
FPGC3087M S 30" Gas
Built-In Cooktop Specifications
•Product Shipping Weight (approx.) – 55 Lbs.
•Voltage Rating – 120V / 60 Hz / 15 Amps
•For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.
•Amps @ 120 Volts = 1.0 Amps
•Always consult local and national electric and gas codes.
•Cooktop cutout height includes clearance needed beneath cooktop
to allow for gas supply connection. Recommended location for
grounded 120V outlet is on rear wall in an 8"-wide by 10"-high area,
positioned 22" above floor surface and 4" from right side of cooktop
centerline. Access to underside of cooktop and junction box must
be provided for inspection and service.
•Cooktop ships with 3/4" factory regulator.
•LP Gas conversion kit supplied.
•Overhead cabinetry should not exceed a 13" maximum depth.
•Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than 30".
•Allow 30" minimum clearance between top of cooktop platform and
bottom of unprotected wood or metal overhead cabinet.
•Allow 2" minimum distance between rear edge of cutout and adjacent
combustible surface (or backsplash).
•Allow 9" minimum required clearance from left edge of cooktop to
adjacent combustible surface and 9" minimum from right edge of
cooktop to adjacent combustible surface.
•Installation of drawer beneath cooktop requires 6-1/2" minimum
clearance beneath countertop surface, and assured clearance for gas
and electrical connections.
•To reduce risk of fire when using overhead cabinetry, install range
hood that projects horizontally a recommended minimum of 5"
beyond bottom of cabinets.
•Gas Built-In Cooktop model FPGC3087M is approved to be used
over any Frigidaire® Electric Single Wall Oven. (Refer to Gas Cooktop
Installation Over 30" / 27" Electric Single Wall Oven Specifications
page on web.)
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
•Granite Countertop Installation Kit – (PN # 903103-9010).
Product Dimensions Required Clearances
A- Width B- Depth C- Height G(min.) H(min.) I(min.) J(min.)
30" 21-3/4" 4-1/4" 2-1/2" 9" 9" 2-1/4"
Product Cutout Dimensions K- Cabinet Opening Width
(min.)
Utility Connection Locations
D- Width (min. - max.) E- Depth (min. - max.) F- Height (min.)* Power Supply Gas Supply
27-1/4" - 28-1/2" 19-1/8" - 19-3/4" 8" 30" Right Rear Right Rear

Specifications
subject to change.
30"/ 27" Electric Single Wall Oven
Under-Counter Installation Specifications
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•For detailed electrical requirements, refer to model-specific product
page and installation guide on web.
•Always consult local and national electric codes.
•Minimum 21" clearance for oven door depth when open.
•Minimum 23-1/2" deep cutout dimension is critical for proper
installation, to ensure that oven’s faceplate will fit flush against
cabinet front.
•Side filler panels necessary to isolate oven from adjoining cabinets.
•Full oven base of solid plywood or similar material required, capable
of supporting 200 Lbs. (30" models) or 150 Lbs. (27" models).
Install over two runners and flush with toe plate.
•Base must be level and cabinet front must be square.
•Allow 5" maximum height from oven base to floor, if NO cooktop is
installed directly over wall oven.
Gas Cooktop Installation Over
30"/ 27" Electric Single Wall Oven Specifications
All Frigidaire® Electric Single Wall Ovens are approved to be used
beneath any approved Frigidaire® Gas Cooktop. (This installation page
excludes approved wall oven model GLEB27Z7H. For model-specific
installation details, refer to Gas Cooktop Installation Over 27" Electric
Single Wall Oven GLEB27Z7H Specifications pages on web.)
For detailed Gas Cooktop installation, refer to model-specific product
page and installation guide on web.
•Side filler panel height may need to be modified to accommodate the
depth of approved gas cooktop models.
•Minimum height opening of 6-1/2" (from top of counter) required in
right side filler panel, to route gas and electric hookups.
•Allow 4-1/2" maximum height from oven base to floor, if cooktop is
installed directly over wall oven.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
GC_EW INST FR 03/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Combination Frigidaire Gas Cooktop/
30" & 27" Electric Wall Oven Under-Counter Installation
(excludes side swing wall oven)
Gas Cooktop Installation
Over 30"/27" Electric Single Wall Oven

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
GC_EW_SS INST FR 03/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Combination Frigidaire Gas Cooktop/ 27" Electric
Side-Swing Wall Oven Under-Counter Installation
Frigidaire Gallery Model GLEB27Z7H
27" Electric Single Wall Oven (GLEB27Z7H)
Under-Counter Installation Specifications
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•For detailed electrical requirements, refer to model-specific product
page and installation guide on web.
•Always consult local and national electric codes.
•Minimum 27-1/4" clearance for oven door depth when open.
•Minimum 23-1/2" deep cutout dimension is critical for proper
installation, to ensure that oven’s faceplate will fit flush against
cabinet front.
•Minimum 4-1/2" distance required from door hinge side of oven’s
cutout opening to any adjoining cabinetry or wall, to allow sufficient
clearance for oven rack removal.
•Side filler panels necessary to isolate oven from adjoining cabinets.
•Oven base of solid plywood or similar material required, capable of
supporting 150 Lbs. Install over two runners and flush with toe plate.
•Base must be level and cabinet front must be square.
•Recommended that bottom of cabinet remain partially opened to
permit free air circulation, avoiding possible water condensation
which may appear inside control panel while operating oven.
•Allow 5" maximum height from oven base to floor, if NO cooktop is
installed directly over wall oven.
Gas Cooktop Installation Over
27" Electric Single Wall Oven (GLEB27Z7H) Specifications
Frigidaire® Single Wall Oven model GLEB27Z7H is approved to be used
beneath any approved Frigidaire® Gas Cooktop.
For detailed Gas Cooktop installation, refer to model-specific product
page and installation guide on web.
•Side filler panel height may need to be modified to accommodate the
depth of approved gas cooktop models.
•Minimum height opening of 6-1/2" (from top of counter) required in
right side filler panel to route gas and electric hookups.
• Allow 4-1/2" maximum height from oven base to floor, if cooktop is
installed directly over wall oven.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Gas Cooktop Installation
Over 27" Electric Single Wall Oven (GLEB27Z7H)
