Frigidaire FRT18PRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18PRHD1 FRT18PRH 134A almond 115
FRT18PRHW1 FRT18PRH 134A white 115
MARKET
North America
Publication No.
5995343638
000920
-EN/SERVICE /DJH
390
REFRIGERATOR
Model No.
FRT18PRH
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218989100
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

09/00 2
Publication No. FRT18PRH
5995343638
DOOR

# = Fast-moving Parts 3 09/00
* = Non-Illustrated Parts
FRT18PRH Publication No.
5995343638
DOOR
A = FRT18PRH (FRT18PRHD1)
B = FRT18PRH (FRT18PRHW1)
POS. NO PART NO DESCRIPTION
1 # 215608916 A B Gasket-frzr door,white ,magnetic
2 # 218730605 A B Gasket-refr door,white ,magnetic
3 218360001 A B Panel-inner door,refr
4 218763639 A B Rack-door,20.81" x 2.04"
5 218809801 A B Support-door rack,RH
5A 218758602 A B Support-door rack,RH/LH
6 218809701 A B Support-door rack,LH
7 218287908 A B Door-dairy,10.71" wide ,clear ,no graphics
8 218763638 A B Rack-door,22.36" x 2.04"
9 218360101 A B Panel-inner door,frzr
10 5303001308 A - Plug-button,almond ,hinge brg hole
10 5308000134 - B Plug-button,white ,hinge brg hole
11 5303917807 A - Panel-frzr door,almond ,w/insulation
11 5303917805 - B Panel-frzr door,white ,w/insulation
12 218917602 A - Label-nameplate,almond
12 218917601 - B Label-nameplate,white
13 218800300 A B Door Stop,plated
13A 218249002 A - Door Stop,almond ,frzr section
13A 218249001 - B Door Stop,white ,frzr section
14 218915702 A - Plug-button,almond
14 218915701 - B Plug-button,white
15 5303917808 A - Panel-refr door,almond ,w/insul & brace
15 5303917806 - B Panel-refr door,white ,w/insul & brace
18 218668002 A - Handle-door,almond
18 218668001 - B Handle-door,white
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B Bearing-hinge
37A 215870630 A - Trim-handle,2.47" ,almond ,w/satin AL band
37A 215870629 - B Trim-handle,2.47" ,white ,w/satin AL band
37A* 218676004 A B Band-decorative,satin aluminum ,handle trim
58 218749600 A B Screw,#10 pan hd ,8-18 x .5
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

09/00 4
Publication No. FRT18PRH
5995343638
CABINET

# = Fast-moving Parts 5 09/00
* = Non-Illustrated Parts
FRT18PRH Publication No.
5995343638
CABINET
A = FRT18PRH (FRT18PRHD1)
B = FRT18PRH (FRT18PRHW1)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 218985301 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 # 218878701 A B Motor-evap fan
14 5303205119 A B Bracket-motor mtg,rear
17 218973201 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774911 A - Plug-button,almond ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
29* 5308000186 A B Washer,.34 x .62 x .10 ,nylon
30 5304409595 A B Bracket-lower hinge,zinc plate
30* 215882300 A B Tapping Plate,lower hinge ,(2)
30* 218368500 A B Shim-lower hinge
35 218998902 A - Bracket-ctr hinge,almond
35 218998901 - B Bracket-ctr hinge,light gray
36 218251300 A B Pin-center hinge
37 5303321082 A - Trim-cabinet corner,almond
37 5303321081 - B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
40 3206105 A - Cover-upper hinge,almond
40 3206101 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 215880100 A B Screw-hinge mtg,hex wshr hd,1/4-20x 0.685,(2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B Roller
43* 5308009761 A B Bolt-roller adj
43* 5308009790 A B Spring-roller adj
43* 5308011326 A B Washer,.34 x .62 x .02 ,nylon
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
45* 218843800 A B Screw,hex wshr hd ,8-15A x 0.5,wiring clamps
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 215507300 A B Screw,hex washer head ,8-18AB x 1-1/2
56 218220300 A B Pin-lower hinge
59 218188000 A B Screw,pan hd ,10-32x.625,hinge/mull,thrd form
72 218915402 A - Grille/Kickplate,almond ,w/fasteners
72 218915401 - B Grille/Kickplate,white ,w/fasteners
73 218896804 A B Fastener-grille,button ,(2)
78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - Plug-button,almond
98 215099701 - B Plug-button,white
* 5303305325 A - Paint,touch-up ,almond
* 5303305324 - B Paint,touch-up ,white
* 5308016571 A B Plug-button,cab liner holes

09/00 6
Publication No. FRT18PRH
5995343638
SHELVES

# = Fast-moving Parts 7 09/00
* = Non-Illustrated Parts
FRT18PRH Publication No.
5995343638
SHELVES
A = FRT18PRH (FRT18PRHD1)
B = FRT18PRH (FRT18PRHW1)
POS. NO PART NO DESCRIPTION
1 218874311 A - Mullion,almond
1 218874301 - B Mullion,white
5 # 218781003 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Panel-top,refr cavity
8 218872903 A B Divider,styrofoam ,w/foil tape
8* # 218878500 A B Wiring Harness,control/divider
9 218814700 A B Panel-bottom,frzr cavity
10 215667501 A B Tray-ice,plastic
11 5303288242 A B Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 # 5303001179 A B Light Bulb/Lamp,40 W
16A# 218906801 A B Socket-light/lamp
17 5304414816 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5303321453 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B Tube,PVC ,white ,@ air deflector ,insulator
23 # 215846605 A B Timer-defrost,60 Hz ,120 V ,10 hour/21 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 215919161 A B Frame-full shelf,cantilever
25 215686501 A B Cover-crisper pan,with beam
25A 218905812 A B Trim-crisper cover,w/humidity hole
25B 5303301393 A B Control-humidity
26 3206438 A B Pan-crisper
28 3201150 A B End Cap-shelf,protector ,frzr shelf
29 218830303 A B Trim-glass shelf,24.92" ,front
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 215919160 A B Frame-half shelf,cantilever
37 218830309 A B Trim-glass shelf,12.13" ,front
40 218498173 A B Glass-shelf,24.88" x 14.57" ,w/graphics
41 215919803 A B Trim-glass shelf,24.92" ,rear
42 218971202 A B Hanger-meat pan,LH
42 218971302 A B Hanger-meat pan,RH
43 218498172 A B Glass-shelf,12.09" x 14.57" ,w/graphics
44 215919809 A B Trim-glass shelf,12.13" ,rear
46 215357609 A B Front-crisper pan
47 218498174 A B Insert-pan cover,24.60" x 12.75" ,glass
59 218188000 A B Screw,pan hd ,10-32 x .625 hinge/mulli,thrd form
67 215357813 A B Front-meat pan
81 5303001380 A B Screw,truss head ,8-10 x 1.625
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in

09/00 8
Publication No. FRT18PRH
5995343638
SYSTEM

# = Fast-moving Parts 9 09/00
* = Non-Illustrated Parts
FRT18PRH Publication No.
5995343638
SYSTEM
A = FRT18PRH (FRT18PRHD1)
B = FRT18PRH (FRT18PRHW1)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
1* 5303208866 A B Spacer-cond tube,black
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10 ,grounding
4 218944001 A B Drier-filter,R134a System
5 # 218878500 A B Wiring Harness,control/divider
6 # 215257004 A B Wiring Harness,compressor
7 # 5316254901 A B Cord-electric power
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 218955901 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 218973101 A B Insulator-evap
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 218969902 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846902 A B Compressor,R134a ,w/o electricals
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Clamp,elec cont mtg ,compressor
41 5308000039 A B Screw,hex washer hd ,8-32CA x 0.5,(7),serrat hd
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.625 ID
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
45* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500 ,wiring clamps
45* 5300141713 A B Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
* # 3916557 A B Hot Tube Repair Kit,Service
