Frigidaire FPGC3685K User manual

FPGC3685KS.tif MFPGC3685KSA.eps BRFPGC3685KSA.eps 318047112.eps
Product No. FPGC3685KSA
37757463990S1
Series 36" gas
Color stainless
Market North America
Wiring Diagram 318047112
Owner's Guide 318203657
Installation Instructions 318201482
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995540480
09/05/15
(EN/SERVICE/ECL)
377
36” GAS COOK-TOP
Model No.
FPGC3685K
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995540480 FPGC3685KSA
05/09 2
COOK TOP
136
137
88
88
136
137
132
39
22A
22B
88A
43
43
43A
88A
16
46
MFPGC3685KSA
22 22
22C
20
20
20A

FPGC3685KSA Publication No: 5995540480
# Functional Parts 3 05/09
* Non-Illustrated Parts
COOK TOP
POS. NO PART NO. DESCRIPTION
16 318560001 Maintop, assembly, stainless
20 318560110 Grate, burner, black, (2)
20A 318560320 Grate, burner, black, center
22 316441204 Cap, 17K twin burner, black, (2)
22A 316438304 Cap, 5K burner, black
22B 316527704 Cap, 9.5K burner, black, medium
22C 316438104 Cap, 12K-burner, black
39 318144006 Cord, service
43 316564605 Knob, control, stainless, single
43A 316564606 Knob, control, stainless, dual
46 318279006 Box, burner
* 5303323168 Tape, aluminum, 3" wide
88 318280101 Gasket, cooktop, 21.48", sides, (2)
88A 318280102 Gasket, cooktop, 35.78", front/back, (2)
132 3201437 Strain relief
136 318264301 Support, box, (2)
137 5303285443 Screw, lock bracket, 10-24 x 2.00
* 318163602 Cleaner, stainless steel
* 5303307980 Screw, 8-32 x 0.437, (8)
* 5303323140 Screw, ground, 10-32 x 0.375

Publication No: 5995540480 FPGC3685KSA
05/09 4
BURNER
77
14
77
77A
BRFPGC3685KSA
10
11
4
10A
11A
44
10B
11B
44
10B
11B
4
10C
11C
1
72
72
72
35
35
3
12
12
12B
12A
12C
12D
11A
44A
47
37
11C
44C
47
37
11
47
37A
44B
44B
44
47
11B
44B
37
47
11B
44B
37
8
73
2
2A
2B
2B
2C

FPGC3685KSA Publication No: 5995540480
# Functional Parts 5 05/09
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 318177016 Manifold Pipe
2 # 318321803 Valve, top burner, dual port
2A # 318233900 Valve, top burner, 5000 BTU
2B # 318233910 Valve, top burner, 9500 BTU
2C # 318233920 Valve, top burner, 12000 BTU
3 # 318232621 Wiring Harness, w/igntr switch
4 5304472956 Screw, hex wash, 6-32 x .485
8 # 318079001 Module, spark
* 5303307980 Screw, 8-32 x 0.437, (8)
10 # 318567000 Burner Assembly, twin
10A# 316438200 Burner, sealed, 5K
10B# 316558300 Burner, sealed, 9.5K
10C# 316438000 Burner, sealed, 12K
11 # 316440100 Ignitor/orifice assy., top burner, twin, 17K, w/holder
11A# 316540800 Ignitor/orifice assy., top burner, 5K, w/holder
11B# 316540700 Ignitor/orifice assy., top burner, 9.5K, w/holder
11C# 316540702 Ignitor/orifice assy., top burner, 12K, w/holder
12 # 318560710 Tube, burner, LF & LR, (2)
12A# 318560712 Tube, burner, RR
12B# 318560713 Tube, burner, RF
12C# 318560714 Tube, burner, center
12D# 318560715 Tube, twin burner, center
14 # 318122717 Regulator, pressure
35 318146301 Bushing
37 5303323130 Screw, 8 x 1/4, (6)
37A 5303325980 Screw, 10-32 x 0.437
44 316527514 Orifice, top burner, simmer
44A 316527504 Orifice, top burner, 5K
44B 316527500 Orifice, top burner, 9.5K
44C 316527502 Orifice, top burner, 12K
47 # 318565403 Conversion Kit, LP
72 316215600 Screw, valve mtg., 1/4 - 20
73 318024209 Deflector, spark module
77 318564100 Bracket, transverse
77A 318565500 Bracket, transverse
* # 318199780 Wiring Harness, ignitor
* 5303211311 Screw, 8 x 0.500
* 5303300195 Screw, 10-32 x 0.375, (2)
* 5303323140 Screw, ground, 10-32 x 0.375

Publication No: 5995540480 FPGC3685KSA
05/09 6
WIRING DIAGRAM
