Frigidaire FRT21LRG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21LRGD9 FRT21LRG R134a almond 115
FRT21LRGW9 FRT21LRG R134a white 115
MARKET
North America
Publication No.
5995344404
001006
-EN/SERVICE/KHB
357
REFRIGERATOR
Model No.
FRT21LRG
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - #193832
OWNER’S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624

10/00 2
Publication No. FRT21LRG
5995344404
DOOR

# = Fast-moving Parts 3 10/00
* = Non-Illustrated Parts
FRT21LRG Publication No.
5995344404
DOOR
A = FRT21LRG (FRT21LRGD9)
B = FRT21LRG (FRT21LRGW9)
POS. NO PART NO DESCRIPTION
1 215608972 A B Gasket-frzr door,white ,magnetic
2 218730609 A B Gasket-refr door,white ,magnetic
3 215393201 A B Panel-inner door,refr
4 218763617 A B Rack-door,23.09" x 2.04"
4A 218763616 A B Rack-door,22.51" x 2.04"
4B 218763615 A B Rack-door,9.24" x 2.04"
5 218758601 A B Support-door rack,RH/LH
5A 218809701 A B Support-door rack,LH
5B 218809801 A B Support-door rack,RH
7 5303308341 A B Door-dairy,12.96" wide
8 218763618 A B Rack-door,23.47" x 2.04" ,(2)
9 215530301 A B Panel-inner door,frzr
10 5303001308 A - Plug-button,almond ,hinge brg hole
10 5308000134 - B Plug-button,white ,hinge brg hole
11 5303917811 A - Panel-frzr door,almond ,w/insulation
11 5303917810 - B Panel-frzr door,white ,w/insulation
12 218156515 A - Nameplate Assy,almond ,with magnet
12 218156514 - B Nameplate Assy,white ,with magnet
12* 215008608 A - • Label-nameplate,almond
12* 215008607 - B • Label-nameplate,white
12* 215518000 A B • Magnet-nameplate
12* 218364002 A - • Frame-nameplate,almond
12* 218364001 - B • Frame-nameplate,white
13 218800300 A B Door Stop,plated
13A 218249002 A - Door Stop,almond ,frzr section
13A 218249001 - B Door Stop,white ,frzr section
14 218915702 A - Plug-button,almond
14 218915701 - B Plug-button,white
15 5303917813 A - Panel-refr door,almond ,w/insul & brace
15 5303917812 - B Panel-refr door,white ,w/insul & brace
18 218668002 A - Handle-door,almond
18 218668001 - B Handle-door,white
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B Bearing-hinge
37 215867059 A - Trim-handle, 4.97", almond, w/band & lock
37 215867058 - B Trim-handle,4.97" ,white ,w/band & lock
37* 218676001 A B • Band-decorative,chrome ,handle trim
37* 218906701 A B • Lock-handle trim,stick-on
58 218781100 A B Screw,pan head ,8-18 x 0.625
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

10/00 4
Publication No. FRT21LRG
5995344404
CABINET

# = Fast-moving Parts 5 10/00
* = Non-Illustrated Parts
FRT21LRG Publication No.
5995344404
A = FRT21LRG (FRT21LRGD9)
B = FRT21LRG (FRT21LRGW9)
POS. NO PART NO DESCRIPTION
1 5304402655 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 218973801 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 218878801 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218974001 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
20 5303001286 A B Ferrule-inner
21 5303001287 A B Ferrule-outer
22 215774911 A - Plug-button,almond ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
23 5303210377 A B Tube-drain,w/seal ring
24 5303207353 A B Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
26 218605102 A - Base-cabinet,almond
26 218605101 - B Base-cabinet,white
27 5303212922 A B Screw-leveling
28 5303271412 A B Bolt-roller adj, hex hd sems, 1/4-28 x 2.750, (2)
29 218666700 A B Washer,.28 x .62 x .03 ,nylon
29* 218875801 A B Washer,nylon ,0.245 ID w/nibs
30 218220203 A B Bracket-lower hinge,zinc chromate
30* 218605200 A B Tapping Plate/Gusset,RH
30* 218605300 A B Tapping Plate/Gusset,LH
35 218998902 A - Bracket-ctr hinge,almond
35 218998901 - B Bracket-ctr hinge,light gray
36 218251300 A B Pin-center hinge
37 5303321082 A - Trim-cabinet corner,almond
37 5303321081 - B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
40 3206105 A - Cover-upper hinge,almond
40 3206101 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
43 218703001 A B Roller Assy,front ,(2)
43* 5308009790 A B Spring-roller adj
43* 5308011326 A B Washer,.34 x .62 x .02, nylon
44 218713600 A B Roller Assy, rear, (2)
45 5303001343 A B Screw, hex washer head, 8-15A x 0.500
45* 218754500 A B Screw, hex hd ser wshr, 8-18 x 0.375
46 5308009762 A B Bolt-roller mtg, hex wshr hd, 1/4-28 x 0.500,(2)
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1.250
56 218220300 A B Pin-lower hinge
59 218188000 A B Screw,pan hd ,10-32 x 0.625, hinge/mull, thrd forming
78 5303274237 A B Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - Plug-button,almond
98 215099701 - B Plug-button,white
100 5303288973 A B Support-pan cover
110 215363501 A B Support-crisper rod
116 215426703 A B Rod-crisper support
* 218905701 A B Cover-sound insul, pressboard/foam, machine compt
* 218990901 A B Clip-wire
* 5303305325 A - Paint,touch-up ,almond
* 5303305324 - B Paint,touch-up ,white
* 5308016571 A B Plug-button,cab liner holes
CABINET

10/00 6
Publication No. FRT21LRG
5995344404
SHELVES

# = Fast-moving Parts 7 10/00
* = Non-Illustrated Parts
FRT21LRG Publication No.
5995344404
SHELVES
A = FRT21LRG (FRT21LRGD9)
B = FRT21LRG (FRT21LRGW9)
POS. NO PART NO DESCRIPTION
1 218651901 A - Mullion,almond
1 218651900 - B Mullion,white
5 # 218781002 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218866101 A B Top Panel-refr
8 218909706 A B Divider,styrofoam ,w/foil tape
8* # 218878600 A B Wiring Harness,control/divider
9 218865900 A B Bottom Panel-frzr
10 215667501 A B Tray-ice,plastic
11 5303288243 A B Shelf-freezer, fixed/flat, full width, wire
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 # 5303001179 A B Light Bulb/Lamp,40 W
16A# 218906801 A B Socket-light/lamp
17 5304414816 A B Control Box
17* 5308016567 A B Nut-anchor
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5304403736 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B Tube, PVC, white, @ air deflector, insulator
23 # 215846606 A B Timer-defrost, 60 Hz, 120 V, 10 hr/30 min
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 5303300042 A B Shelf,cantilever ,full width ,wire
25 215363203 A B Cover-crisper pan,less insert
25A 5303310151 A B Trim-crisper cover
26 215363301 A B Pan-crisper,tilt-out
28 3201150 A B End Cap-shelf,protector ,frzr shelf
29 5303284483 A B Trim-shelf,26.80" ,front
31 215742602 A B Pan-meat
34 5303212918 A B Container-ice
36 5303310497 A B Shelf,cantilever ,half width ,wire
36A 215919173 A B Frame-half shelf,cantilever
37 5303284484 A B Trim-shelf,13.06" ,front
37A 215919411 A B Trim-half shelf,front
42 218971202 A B Hanger-meat pan,LH
42 218971302 A B Hanger-meat pan,RH
43 218390525 A B Glass-shelf,13.03" x 14.57"
44 215919811 A B Trim-glass shelf,13.07" ,rear
46 215412105 A B Front-crisper pan,(2)
47 218390526 A B Insert-pan cover,glass
59 218188000 A B Screw,pan hd, 10-32 x 0.625, hinge/mull, thrd forming
67 215357809 A B Front-meat pan
81 218362500 A B Screw,hex washer head ,8-18AB x 1.250
123 215005100 A B Screw-roller/hanger, 8-10 x 0.438
145 218660800 A B Clip, plastic, temp sensor mtg, snap-in
* 3205266 A B Edge Protector,wiring harness

10/00 8
Publication No. FRT21LRG
5995344404
SYSTEM

# = Fast-moving Parts 9 10/00
* = Non-Illustrated Parts
FRT21LRG Publication No.
5995344404
SYSTEM
A = FRT21LRG (FRT21LRGD9)
B = FRT21LRG (FRT21LRGW9)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B Condenser
1* 5304406039 A B Spacer-tube,5/8 OD x 3" lg
1* 5304406040 A B Spacer-tube,5/8 OD x 12" lg
1* 5304406721 A B Spacer-cond tube,round ,5/8 OD x .81"lg
1* 5304406722 A B Spacer-tube,5/8 OD x 2" lg
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10 ,grounding
4# 218944001 A B Drier-filter,R134a System
5 # 218878600 A B Wiring Harness,control/divider
6 # 215257001 A B Wiring Harness,compressor
7 # 5316254901 A B Cord-electric power
7* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500, wiring clamps
8 5303001197 A B Cover-wiring
13 # 215076408 A B Heat Exchanger,suction line
14 # 5317842502 A B Heater-defrost
15 # 218955701 A B Evaporator,bundy
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 218973901 A B Insulator-evap,plastic
18 218998101 A B Block-evap coil,styrofoam insul ,RH
20 218821201 A B Insulation Block,LH
21 # 218969902 A B Thermostat-defrost
22 5308013663 A B Plate-compr mtg
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
26* 5308017610 A B Sound Tape,defrost pan
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 218973601 A B Compressor,w/o electricals
30 # 218721108 A B Starter-PTC
32 218973501 A B Clamp,elec cont mtg, compressor
41 5308000039 A B Screw, hex wshr hd, 8-32CA x 0.500, (7),serratd hd
43 5303001199 A B Clamp-wiring harness, strain relief, galv steel
43* 5308000133 A B Clamp,nylon ,.625 ID
44 218974101 A B Clamp,nylon ,1.00 OD tube
45 5303001343 A B Screw,hex washer head ,8-15A x 0.500
45* 218754500 A B Screw,hex hd ser wshr ,8-18 x 0.375
45* 5300141713 A B Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 218909901 A B Capacitor-run,220 VAC ,15 microfarad
* 218905701 A B Cover-sound insul, pressboard/foam, machine compt
* # 5300189383 A B Hot Tube Repair Kit,Service

10/00 10
Publication No. FRT21LRG
5995344404
WIRING SCHEMATIC

# = Fast-moving Parts 11 10/00
* = Non-Illustrated Parts
FRT21LRG Publication No.
5995344404
WIRING DIAGRAM
