Frigidaire GLGC30S8A User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
GLGC30S8ABA GLGC30S8A 3775622381061 black North America
GLGC30S8AQA GLGC30S8A 3775624381041 bisque North America
GLGC30S8ASA GLGC30S8A 3775623381011 white North America
Publication No.
5995360202
011019
-EN/SERVICE /ECL
377
GAS
COOKTOP
Model No.
GLGC30S8A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318047105
OWNER’S GUIDE - # 318200658
INSTALLATION INSTRUCTIONS - # 318201450
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

10/01 2
Publication No. GLGC30S8A
5995360202
COOK TOP

# = Functional Parts 3 10/01
* = Non-Illustrated Parts
GLGC36S8A Publication No.
5995360202
COOK TOP
A = GLGC30S8A (GLGC30S8ASA)
B = GLGC30S8A (GLGC30S8ABA)
C = GLGC30S8A (GLGC30S8AQA)
POS. NO PART NO DESCRIPTION
3 318171400 A B C Support,glass
16 318018530 A - - Main Top,white
16 318018532 - B - Main Top,black
16 318018531 - - C Main Top,bisque
19 318168116 A - - Pan,burner ,white ,medium
19 318168114 - B - Pan,burner ,black ,medium
19 318168117 - - C Pan,burner ,bisque ,medium
19A 318168126 A - - Pan,burner ,white ,large
19A 318168124 - B - Pan,burner ,black ,large
19A 318168127 - - C Pan,burner ,bisque ,large
19B 318168106 A - - Pan,burner ,white ,small
19B 318168104 - B - Pan,burner ,black ,small
19B 318168107 - - C Pan,burner ,bisque ,small
20 318120104 A - - Grate,grey ,(4)
20 318120103 - B - Grate,black ,(4)
20 318120108 - - C Grate,brown ,(4)
22 318076411 A - - Cap,burner ,grey ,medium LF & LR
22 318076410 - B - Cap,burner ,black ,medium LF & LR
22 318076414 - - C Cap,burner ,brown ,medium LF & LR
22A 318076421 A - - Cap,burner ,grey ,large RF
22A 318076420 - B - Cap,burner ,black ,large RF
22A 318076424 - - C Cap,burner ,brown ,large RF
22B 318076401 A - - Cap,burner ,grey ,small RR
22B 318076400 - B - Cap,burner ,black ,small RR
22B 318076404 - - C Cap,burner ,brown ,small RR
31 318053901 A B C Gasket,burner pan
36 318196100 A - - Knob,control ,white
36 318196101 - B - Knob,control ,black
36 318196102 - - C Knob,control ,bisque
45 318146220 A B C Bushing
46 5303307897 A B C Burner Box
47 # 5303303991 A B C Cord,electric power
64 5303304033 A B C Bracket,retainer
65 5303304032 A B C Seal,rubber
132 3201437 A B C Strain relief
136 5303935029 A B C Support
137 5303323138 A B C Screw,10-24x1/2
* 5303211311 A B C Screw,8 x 0.500
* 5303300265 A B C Screw,8-18 x 0.500 ,chrome
* 5303311532 A B C Screw,6-32 x 1/4" ,back
* 5303323140 A B C Screw,ground ,10-32 x 0.375
* 5304403558 A B C Screw,10-16 x 0.250

10/01 4
Publication No. GLGC30S8A
5995360202
BURNER

# = Functional Parts 5 10/01
* = Non-Illustrated Parts
GLGC36S8A Publication No.
5995360202
BURNER
A = GLGC30S8A (GLGC30S8ASA)
B = GLGC30S8A (GLGC30S8ABA)
C = GLGC30S8A (GLGC30S8AQA)
POS. NO PART NO DESCRIPTION
1 318177003 A B C Manifold Pipe
2 318087040 A B C Valve,top burner ,13000 BTU
2A # 318087001 A B C Valve,top burner ,5000 BTU
2B # 5303935042 A B C Valve,top burner ,2-position ,9100 BTU
3 # 316032002 A B C Switch,ignitor
4 # 318167703 A B C Tube,burner ,RF
5 # 318167700 A B C Tube,burner ,LF
6 # 318167702 A B C Tube,burner ,RR
7 # 318167701 A B C Tube,burner ,LR
8 # 316135701 A B C Module,spark
10 # 318148001 A B C Burner,top ,9100 BTU ,medium LF & LR
10A# 318148002 A B C Burner,top ,13000 BTU ,large RF
10B# 318148000 A B C Burner,top ,5000 BTU ,small RR
14 # 5308007974 A B C Regulator,pressure
35 318146300 A B C Bushing
72 5303323141 A B C Screw,valve mtg ,1/4-20 x 5/16
73 318024201 A B C Bracket,spark module
74 # 318148700 A B C Ignitor,top burner
75 318148800 A B C Clip,electrode
76 # 318167801 A B C Tube,mixing ,medium & large
76A# 318167800 A B C Tube,mixing ,small
77 318112010 A B C Bracket,burner mtg ,medium & large
77A 318112000 A B C Bracket,burner mtg ,small
77B 318180900 A B C Bracket,burner tube
* # 318127410 A B C LP Conversion Kit
* 5303211311 A B C Screw,8 x 0.500
* 5303307980 A B C Screw,8-32 x 0.437

10/01 6
Publication No. GLGC30S8A
5995360202
WIRING DIAGRAM
