Froggit DP150 User manual

1
DP150
Soil temperature sensor
Manual (EN)
Support/updates/manuals/spare parts/compatible products:
www.froggit.de / [email protected]

2
Overview
Figure 1: Soil temperature sensor
Temperature sensor:
 Measures temperature with a 0cm stainless steel probe sensor
 Transmits readings every 77 seconds.
 Waterproof according to IP65.
 LCD display for current reading.
When paired with a DP1500 Wi-Fi gateway:
 Displays temperature readings on the live data page of the WS View app
(requires the DP1500 and your smartphone to use the same Wi-Fi network).
 Up to 8 channels are supported. The channel names can be edited in the app.
 Battery level information is displayed in the WS View app.

When paired with a weather station onsole (HP1000SE PRO series / WH3900):
 Real-
time temperature data shown on the display (HP1000SE PRO series
only).

Up to 8 channels are supported. The channel names can be edited on the
console.
 Use of
Ecowitt Weather Server:View current temperature data, historical
records and graphs on the website.

Receive email alerts from the server.

Remote monitoring with smartphone, laptop or computer by visiting the
website.
Setup ( ommissioning):
Inserting the battery
1.
remove the battery compartment on the back of the transmitter by removing
the screw (see figure 2):
2.
insert a 1.5 V AA battery (pay attention to the polarity: the flat side of the
battery must be against the spring
The temperature reading is immediately displayed on the LCD screen and is
normally updated every 77 seconds (the sensor transmission update period).
Note: If no reading is displayed on the screen, make sure the battery i
inserted correctly or a proper reset has been performed. Make sure the battery
is inserted correctly. Do not insert the battery upside down.
.
close the battery cover
3
When paired with a weather station onsole (HP1000SE PRO series / WH3900):
time temperature data shown on the display (HP1000SE PRO series
Up to 8 channels are supported. The channel names can be edited on the
Ecowitt Weather Server:View current temperature data, historical
records and graphs on the website.
Receive email alerts from the server.
Remote monitoring with smartphone, laptop or computer by visiting the
remove the battery compartment on the back of the transmitter by removing
the screw (see figure 2):
Figure 2: Inserting the battery
insert a 1.5 V AA battery (pay attention to the polarity: the flat side of the
battery must be against the spring
side of the battery compartment).
The temperature reading is immediately displayed on the LCD screen and is
normally updated every 77 seconds (the sensor transmission update period).
Note: If no reading is displayed on the screen, make sure the battery i
inserted correctly or a proper reset has been performed. Make sure the battery
is inserted correctly. Do not insert the battery upside down.
close the battery cover
When paired with a weather station onsole (HP1000SE PRO series / WH3900):
time temperature data shown on the display (HP1000SE PRO series
Up to 8 channels are supported. The channel names can be edited on the
Ecowitt Weather Server:View current temperature data, historical
Remote monitoring with smartphone, laptop or computer by visiting the
remove the battery compartment on the back of the transmitter by removing
insert a 1.5 V AA battery (pay attention to the polarity: the flat side of the
side of the battery compartment).
The temperature reading is immediately displayed on the LCD screen and is
normally updated every 77 seconds (the sensor transmission update period).
Note: If no reading is displayed on the screen, make sure the battery i
s
inserted correctly or a proper reset has been performed. Make sure the battery

Pla ement of the sensor:
To mount the unit on a wall or wooden beam:
 Use a screw (scre
w ST D .2*M2.0*6) to fix the bracket to the wall, then pass
the probe through the hole in the bracket as shown in Figure :

Attach the sensor to the bracket with the M12 hex nut and tighten the screw as
shown in figure 4: (Turn the nut by hand
turn 1/ to 1/2 turn and no more. Do not over tighten).
For atta hing the unit to a pole (not in luded in the s ope of delivery) with the
supplied hose lamp:
4
To mount the unit on a wall or wooden beam:
w ST D .2*M2.0*6) to fix the bracket to the wall, then pass
the probe through the hole in the bracket as shown in Figure :
Figure
Attach the sensor to the bracket with the M12 hex nut and tighten the screw as
shown in figure 4: (Turn the nut by hand
until it is tight, then use a spanner to
turn 1/ to 1/2 turn and no more. Do not over tighten).
Figure 4
For atta hing the unit to a pole (not in luded in the s ope of delivery) with the
w ST D .2*M2.0*6) to fix the bracket to the wall, then pass
the probe through the hole in the bracket as shown in Figure :
Attach the sensor to the bracket with the M12 hex nut and tighten the screw as
until it is tight, then use a spanner to
For atta hing the unit to a pole (not in luded in the s ope of delivery) with the

Wi-
Fi Configuration:
To view
sensor data on your mobile app and receive email alerts on our
weather server, you need to pair this device with our froggit DP1500 or our
HP1000SE PRO Series / WH 900 weather station (each sold separately).
Pairing with froggit DP1500:
If the DP1500 has
already been in use
sensor before, simply switch on the sensor and the DP1500 will automatically
accept the sensor data.
Note: The
DP1500 can support up to 8 DP
new sensor will be recognised as
sequence. You can assign a label to the channel on each sensor to distinguish
it. The channel name can be edited both in the app and on ecowitt.net (the
name edited in the app is not synchronised with the ecowitt.net
should be edited separately on the device setup page on ecowitt.net).
If you want to use a new DP
already configured on a specific channel), please try the following:
1. open the Sensor ID page in the
Switch off the old sensor and switch on the new sensor. .
On the Sensor ID page, click 'Register New'.
The new sensor will then be enrolled and the old sensor will be deleted.
View online data with WS View:
5
Figure 5
Fi Configuration:
sensor data on your mobile app and receive email alerts on our
weather server, you need to pair this device with our froggit DP1500 or our
HP1000SE PRO Series / WH 900 weather station (each sold separately).
Pairing with froggit DP1500:
already been in use
and you have never set up a DP
sensor before, simply switch on the sensor and the DP1500 will automatically
accept the sensor data.
DP1500 can support up to 8 DP
150
temperature sensors. Each
new sensor will be recognised as
a new channel according to the power
sequence. You can assign a label to the channel on each sensor to distinguish
it. The channel name can be edited both in the app and on ecowitt.net (the
name edited in the app is not synchronised with the ecowitt.net
should be edited separately on the device setup page on ecowitt.net).
If you want to use a new DP
150
sensor to replace the old one (which is
already configured on a specific channel), please try the following:
1. open the Sensor ID page in the
WS View app and locate your old sensor ID.
Switch off the old sensor and switch on the new sensor. .
On the Sensor ID page, click 'Register New'.
The new sensor will then be enrolled and the old sensor will be deleted.
View online data with WS View:
sensor data on your mobile app and receive email alerts on our
weather server, you need to pair this device with our froggit DP1500 or our
HP1000SE PRO Series / WH 900 weather station (each sold separately).
and you have never set up a DP
150
sensor before, simply switch on the sensor and the DP1500 will automatically
temperature sensors. Each
a new channel according to the power
-up
sequence. You can assign a label to the channel on each sensor to distinguish
it. The channel name can be edited both in the app and on ecowitt.net (the
name edited in the app is not synchronised with the ecowitt.net
website and
should be edited separately on the device setup page on ecowitt.net).
sensor to replace the old one (which is
already configured on a specific channel), please try the following:
WS View app and locate your old sensor ID.
The new sensor will then be enrolled and the old sensor will be deleted.

When the Wi-
Fi configuration is complete (to tell the DP1500 to connect to
your Wi-
Fi network), your sensor data and the sensor's battery voltage
information will be displayed in the WS View app on the Live Data page.
Note:
Your smartphone and the DP15
viewing live data from your sensor in the WS View App. Live data refers to
actual data received from the DP1500 and is not stored in the WS View App.
However, the data is always transferred to and stored in the www.ecowi
Cloud (under your registered account, and you can access it at any time via
your browser).
Set email alerts:
Once your device has been successfully added to the Ecowitt weather server,
you can set alerts for the sensor on the website to receive
6
Fi configuration is complete (to tell the DP1500 to connect to
Fi network), your sensor data and the sensor's battery voltage
information will be displayed in the WS View app on the Live Data page.
Your smartphone and the DP15
00 must be on the same network when
viewing live data from your sensor in the WS View App. Live data refers to
actual data received from the DP1500 and is not stored in the WS View App.
However, the data is always transferred to and stored in the www.ecowi
Cloud (under your registered account, and you can access it at any time via
Once your device has been successfully added to the Ecowitt weather server,
you can set alerts for the sensor on the website to receive
email notifications.
Fi configuration is complete (to tell the DP1500 to connect to
Fi network), your sensor data and the sensor's battery voltage
information will be displayed in the WS View app on the Live Data page.
00 must be on the same network when
viewing live data from your sensor in the WS View App. Live data refers to
actual data received from the DP1500 and is not stored in the WS View App.
However, the data is always transferred to and stored in the www.ecowi
tt.net
Cloud (under your registered account, and you can access it at any time via
Once your device has been successfully added to the Ecowitt weather server,
email notifications.

Spe ifi ations:

Power supply: 1x1.5V AA battery (not included).

Sensor type: epoxy sealed thermistor or NTC

Frequency: 868 MHz
Caution !
This booklet may contain
errors
hecked and correction are
included
We disclaim any
responsibility
The specification of this
pro
7
Power supply: 1x1.5V AA battery (not included).
Sensor type: epoxy sealed thermistor or NTC
Frequency: 868 MHz
errors
or misprints. The information is
contains
included
in subsequence editions.
responsibility
for any printing error, or their
consequences
pro
duct may change without prior notice.
contains
is regularly c
consequences
.

8
Gerneral safety insru tions
Danger of asphyxiation:
Keep all packaging materials (plastic bags, rubber bands, etc.) away from children.
There is a danger of suffocation!
Danger of burns:
Caution! Leaking / leaking battery acid can lead to burns! Avoid contact of battery
acid with eyes, mucous membranes and skin. In case of contact, rinse the affected
areas immediately with clear water and consult a doctor.
Risk of ele tri sho k:
Children must not be unattended with the device, because the device contains
electronic parts which are operated by means of a power source. The device may
only be used as described in the instructions. If not, there is a risk of electric shock.
Danger of fire & explosion:
Use only recommended batteries. Never short-circuit the unit or batteries. Never
throw the device or batteries into a fire! Overheating and improper handling may
result in short circuits which can cause fires and explosions.
Important:
If there is a defect, contact your dealer immediately. Never disassemble the device!
The dealer will contact the service department. Never expose the device to water!
Protect the device from vibrations. Only use recommended batteries. Never mix
batteries - Always replace empty batteries with a complete set of full power batteries.
If the unit is not powered for a longer period of time or is not in use, remove the
batteries from the unit. The manufacturer accepts no liability for incorrectly inserted
batteries
Notes on the return of batteries according to §12 BatterieVO: Batteries do not belong
in the household waste. Please dispose of all batteries as required by law, disposal in
domestic waste is expressly prohibited. Batteries and rechargeable batteries can be
dispensed free of charge at municipal collection points or in the shops on the spot.
This manual may not be reproduced in any form without the written permission of the
publisher, even in excerpts.
This manual may contain errors and misprints. However, the information in this

9
manual is regularly reviewed and corrections made in the next issue. We accept no
liability for technical errors or printing errors, and their consequences.
All trademarks and copyrights are acknowledged.
www.froggit.de
HS Group GmbH & Co. KG
Escherstr. 1
507 Koeln
Germany
Telefon
E-Mail
0221 / 67 48 05
[email protected]
Registergericht Amtsgericht
Koeln HRA 2649
Komplementaer: HS Group
Verwaltungsgesellschaft mbH
Sitz Koeln
Registergericht Amtsgericht
Koeln HRB 647 4
Geschaeftsfuehrer: Peter
Haefele, Carl Schulte
UStId DE2 7971721
WEEE Reg. Nr. 66110125
declaration of conformity
Hereby we declare, HS-Group GmbH & Co.KG, Escherstr. 1, 507 D-Cologne,
that this product is in compliance with the essential requirements and other relevant
provisions of Directive 2014/5 /EU.
The declaration of conformity for this product can be found at: www.froggit.de or on
request.
