Frigidaire GLTF2070DS0 User manual

Installation
Instructions
Full Size Tumble Action Washers
Before beginning installation, carefully read these instructions• This will simplify the
installation and ensure the washer is installed correctly and safely• Leave these instructions
near the washer after installation for future reference•
NOTE: The electrical service to the washer must conform with local codes and ordinances
and the latest edition of the National Electrical Code, ANSI/NFPA 70.
For your safety the information in
this manual must be followed to minimize the
risk of fire or explosion or to prevent property
damage, personal injury or loss of life.
-Do not store or use gasoline or other
flammable vapors and liquid in the vicinity of
this or any other appliance.
- WHATTO DO IFYOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppliers
instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
Contents
SUBJECT PAGE
Pre-tnstallation Requirements 2
Electrical Requirements 2
Grounding Requirements 2
Water Supply Requirements 2
Drain Requirements 2
Rough-In Dimensions 3
Location OfYourWasher 4
Unpacking 4
Installation 5
Replacement Parts 5
Printed in U.S.A. PIN 134305600 (0310)

PRE-INSTALLATION REQUIREMENTS
Tools Required for Installation:
1. 1/4 in. nut driver
2. 3/8 in. socket with ratchet.
3. 3/8 in. open end wrench.
4. 7/16 in. socketwith ratchet.
5. 9/16 in. open end wrench.
6. Channel-lock adjustable pliers.
7. Carpenter's level.
ELECTRICAL REQUIREMENTS
CIRCUIT - Individual, properly polarized and grounded
15 amp. branch circuit fused with 15 amp. time delay
fuse or circuit breaker.
POWER SUPPLY - 2 wire, with ground, 120 volt, single
phase, 60 Hz,Alternating Current. NOTE: The use of this
washerwi_ powercreated bygasboweredgenerators,solar
powered generators,wind powered generators or any other
generator other than the local utility company is not
recommended.
into an appropriate, copper wired receptacle that is
properly installed and grounded inaccordance with all
localcodes and ordinances or in the absence oflocal
codes,with the National ElectricalCodes, ANSI/N FPA
70 (latestedition). Ifin doubt, calla licensed electrician.
DO NOT cut off or alter the grounding prong on the
power supply cord. In situations where a two-slot
receptacle ispresent, itisthe owner's responsibility to
have a licensed electrician replace itwith a properly
grounded three prong grounding type receptacle.
WATER SUPPLY REQUIREMENTS
Hot and cold water faucets MUST be installed within
42 inches (107 cm) of your washer's water inlet. The
faucets MUST be 3/4 inch (1.9 cm) garden hose type
so inlet hoses can be connected. Water pressure MUST
be between 30 and 120pounds per square inch(maximum
unbalance pressure, hot vs. cold, 10 psi.)Your water
department canadvise youofyour water pressure.The hot
watertemperatureshouldbeabout140degreesF(60degrees
c).
DRAIN REQUIREMENTS
1. Drain capable of eliminating 17 gals (64.3 L) per
minute.
2. A standpipe diameter of 1-1/4 in. (3.18 cm)
minimum.
3. The standpipe height above the floor should be:
Minimum height: 24in. (61 cm)
Maximum height: 96 in. (244 cm)
OUTLET RECEPTACLE -Properly grounded 3-prong
receptacle to be located so the power supply cord is
accessible when the washer is in an installed position.
NOTE: GFI (Ground Fault Interrupter) receptacle is not
required.
GROUNDING REQUIREMENTS
_ Improper connection ofthe equipment
grounding conductor can result in a risk of electrical
shock. Check with a licensed electrician if you are in
doubt as to whether the appliance is properly grounded.
.The washer MUST be grounded. In the event of
malfunction or breakdown, grounding will reduce
the risk of electrical shock by a path of least
resistance for electrical current.
2. Since yourwasher is equipped with a power supply
cord having an equipment-grounding conductor
and a grounding plug, the plug MUST be plugged
NOTE:
O
BACK
96 in.
(244 cm)
Max.
24 in.
(61 cm)
Min.
Drain hose attached to the washer can reach a 58
in. (147 cm) high standpipe. For higher standpipe
usehose P/N 134049201,availablefrom anauthorized
parts distributor. Ifdrain is less than 24 in. (61 cm),
install a siphon break kit, available at your local
hardwarestore.

17 1/2
21/2
(6.4) r
=g=
inch (cm)
24
(61)
SIDE
Adjustable Legs
ROUGH-IN DIMENSIONS
60
(152.4)
1
11/2 351/4
(89.5)
Power
Cord
331/2
(85)
263/4
"_ (67.9)
z113/4 .-
(29.8)
C BACK
27/8
(7.3)
Water
Inlets
31%
(80.3)
171/2
(44.5)_
21/2
(6.4)
inch (cm)
24
(61)
SIDE
Adjustable Legs
60
(152.4)_J
=(2.54) T
11/2 351/4
(89.5)
Power
Cord
331/2
(85)
263,4
(67.9) ]P.
113/4 J I
(29'8) ']° o O
(7.3)
Water
Inlets
31%
(80.3)

LOCATION OF YOUR WASHER
DO NOT INSTALLYOUR WASHER:
1. In an area exposed to dripping water or outside
weather conditions. The ambient temperature
should never be below 60 ° F (15.6 ° C) for proper
washer (detergent breakdown) operation.
2. In an area where it will come in contact with
curtains or drapes.
3. In an area (garage or garage-type building) where
gasoline of other flammables are kept or stored
(including automobiles).
4. On carpet. Floor MUST be solid with a maximum
slope of 1/2 in. per foot (1.27 cm per 30.5 cm). To
ensure vibration or movement does not occur,
reinforcement of the floor may be necessary.
IMPORTANT
MINIMUM INSTALLATION CLEARANCES
When installed in alcove or closet:
Sides, Rear = 0 in. (0 cm)
Top = 0 in. (0 cm) Front Console Model
Top = 15 in. (38.1 cm) Rear Console Model
When installed in closet: Front = 1 in. (2.54 cm)
Closet door ventilation required: 2 Iouvered openings
each 60 in2(387 cm2),3 in.(7.6 cm) from top and bottom
of door.
3. Remove the styrofoam base.
4. Carefully return the washer toan upright position and
remove the carton.
5. Carefully move the washer towithin 4 feet (122cm) of
the final location.
6. Remove the following from the back side of the
washer: 4 bolts,
4 yellow plastic spacers,
3 metal "P" clamps.
7. Remove the service panel from the front of the
washer.
8. Remove the 4 nuts and 6 large washers that attach
the 2 yellow shipping braces to the drum and the
base. Lift up on the drum and remove the braces
(a yellow ribbon surrounds the items to be
removed). These braces must be removed to allow
the power supply cord to be released from the
shipping ring.
9. Remove the large styrofoam block located under
the drum. Lift up on the drum, tilt the base of the
foam block inwards toward the rear of the washer
until free, then pull it out.
10. Remove and discard the yellow ribbon and label
from the front of the washer.
UNPACKING
1. Cut the shipping carton along the dotted line along
the base of the unit.
2. While in the carton carefully lay the washer on its
back side.
Q BOLT
@ SPACER
"P" CLAMP
11. From the rear of the washer, carefully pull out the
power supply cord through the hole in the
backsheet.
12. Replace the service panel and screws.
NOTE: If the washer is to be transported at a later
date, the shipping support hardware must
be reinstalled to prevent shipping
damage. Retain the hardware in the
plastic bag provided.

Cable
Tie
2.
4.
5.
6.
INSTALLATION
Run some water from the hot
and cold faucets to flush the
water lines and remove
particles that might clog up the
water valve screens.
Remove the inlet hoses and
rubber washers from the
plastic bag and install the
rubber washers in each end
of the inlet hoses.
Carefully connect the inlet hose
(90 ° elbow end) marked "HOT"
to the outside "H" outlet of the
water valve. Tighten by hand, then
tighten another 2/3 turn with
pliers. Carefully connect the other
inlet hose (90 ° elbow end) to the
inside "C" outlet of the water valve.
Tighten by hand, then tighten
another 2/3 turn with pliers. Do
not crossthread or over-
tightenthese connections.
Connect the inlet hose ends to the HOT and COLD water
faucets tightly by hand, then tighten another 2/3 turn with
pliers. Turn the water on and check for leaks.
NOTE: Use only new hoses.
Carefully move the washer to its final location.
NOTE: Do not use the dispenser drawer or door to lift
washer.
With the washer in its final position, place a level on top of
the washer, no rocking of the washer should exist. Adjust the
front leveling legs up or down to ensure the washer is resting
solid. Rear leg adjustment is accessible through the front
service panel. Turn the lock nuts on each leg up towards the
base of the washer and snug with a wrench.
NOTE: Keep the leg extension at a minimum to prevent
excessive vibration. The farther out the legs are
extended the more the washer will vibrate.
Form a U shape on the end of the drain hose with the hose
pointed toward the drain. Place in a laundry tub or standpipe
and secure with the cable tie provided in the enclosure
package.
NOTE: If the drain hose is placed in a standpipe without
forming a U shape, a siphoning action could occur.
There must be an air gap around the drain hose. A
snug hose fit can also cause a siphoning action.
Cable Tie
Cable
Tie
Cable
Tie
8. Plug the power cord into a grounded outlet.
NOTE: Check to ensure the power is off at a circuit
breaker/fuse box before plugging the power
cord into an outlet.
9. Turn on the power at a circuit breaker/fuse box.
10. Read the Operating instructions and Owner's Guide
provided with the washer. They contain valuable
and helpful information that will save you time and
money.
11. Run the washer through a complete cycle. Check for water
leaks and proper operation.
12. If your washer does not operate, please review the
"Avoid Service Checklist" in your Owner's Guide before
calling for service.
13. Place these instructions in a location near the washer
for future reference.
NOTE: A wiring diagram and technical data sheet are located in
an envelope attached to the left hand side panel on the
inside of the washer.
REPLACEMENT PARTS
If replacements parts are needed for your washer,
contact the source where you purchased your
washer, call 1-800-944-9044, or visit our website,
www.frigidaire.com, for the Frigidaire Company
Authorized Parts Distributor nearest you.
r:''i'lzl_l_'li_L_ Destroy the carton and plastic bags
after the washer is unpacked. Children might use them
for play. Cartons covered with rugs, bedspreads, or
plastic sheets can become airtight chambers causing
suffocation. Place all materials in a garbage container
or make materials inaccessible to children.
_The instructions in this manual and all
other literature included with this washer are not meant to
cover everypossible condition and situationthat may occur.
Good safe practice and caution MUST be applied when
installing, operating and maintaining any appliance.
Maximum benefits and enjoyment are achieved
when all the Safety and Operating instructions are
understood and practiced as a routine with your
laundering tasks.
