SERVICE DATA
SHEET
318127007
(0105) Rev. A
Dual
Fuel (Gas Cooktop -
Electric Oven)
Slide
-in
Range
with
ES300
Electronic
Oven
Control
and
Speed Bake Feature
NOTICE
This service data sheet is intended for
use by
persons
having
electrical and mechanical training and
a
level of .
knowledge
of these
subjects generally
considered acceptable in
the appliance
repair
trade. The manufacturer
cannot be responsible, nor
assume any liability, for injury
or damage of any
kind arising
from
the use
of
this
data sheet.
SAFE SERVICING
PRACTICES
To avoid
the
possibility
of
personal injury
and/or
property
damage, it is important that safe servicing practices
be
observed.
The
following
are examples, but without limitation, of such
practices.
1. Do not attempt a product repair if you have any doubts
as to
your
ability to complete it
in
a safe and
satisfactory manner.
2. Before
servicing
or
moving
an appliance, remove
power
cord from electric
outlet,
trip circuit breaker
to
Off,
or remove fuse and turn off gas supply.
3. Never interfere
with
the
proper
installation of
any
safety
device.
4. USE
ONLY
REPLACEMENT PARTS CATALOGED FOR THIS
APPLIANCE. SUBSTITUTIONS
MAY DEFEAT COMPLIANCE
WITH SAFETY STANDARDS SET FOR HOME
APPLIANCES.
5. GROUNDING: The standard color coding
for
safety ground
wires is
GREEN OR
GREEN
WITH YELLOW
STRIPES.
Ground leads are not to
be
used as current carrying
conductors.
IT
IS
EXTREMELY IMPORTANT THAT THE
SERVICE TECHNICIAN REESTABLISH ALL SAFETY
GROUNDS PRIOR TO COMPLETION OF
SERVICE. FAILURE
TO
DO SO
WILL CREATE A POTENTIAL HAZARD.
6. Prior to returning the product to service, ensure that:
•
All
electric
connections
are
correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high -temperature components,
and moving parts.
• All non -insulated electrical terminals, connectors,
heaters, etc. are adequately spaced away
from all
metal parts and panels.
• All
safety grounds
(both internal and external)
are correctly
and
securely
reassembled.
• All panels are
properly
and
securely
reassembled.
1

ES300 ELECTRONIC
OVEN
CONTROL
The
ES300 electronic
oven control
is almost identical
to the current
control with
a
few
exceptions.
e
—e®
G
,,
PS
K4~
K5~
B
Kt
Broil Relay P3 -
L1
Fl —
Bate
15
Note: The
ES300's are not field repairable. Only
temperature
settings
can
be changed.
See
oven
calibration.
Note:
Depending on
model,
the size and
shape
of touch
pads may vary
(for
example
round instead
of
elliptical).
NORMAL
BAKE
During
a
normal
bake
mode,
the
control
preheats the oven with
the bake
element.
When
the
desired
temperature
is reached, the control adds
top heat by cycling
the
broil
element
on
for 6
to 9 seconds per minute.
The
bake
element
is
on for
the
remaining
time of
the minute. Both
elements
use
full
power when
they
are
on
but they
are never on
at the same time.
CLEAN
During
a
cleaning
process, the oven
uses the bake
element.
When
this
mode is called, the door
locks right after start
button is
pushed.
FIRST RISE
It is normal
to see
a
temperature
overshoot
in
the
first rise of all
modes
when
you monitor
the
temperature.
0
t (sec)
First rise
overshoot
set
point
OVEN CALIBRATION
Set
the electronic
oven
control
for
normal baking
at 350°F/1
76°C. Obtain
an
average
oven
temperature after
a
minimum
of
5 cycles. Press Cancel to
end bake mode.
Note:
Changing calibration
affects all
the
cooking
modes but not
the clean
mode.
2

ELECTRONIC
OVEN
CONTROL
ELECTRONIC OVEN
CONTROL FAULT CODE DESCRIPTIONS AND
RTD SCALE
Note:
Onlythreefault codes
aredisplayed bythis control "Fl", "F3", and "F9". Generallyspeaking
"Fl"
implies
a
control
failure,
"F3" an oven
probe problem,
and
"F9" a latch motor problem.
In
all ocurrences the alarm
is accompanied
by
a display of "Fl"
Fault
Code
Likely
Failure
Condition/Cause
Suqqested Corrective Action
F 1
1.
Shorted keypad.
2.
Control's internal
checksum may
have
become corrupted.
3.
Control
has sensed a potential
runaway oven condition.
Control
may
have shorted relay, RTD sensor
probe may have gone bad.
1.
Replace EOC.
2.
Disconnect
power,
wait
30 seconds and
reapply
power.
If
fault returns
upon power
-up, replace EOC.
3.
Check
RTDsensorprobeandreplaceifnecessary.
lfoven
is
overheating, disconnect power.
If oven
continues to
overheat
when
the
power is reapplied, replace EOC.
Severe
overheating
may require
the
entire
oven to
be
replaced,
should
damage
be extensive.
F3
1. Open RID
sensor probe/ wiring
problem.
Note:
EOC
may
initially
display
an
'Fl", thinking
a
runaway
condition exists.
2.
Shorted RTD sensor
probe /
wiring
problem. Note: "F3" is displayed
when
oven
is in active mode
or
an
attempt
to
enter
an
active mode is
made.
1. Checkwiringinprobecircuitforpossibleopencondition.
Check RTDresistanceatroomtemperature(compareto
probe
resistance
chart). If
resistance does not
match
the
chart,
replace
the RTD sensor
probe.
2.
Checkwiring in
probe circuitfor possibleshortcondition.
Check
RTD resistance
at
room temperature
(compare
to
probe
resistance
chart).
If
resistance
does not
match
the
chart,
replace the
RTD sensor
probe.
F9
1. Door motor failure/jammed.Latch
motor switch failure.
2.
Control software failure, or
component
failure
(relay stuck).
3.
Safetythermostatopened,orcooling
fan stalled.
4. Wiring Problem.
1 . P ress CLEAR k e y .
2. If CLEAR key
does
not eliminate
problem, turn off power
for 30
seconds,
then
turn
on
power.
3. Check wiring
of
Lock
Motor,
and
Lock
Switch A
and B,
and
Door
Switch
circuits.
Look for stalled
cooling
fan,
broken safetythermostat, shorts
or
opens.
4. Unplug P4, apply
power (L1)directlyto
the Lock Motor,
if
the
motor does
not
rotate,
replace
Lock MotorAssembly.
Plug P4.
5. Check Lock
Switch
A,
and B for proper
operation (do they
open
and
close,
checkwith ohmmeter). The
Lock Motor
may be
powered
as
in above step to
open
and
close Lock
Switches.
If the Lock Switches are
defective, replace
Motor
Lock
Assembly.
6. If all above steps
fail
to
correct
situation,
replace
control.
3

Temp. °F
RTD
SCALE
Temp. °C Resistance
(ohms)
32±
1.9
0.0±
1.1
1000±4.0
75±2.5
23.9±1.4 1091±5.3
250±4.4
121.1±2.4 1453±8.9
350±5.4
176.7±3.0
1654±10.8
450±6.9
232.2±3.8
1852±13.5
550±8.2
287.8±4.6
2047±15.8
650
± 9.6
343.3 ± 5.3
2237
± 18.5
900±13.6
482.2±7.6
2697±24.4
CIRCUIT ANALYSIS MATRIX
Bake
P1 & P2
Broil
P1
&
P3
MDL
P5.6 & N
Lock Motor
A
Switches
B
Bake
X
X*
Broil
X
Clean
X
X X
Unlocked
Locking
X
Locked
X X
Unlocking
X
Speed Bake
X
* Denotes broil
element alternate with bake element.
ELECTRICAL
Kw Rating
240/208
V
RATING
See
nameplate
Broil Element
Wattage
2750W/2065W
Warmer Drawer
Element
450W/1
20V
Bake
Element
Wattage
3000W/2253W
DOOR LOCK
MECHANISM
The
appliance is
equipped
with an electronic oven control and has
an
auto
locking door latch feature.
When
the self clean cycle is
programmed,
the door is locked by a
motor
operated
latch system. The
interior
of
oven
does'nt
need to heat up
to 500°F/260°C
before the door locks. However, until the temperature
inside
oven
reaches
500°F/260°C, the
self -clean program
can be
canceled and
door will unlock immediately.
After oven
reaches
temperatures
over
500°F/260°C, the door
will
not unlock until temperature
drops below 500°F/260°C.
LEFT
MOTOR
OMIT
SWITCH
A "
DOOR
LATCH
MOTOR
ti
DOOR LATCH
CAM
ASSEMBLY
RIGHT
MOTOR
LIMIT
SWITCH
DOOR
LACKING
MECHANISM
ASSEMBLY
MOTOR
COOLING
FAN
I
SAFETY
THERMOSTAT
ROD
SPRING
ROD
BUSHING
4

OVEN DOOR
REMOVAL AND
REPLACEMENT
Lock in
normal
position
Lock
engaged
for door
removal
HINGE SLOT
Door
removed
from
the
range
To Remove the
Oven Door:
1.
Disconnect
range
from electrical supply
2. Open the
door
to the
fully
opened position.
3. Pull up the
lock
located
on
both
hinge supports and engage it
in the
hinge levers.
You
may have to
apply
a
little downward
pressure on
the
door
to
pull
the locks fully over
the hooks.
4.
Grab
the door
by
the sides, pull the bottom of
the door
up and toward
you
to
disengage the hinge
supports. Keep
pulling the bottom
of
the
door toward you
while
rotating the
top of the
door
toward
the
range to
completely
disengage
the hinge
levers.
To Replace the
Oven
Door:
1.
Grab
the
door
by the sides; place
the
hinge
supports in the
hinge slots.
Open
the
door to
the
fully
opened
position.
2. Disengage the lock
from
the hinge levers on both
sides.
Note:
Make sure the hinge supports
are
fully
engaged before unlocking
the hinge levers.
3.
Close the oven door.
a
CAUTION
The door
is
heavy.
After
removing
door, lay it flat on
the
floor
with the inside of
the
door facing
GAS
COOKTOP
EXPLODED VIEW
1.
Shut
off gas to range.
2. Disconnect
power.
3. Remove gas
supply
line at the
regulator. If
necessary, move range out of the cabinet opening.
4. Remove grates,
burner
covers,
knobs
and seals, inspect
burners.
5. Remove screws
securing
burner
pans.
Inspect
electrode, cleanliness,
etc.
Note: The
electrode can not be removed from the pan.
6.
Remove left and
right screws
on each
side of range securing panel
top to body.
Note:
Screws are located
1/1/2"
from
console
and
3"
from
back
of
range.
7. Remove
machine
screw
on manifold side
of
range
(2-3/4" from
cooktop)
securing
manifold to
cooktop.
8.
Remove
glass top and
gasket.
9. To
reassemble cooktop,
reverse
procedure.
5

OVEN
DOOR EXPLODED VIEW
Handle
Trim Bracket
Oven Door
Seal
Handle Trim
Bracket
Rope
Seal
Inner Glass
Bracket
Door
Latch
Oven
Door
Liner
Door
Insulation
Inner Glass Bracket
Hinge
Door Insulation
Models with
Small
Oven Door Window
Oven Door
Seal
Handle
Trim
Bracket
Oven Door
Liner
Door
Latch
Inner Glass
Hinge
Models with Large Oven Door
Window
Inner Glass
Glass
Frame
Side Trim
Rope
Seal
Handle
Trim
Bracket
Door Insulation
Glass
Frame
Middle
Glass
Middle
Glass
Insulation
Shield
Upper
Trim
Tape
Neoprene
Door
Glass
Side Trim
6
Insulation Shield
Upper Trim
Door
Handle
Tape Neoprene
Door Glass
Door
Handle

WARMER
DRAWER
(SOME MODELS)
COMPLETE CIRCUIT
Li
C NC
WARMER
DRAWER
SAFETY
INFINITE
THERMOSTAT
SWITCH
WARMER
DRAWER
ELEMENT
DIODE
WARMER
DRAWER
INFINITE
SWITCH
L i H i
WARMER
DRAWER
INDICATOR
LIGHT
H2 L2
PREHEAT THERMOSTAT
=o
r>
130°F CUT-OUT
T"< 115°F CUT -IN
N
N
When
the
Warm and Serve
Drawer
is first turned
on,
a "Preheat"
circuit is established to provide
full power
(120
volts)
through the lock
switch,
L1 to Hi of the warmer
switch,
the
warmer
element and the preheat thermostat.
PREHEAT
WARMER
DRAWER
L1
ELEMENT
PREHEAT
C NC
LI
H1
450W
SAFETY
WARMER
THERMOSTAT
THERMOSTAT
DRAWER
WARMER
INFINITE
DRAWER
N
SWITCH
INDICATOR
1"> 130°F CUT OUT
LIGHT
T°
<115°F CUT
-IN
When the
temperature
at
the
preheat
thermostat
reaches 130°F the thermostat
opens. This forces
the current to flow
through
the
parallel circuit
which
contains the diode. The diode allows only half power (every
other
pulse
of
electric-
ity or
pulsating DC)
to
flow through
the
element,
resulting in lower
heat
output by the element. The infinite heat
control
switch will cycle
as
necessary
to
maintain
the
temperature
in
the
drawer
as indicated by the control
switch
setting.
If the
control
is
placed on
a
lower setting,
it is possible
for
the temperature in the
drawer to
drop
enough to
allow the
preheat
thermostat
to close
again which will allow
the element
to
reenter
the
"Preheat"
mode
at
full
power.
AFTER
CUT-OUT
Li
SAFETY
WARMER DRAWER
THERMOSTAT
INFINITE
-
SWITCH
- 0-
C
T
O
NC
WARMER
DRAWER
ELEMENT
^
-225W
WARMER
DRAWER
INDICATOR
LIGHT
WARMER DRAWER
INFINITE
DIODE
SWITCH -
• O
H2 L2
N
N
An
indicator
lamp
wired in
parallel
with the element
is
illuminated
whenever the control switch is turned on.
7

NOTES
8
