Frigidaire FRT21IQRJZ1 User manual

Product Registration.................................. 2
Important Safety Instructions................... 2
Versión en Español..................................... 2
First Steps ................................................... 3
Connecting Ice aker to Water Supply .... 4
Energy Saving Ideas................................... 5
Setting the Controls .................................... 5
Fresh Food Storage..................................6-7
Care and Cleaning ...................................8-9
Automatic Ice aker .................................. 9
Door Reversal Instructions................ 10-12
Toe Grille Assembly Instructions............. 13
Avoid Service Checklist...................... 14-16
Normal Operating Sounds ....................... 16
Warranty .................................................... 17
Service Information (Canada) .................. 18
P/N 218989102 (0101)

2
Record the Model Number and Serial Number of this refrigerator in the space
providedbelow.Thesenumbersarefoundontheserialplatelocatedonthetopleft
walloftherefrigeratorcompartment.
Model Number:
SerialNumber:
Register Your Product
Theself-addressedPRODUCTREGISTRATIONCARDshould befilled incompletely,
signed and returned to Frigidaire, or in Canada, Frigidaire Canada.
Read all instructions before using this refrigerator.
For Your Safety
Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityof
this or any other appliance. Read product labels for flammability and other warnings.
Child Safety
• Destroy carton, plastic bags, and any exterior wrapping material immediately
aftertherefrigeratorisunpacked.Childrenshouldneverusetheseitemsforplay.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
become airtight chambers and can quickly cause suffocation.
• Remove all staples from the carton. Staples can cause severe cuts and destroy
finishes if they come in contact with other appliances or furniture.
• Anempty,discardedicebox,refrigeratororfreezerisaverydangerousattraction
to children. Remove the door of any appliance that is not in use, even if
it is being discarded.
ElectricalInformation
Theseguidelinesmustbefollowedtoensurethatsafetymechanisms inthe
design of this refrigerator will operate properly.
•The refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a 3-prong
grounding plug for your protection against shock hazards. It must be plugged
directly into a properly grounded 3-prong receptacle. The receptacle must be
installed in accordance with local codes and ordinances. Consult a qualified
electrician. Do not use an extension cord or an adapter plug.
• Ifvoltagevariesby10percent ormore,performanceofyourrefrigeratormaybe
affected. Operating the refrigerator with insufficient power can damage the
compressor.Suchdamageisnotcoveredunderyourwarranty.Ifyoususpectyour
voltage is high or low, consult your power company for testing.
• Topreventtherefrigeratorfrombeingturnedoffaccidentally,donotplugtheunit
into an outlet controlled by a wall switch or pull cord.
• Do not pinch, knot, or bend the power cord in any manner.
Other Precautions
• Neverunplugtherefrigeratorbypullingonthepowercord.Alwaysgriptheplug
firmly and pull straight out from the receptacle.
• To avoid electrical shock, unplug the refrigerator before cleaning and before
replacingalightbulb.NOTE:TurningthecontroltoOFFturnsoffthecompressor,but
doesnot disconnect power to the light bulb or other electrical components.
• Do not operate the refrigerator in the presence of explosive fumes.
• Iftherefrigeratorhasanautomaticicemaker,avoidcontactwithanymovingparts.
Product Registration
Versión en español
Si desea obtener una copia en español
de este Manual del Usuario, sírvase
escribir a la dirección que se incluye a
continuación.Solicite la P/N 218989101.
SpanishOwner'sGuides
FrigidaireHomeProducts
P.O.Box 212378
Augusta,GA30917
Important Safety
Instructions
© 2001 White Consolidated Industries, Inc.
All rights reserved.
Proper Disposal of
Your Refrigerator/Freezer
Risk of child entrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandoned refrigerators or freezers are
still dangerous — even if they will sit for
"justafewdays."Ifyouaregettingridof
your old refrigerator or freezer, please
follow the instructions below to help
preventaccidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
Remove
doors.
Leave
shelves in
place so
children
may not
easily climb
inside.
Avoid fire hazard or
electric shock. Do not use an extension
cordoranadapterplug.Donotremove
anyprong from the power cord.

3
First Steps
1"
1"
1/2"
1/2"
3" AIR SPACE
Clearance
Proper air circulation and leveling will
ensure efficient operation.
Before starting the refrigerator, follow these important first steps:
Location
• Chooseaplacethatisnearagroundedelectricaloutlet.DONOTuseanextension
cord or an adapter plug.
• If possible, place the refrigerator out of direct sunlight and away from the
range, dishwasher or other heat sources.
• The refrigerator must be installed on a floor that is level and strong enough
tosupport a fullyloadedrefrigerator.
• Consider water supply availability for models equipped with an automatic ice
maker.
Installation
• Do not install the refrigerator where the temperature will drop below 60°F
(15°C) or rise above 110°F (43°C). The compressor will not be able to maintain
propertemperatures.
• Allowspacearoundtheunitforgoodaircirculation.Leavea1inch(25mm)space
behind and a 3 inch (75 mm) space above the refrigerator for adequate
circulation.
• In a recessed installation, allow an extra 1/2 inch (10-15 mm) on each side
for ease of installation.
• For best circulation, elevate the unit 1 inch (25 mm) from the floor, especially if
the floor is carpeted.
Door Opening
The doors should open to allow easy access to a counter when removing food.
• Donotpositiontherefrigeratorsoyouhavetowalkaroundtherefrigerator
doors.
• Reverse the doors if necessary. See Door Reversal Instructions.
Leveling
Allfour cornersof refrigeratormust rest firmly on a solid floor.Somemodels
are equipped with adjustable screw-type levelers. Others are equipped with rollers.
Ifyourrefrigeratordidnotcomewithrollers,theycanbepurchasedfromyourdealer.
Remove toe grille (some models). See Toe Grille Instructions on page 13.
•Toadjust screw-typelevelers (somemodels): Tipcabinetbackslightly and
raise adjusting bolts as needed.
•To adjust front rollers (some models): Use a screwdriver, 3/8" socket
wrench,or nutdriver to adjust rollers asshown.
Raise the front ofcabinetenoughso doorswillclosefreelywhen openedhalfway.
Level cabinet side to side.
Cleaning
• Wash the inside, all removable parts and the outside with mild detergent and
warm water. Wipe dry. Do not use harsh cleaners on these surfaces.
• Do not use razor blades or other sharp instruments, which can scratch the
appliance surface, when removing adhesive labels. Any glue left from the
tape or energy label can be removed with a mixture of warm water and mild
detergent, or, touch the glue with the sticky side of tape already removed.
•Do not remove the serial plate.
Sunken bolt (some models)
Exposed bolt (some models)

4
IMPORTANT:
Ensure that your water supply line connections comply with all local plumbing codes.
Before Installing The Water Supply Line, You Will Need
•Basic tools: adjustable wrench and standard, flat blade screwdriver.
• Access to a household cold water line with water pressure between 20 and 120 psi.
• A water supply line made of ¼ inch (6.4 mm) OD, copper tubing. To determine the length of copper tubing needed, you
will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water pipe.
Then add approximately 7 feet (2.1 meters), so the refrigerator can be moved out for cleaning. See Figure 2.
• A shutoff valveto connect the water supply line to your household water system. (DO NOT use a self-piercing type shutoff
valve.)
• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.
NOTE: Water line kit number 5303917950, available from your appliance dealer at additional cost, contains 25 feet (7.6
meters) of ¼” OD copper tubing, a saddle type shutoff valve (nonpiercing), (2) ¼” brass compression nuts, (2) ferrules/sleeves,
and instructions for installing a water supply line.
To Connect Water Supply Line To Ice Maker Inlet Valve
1. Disconnectrefrigeratorfromelectricpowersupply.
2. Place end of water supply line into sink or bucket. Turn ON water supply
and flush supply line until water is clear. Turn OFF water supply at shutoff
valve.
3. Unscrew plastic cap from water valve inlet (some models) and discard cap.
4. Slide brass compression nut, then ferrule (sleeve), onto water supply line,
as shown in Figure 1.
5. Push water supply line into water valve inlet as far as it will go (¼ inch). Slide
ferrule (sleeve) into valve inlet and finger tighten compression nut onto
valve.Tighten another half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to rear panel
of refrigerator at location shown in Figure 2.
7. Coil excess water supply line (about 2½ turns) behind refrigerator as
shown in Figure 2 and arrange coils so they do not vibrate or wear
against any other surface.
8. Turn ON water supply at shutoff valve and tighten any connections
that leak.
9. Reconnectrefrigeratorto electricpowersupply.
10.To turn ice maker on, lower wire signal arm. (See ice maker front
coverforon/off position of arm.)
It takes approximately 24 hours for the ice maker to begin producing
ice. Air in new plumbing lines may cause ice maker to cycle two or three times before making a full tray of ice. New
plumbing may cause ice to be discolored or have poor flavor. Discard ice made during the first 24 hours.
Figure 1
Figure 2
To Avoid Property Damage:
• Copper tubing is recommended for the water supply line. Water supply tubing made of 1/4” plastic is not recommended since it
greatly increases the potential for water leaks. Manufacturer will not be responsible for any damage if plastic tubing is used for
supply line.
•DO NOT install water supply tubing in areas where temperatures fall below freezing.
• Connect the ice maker to a potable water source that is not tied into a water softening system. Chemicals from the softener may
damage the ice maker, causing it to malfunction.
To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator from
electrical power before connecting a water supply line to the refrigerator.
Connecting Ice Maker
to Water Supply

5
• Locatetherefrigeratorinthecoolestpartoftheroom,outofdirectsunlightand
awayfromheatingductsorregisters.Donotplacetherefrigeratornexttoheat-
producingappliancessuchasarange,ovenordishwasher.Ifthisisnotpossible,
a section of cabinetry or an added layer of insulation between the two
appliances will help the refrigerator operate more efficiently.
• Level the refrigerator so the doors close tightly.
• Refer to this Owner's Guide for the suggested refrigerator settings.
• Periodiccleaningofthecondenserwillhelptherefrigeratorrunmoreefficiently.
See Outside in the "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigeratortorunlongerandusemoreenergy.Shelvesshouldnotbelinedwith
aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Cover foods and wipe containers dry before placing them in the refrigerator.
This cuts down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Setting the Controls
Energy Saving Ideas
G05C0061
Freezer Control
Cool Down Period
To ensure safe food storage, allow the refrigerator to operate with the doors
closed for at least 8 to 12 hours before loading with food.
Refrigerator and Freezer Controls
• To start out, set control dials to the midpoint for a trial period of 24 hours.
Temperatures
• After 24 hours, adjust the controls as needed. Adjust temperature one
number at a time. For colder temperatures, turn the dial toward COLDEST.
Forwarmer temperatures, turn the dialtoward COLD. The temperature will
increase or decrease, but not necessarily by 1, 2, or 3 degrees.
An adjustment made to one compartment may require an adjustment to the
other.
• Turning the refrigerator control will change the temperature in BOTH
compartments. If the refrigerator control is turned to OFF, cooling stops
in both compartments.
• Turning the freezer control will change only the temperature in the
freezer compartment.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air vents with food items.
Moisture Reduction Switch (some models)
If moisture forms on the metal between the two doors, set the Moisture
Reduction Switch (located on the control box in the refrigerator compartment) to
the “ON” position. Aheater will warm the surface and allowmoisture to evaporate.
Refrigerator Control
Moisture Reduction Switch
