Fromm FS335 Manual

Fromm Holding AG
Hinterbergstrasse 26
6312 Steinhausen
Switzerland
FS335
FS370
FS340-350-380-385
Rev.2 01/03/2021
EN
Operator Panel
Translation of the original
Turntable - Mast

Fromm
Summary
I
1 GENERAL CONTROLS 1
1.1 COMMANDSWITHBUTTONS................................................................1
1.1.1 FS335 PANEL ................................................................................. 1
1.1.2 FS370 - FS340-350-380-385 PANEL.............................................. 2
1.1.3 CONTROLS DESCRIPTION ............................................................ 3
1.1.4 FS335 / FS370 / FS340-350-380-385 OPERATION ....................... 4
2 FUNCTIONS 7
2.1 CONTROL PANEL FUNCTIONS...............................................................7
2.2 ADDITIONAL MANUAL CONTROLS .....................................................11
2.3 AUTOMATIC CYCLES ............................................................................12
2.4 SEMIAUTOMATIC OPERATING CYCLE ................................................14
2.5 ALARM LIST ..........................................................................................15
2.5.1 RESTART AFTER AN ALARM OR AS RESULT OF TORN / FINISHED
FILM ............................................................................................. 20

Fromm 1
GENERAL CONTROLS
1
1 GENERAL CONTROLS
1.1 COMMANDS WITH BUTTONS
1.1.1 FS335 PANEL
O
H P
C
V
D
B
G
E
O
F
A
Picture 1

2Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
2
1.1.2 FS370 - FS340-350-380-385 PANEL
O
H P
C
F
V
D
B
G
E
OA
Picture 2

Fromm 3
GENERAL CONTROLS
3
1.1.3 CONTROLS DESCRIPTION
A Programmed cycle START button.
B Carriage up manual retention button.
If pressed together with (E)
, the presser automatically rises to
the up cycle start position.
CDecrease values button.
DIncrease values button.
EAlarm reset (fast pressure – less than 2 second);
Saving parameters (press until the LED flashes - more than 3
seconds);
When pressed along with the STOP
button, it stops and resets
the cycle (the display (V) shows INI to show the cancellation).
F
2-digit display indicating the functions (parameters) of the
selected programme;
During the cycle it shows the current operating status;
CF on the display (V)
at the end of the cycle means the film is
depleted;
AA on the display (V) means there is an alarm on the machine.
G
Carriage down manual retention button (if pressed together
with (E)
, the carriage automatically descends to the low cycle
start position).
H
Rotating arm manual, hold down to stop the rotating arm in
phase (if pressed together with “E” the table automatically turns
to the phase position).
O STOP
cycle pause button, the rotating arm decelerates and
stops, the cycle can be resumed from the same point.
P 2-digit display showing the selected programme;
During the cycle it shows an animation of the rotation of the
platform;
NOTE
: the flashing display indicates that a parameter has been
changed).
V 3-digit display indicating the value of the displayed function;
During the cycle or manually moving the film carriage, it indicates
the current height;
The central and left points are decimal points for the values.
When the right point is lit, the V+ and V-
keys are blocked and
the parameter values cannot be changed.

4Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
4
1.1.4 FS335 / FS370 / FS340-350-380-385 OPERATION
»See Picture 1 - pag. 1
»See Picture 2 - pag. 2
Loading of parameters: takes place automatically by selecting the
desired programme.
Saving of parameters: if the LED of the RESET key (E)
is turned off,
press the RESET
key for more than 4 seconds. This LED will start to
flash rapidly to indicate that the parameters have been saved.
The program P=00 is read-only and it is configured with default values.
Up to 99 programmes can be created (
based on the machine
model):
To copy the parameters of an existing program on a virgin
program, select the program source, press and hold RESET
and act
on P+ and P- buttons to select the target program. Release the
RESET
button within 4 seconds the parameters will be copied only, if held
down for more than 4 seconds and then released, will be copied and
saved.
NB: The virgin target programme must always be released (F00
=1) (LED
of the RESET key (E) is turned off).
Automatic opening of the program used previously.
When the machine is turned on again, the parameters from the last
programme selected and started will be loaded.
Keyboard block/ release:
prevents modification of parameters by
blocking the keys V+ e V-; hold down at the same time F+ and F-
and
then press RESET
to enable / disable the block. When the active function
the right LED of the display (V) lights up and stays lit.
The disabled/enabled status remains even after the machine has been
turned off and on again.
FIGURA
1) indicates the decimal point (values from 0.00 to 9.99)
2) indicates the decimal point (values from 0.0 to 9.9)
3) indicates the block status of keyboard
ON: keyboard blocked (V+ and V- blocked)
OFF: keyboard released (V+ e V- sbloccati)
Signals
The LED of the RESET key (E) indicates the writing protection status of
the selected programme. If turned on, it is not possible to rewrite the
modified parameters. It is necessary to select the parameter F00 on
the same programme to carry out modifications and set the value 1
in the parameter, and then hold down RESET for at least 3 seconds. If
the programme is to be saved and at the same time blocked in writing,
after saving it, set 1 in parameter F00 (padlock open) and then 0 again
(padlock closed) and then hold down RESET for at least 3 seconds. The
LED will blink fast only pressing the RESET for more than 3 seconds,
indicating the machine is ready to store the parameters; by depressing
the RESET button, the parameters will be stored. The LED wil blink slow
only to report the alarm status
The LED next to the FOOTBOARD MANUAL button indicates the
automatic command of footboard rotation.
The LED next to the MANUAL CARRIAGE RISE indicates the automatic
command of the carriage rise.
The LED next to the MANUAL CARRIAGE DESCENT indicates the
automatic command of the carriage descent.
Indication of the film consumed
At the end of each cycle (or by selecting the parameter CF on the display
(F)), the machine will indicate the consumption of the film in grams
on the display (V) and showing CF on the display (F). To obtain good
precision, correctly set the thickness of the film in the parameter F24.
NOTE: It is also possible to order models with film consumption
expressed in metres. In this case as well, to obtain good precision,
correctly set the diameter of the measurement roller in the parameter
F24.
Turntable end carriage in-phase stop
Through the combination of multiple buttons you can stop in-phase
the machines.
Pressing the button (H) and, keeping it pressed, press the button (E),
the turntable rotates until it reaches a predetermined position (called
stop in-phase) and then stops.
Pressing the button (G), and keeping it pressed, press the button (E),
the carriage falls to the low position and then stops.
Press the button (B) and, holding it down, press the button (E). The
presser automatically ascends to the start cycle top position.

Fromm 5
GENERAL CONTROLS
5
DISPLAY (V)
1 2 3
Picture 3 - DISPLAY (V)
Loading of parameters: takes place automatically by selecting the
desired programme.
Saving of parameters: if the LED of the RESET key (E) is turned off,
press the RESET key for more than 4 seconds. This LED will start to
flash rapidly to indicate that the parameters have been saved.
The program P=00 is read-only and it is configured with default values.
Up to 99 programmes can be created (based on the machine
model): To copy the parameters of an existing program on a virgin
program, select the program source, press and hold RESET and act
on P+ and P- buttons to select the target program. Release the RESET
button within 4 seconds the parameters will be copied only, if held
down for more than 4 seconds and then released, will be copied and
saved.
NB: The virgin target programme must always be released (F00=1) (LED
of the RESET key (E) is turned off).
Automatic opening of the program used previously.
When the machine is turned on again, the parameters from the last
programme selected and started will be loaded.
Keyboard block/ release: prevents modification of parameters by
blocking the keys V+ e V-; hold down at the same time F+ and F- and
then press RESET to enable / disable the block. When the active function
the right LED of the display (V) lights up and stays lit.
The disabled/enabled status remains even after the machine has been
turned off and on again.
FIGURA
1) indicates the decimal point (values from 0.00 to 9.99)
2) indicates the decimal point (values from 0.0 to 9.9)
3) indicates the block status of keyboard
ON: keyboard blocked (V+ and V- blocked)
OFF: keyboard released (V+ e V- sbloccati)
Signals
The LED of the RESET key (E)
indicates the writing protection status of
the selected programme. If turned on, it is not possible to rewrite the
modified parameters. It is necessary to select the parameter F00
on
the same programme to carry out modifications and set the value 1
in the parameter, and then hold down RESET
for at least 3 seconds. If
the programme is to be saved and at the same time blocked in writing,
after saving it, set 1 in parameter F00
(padlock open) and then 0 again
(padlock closed) and then hold down RESET
for at least 3 seconds. The
LED will blink fast only pressing the RESET
for more than 3 seconds,
indicating the machine is ready to store the parameters; by depressing
the RESET
button, the parameters will be stored. The LED wil blink slow
only to report the alarm status
The LED next to the FOOTBOARD MANUAL button indicates the
automatic command of footboard rotation.
The LED next to the MANUAL CARRIAGE RISE indicates the automatic
command of the carriage rise.
The LED next to the MANUAL CARRIAGE DESCENT indicates the
automatic command of the carriage descent.
Indication of the film consumed
At the end of each cycle (or by selecting the parameter CF on the display
(F)), the machine will indicate the consumption of the film in grams
on the display (V) and showing CF on the display (F). To obtain good
precision, correctly set the thickness of the film in the parameter F24.
NOTE: It is also possible to order models with film consumption
expressed in metres. In this case as well, to obtain good precision,
correctly set the diameter of the measurement roller in the parameter
F24.
Turntable end carriage in-phase stop
Through the combination of multiple buttons you can stop in-phase
the machines.
Pressing the button (H) and, keeping it pressed, press the button (E),
the turntable rotates until it reaches a predetermined position (called
stop in-phase) and then stops.
Pressing the button (G), and keeping it pressed, press the button (E),
the carriage falls to the low position and then stops.
Press the button (B) and, holding it down, press the button (E). The
presser automatically ascends to the start cycle top position.

6Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
6
Loading of parameters: takes place automatically by selecting the
desired programme.
Saving of parameters: if the LED of the RESET key (E) is turned off,
press the RESET key for more than 4 seconds. This LED will start to
flash rapidly to indicate that the parameters have been saved.
The program P=00 is read-only and it is configured with default values.
Up to 99 programmes can be created (based on the machine
model): To copy the parameters of an existing program on a virgin
program, select the program source, press and hold RESET and act
on P+ and P- buttons to select the target program. Release the RESET
button within 4 seconds the parameters will be copied only, if held
down for more than 4 seconds and then released, will be copied and
saved.
NB: The virgin target programme must always be released (F00=1) (LED
of the RESET key (E) is turned off).
Automatic opening of the program used previously.
When the machine is turned on again, the parameters from the last
programme selected and started will be loaded.
Keyboard block/ release: prevents modification of parameters by
blocking the keys V+ e V-; hold down at the same time F+ and F- and
then press RESET to enable / disable the block. When the active function
the right LED of the display (V) lights up and stays lit.
The disabled/enabled status remains even after the machine has been
turned off and on again.
FIGURA
1) indicates the decimal point (values from 0.00 to 9.99)
2) indicates the decimal point (values from 0.0 to 9.9)
3) indicates the block status of keyboard
ON: keyboard blocked (V+ and V- blocked)
OFF: keyboard released (V+ e V- sbloccati)
Signals
The LED of the RESET key (E) indicates the writing protection status of
the selected programme. If turned on, it is not possible to rewrite the
modified parameters. It is necessary to select the parameter F00 on
the same programme to carry out modifications and set the value 1
in the parameter, and then hold down RESET for at least 3 seconds. If
the programme is to be saved and at the same time blocked in writing,
after saving it, set 1 in parameter F00 (padlock open) and then 0 again
(padlock closed) and then hold down RESET for at least 3 seconds. The
LED will blink fast only pressing the RESET for more than 3 seconds,
indicating the machine is ready to store the parameters; by depressing
the RESET button, the parameters will be stored. The LED wil blink slow
only to report the alarm status
The LED next to the FOOTBOARD MANUAL button indicates the
automatic command of footboard rotation.
The LED next to the MANUAL CARRIAGE RISE indicates the automatic
command of the carriage rise.
The LED next to the MANUAL CARRIAGE DESCENT indicates the
automatic command of the carriage descent.
Indication of the film consumed
At the end of each cycle (or by selecting the parameter CF
on the display
(F)
), the machine will indicate the consumption of the film in grams
on the display (V) and showing CF on the display (F)
. To obtain good
precision, correctly set the thickness of the film in the parameter F24.
NOTE
: It is also possible to order models with film consumption
expressed in metres. In this case as well, to obtain good precision,
correctly set the diameter of the measurement roller in the parameter
F24.
Turntable end carriage in-phase stop
Through the combination of multiple buttons you can stop in-phase
the machines.
Pressing the button (H) and, keeping it pressed, press the button (E)
,
the turntable rotates until it reaches a predetermined position (called
stop in-phase) and then stops.
Pressing the button (G), and keeping it pressed, press the button (E)
,
the carriage falls to the low position and then stops.
Press the button (B) and, holding it down, press the button (E)
. The
presser automatically ascends to the start cycle top position.

Fromm 7
FUNCTIONS
7
2 FUNCTIONS
2.1 CONTROL PANEL FUNCTIONS
FS335 / /
FS370
FS340-
350-380-
385
Eva Synthesi Synthex Mytho
X X X X F00 This parameter is used to prevent cycle parameters from being
overwritten: 0block, 1release
X X X X F01 Set cycle: 01 up and down 02 up or down; 03 manual; 04 fast
cycle up and down and 05 layers
X X X X F02 Table rotation speed: selectable from 05 to 100
X X X X F03 Carriage up speed: selectable from 05 to 100
X X X X F04 Carriage down speed: selectable from 05 to 100
X X X X F05 Number of bottom wraps
X X X X F06 Number of top wraps
X X F07 Number of intermediate wraps (F08)
X X F08 Height at which wraps are performed (F07), referred to the
centre of the film (as the roll is 50 cm high, values of less than
25 cm cannot be set)
NOTE: the stretch is set in parameter F32 while the pre-stretch
is set in parameter F33 (only for the PS (MPS2) carriage)
X X X X F09 Strip of film placed over the top of the product
X X F10 Height at which the winding cycle begins, referred to the lower
edge of the roll of film
X X F11 Height at which the winding cycle ends, referred to the lower
edge of the roll of film
X X X X F12 Height at which the carriage stop rising, referred to the upper
edge of the roll of film (product presence photocell disabled)
OPT OPT F13 Tension of film during bottom wrapping: selectable from 0 to
100
OPT OPT OPT F14 Tension of film during the ascent of the carriage: selectable
from 0 to 100
OPT OPT F15 Tension of film during top wrapping: selectable from 0 to 100
OPT OPT OPT F16 Tension of film during the descent of the carriage: selectable
from 0 to 100
OPT F17 PS (MPS2) carriage only: film extension during bottom wraps:
selectable from 120 to 400
OPT F18 PS (MPS2) carriage only: film extension during the ascent of
the carriage: selectable from 120 to 400
OPT F19 PS (MPS2) carriage only: film extension during top wrapping:
selectable from 120 to 400
OPT F20 PS (MPS2) carriage only: film extension during the descent of
the carriage: selectable from 120 to 400
OPT OPT OPT F21 Cycle with presser unit
(Opt.): enabled 1or disabled 0
X X X X F22 Cycle with pause: enabled 1or disabled 0
X X X X F23 Carriage descent position with F22 = 1
OPT OPT OPT OPT F24 Thickness of film being used: 10 ÷ 35 microns
(Opt: for models with film consumption in metres, set the
diameter of the measurement roller from 60 ÷ 120 mm)
OPT OPT OPT F25 End delay of the pressure descent (adjustment of pressure on
product)
OPT OPT OPT F26 Cycle with cutting
OPT 0 = excluded, 1included with one blade stroke, 2included
with two blade strokes
OPT OPT OPT F27 Cutting time after the phase:0 ÷ 100 tenths of a second (Film
cutting tension)
OPT OPT OPT F28 Film exit time after cutting: 0 ÷ 100 tenths of a second
X X X X F29 Film extraction time with light tension at the beginning of the
cycle
X X F30 Upward cycle in steps of the roll holder carriage; 0 = disabled
X X F31 Number of step revs (F30)
OPT OPT F32 Film tension on the product during the step cycle rotations
OPT OPT F33 Only PS (MPS2) carriage: lengthening of the film during the
step cycle rotations
OPT OPT F34 Number of initial creasing rotations at the base of the product
(after F05 rotations with film open); if = 0 do not perform
creasing at the base
OPT OPT F35 0: creasing in ascent disabled
1: creasing complete in ascent
(Opt: advanced creasing) 2: creasing from low rotations up to
the reinforcement (excluded)
(Opt: advanced creasing) 3: creasing from the reinforcement
(included) at high rotations
(Opt: advanced creasing) 4: creasing only during reinforcement
OPT OPT F36 Number of creasing rotations at the top of the product
(Opt: advanced creasing) before performing the creasing
rotations, raise F63 cm; if F36 = 0, do not perform creasing at
high rotations
OPT OPT F37 0: creasing in descent disabled
1: creasing complete in descent
(Opt: advanced creasing) 2: creasing from the reinforcement
(included) at low rotations
(Opt: advanced creasing) 3: creasing from high rotations up to
the reinforcement (excluded)
OPT OPT F38 Number of final rotations at the base of the product; if F38 =
0, do not perform creasing
OPT OPT F39 Crease closing adjustment time (permits wrapping with
partially closed film)
OPT OPT OPT F60 Presser rise time in the cycle with F22 = 1(F22 Cycle with
pause: enabled 1or disabled 0)
OPT OPT OPT F61 Number of wraps at the restart of the layers cycle (optional,
F01 = 5)
X X X X F62 Comfort height included 1, excluded 0
OPT OPT F63 (Opt: advanced creasing) further ascent of the carriage after
the high rotations

8Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
8
FS335 / /
FS370
FS340-
350-380-
385
Eva Synthesi Synthex Mytho
X X X X F00 This parameter is used to prevent cycle parameters from being
overwritten: 0block, 1release
X X X X F01 Set cycle: 01 up and down 02 up or down; 03 manual; 04 fast
cycle up and down and 05 layers
X X X X F02 Table rotation speed: selectable from 05 to 100
X X X X F03 Carriage up speed: selectable from 05 to 100
X X X X F04 Carriage down speed: selectable from 05 to 100
X X X X F05 Number of bottom wraps
X X X X F06 Number of top wraps
X X F07 Number of intermediate wraps (F08)
X X F08 Height at which wraps are performed (F07), referred to the
centre of the film (as the roll is 50 cm high, values of less than
25 cm cannot be set)
NOTE: the stretch is set in parameter F32 while the pre-stretch
is set in parameter F33 (only for the PS (MPS2) carriage)
X X X X F09 Strip of film placed over the top of the product
X X F10 Height at which the winding cycle begins, referred to the lower
edge of the roll of film
X X F11 Height at which the winding cycle ends, referred to the lower
edge of the roll of film
X X X X F12 Height at which the carriage stop rising, referred to the upper
edge of the roll of film (product presence photocell disabled)
OPT OPT F13 Tension of film during bottom wrapping: selectable from 0 to
100
OPT OPT OPT F14 Tension of film during the ascent of the carriage: selectable
from 0 to 100
OPT OPT F15 Tension of film during top wrapping: selectable from 0 to 100
OPT OPT OPT F16 Tension of film during the descent of the carriage: selectable
from 0 to 100
OPT F17 PS (MPS2) carriage only: film extension during bottom wraps:
selectable from 120 to 400
OPT F18 PS (MPS2) carriage only: film extension during the ascent of
the carriage: selectable from 120 to 400
OPT F19 PS (MPS2) carriage only: film extension during top wrapping:
selectable from 120 to 400
OPT F20 PS (MPS2) carriage only: film extension during the descent of
the carriage: selectable from 120 to 400
OPT OPT OPT F21 Cycle with presser unit
(Opt.): enabled 1or disabled 0
X X X X F22 Cycle with pause: enabled 1or disabled 0
X X X X F23 Carriage descent position with F22 = 1
OPT OPT OPT OPT F24 Thickness of film being used: 10 ÷ 35 microns
(Opt: for models with film consumption in metres, set the
diameter of the measurement roller from 60 ÷ 120 mm)
OPT OPT OPT F25 End delay of the pressure descent (adjustment of pressure on
product)
OPT OPT OPT F26 Cycle with cutting
OPT 0 = excluded, 1included with one blade stroke, 2included
with two blade strokes
OPT OPT OPT F27 Cutting time after the phase:0 ÷ 100 tenths of a second (Film
cutting tension)
OPT OPT OPT F28 Film exit time after cutting: 0 ÷ 100 tenths of a second
X X X X F29 Film extraction time with light tension at the beginning of the
cycle
X X F30 Upward cycle in steps of the roll holder carriage; 0 = disabled
X X F31 Number of step revs (F30)
OPT OPT F32 Film tension on the product during the step cycle rotations
OPT OPT F33 Only PS (MPS2) carriage: lengthening of the film during the
step cycle rotations
OPT OPT F34 Number of initial creasing rotations at the base of the product
(after F05 rotations with film open); if = 0 do not perform
creasing at the base
OPT OPT F35 0: creasing in ascent disabled
1: creasing complete in ascent
(Opt: advanced creasing) 2: creasing from low rotations up to
the reinforcement (excluded)
(Opt: advanced creasing) 3: creasing from the reinforcement
(included) at high rotations
(Opt: advanced creasing) 4: creasing only during reinforcement
OPT OPT F36 Number of creasing rotations at the top of the product
(Opt: advanced creasing) before performing the creasing
rotations, raise F63 cm; if F36 = 0, do not perform creasing at
high rotations
OPT OPT F37 0: creasing in descent disabled
1: creasing complete in descent
(Opt: advanced creasing) 2: creasing from the reinforcement
(included) at low rotations
(Opt: advanced creasing) 3: creasing from high rotations up to
the reinforcement (excluded)
OPT OPT F38 Number of final rotations at the base of the product; if F38 =
0, do not perform creasing
OPT OPT F39 Crease closing adjustment time (permits wrapping with
partially closed film)
OPT OPT OPT F60 Presser rise time in the cycle with F22 = 1(F22 Cycle with
pause: enabled 1or disabled 0)
OPT OPT OPT F61 Number of wraps at the restart of the layers cycle (optional,
F01 = 5)
X X X X F62 Comfort height included 1, excluded 0
OPT OPT F63 (Opt: advanced creasing) further ascent of the carriage after
the high rotations

Fromm 9
FUNCTIONS
9
FS335 / /
FS370
FS340-
350-380-
385
Eva Synthesi Synthex Mytho
X X X X F00 This parameter is used to prevent cycle parameters from being
overwritten: 0block, 1release
X X X X F01 Set cycle: 01 up and down 02 up or down; 03 manual; 04 fast
cycle up and down and 05 layers
X X X X F02 Table rotation speed: selectable from 05 to 100
X X X X F03 Carriage up speed: selectable from 05 to 100
X X X X F04 Carriage down speed: selectable from 05 to 100
X X X X F05 Number of bottom wraps
X X X X F06 Number of top wraps
X X F07 Number of intermediate wraps (F08)
X X F08 Height at which wraps are performed (F07), referred to the
centre of the film (as the roll is 50 cm high, values of less than
25 cm cannot be set)
NOTE: the stretch is set in parameter F32 while the pre-stretch
is set in parameter F33 (only for the PS (MPS2) carriage)
X X X X F09 Strip of film placed over the top of the product
X X F10 Height at which the winding cycle begins, referred to the lower
edge of the roll of film
X X F11 Height at which the winding cycle ends, referred to the lower
edge of the roll of film
X X X X F12 Height at which the carriage stop rising, referred to the upper
edge of the roll of film (product presence photocell disabled)
OPT OPT F13 Tension of film during bottom wrapping: selectable from 0 to
100
OPT OPT OPT F14 Tension of film during the ascent of the carriage: selectable
from 0 to 100
OPT OPT F15 Tension of film during top wrapping: selectable from 0 to 100
OPT OPT OPT F16 Tension of film during the descent of the carriage: selectable
from 0 to 100
OPT F17 PS (MPS2) carriage only: film extension during bottom wraps:
selectable from 120 to 400
OPT F18 PS (MPS2) carriage only: film extension during the ascent of
the carriage: selectable from 120 to 400
OPT F19 PS (MPS2) carriage only: film extension during top wrapping:
selectable from 120 to 400
OPT F20 PS (MPS2) carriage only: film extension during the descent of
the carriage: selectable from 120 to 400
OPT OPT OPT F21 Cycle with presser unit
(Opt.): enabled 1or disabled 0
X X X X F22 Cycle with pause: enabled 1or disabled 0
X X X X F23 Carriage descent position with F22 = 1
OPT OPT OPT OPT F24 Thickness of film being used: 10 ÷ 35 microns
(Opt: for models with film consumption in metres, set the
diameter of the measurement roller from 60 ÷ 120 mm)
OPT OPT OPT F25 End delay of the pressure descent (adjustment of pressure on
product)
OPT OPT OPT F26 Cycle with cutting
OPT 0 = excluded, 1included with one blade stroke, 2included
with two blade strokes
OPT OPT OPT F27 Cutting time after the phase:0 ÷ 100 tenths of a second (Film
cutting tension)
OPT OPT OPT F28 Film exit time after cutting: 0 ÷ 100 tenths of a second
X X X X F29 Film extraction time with light tension at the beginning of the
cycle
X X F30 Upward cycle in steps of the roll holder carriage; 0 = disabled
X X F31 Number of step revs (F30)
OPT OPT F32 Film tension on the product during the step cycle rotations
OPT OPT F33 Only PS (MPS2) carriage: lengthening of the film during the
step cycle rotations
OPT OPT F34 Number of initial creasing rotations at the base of the product
(after F05 rotations with film open); if = 0 do not perform
creasing at the base
OPT OPT F35 0: creasing in ascent disabled
1: creasing complete in ascent
(Opt: advanced creasing) 2: creasing from low rotations up to
the reinforcement (excluded)
(Opt: advanced creasing) 3: creasing from the reinforcement
(included) at high rotations
(Opt: advanced creasing) 4: creasing only during reinforcement
OPT OPT F36 Number of creasing rotations at the top of the product
(Opt: advanced creasing) before performing the creasing
rotations, raise F63 cm; if F36 = 0, do not perform creasing at
high rotations
OPT OPT F37 0: creasing in descent disabled
1: creasing complete in descent
(Opt: advanced creasing) 2: creasing from the reinforcement
(included) at low rotations
(Opt: advanced creasing) 3: creasing from high rotations up to
the reinforcement (excluded)
OPT OPT F38 Number of final rotations at the base of the product; if F38 =
0, do not perform creasing
OPT OPT F39 Crease closing adjustment time (permits wrapping with
partially closed film)
OPT OPT OPT F60 Presser rise time in the cycle with F22 = 1(F22 Cycle with
pause: enabled 1or disabled 0)
OPT OPT OPT F61 Number of wraps at the restart of the layers cycle (optional,
F01 = 5)
X X X X F62 Comfort height included 1, excluded 0
OPT OPT F63 (Opt: advanced creasing) further ascent of the carriage after
the high rotations

10 Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
10
FS335 / /
FS370
FS340-
350-380-
385
Eva Synthesi Synthex Mytho
X X X X F00 This parameter is used to prevent cycle parameters from being
overwritten: 0block, 1release
X X X X F01 Set cycle: 01 up and down 02 up or down; 03 manual; 04 fast
cycle up and down and 05 layers
X X X X F02 Table rotation speed: selectable from 05 to 100
X X X X F03 Carriage up speed: selectable from 05 to 100
X X X X F04 Carriage down speed: selectable from 05 to 100
X X X X F05 Number of bottom wraps
X X X X F06 Number of top wraps
X X F07 Number of intermediate wraps (F08)
X X F08 Height at which wraps are performed (F07), referred to the
centre of the film (as the roll is 50 cm high, values of less than
25 cm cannot be set)
NOTE: the stretch is set in parameter F32 while the pre-stretch
is set in parameter F33 (only for the PS (MPS2) carriage)
X X X X F09 Strip of film placed over the top of the product
X X F10 Height at which the winding cycle begins, referred to the lower
edge of the roll of film
X X F11 Height at which the winding cycle ends, referred to the lower
edge of the roll of film
X X X X F12 Height at which the carriage stop rising, referred to the upper
edge of the roll of film (product presence photocell disabled)
OPT OPT F13 Tension of film during bottom wrapping: selectable from 0 to
100
OPT OPT OPT F14 Tension of film during the ascent of the carriage: selectable
from 0 to 100
OPT OPT F15 Tension of film during top wrapping: selectable from 0 to 100
OPT OPT OPT F16 Tension of film during the descent of the carriage: selectable
from 0 to 100
OPT F17 PS (MPS2) carriage only: film extension during bottom wraps:
selectable from 120 to 400
OPT F18 PS (MPS2) carriage only: film extension during the ascent of
the carriage: selectable from 120 to 400
OPT F19 PS (MPS2) carriage only: film extension during top wrapping:
selectable from 120 to 400
OPT F20 PS (MPS2) carriage only: film extension during the descent of
the carriage: selectable from 120 to 400
OPT OPT OPT F21 Cycle with presser unit
(Opt.): enabled 1or disabled 0
X X X X F22 Cycle with pause: enabled 1or disabled 0
X X X X F23 Carriage descent position with F22 = 1
OPT OPT OPT OPT F24 Thickness of film being used: 10 ÷ 35 microns
(Opt: for models with film consumption in metres, set the
diameter of the measurement roller from 60 ÷ 120 mm)
OPT OPT OPT F25 End delay of the pressure descent (adjustment of pressure on
product)
OPT OPT OPT F26 Cycle with cutting
OPT 0 = excluded, 1included with one blade stroke, 2included
with two blade strokes
OPT OPT OPT F27 Cutting time after the phase:0 ÷ 100 tenths of a second (Film
cutting tension)
OPT OPT OPT F28 Film exit time after cutting: 0 ÷ 100 tenths of a second
X X X X F29 Film extraction time with light tension at the beginning of the
cycle
X X F30 Upward cycle in steps of the roll holder carriage; 0 = disabled
X X F31 Number of step revs (F30)
OPT OPT F32 Film tension on the product during the step cycle rotations
OPT OPT F33 Only PS (MPS2) carriage: lengthening of the film during the
step cycle rotations
OPT OPT F34 Number of initial creasing rotations at the base of the product
(after F05 rotations with film open); if = 0 do not perform
creasing at the base
OPT OPT F35 0: creasing in ascent disabled
1: creasing complete in ascent
(Opt: advanced creasing) 2: creasing from low rotations up to
the reinforcement (excluded)
(Opt: advanced creasing) 3: creasing from the reinforcement
(included) at high rotations
(Opt: advanced creasing) 4: creasing only during reinforcement
OPT OPT F36 Number of creasing rotations at the top of the product
(Opt: advanced creasing) before performing the creasing
rotations, raise F63 cm; if F36 = 0, do not perform creasing at
high rotations
OPT OPT F37 0: creasing in descent disabled
1: creasing complete in descent
(Opt: advanced creasing) 2: creasing from the reinforcement
(included) at low rotations
(Opt: advanced creasing) 3: creasing from high rotations up to
the reinforcement (excluded)
OPT OPT F38 Number of final rotations at the base of the product; if F38 =
0, do not perform creasing
OPT OPT F39 Crease closing adjustment time (permits wrapping with
partially closed film)
OPT OPT OPT F60 Presser rise time in the cycle with F22 = 1(F22 Cycle with
pause: enabled 1or disabled 0)
OPT OPT OPT F61 Number of wraps at the restart of the layers cycle (optional,
F01 = 5)
X X X X F62 Comfort height included 1, excluded 0
OPT OPT F63 (Opt: advanced creasing) further ascent of the carriage after
the high rotations

Fromm 11
FUNCTIONS
11
2.2 ADDITIONAL MANUAL CONTROLS
The (F) display is used for showing the manual controls. To execute
the manual command, use the buttons F+ and F-
to select the desired
command and press the button indicated in the list below:
COMBINATIONS
COMMANDS/BUTTONS ACTION
C0 Button (B) Clockwise arm rotation
C0 Button (G) Counterclockwise rotation arm (only on Station)
C1 Button (B) Carriage up
C1 Button (G) Carriage down
C2 Button (B) Presser up
C2 Button (G) Presser down
C3 Button (B) Rotating roller conveyor, loads pallets up to the wrapping position
C3 Button (G) Rotating roller conveyor, unloads pallets
C4 Button (B) Clamp closing
C4 Button (G) Clamp opening
C5 Button (B) Lift connector
C5 Button (G) Film cutting/sealing test sequence (the alarms are disabled; allows
checking the position of the sensors and the valve adjustments)
C6 Button (B) Lift creasing carriage
C6 Button (G) Lower creasing carriage
C7 Button (B) Roller conveyors forward, aligns the pallets with the first available
photocells
C7 Button (G) Roller conveyors forward, unloads the pallets from the line (when
applicable)
C8 Button (B) Cutting actuation

12 Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
12
2.3 AUTOMATIC CYCLES
O
G
B
H
»See Picture 4 - pag. 12
F01 = 01 - COMPLETE UP/DOWN CYCLE
Automatic cycle which wraps the pallet starting from the bottom,
reaching the top and returning to the bottom.
During winding, buttons (B) (carriage going up) or (G)
(carriage going
down) can be pressed to stop the carriage, add extra wraps wherever
required, and start it again.
FIGURA
F01 = 02 - UP ONLY OR DOWN ONLY CYCLE
DANGER
The cycle “up only or down only” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic cycle which wrapp the pallet starting from the bottom to
reach the top or starting from the top to reach the bottom.
During winding, buttons (B) (carriage going up) or (G) (carriage going
down) can be pressed to stop the carriage, add extra wrapp wherever
required, and start it again.
F10 - CYCLE START AT PRESET HEIGHT
Automatic cycle that wraps the pallet starting from a preset height
which is set with the F10 function.
F11 - CYCLE STOP AT PRESET HEIGHT
Automatic cycle that wraps the pallet stopping at a preset height which
is set with the F11 function.
F21 = 01 - CYCLE WITH PRESSER (OPTIONAL)
Automatic cycle that can be used when the machine is equipped with
the optional presser.
F21 = 1 ENABLED F21 = 0 DISABLED
Once the start cycle button has been pressed (A), an acoustic warning
signals five seconds in advance that the presser plate is going to
descend.
-After the audible warning time has elapsed, the presser descends until it
is in contact with the top of the product. The function F25 delays the stop
of the descent to adjust the pressure on the product.
-The table begins to turn and the wrapping phase of the product on
the pallet starts.
-At the end of the cycle the turntable stops and the presser plate
returns upwards, leaving the product free for unloading.
To manually control the ascent and descent of the pressure unit the
Functions display needs be set to F21 (which needs to be set to 1as
Value) and press button (B) for ascent or button (G) for descent.
F22 = 01 - COMPLETE UP/DOWN CYCLE WITH PAUSE
DANGER
The cycle “up/down with pause” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic Up and Down cycle or Up only with a pause when the top of
the product being wrapped is reached; before the pause the carriage
can descend by a distance set with F23. The machine stop and wait to
restart emitting a slow intermittent signal. If the machine has a presser,
it ascends for the amount of time set in F60.
To complete the paused wrapping cycle press the start cycle button
(A).
If the cycle set is for ascent and descent, the carriage ascends, performs
the top rotations, descends toward the base, and then the cycle stops.
If the cycle set is for ascent only, the carriage ascends, performs the
top rotations, and then the cycle stops.
Picture 4

Fromm 13
FUNCTIONS
13
F01 = 01 - COMPLETE UP/DOWN CYCLE
Automatic cycle which wraps the pallet starting from the bottom,
reaching the top and returning to the bottom.
During winding, buttons (B) (carriage going up) or (G) (carriage going
down) can be pressed to stop the carriage, add extra wraps wherever
required, and start it again.
FIGURA
F01 = 02 - UP ONLY OR DOWN ONLY CYCLE
DANGER
The cycle “up only or down only” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic cycle which wrapp the pallet starting from the bottom to
reach the top or starting from the top to reach the bottom.
During winding, buttons (B) (carriage going up) or (G)
(carriage going
down) can be pressed to stop the carriage, add extra wrapp wherever
required, and start it again.
F10 - CYCLE START AT PRESET HEIGHT
Automatic cycle that wraps the pallet starting from a preset height
which is set with the F10 function.
F11 - CYCLE STOP AT PRESET HEIGHT
Automatic cycle that wraps the pallet stopping at a preset height which
is set with the F11 function.
F21 = 01 - CYCLE WITH PRESSER (OPTIONAL)
Automatic cycle that can be used when the machine is equipped with
the optional presser.
F21 = 1 ENABLED F21 = 0 DISABLED
Once the start cycle button has been pressed (A)
, an acoustic warning
signals five seconds in advance that the presser plate is going to
descend.
-
After the audible warning time has elapsed, the presser descends until it
is in contact with the top of the product. The function F25
delays the stop
of the descent to adjust the pressure on the product.
-
The table begins to turn and the wrapping phase of the product on
the pallet starts.
-
At the end of the cycle the turntable stops and the presser plate
returns upwards, leaving the product free for unloading.
To manually control the ascent and descent of the pressure unit the
Functions display needs be set to F21 (which needs to be set to 1
as
Value) and press button (B) for ascent or button (G) for descent.
F22 = 01 - COMPLETE UP/DOWN CYCLE WITH PAUSE
DANGER
The cycle “up/down with pause” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic Up and Down cycle or Up only with a pause when the top of
the product being wrapped is reached; before the pause the carriage
can descend by a distance set with F23. The machine stop and wait to
restart emitting a slow intermittent signal. If the machine has a presser,
it ascends for the amount of time set in F60.
To complete the paused wrapping cycle press the start cycle button
(A).
If the cycle set is for ascent and descent, the carriage ascends, performs
the top rotations, descends toward the base, and then the cycle stops.
If the cycle set is for ascent only, the carriage ascends, performs the
top rotations, and then the cycle stops.
»See Picture 4 - pag. 12

14 Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
14
2.4 SEMIAUTOMATIC OPERATING CYCLE
F01 = 01 - COMPLETE UP/DOWN CYCLE
Automatic cycle which wraps the pallet starting from the bottom,
reaching the top and returning to the bottom.
During winding, buttons (B) (carriage going up) or (G) (carriage going
down) can be pressed to stop the carriage, add extra wraps wherever
required, and start it again.
FIGURA
F01 = 02 - UP ONLY OR DOWN ONLY CYCLE
DANGER
The cycle “up only or down only” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic cycle which wrapp the pallet starting from the bottom to
reach the top or starting from the top to reach the bottom.
During winding, buttons (B) (carriage going up) or (G) (carriage going
down) can be pressed to stop the carriage, add extra wrapp wherever
required, and start it again.
F10 - CYCLE START AT PRESET HEIGHT
Automatic cycle that wraps the pallet starting from a preset height
which is set with the F10 function.
F11 - CYCLE STOP AT PRESET HEIGHT
Automatic cycle that wraps the pallet stopping at a preset height which
is set with the F11 function.
F21 = 01 - CYCLE WITH PRESSER (OPTIONAL)
Automatic cycle that can be used when the machine is equipped with
the optional presser.
F21 = 1 ENABLED F21 = 0 DISABLED
Once the start cycle button has been pressed (A), an acoustic warning
signals five seconds in advance that the presser plate is going to
descend.
-After the audible warning time has elapsed, the presser descends until it
is in contact with the top of the product. The function F25 delays the stop
of the descent to adjust the pressure on the product.
-The table begins to turn and the wrapping phase of the product on
the pallet starts.
-At the end of the cycle the turntable stops and the presser plate
returns upwards, leaving the product free for unloading.
To manually control the ascent and descent of the pressure unit the
Functions display needs be set to F21 (which needs to be set to 1as
Value) and press button (B) for ascent or button (G) for descent.
F22 = 01 - COMPLETE UP/DOWN CYCLE WITH PAUSE
DANGER
The cycle “up/down with pause” is required for maximum height
of the product to be wrapped at 1500 mm. Beyond this height,
you must use appropriate personal protective equipment based
on the risk of falling and work height exceeding 1500 mm.
Automatic Up and Down cycle or Up only with a pause when the top of
the product being wrapped is reached; before the pause the carriage
can descend by a distance set with F23
. The machine stop and wait to
restart emitting a slow intermittent signal.
If the machine has a presser,
it ascends for the amount of time set in F60.
To complete the paused wrapping cycle press the start cycle button
(A).
If the cycle set is for ascent and descent, the carriage ascends, performs
the top rotations, descends toward the base, and then the cycle stops.
If the cycle set is for ascent only, the carriage ascends, performs the
top rotations, and then the cycle stops.
»See Picture 4 - pag. 12
»See Picture 4 - pag. 12
F01 = 03 - SEMIAUTOMATIC OPERATING CYCLE
After setting the semiautomatic cycle press START (A).
The table starts rotating again and the pallet wrapping phase begins.
Press buttons (B) and (G)
to wrap the pallet. To stop the machine, press
the button (H).
F30 SEMIAUTOMATIC OPERATING CYCLE
Automatic cycle that allows the pallet to be wrapped in steps.
The carriage ascends to the height set in F30
, performs a number of
rotations set in F31
, and repeats until the top of the product is reached.
During the reinforcement rotations, the tension and lengthening of the
film can be adjusted using the parameters set in F32 and F33.

Fromm 15
FUNCTIONS
15
2.5 ALARM LIST
Code Description Causes Solutions
E01 Transpallet photocell
interrupted
-The safety photocell is activated.
-The photocell has no obstacles but
the signal does not get to the card.
- Remove the obstacle / check the mirror on the
safety photocell.
- Make sure the photocell is operating and the LED
changes status when an obstacle is inserted. If it
is not working, replace it. Check the continuity of
the cable with the signals on the panel 1+ and
8.3. Replace if broken.
E02 Rotation or running
anomaly, motor blocked
-The sensor does not read the
petals because it is too far from the
phonic wheel.
-The sensor does not read the
petals because the phonic wheel is
broken or crooked.
-The sensor does not send the
signal to the card.
- The motor seems to rotate at less
than 500 rpm for more than 2.5 s.
- The machine does not move, even
with manual controls.
- Adjust the position of the sensor compared to
the petals of the phonic wheel (distance < 2 mm).
- Fix / replace the phonic wheel.
-
Check the correct operation of the sensor,
bringing it close to a metallic object. If the LED
lights up, replace the cable, if the sensor does
not work, it needs to be replaced.
- If the robot is rotating on unsuitable fl ooring
(carpet), choose a smooth and fl at fl oor that is
not slippery. If the alarm occurs during slowing,
the sensor is not reading all the petals of the
phonic wheel.
-
The drive or inverter does not receive
consent to start, check the wiring.
The drive or inverter is faulty,
communicate the code shown on the
latter. For a DC motor, check the brushes.
The motor cable is not connected well, check
the wiring and tightness, even on the brake, if
present. The electromechanical brake on the
motor, if present, may not release. If this occurs,
it must be adjusted or replaced. The motor unit
may be damaged or defective; replace it.
E03 Restart after power
outage.
-The card restarted.
- The machine shut down and shows
this warning.
- Press the RESET key.
- There was a power outage and the machine
shut down and then restarted: Press the RESET
button (no power) or bell (touch).
E04 Carriage, crush
prevention limit switch
triggered
-Obstacle below the carriage.
- The E04 alarm persists without any
obstacle.
- Remove the obstacle and press RESET.
- Check the proper mechanical operation of the
micro and the crush-prevention plate. If a sensor
is broken or the plate is deformed, they must
be replaced. Check the electrical contacts and
that the signal reaches the card. If the sensor is
broken or the cable is interrupted, replace it.
E08 Carriage ascend/descend
anomaly
-The sensor does not read the
petals because it is too far from the
phonic wheel.
- The carriage only moves in one
direction.
-The sensor does not send the
signal to the card.
-The roll holder carriage does not
move, even with manual controls.
- Adjust the position of the sensor compared to
the petals of the phonic wheel (distance < 2
mm). If the phonic wheel is broken or damaged,
it must be replaced.
-Check if the control signal reaches the drive,
then verify if the status LED is lit. Check if the
carriage limit switch is pressed or blocked.
-Check the correct operation of the sensor,
bringing it close to a metallic object. If the LED
lights up, replace the cable, if the sensor does
not work, it needs to be replaced.
-The drive or inverter does not receive consent
to start, check the wiring. The drive or inverter
is faulty, communicate the code shown on
the latter. For a DC motor, check the brushes.
The motor cable is not connected well, check
the wiring and tightness, even on the brake, if
present. The motor unit may be damaged or
defective; replace it. Check the battery.
E09 Stop after fi lm breakage
or fi lm end.
- The fi lm roll is fi nished.
- The fi lm fl ap came off or the fi lm is
broken.
- The fi lm does not come out.
- The fi lm is not properly connected
to the product.
-Change the roll.
- Hook the fi lm back on the pallet.
-Check the proper operation of the dancer sensor
removing the fi lm and operating it manually. If it
does not work, make sure the sensor is operating
properly. The fi lm pull value is high, lower it.
- If the fi lm does not glide within the carriage for
fi rst (x) seconds, the alarm is triggered. Attache
the fi lm tighter.
E10 Carriage limit switch
error
-Wiring or power outage error - Check the limit switch wiring and power Check
the carriage motor brushes.
E11 Low limit switch error:
it did not close during
carriage ascent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
-Unblock the sensor or replace it if faulty. Check
the carriage motor brushes.
E12 High limit switch error:
it did not close during
carriage descent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
-Unblock the sensor or replace it if faulty.
E13 Low limit switch error: it
opened during carriage
ascent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
E14 High limit switch error: it
opened during carriage
descent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
E16 Emergency intervention - Emergency button pressed.
-Carriage door open.
-Unblock the button and restore the power
circuit.
-Close the door and restore the power circuit.
If FE or FM carriage, check the bridge on the
connector. Check the emergency microswitch.
E20 Non-volatile memory
error functions (I2C) #0
- No response from memory. - Replace the memory I
2
C (24LC256).
E21 Non-volatile memory
error functions (I2C) #1
- Memory timeout. - Replace the memory (24LC256).
E22 Non-volatile memory
error functions (I2C) #2
- Communication error. - Replace the memory (24LC256).
E23 Non-volatile memory
error functions (I2C) #3
- Communication error. - Replace the memory (24LC256).
E24 Non-volatile memory
error functions (I2C) #4
- Memory occupied. - Replace the memory (24LC256).
E25 Non-volatile memory
error functions (I2C) #5
-Write error. - Replace the memory (24LC256).
E26 Non-volatile memory
error hidden parameters
(EE) #1
-Periphery occupied. - Replace the microcontroller (PIC).
E27 Non-volatile memory
error hidden parameters
(EE) #2
-Interruption during writing. - Replace the microcontroller (PIC).
E28 Non-volatile memory
error hidden parameters
(EE) #3
-Failed check given after writing. - Replace the microcontroller (PIC).
E29 Non-volatile memory
error hidden parameters
(EE) #4
- Timeout writing data. - Replace the microcontroller (PIC).
E50 Error in creasing position
sensors
-Both sensors are engaged. -Check the proper electrical wiring or proper
installation and mechanical operation.
E51 Creasing locked during
closure
-Creasing blocked on the top sensor. - Check motor operation.
-Check electrical connection
- Make sure there are no mechanical obstacles.
-Check sensor operation
E52 Creasing block during
opening
- Creasing blocked on the bottom
sensor.
- Check motor operation.
-Check electrical connection
- Make sure there are no mechanical obstacles.
-Check sensor operation
E53 Top limit switch error: did
not engage during ascent
command (creasing)
-The carriage blocked during ascent. - Check motor operation.
-Check operation of the top sensor and replace
if broken.
- Make sure there are no mechanical obstacles.
E54 Bottom limit switch error:
did not engage during
descent command
(creasing)
-The carriage blocked during
descent.
- Check motor operation.
- Check operation of the bottom sensor and
replace if broken.
- Make sure there are no mechanical obstacles.
E62 Presser carriage
descending but the
presser plate is out of
position, cannot detect
pallet (tables)
-Presser plate blocked. -Manually rotate the presser plate.
The presser plate cam must pass <2 mm from
the sensor. Check the correct operation of the
sensor, bringing a metallic object near it. If the
LED lights up, check the cable, if the sensor does
not signal anything, replace it.
E64 Presser carriage
encountered the fi lm
carriage fi rst, but not the
pallet (Tables)
-The pallet is too low. - To wrap, exclude the presser.
E90 The entry photocell
engaged during transport
of a pallet on the rotating
roller unit (tables)
-Pallet out of position. -Reposition the pallet and check the photocell
operation.
E91 Attempt to start the
platform while a
photocell on the entry
and exit of the rotating
roller unit is engaged
(Tables)
-Pallet in transit. - Remove the pallet.
E92 Alarm, rotating roller unit
already engaged during
loading of a new pallet:
the photocells on the
roller unit must both
be free before loading
(Tables)
-Pallet unloading while a new one is
loading.
-First unload the pallet in transit, then load the
new one.
E93 Alarm detected non
standard pallet on the
rotating roller unit: the
photocells on the roller
are both engaged during
loading. (Tables)
-The pallet is too long. - Remove the pallet.
E94 Alarm, platform out
of phase during pallet
transport into and out of
the roller unit (Tables)
-The table was not set in phase. - Exit automatic mode and turn the table in phase.
E95 Alarm, exit occupied
while unloading the pallet
from the rotating roller
unit. The two photocells
on the unloading line are
both engaged. (Tables)
-The photocells are engaged. -Check the status of the photocells.
E96 Alarm, maximum timeout
during pallet loading
(Tables)
- Timeout loading pallet. -Check loading of the pallet.
E97 Alarm, maximum timeout
during pallet unloading
(Tables)
- Timeout unloading pallet. -Check loading of the pallet.
E99 Alarm maximum timeout
during transport of a
pallet on the entry roller
units (Tables)
- Timeout transporting pallet. -Check the pallet transport on the roller units.

16 Rev.2 01/03/2021
Operator Panel | TURNTABLE - MAST
16
Code Description Causes Solutions
E01 Transpallet photocell
interrupted
-The safety photocell is activated.
-The photocell has no obstacles but
the signal does not get to the card.
- Remove the obstacle / check the mirror on the
safety photocell.
- Make sure the photocell is operating and the LED
changes status when an obstacle is inserted. If it
is not working, replace it. Check the continuity of
the cable with the signals on the panel 1+ and
8.3. Replace if broken.
E02 Rotation or running
anomaly, motor blocked
-The sensor does not read the
petals because it is too far from the
phonic wheel.
-The sensor does not read the
petals because the phonic wheel is
broken or crooked.
-The sensor does not send the
signal to the card.
- The motor seems to rotate at less
than 500 rpm for more than 2.5 s.
- The machine does not move, even
with manual controls.
- Adjust the position of the sensor compared to
the petals of the phonic wheel (distance < 2 mm).
- Fix / replace the phonic wheel.
-Check the correct operation of the sensor,
bringing it close to a metallic object. If the LED
lights up, replace the cable, if the sensor does
not work, it needs to be replaced.
- If the robot is rotating on unsuitable fl ooring
(carpet), choose a smooth and fl at fl oor that is
not slippery. If the alarm occurs during slowing,
the sensor is not reading all the petals of the
phonic wheel.
-The drive or inverter does not receive
consent to start, check the wiring.
The drive or inverter is faulty,
communicate the code shown on the
latter. For a DC motor, check the brushes.
The motor cable is not connected well, check
the wiring and tightness, even on the brake, if
present. The electromechanical brake on the
motor, if present, may not release. If this occurs,
it must be adjusted or replaced. The motor unit
may be damaged or defective; replace it.
E03 Restart after power
outage.
-The card restarted.
- The machine shut down and shows
this warning.
- Press the RESET key.
- There was a power outage and the machine
shut down and then restarted: Press the RESET
button (no power) or bell (touch).
E04 Carriage, crush
prevention limit switch
triggered
-Obstacle below the carriage.
- The E04 alarm persists without any
obstacle.
- Remove the obstacle and press RESET.
- Check the proper mechanical operation of the
micro and the crush-prevention plate. If a sensor
is broken or the plate is deformed, they must
be replaced. Check the electrical contacts and
that the signal reaches the card. If the sensor is
broken or the cable is interrupted, replace it.
E08 Carriage ascend/descend
anomaly
-The sensor does not read the
petals because it is too far from the
phonic wheel.
- The carriage only moves in one
direction.
-The sensor does not send the
signal to the card.
-The roll holder carriage does not
move, even with manual controls.
- Adjust the position of the sensor compared to
the petals of the phonic wheel (distance < 2
mm). If the phonic wheel is broken or damaged,
it must be replaced.
-Check if the control signal reaches the drive,
then verify if the status LED is lit. Check if the
carriage limit switch is pressed or blocked.
-
Check the correct operation of the sensor,
bringing it close to a metallic object. If the LED
lights up, replace the cable, if the sensor does
not work, it needs to be replaced.
-The drive or inverter does not receive consent
to start, check the wiring. The drive or inverter
is faulty, communicate the code shown on
the latter. For a DC motor, check the brushes.
The motor cable is not connected well, check
the wiring and tightness, even on the brake, if
present. The motor unit may be damaged or
defective; replace it. Check the battery.
E09 Stop after fi lm breakage
or fi lm end.
- The fi lm roll is fi nished.
- The fi lm fl ap came off or the fi lm is
broken.
- The fi lm does not come out.
- The fi lm is not properly connected
to the product.
-Change the roll.
- Hook the fi lm back on the pallet.
-Check the proper operation of the dancer sensor
removing the fi lm and operating it manually. If it
does not work, make sure the sensor is operating
properly. The fi lm pull value is high, lower it.
- If the fi lm does not glide within the carriage for
fi rst (x) seconds, the alarm is triggered. Attache
the fi lm tighter.
E10 Carriage limit switch
error
-Wiring or power outage error - Check the limit switch wiring and power Check
the carriage motor brushes.
E11 Low limit switch error:
it did not close during
carriage ascent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
-Unblock the sensor or replace it if faulty. Check
the carriage motor brushes.
E12 High limit switch error:
it did not close during
carriage descent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
-Unblock the sensor or replace it if faulty.
E13 Low limit switch error: it
opened during carriage
ascent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
E14 High limit switch error: it
opened during carriage
descent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
E16 Emergency intervention - Emergency button pressed.
-Carriage door open.
-Unblock the button and restore the power
circuit.
-Close the door and restore the power circuit.
If FE or FM carriage, check the bridge on the
connector. Check the emergency microswitch.
E20 Non-volatile memory
error functions (I2C) #0
- No response from memory. - Replace the memory I
2
C (24LC256).
E21 Non-volatile memory
error functions (I2C) #1
- Memory timeout. - Replace the memory (24LC256).
E22 Non-volatile memory
error functions (I2C) #2
- Communication error. - Replace the memory (24LC256).
E23 Non-volatile memory
error functions (I2C) #3
- Communication error. - Replace the memory (24LC256).
E24 Non-volatile memory
error functions (I2C) #4
- Memory occupied. - Replace the memory (24LC256).
E25 Non-volatile memory
error functions (I2C) #5
-Write error. - Replace the memory (24LC256).
E26 Non-volatile memory
error hidden parameters
(EE) #1
-Periphery occupied. - Replace the microcontroller (PIC).
E27 Non-volatile memory
error hidden parameters
(EE) #2
-Interruption during writing. - Replace the microcontroller (PIC).
E28 Non-volatile memory
error hidden parameters
(EE) #3
-Failed check given after writing. - Replace the microcontroller (PIC).
E29 Non-volatile memory
error hidden parameters
(EE) #4
- Timeout writing data. - Replace the microcontroller (PIC).
E50 Error in creasing position
sensors
-Both sensors are engaged. -Check the proper electrical wiring or proper
installation and mechanical operation.
E51 Creasing locked during
closure
-Creasing blocked on the top sensor. - Check motor operation.
-Check electrical connection
- Make sure there are no mechanical obstacles.
-Check sensor operation
E52 Creasing block during
opening
- Creasing blocked on the bottom
sensor.
- Check motor operation.
-Check electrical connection
- Make sure there are no mechanical obstacles.
-Check sensor operation
E53 Top limit switch error: did
not engage during ascent
command (creasing)
-The carriage blocked during ascent. - Check motor operation.
-Check operation of the top sensor and replace
if broken.
- Make sure there are no mechanical obstacles.
E54 Bottom limit switch error:
did not engage during
descent command
(creasing)
-The carriage blocked during
descent.
- Check motor operation.
- Check operation of the bottom sensor and
replace if broken.
- Make sure there are no mechanical obstacles.
E62 Presser carriage
descending but the
presser plate is out of
position, cannot detect
pallet (tables)
-Presser plate blocked. -Manually rotate the presser plate.
The presser plate cam must pass <2 mm from
the sensor. Check the correct operation of the
sensor, bringing a metallic object near it. If the
LED lights up, check the cable, if the sensor does
not signal anything, replace it.
E64 Presser carriage
encountered the fi lm
carriage fi rst, but not the
pallet (Tables)
-The pallet is too low. - To wrap, exclude the presser.
E90 The entry photocell
engaged during transport
of a pallet on the rotating
roller unit (tables)
-Pallet out of position. -Reposition the pallet and check the photocell
operation.
E91 Attempt to start the
platform while a
photocell on the entry
and exit of the rotating
roller unit is engaged
(Tables)
-Pallet in transit. - Remove the pallet.
E92 Alarm, rotating roller unit
already engaged during
loading of a new pallet:
the photocells on the
roller unit must both
be free before loading
(Tables)
-Pallet unloading while a new one is
loading.
-First unload the pallet in transit, then load the
new one.
E93 Alarm detected non
standard pallet on the
rotating roller unit: the
photocells on the roller
are both engaged during
loading. (Tables)
-The pallet is too long. - Remove the pallet.
E94 Alarm, platform out
of phase during pallet
transport into and out of
the roller unit (Tables)
-The table was not set in phase. - Exit automatic mode and turn the table in phase.
E95 Alarm, exit occupied
while unloading the pallet
from the rotating roller
unit. The two photocells
on the unloading line are
both engaged. (Tables)
-The photocells are engaged. -Check the status of the photocells.
E96 Alarm, maximum timeout
during pallet loading
(Tables)
- Timeout loading pallet. -Check loading of the pallet.
E97 Alarm, maximum timeout
during pallet unloading
(Tables)
- Timeout unloading pallet. -Check loading of the pallet.
E99 Alarm maximum timeout
during transport of a
pallet on the entry roller
units (Tables)
- Timeout transporting pallet. -Check the pallet transport on the roller units.
