Frigidaire PLES389ECG Instruction Manual

PLES389EC.eps LA20BG0049.eps BPLES389ECB.eps LA20CT0083.eps
DPLES389ECB.eps 318271934-1.eps 318271934-2.eps
Product No. PLES389ECG
37957366H53S7
Series 30" slide-in
Color stainless
Market North America
Wiring Diagram 318271934
Owner's Guide 318203859
Installation Instructions 318201611
Timer Guide 318200194
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995479564
06/11/22
(EN/SERVICE/ECL)
377
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
PLES389E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995479564 PLES389ECG
11/06 2
BACKGUARD

PLES389ECG Publication No: 5995479564
# Functional Parts 3 11/06
* Non-Illustrated Parts
BACKGUARD
POS. NO PART NO. DESCRIPTION
16 318299102 Console, assy., black
16* 5304447071 Clip, console, (2)
17 318306900 Bracket, bushing, (2)
19 318313830 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
19A 318224405 Panel, control mtg.
20 # 316418735 Clock/Timer, electronic, ES510
20* 5304453707 Screw, control mtg.
35 318233720 Retainer, control panel, black
36 318319301 Knob, control, black, (4)
42 318298001 Trim, vent, black, upper
54A# 316441801 Control, electronic, dual element, (3), w/potentiometer
54B# 316441804 Control, electronic, right front, dual element, w/potentiometer
55 316247700 Nut, mounting, (2)
55A 316247800 Washer, lock, control mtg
69 5303323134 Screw, 8-32 x 0.188
99 316435702 Board, power supply
99A 318223900 Gasket, dark grey
101 318233400 Bushing, retainer
* # 318228820 Harness, wiring, main, backguard
* # 318224813 Harness, wiring, timer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303311333 Screw, 8-32 x 3/8

Publication No: 5995479564 PLES389ECG
11/06 4
BODY

PLES389ECG Publication No: 5995479564
# Functional Parts 5 11/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
1 318259204 Back, main
1A 318225110 Panel, main back, upper
2 318258902 Shield, insulation, upper
3 318225210 Panel, bodyside, upper RH
3A 318225211 Panel, bodyside, upper LH
5 318175503 Screw, leveling
6 318345208 Rack, oven
6A 318365800 Rack, broiler pan
8 318262001 Cover, element
8A 318318600 Bracket, element, hidden bake
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 # 318089917 Switch, light
14 318224000 Receptacle, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 5303935061 Terminal Block Kit
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
63 318264200 Plate, grounding strap
66 # 318255600 Element, broil, 2750W
67 318254901 Element, bake, 3400W, 8 pass
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258708 Shield, insulation, lower
83 318261400 Liner, oven assy
86 318342400 Receptacle, hinge
87 318260608 Bracket, cable mtg.
87A 318111804 Plate, cord set mtg
89 # 318261205 Motor, latch assy
90 318296904 Panel, filler, black, RH
90A 318296905 Panel, filler, black, LH
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 318249401 Tube, protector
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer

Publication No: 5995479564 PLES389ECG
11/06 6
BODY

PLES389ECG Publication No: 5995479564
# Functional Parts 7 11/06
* Non-Illustrated Parts
BODY
POS. NO PART NO. DESCRIPTION
112# 318112703 Relay
119# 318005212 Switch, thermal cutout
125# 316415800 Motor, fan
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
161# 318255503 Element, convection, 350 W
163 318014110 Spacer, (6)
166 318298410 Bracket, base support, (2)
166A 318298403 Bracket, base support, lower, (2)
170 318335500 Anti-tip & accessories
185 318165800 Spacer
200 318298201 Frame, drawer, black, front
201 318298210 Frame, drawer
219# 318003614 Thermostat, safety
219A 318003613 Thermostat, safety, 1.375" mtg, 105/120
263 316136500 Washer, flat
* # 318224945 Harness, wiring, main
* 318235300 Connector assy., w/3 lugs, & instructions
* 3051050 Screw, shoulder
* 3201861 Screw, 6 x 0.375, (4)
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303307980 Screw, 8-32 x 0.437, (4)
* 5303323129 Screw, 8 X 0.750
* 5304415832 Screw, 8-18 x 0.406
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995479564 PLES389ECG
11/06 8
TOP/DRAWER
46
52C
52B
52B
52C
15B
15C
15C
15B
165
16
51
1A
1A
95
84
141
124
13A
124
13
1C
85
81
86
86
87
2
60 29
29
60
4
39
1
LA20CT0083

PLES389ECG Publication No: 5995479564
# Functional Parts 9 11/06
* Non-Illustrated Parts
TOP/DRAWER
POS. NO PART NO. DESCRIPTION
1 318304401 Drawer, body assembly
1A 318300000 Panel, warmer drawer, side, (2)
1C 318300300 Panel, warmer drawer, rear
2 318303901 Panel, drawer, black, inner
4 318298811 Panel, drawer, stainless, front
13 318259507 Glide, warmer, inner RH
13A 318259506 Glide, warmer, inner LH
15B# 318198932 Element, surface, 6/9, 1200/2500W, dual radiant
15C# 318198936 Element, surface, 750/1800W, dual radiant
16 318223640 Main Top, glass assy., black
29 318147430 Bumper, (2)
39 316246100 Handle, door/drawer, stainless
46 318225410 Box, burner
51 # 318044822 Light, indicator, clear
52B 318122010 Spring, element mtg, 3000W
52C 318122008 Spring, element mtg, 1800W/3000W
60 5303311174 Screw, 10-24 x 3/8
81 # 318255300 Element, warmer drawer
84 # 318005108 Thermostat
85 318345600 Rack, warmer drawer
86 316095800 Clip, hold down, warmer element
87 318300100 Panel, warmer drawer, lower
95 318303800 Shield, wire
124 316105501 Glide, outer/RH & LH, (2)
141# 318005213 Switch, thermal cutout
165 318227503 Plate, mounting
* # 318228932 Harness, wiring, cooktop
* # 318231848 Harness, wiring, pilot light
* 318199749 Wiring Harness, drawer
* 5303325171 Washer, plastic
* 318163601 Cleaner-cooktop
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303311333 Screw, 8-32 x 3/8

Publication No: 5995479564 PLES389ECG
11/06 10
DOOR

PLES389ECG Publication No: 5995479564
# Functional Parts 11 11/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260520 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, door
10 5303311174 Screw, 10-24 x 3/8
12 318053120 Seal, door, lower oven
13 318272189 Door Assy, w/nameplate, stainless steel, outer, w/tape & foil
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, door, (2)
24 318260301 Trim, door, black, lower
39 316246100 Handle, door/drawer, stainless
40 318242700 Bracket, glass holder, (2)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 316221001 Label, anti-tip
* 5304415832 Screw, 8-18 x 0.406

Publication No: 5995479564 PLES389ECG
11/06 12
WIRING DIAGRAM
LEGEND/LEGENDE
SW. - SWITCH/INTERRUPTEUR
R.F. - RIGHT FRONT/AVANT DROIT
R.R. - RIGHT REAR/ARRIERE DROIT
L.F. - LEFT FRONT/AVANT GAUCHE
L.R. - LEFT REAR/ARRIERE GAUCHE
LIM.-LIMITOR/LIMITEUR
H.S.-HOT SURFACE/SURFACE CHAUDE
T.B.-TERMINAL BLOCK/BLOC DE
CONNECTION
CON. -CONTROL/CONTROLE ESEC 15
C.T.-COOK TOP/TABLE DE CUISSON
MDL.-MOTOR DOOR LATCH/MOTEUR PORTE VERROU
COLOR CODE/CODE DE COULEUR
G.-GREEN/VERT
W.-WHITE/BLANC
R.-RED/ROUGE
O.-ORANGE/ORANGE
Y.-YELLOW/JAUNE
BR.-BROWN/BRUN
BL.-BLUE/BLEU
BK.-BLACK/NOIR
WIRE GAUGE TEMP.C CSA UL
FIL CALIBRE
1 18 125 CL1251 3173
2 16 125 CL1251 3173
3 14 125 CL1251 3173
4 12 125 CL1251 3173
5 18 150 EXL-150 3321
6 16 150 EXL-150 3321
7 14 150 EXL-150 3321
8 12 150 EXL-150 3321
9 10 150 EXL-150 3321
10 18 200 SEW-1 3122
11 16 200 SEW-1 3122
12 12 250 3252
13 16 250 3252
14 20 150 EXL-150 3321
15 8 150 EXL-150 3321
318271934 REV:B
SHEET/FEUILLE:1/2
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATTENTION:COUPEZ L`ALIMENTATION AVANT D`EFFECTUER LA REPARATION.
T.B.
L2
N
L1
W-1
R-9
W-5
BL-2
BK-6
123456
P7
123456
P7
123456
P7
123456
P7
123
P4
6
5
43212 345
678
P5
ELECTRONIC OVEN CONTROL ES 510
COMMANDE FOUR ELECTRONIQUE ES 510
DLB IN
DLB OUT
CONV. BAKE
BROIL L1
1
BROIL ELEMENT
ELEMENT GRIL
BL-6
BL-6
BAKE ELEMENT
ELEMENT CUISSON B10 Y-2
Y-6
Y-6
B14
BR-6
BR-2
t
V-14
B3
B6
B15
CONVECTION MOTOR
MOTEUR CONVECTION
B9
B5
BR-14
B4
B11
BR-1
GY-1
BR-5
MDL
OVEN LAMP
LAMPE FOUR
BR-1
DOOR SWITCH
INTER. PORTE
B8
SW.A
MDL SW.
P8 P7 P9 P3 P2 P1
CON
C
THERMAL CIRCUIT BREAKER
DISJONCTEUR THERMIQUE
PROBE
SONDE
123
654
987
12
11
10
15
14
13
CONNECTOR
CONNECTEUR
B
BL-14 NO
NC
BR-19
BL-5
O-14
BR-10
B1
B4
BK-21
B13
R-6 R-2
BR-5
123
654
987
12
11
10
CONNECTOR
CONNECTEUR
A
V-19
WARMER ELEMENT/ELEMENT RECHAUD
WARMER DRAWER/TIROIR RECHAUD
Y-5 Y-5
W-5BR-5
TIMER
MINUTERIE
P11-1
TIMER
MINUTERIE
P11-2
LO LIMIT THM/THM BASSE LIMITE
TIMER
MINUTERIE
P11-4
OPTIONAL
FACULTATIF
V-14
V-14
BL-19
B12
O-19
BR-19
OVEN CIRCUIT // CIRCUIT DU FOUR
BK-6
BR-5
WIRE GAUGE TEMP.C CSA UL
FIL CALIBRE
16 8 60
17 10 60
18 10 200 SEW-1 3122
19 20 125 SEW-1 3173
20 20 200 SEW-1 3122
21 22 125 CL-1252 3266
22 22 150 10109
BR-10
COOLING RELAY
RELAIS VENTILATEUR
FAN HOLD THERMOSTAT
THERMOSTAT DE MAINTIEN
DU VENTILATEUR
LOW SPEED
BASSE VITESSE
HIGH SPEED
HAUTE VITESSE
BK-5
R-5 R-5
BK-5 W-5
BR-5
R-5
CNO
NC
W-5
R-5R-5
CONVECTION ELEMENT
ELEMENT CONVECTION
O-5 O-5
O-5
OVEN LAMP
LAMPE FOUR
W-5
BK-5
OPTION
FACULTATIF
DIODE
DIODE
MR754
BK-1
BK-9
V-19
THERMAL CIRCUIT BREAKER
DISJONCTEUR THERMIQUE

PLES389ECG Publication No: 5995479564
# Functional Parts 13 11/06
* Non-Illustrated Parts
WIRING DIAGRAM
318271934 REV:B
SHEET/FEUILLE:2/2
CAUTION: DISCONNECT POWER BEFORE SERVICING UNIT.
ATTENTION:COUPEZ L`ALIMENTATION AVANT D`EFFECTUER LA REPARATION.
P3
P1
TRANSFORMATOR
TRANSFORMATEUR
P2
P3
P4
P5
1
2
3
4
5
CON. R.F.
11
L2 N
L1
R.F. ELM2
LIM.
R.F. ELM1
BR-11
W-5
BR-2
BL-1
BK-21
R-21
BL-21
H.S.
LIM.
P2
P3
P4
P5
1
2
3
4
5
CON. L.F.
O-11
R-2
P2
P3
P4
P5
1
2
3
4
5
CON. L.R.
L.R. ELM1
Y-11
R-2
P2
P3
P4
P5
1
2
3
4
5
CON. R.R.
R.R. ELM1 W-11
R-2
LIM.
BL-5
BL-10
B15
R-2
BK-2
BK-11
GY-10
BK-11
BL-11
B11A2
BK-6 BK-2
W-2
BK-2
BK-11
BK-11
BL-11
B12
BK-2
A1
BK-6
Y-11
BK-2
BK-11
BK-11
BL-11
B13
BK-2
A9
BK-6
O-2
BK-2
BK-11
BK-11
BL-11
B14
BK-2
A10
BK-6
BL-21
Y-21
R-21
BK-21
BL-21
Y-21
R-21
BK-21
BL-21
Y-21
R-21
BK-21
BK-22
A12
A11
A6
A5
123
654
987
12
11
10
151413
CONNECTOR
CONNECTEUR
B
BL-10
W-10
BR-10
B1
A8
B2
B4
A7
B3
B6
A4
B5
B7
A3
B8
123
654
987
12
11
10
CONNECTOR
CONNECTEUR
A
R-9
BK-9
COOKTOP CIRCUIT // CIRCUIT TABLE CUISSON
NO
NC
C
SW.A
SW.A
LATCH MOTOR
MOTEUR VERROU
2A
1A
1B 2B
LIMITER/LIMITEUR
CERAMASPEED/EIKA
2
4
SH
LIMITER/LIMITEUR
E.G.O./A.K.O.
H.S.
LIM.
H.S.
BK-11
BL-11
LIM.
H.S.
L.F. ELM1
L.F. ELM2
LR. ELM2
P3
P1
TRANSFORMATOR
TRANSFORMATEUR
P2
P3
P4
1
2
3
4
5
CON. R.F.
11
L2
N
L1
R.F. ELM2
LIM.
R.F. ELM1
BR-11
W-5
BR-2
BL-22
Y-21
R-21
BL-21
H.S.
LIM.
P2
P3
P4
1
2
3
4
5
CON. L.F.
O-11
R-2
P2
P3
P4
1
2
3
4
5
CON. L.R.
Y-11
R-2
P2
P3
P4
1
2
3
4
5
CON. R.R.
R.R. ELM1 W-11
R-2
LIM.
BL-5
BL-10
B15
R-2
BK-2
BK-11
GY-10
BK-11
BL-11
B11A2
BK-6 BK-2
W-2
BK-11
BL-11
B12
BK-2
A1
BK-6
Y-11
BK-11
BL-11
O-2
BK-2
BK-11
BK-11
BL-11
B14
BK-2
A10
BK-6
BL-21
R-21
Y-21
BK-21
BL-21
R-21
Y-21
BK-21
BL-21
R-21
Y-21
BK-21
BK-22
A12
A11
A6
A5
BL-10
W-10
BR-10
B1
A8
B2
A7
B3
A4
B5
B7
A3
B8
R-9
BK-9
H.S.
L.R. ELM1
H.S.
BK-11
BL-11
LIM.
H.S.
L.F. ELM1
L.F. ELM2
P5
P5
P5
P5
BK-11
BK-2
BK-6 LIM.
B13A9
BRIDGE/PONT
LIM.
LIM.
LIM.
BL-22
BL-5
BK-5
BK-1
Y-21
Y-22
R-22
Y-1
R-1
R-5
Y-5
BK-21
BL-5
R-5
Y-5
BK-5
BL-1
R-1
Y-1
BK-1
R-22
Y-22
ELM 1
ELM 2
DUAL ELEMENT
ELEMENT DOUBLE
R-6
R-6
R-6
R-6
R-6
R-6
R-6
R-6
