ICE MAKER
EFIC239

2INTRODUCTION
When you unpack your ice maker, you
may find a small amount of water inside.
Your unit is brand new.
Please follow the initial preparation and
cleaning instructions as detailed in the
User Guide prior to using your new
icemaker.
Any water you may find is from the
standard quality control testing that all
of our ice makers undergo as part of the
manufacturing process.
When using, please avoid direct sunlight.

3IMPORTANT SAFETY INFORMATION
WARNING
WARNING indicates apotentially
hazardous situation which, if not avoided,
could result indeath or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
Safety Instructions
•DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
•Avoid contact with any moving parts
of automatic ice maker.
•Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
withother appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the Ice Maker is unpacked.
Children should NEVER use these items to
play. Cartons covered with rugs, bedspreads,
plastic sheets or stretch wrap may become
airtight chambers, and can quickly cause
suocation.

4SAFETY INSTRUCTIONS
This appliance must be plugged into at least a 15 AMP 110-115 VOLT 60 Hz
GROUNDED OUTLET. This appliance must be grounded. It is equipped with a
3-wire cord having a grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
Avoid the use of an extension cord because it may overheat and cause a risk of
fire. However, if it is necessary to use an extension cord:
A. Use only 3-wire extension cords with 3-blade grounding plug.
B. The marked rating of an extension cord must be be equal to or greater than the
rating of this appliance.
C. It should be positioned such that it does not drape over the counter or tabletop
where it can be pulled on by children intentionally.
Attempting any maintenance or cleaning:
To minimize the possibility of electric shock, unplug this appliance from the power
suply or disconnect at the household distribution panel by removing the fuse or
switching o the circuit breaker before attempting any maintenance or cleaning.
NOTE: Pressing the Power ON/OFF button to an o position does not disconnect
the appliance from the power supply.
WARNING!
Improper use of grounded wire can result in the risk of electric shock.
Consult a physician if necessary. Do not attempt to defeat this safety
feature by modifying the plug.

5GETTING TO KNOW YOUR UNIT
1. lce basket
2. Top cover, removable from the top
3. Secondary water reservoir: It connects directly with the evaporator
4. Float switch
5. Metal shell
6. Water drain cap: at the front bottom side of the unit
7. Filter
8. Control panel
9. Water reservoir
10. Hot Air outlet
11. MAXIMUM WATER LEVEL:
1
2
3
4
5
6 7 8
9
10
11

6OPERATING PROCEDURES & MAINTENANCE
DANGER
1. Remove the exterior and interior packaging, and then check all the accessories
are included. If any parts are missing, please contact our customer service.
2. Remove all the tapes on the unit; take out the accessory parts inside.
3. Clean the interior with lukewarm water and a soft cloth.
4. Locating your ice maker on a level counter table far from direct sunlight and other
sources of heat (i.e.: stove, furnace, and radiator). Make sure that there is at least 6
inches between the back and sides of your ice maker with the wall.
5. Allow one hour for the refrigerant fluid to settle down before plugging your ice
maker in.
6. The power plug must be accessible directly.
WARNING: Fill with drinking water (potable water) only.
*Improper use of the grounded plug can result in the risk of electrical shock. If
the power cord is damaged please call our customer service.
1. This unit should be properly grounded for your safety. The power cord of this
appliance is equipped with a grounding plug which mates with standard grounding
wall outlets to minimize the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do
not be under any circumstances; damage the grounding means of the plug. Any
questions concerning power and or grounding should be directed toward a
certified electrician.
3. This appliance requires a standard 110-120Volt, 60Hz electrical outlet with good
grounding means.
Before using your ice maker, it is strongly recommended to clean it thoroughly.
Unplug the unit before cleaning or making any maintenance.
1. Take out the ice basket.
2. Clean the interior with diluted detergent, warm water and a soft cloth.
3. Then rinse the inside parts with water, and drain out the water by unplugging the
drain cap on the front bottom side.
4. The outside of the ice maker should be cleaned regularly with a mild detergent
solution and warm water.
5. Dry the interior and exterior with a clean soft cloth.
6. When the machine is not in use for a long time, drain water completely out and
dry the interior.
UNPACKING YOUR ICE MAKER
CONNECTING YOUR ICE MAKER
CLEANING AND MAINTAINING YOUR ICE MAKER

7USING YOUR ICE MAKER
How to start the unit
Operation and display areas
Pour water
1. Take out the ice basket and pour potable water into the water reservoir, 0.58
gallon (2.2 liters) waterat most at one time.
2. Put back the ice basket.
3. Plug in the power cord.
Plug in the power cord and the screen is on: You can operate this appliance by
touching the buttonon the panel as shown above.The main function includes: ice,
clean and timer.

USING YOUR ICE MAKER
8
4. Before the cleaning procedure, please make sure the water drain cap has been
inserted into the appliance; otherwise it will not work properly.
5. Press“ICE/CLEAN” button“ ” for 5 seconds and the screen displays 15M and
the “CLEAN" symbol“ ”(as shown in the picture below). lt will run the cleaning
procedure for 15 minutes and automatically exit. Press this button again during
the cleaning procedure and it will exit immediately.
6. After the cleaning procedure, remove the top cover and the ice basket, rinse the
main water tely. Reservoir and the secondary water reservoir, and then move the
appliance to the edge of the desktop. Make sure that the appliance is placed
steadily. Place a water container under the appliance and remove the drain cap
from the bottom. The dirty water will drain into the water container and
then reinsert the drain cap.
Change water in the water reservoir every 24 hours to ensure a reasonable hygiene
level. If the unitisn't to be used, drain all water and dry the water reservoir.
Secondary
water reservoir
Water drain cap
Main water
reservoir
Clean
For the first time, or the clean procedure has not been running for a long time, it
is highly recommended to run this procedure at first.

USING YOUR ICE MAKER 9
How to obtain the ice cube
7. Before we start making ice,please make sure the water drain cap has been
inserted into the appliance; otherwise it will not work properly.
8. Press “ICEICLEAN” button “ ”, the screen displays “ICE”symbol “ ”(as shown
in the figure below) and it begins to work. Press this button again and it will stop
making ice.
9. For the first time, or if the appliance has not been used for a long time, it is
recommended to clean this appliance before starting to make ice.
10. While the ice maker is on, check the water level periodically. If the water pump
can't pump out water, the ice maker will stop automatically and the “Add Water”
symbol “ ”will appear (as shown in thefigure below). You need to pour water
into the water reservoir.
11. The ice maker automatically stops working when the ice basket is full of ice cubes
and the “Ice Full” symbol “ ” appears(as shown in the figure below).

10USING YOUR ICE MAKER
How to set the timer
Timer's Delay Range: 0-24 hours Press once to change: 1H
When the unit is running, you can set the unit with OFF-TIMER to let the unit stop
running after your setting delay time.
And when the unit is at the standby mode, you can set the unit with ON-TIMER to
let the unit start to run automatically after your setting delay time. Then when you go
back home or have a dinner, you can enjoy a happy life accompanied by this ice maker.
12. Press the“TIMER" button “▲” or “▼” to start setting time. Press the “▲” button to
increase the time, and press the “▼” button to decrease the time. Press the
“TIMER” button at the standby mode and it will start after the countdown (as
shown in the figure a); Press the“TIMER” button at the ice-making mode and it
will shut down after the countdown (as shown in the figure b).
13. When the unit has been set with the timer, press the TIMER button, then the delay
time digit and “H” letter display will disappear, which means the timer set has been
canceled.
Tips: The background light on the screen automatically goes out after 30 seconds
without operation. lf you want to keep the light on, press the“TIMER” button “▲”
for 5 seconds; and if you want to cancel the constant light, press the“TIMER”button
“▲” for 5 seconds again.
Timer delay time
a. (Start ice making in three hours) b. (Exit ice making after three hours)
Means Hour, and timer setting duration

11TROUBLESHOOTING GUIDE
Water leakage
The drain plug is not in place.
The seal has reached the end of its
service life.
Pipe joints in the appliance may
loose.
Put the drain plug in place.
Verify by a qualified
technician.
Verify by a qualified
technician.
The ambient temperature or
thewater temperature in the
inner tankis too high.
Refrigerant liquid leakage.
Refrigeration system malfunctions.
Cover motor is broken
The pipe in the cooling system is
blocked.
Please run the ice maker when
the ambient temperature is
below 90 °F and pour colder
water into the tank.
PROBLEM POSSIBLE CAUSES SOLUTION
“ ” is lightening
on and the arrow
flashes.
Lack of Water.
E1
Making Ice too
slowly
Stop the ice maker, fill
water, and press “ICE/
CLEAN” button again
to restart the unit.
Remove the probable
obstacle inside or clean
the inside wall of the ice
storage.
Press the ICE button twice,
restart ice making program,
if this problem show up
again, verify by a qualified
technician.
Hot Air outlet must be
guaranteed to have more
than 15 CM of ventilation.
Press “ICE/CLEAN” button
for 5 seconds ，it will
work for 80 minutes.
Remove some ice cubes.
Verify by a qualified
technician.
Water temperature
requirement between
44.6°F -89.6°F.
There are too much ice cubes.
(If, no ice cube inside).
Hot Air outlet has been blocked
by something.
The water temperature in inner
tank is too high.
“ ” symbol is
lightening and
letter “F” flashes.

12 PRODUCT SPECIFICATIONS
Input Voltage: 115V 60Hz
Power Consumption: 200 W
Daily Ice Output: 20 KGS/24H
Refrigerant: R600a
Dimensions
Product Depth (IN.) 13.2
Product Height (IN.) 15.3
Product Width (IN.) 9.4

Canada
13LIMITED WARRANTY
To make a warranty claim, please email [email protected] or call 1-800-968-9853.
1Year warranty
This product is warranted to be free from defects in material and workmanship for a
period of one (1) year from the date of original purchase. During this period, your
exclusive remedy is repair or replacement of this product or component found to be
defective, at our option; however, you are responsible for all costs associated with
returning the product to us. If the product or component is no longer available, we will
replace with a similar one of equal or greater value. Prior to a replacement being sent,
the product must be rendered inoperable or returned to us.
This warranty does not cover glass, filters, wear from normal use, use not in conformity
with the printed directions., or damage to the product resulting from accident,
alteration, abuse, or misuse. This warranty extends only to the original consumer
purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is
required to make a warranty claim. This warranty is void if the product is used for other
than single-family household use or subjected to any voltage and waveform other than
as on the specified rating on the label (e.g., 120V~60Hz).
We exclude all claims for special, incidental, and consequential damages caused by
breach of express or implied warranty. All liability is limited to the amount of the
purchase price. Every implied warranty, including any statutory warranty or condition
of merchantability or fitness for a particular purpose, is disclaimed except to the extent
prohibited by law, in which case such warranty or condition is limited to the duration of
this written warranty. This warranty gives you specific legal rights. You may have other
legal rights that vary depending on where you live. Some states or provinces do not
allow limitations on implied warranties or special, incidental, or consequential damages,
so the foregoing limitations may not apply to you.
F
ATTACH YOUR PROOF OF PURCHASE HERE, PROOF OF PURCHASE IS REQUIRED
TO OBTAIN WARRANTY SERVICE.
Please have the following information available when you contact the Support Team:
• Name, address and telephone number.
• Model number and serial number.
• A clear, detailed description of the problem.
• Proof of purchase including dealer or retailer name, address and date of purchase.
or faster service, locate the model, type, and serial numbers on your appliance.

FRIGIDAIRE is a pending or registered trademark of
Electrolux Home Products Inc. and used under a
license from Electrolux Home Products, Inc.

USA CANADA 1-800-
APPAREIL À GLAÇON
EFIC239
Les Instructions de Sécurité Importantes........................
Préparer Votre Machine À Glaçons Pour L'utiliser.......
Apprendre À Connaître Votre Unité..................................
Procedures D'exploitation et Maintenance......................
Utilisation de Votre Ice Maker..............................................
Dépannage..................................................................................
Spécifications du Produit......................................................
Carte de Garantie.....................................................................
2
3
5
6
7
11
12
13

2
DANGER
ATTENTION
Votresécuritéetlasécuritédesautressonttrèsimportant
Nousavonsfourniplusieursmanuelsdesécuritéimportantsetvotreappareil.
Lire et obéir à tous les messages de sécurité, s'il vous plaît
C'estlesymboled'alertedesécurité:
!
Touslesmessagesdesécuritésuivrontlesymboled'alertedesécuritéetlesmots«
DANGER»ou«ATTENTION».
Lessensdecesmots:
Vouspouvezêtretuéougravementblessésivousnesuivezpasinstructions
immédiatement.
Touslesmessagesdesécuritévousdirontquelestledangerpotentiel, commentréduire
lerisquedeblessureetcequipeutarriversilesinstructionsnesontpassuivies.
Lorsque vous déballez votre machine à glaçons, vous pouvez trouver une petite
quantité d'eau à l'intérieur.
Votre appareil est tout neuf.
Veuillez suivre les instructions de préparation et de nettoyage initiales décrites
dans le guide de l'utilisateur avant d'utiliser votre nouvelle machine à glaçons.
Lors de l'utilisation, veuillez éviter la lumière directe du soleil.
Toute eau que vous pouvez trouver provient des tests de contrôle de qualité
standard que toutes nos machines à glaçons subissent dans le cadre du processus
de fabrication.
LES INSTRUCTIONS DE SÉCURITÉ IMPORTANTES

3
Lors de l'utilisation d'appareils électriques, des précautions de sécurité élémentaires
doivent être respectées afin de réduire les risques d'incendie, d'électrocution et de
blessures aux personnes ou aux biens. Lisez toutes les instructions avant d'utiliser un
appareil.
Ne l'utilisez pas, ou tout autre appareil avec un cordon endommagé.
Connecter aux prises correctement polarisées uniquement. Aucun autre appareil ne
doit être branché sur la même prise. Assurez-vous que la fiche est complètement
insérée dans le réceptacle.
Ne faites pas passer le cordon d'alimentation sur un tapis ou d'autres isolants
thermiques. Ne couvre pas le cordon. Éloignez le cordon des zones de circulation et
ne l'immergez pas dans l'eau.
Nous ne recommandons pas l'utilisation d'une rallonge, car elle pourrait surchauer
et devenir un risque d'incendie. Si vous devez utiliser une rallonge, utilisez une taille
minimale de 14 AWG et une puissance d'au moins 1875 watts.
Débranchez la machine à glaçons avant de la nettoyer ou de la réparer ou de la
réparer.
Faire preuve de prudence et utiliser une surveillance raisonnable lorsque l'appareil
est utilisé à proximité d'enfants
N'utilisez pas votre machine à glaçons à l'extérieur. Placez le fabricant de glace loin
de la lumière directe du soleil et assurez-vous qu'il y a au moins 6 pouces d'espace
entre l'arrière de votre appareil et le mur. Gardez une distance minimale de 6 pouces
de chaque côté de votre appareil libre
N'utilisez pas d'autre liquide pour faire du glaçon autre que de l'eau.
Ne nettoyez pas votre machine à glaçons avec des liquides inflammables. Les
vapeurs peuvent créer un risque d'incendie ou une explosion.
Ne pas basculer.
Si la machine à glaçons est apportée de l'extérieur en hiver, laissez-la quelques
heures réchauer à température ambiante avant de la brancher.









LESCONSEILSDESÉCURITÉIMPORTANTS
PRÉPARER VOTRE MACHINE À GLAÇONS POUR L'UTILISER

4
IMPORTANT:
Les fils de ce cordon d'alimentation sont colorés conformément au code suivant:
Vert ou vert avec une bande jaune: mise à la terre
Blanc: neutre
Noir: Live
Pour éviter un danger dû à l'instabilité de l'appareil, celui-ci doit être placé sur une
surface plane ou plane.
PRÉPARER VOTRE MACHINE À GLAÇONS POUR L'UTILISER

5APPRENDRE À CONNAÎTRE VOTRE UNITÉ
1. Panier à glace
2. Couvercle supérieur, amovible par le haut
3. Réservoir d'eau secondaire: Il se connecte directement à l'évaporateur
4. Interrupteur à flotteur
5. Coque métallique
6. Bouchon de vidange d'eau: sur le côté avant de l'unité
7. Filtre
8. Panneau de configuration
9. Réservoir d'eau
10. Sortie d'air chaud
11. NIVEAU D'EAU MAXIMUM:
1
2
3
4
5
6 7 8
9
10
11

6 PROCEDURES D'EXPLOITATION ET MAINTENANCE
DANGER
1. Retirez l'emballage extérieur et intérieur. Vérifiez que la corbeille à glace et la pelle à
glace sont incluses. Si des pièces manquent, veuillez contacter notre service clientèle.
2. Nettoyez l'intérieur avec de l'eau tiède et un chion doux. Sortez le panier de glace et
nettoyez-le.
3. Trouvez un endroit pour votre machine à glaçons qui est protégée de la lumière directe
du soleil et d'autres sources de chaleur (c'est à dire. :. La cuisinière, la fournaise, le
radiateur). Placez la machine à glaçons sur une surface plane. Assurez-vous qu'il y a au
moins 6 pouces d'espace entre le dos et les côtés de votre machine à glaçons et le mur.
4. Attendez une heure pour que le fluide frigorigène se stabilise avant de brancher la
machine à glaçons.
5. L'appareil doit être positionné de manière à ce que la fiche soit accessible.
Une mauvaise utilisation de la fiche mise à la terre peut entraîner un risque de
choc électrique. Si le cordon d'alimentation est endommagé, veuillez contacter
notre service clientèle.
1. Cette unité doit être correctement mise à la terre pour votre sécurité. le cordon
d'alimentation de cet appareil est équipé d'une prise à trois broches qui se raccorde
aux prises murales standard à trois broches afin de minimiser les risques
d'électrocution.
2. Faites passer votre appareil dans une prise de courant murale exclusive,
correctement installée et mise à la terre. Ne coupez ou enlevez-en aucun cas la
troisième broche (mise à la terre) du cordon d'alimentation. Toute question concernant
l'alimentation et / ou la mise à la terre doit être adressée à un électricien certifié.
3. Cet appareil nécessite une prise électrique standard de 110-120 volts, 60 Hz avec une
mise à la terre à trois broches.
Avant d'utiliser votre machine à glaçons, il est fortement recommandé de le nettoyer
soigneusement.
1. Sortez le panier à glace.
2. Nettoyez l'intérieur avec un détergent dilué, de l'eau tiède et un chion doux.
DÉBALLERVOTREMACHINEÀGLAÇONS
CONNECTERVOTREMACHINEÀGLAÇONS
CLEANNETTOYERETENTRETENIRVOTREMACHINEÀGLAÇONS
3. Ensuite, rincez les pièces intérieures avec de l'eau et vidangez l'eau en débranchant le
bouchon de vidange sur le côté inférieur avant.
4. L'extérieur de la machine à glaçons doit être nettoyé régulièrement avec un détergent
doux solution et de l'eau chaude.
5. Séchez l'intérieur et l'extérieur avec un chion doux et propre.
6. Lorsque la machine n'est pas utilisée pendant une longue période, vidangez
complètement l'eau et sécher l'intérieur.
