Frigidaire GLEC36S8C User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
GLEC36S8CBA GLEC36S8C 3805642373461 black North America
GLEC36S8CQA GLEC36S8C 3805644373441 bisque North America
GLEC36S8CSA GLEC36S8C 3805643373411 white North America
Publication No.
5995383634
030107
-EN/SERVICE /ECL
377
ELECTRIC
COOKTOP
Model No.
GLEC36S8C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046802
OWNER’S GUIDE - # 318200612
INSTALLATION INSTRUCTIONS - # 318201410
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

01/03 2
Publication No. GLEC36S8C
5995383634
CONTROL PANEL

# = Functional Parts 3 01/03
* = Non-Illustrated Parts
GLEC36S8C Publication No.
5995383634
CONTROL PANEL
A = GLEC36S8C (GLEC36S8CSA)
B = GLEC36S8C (GLEC36S8CBA)
C = GLEC36S8C (GLEC36S8CQA)
POS. NO PART NO DESCRIPTION
16 318096320 A B C Box,instrument mtg
36 318196633 A - - Knob,control ,white
36 318196634 - B - Knob,control ,black
36 318196635 - - C Knob,control ,bisque
36A 318196630 A - - Knob,dual control ,white
36A 318196631 - B - Knob,dual control ,black
36A 318196632 - - C Knob,dual control ,bisque
36C 318196636 A - - Knob,warmer ,white
36C 318196637 - B - Knob,warmer ,black
36C 318196638 - - C Knob,warmer ,bisque
51 # 318044820 A - C Light,indicator ,red
51 # 318044822 - B - Light,indicator ,clear
54 # 318220011 A B C Switch,surface unit ,small
54A# 318220013 A B C Switch,surface unit ,large
54B# 318191000 A B C Switch,infinite ,dual
54C# 318078801 A B C Switch,element ,6" ,warmer
69 5303323134 A B C Screw,switch mtg. ,8-32 x 0.188
69A 5303305528 A B C Screw,8-32 x 1/4
74 5303321205 A B C Bushing
* 5303300265 A B C Screw,8-18 x 0.500 ,chrome
* 5303323140 A B C Screw,ground ,10-32 x 0.375

01/03 4
Publication No. GLEC36S8C
5995383634
MAINTOP / SURFACE UNITS

# = Functional Parts 5 01/03
* = Non-Illustrated Parts
GLEC36S8C Publication No.
5995383634
MAINTOP / SURFACE UNITS
A = GLEC36S8C (GLEC36S8CSA)
B = GLEC36S8C (GLEC36S8CBA)
C = GLEC36S8C (GLEC36S8CQA)
POS. NO PART NO DESCRIPTION
15 # 318198810 A B C Element,surface ,6" ,1200 W
15A# 318177900 A B C Element,bridge
15B# 316224300 A B C Element,dual ,9"/6" ,surface ,2100W/700W,radiant
15C# 316098202 A B C Element,warmer zone ,100W
16 318079374 A - - Main Top Assy,glass/steel ,enamel ,white
16 318079373 - B - Main Top Assy,glass/steel ,enamel ,black
16 318079375 - - C Main Top Assy,glass/steel ,enamel ,bisque
20 318121902 A B C Bracket,retainer
23 5303297401 A B C Panel,Service
46 318077227 A B C Burner Box
52 318122006 A B C Spring,element mtg ,small
52A 318122008 A B C Spring,element mtg
52B 318122010 A B C Spring,element mtg ,1000W/2500W
52C 318122004 A B C Spring,element mtg ,700W & 2100W
159 318125122 A B C Deflector
162 318125210 A B C Deflector
163 318014110 A B C Spacer
164 318125302 A B C Plate,connection
170 318124910 A B C Screen,thermal
* # 318078514 A B C Box & wires assy
* 08016432 A B C Screw,truss head ,8-18 x 0.375
* 5303300265 A B C Screw,8-18 x 0.500 ,chrome
* 5303323129 A B C Screw,8 X 0.750
* 5303323140 A B C Screw,ground ,10-32 x 0.375

01/03 6
Publication No. GLEC36S8C
5995383634
WIRING DIAGRAM
