20128A - CASSARA OTTOMAN
F R O N T G A T E *
O U T F I T T I N G A M E R I C A ' S F I N E S T H O M E S
Page 1 of 2

PART LIST :
HARDWARE :
Part #
QTY
Part #
QTY
A.
TOP
1 PC
H1
ALLEN HEAD BOLT M6X40mm
6 PCS
Description Description
20128A - CASSARA OTTOMAN
F R O N T G A T E *
O U T F I T T I N G A M E R I C A ' S F I N E S T H O M E S
A.
TOP
1 PC
H1
ALLEN HEAD BOLT M6X40mm
6 PCS
B END FRAME - LEFT and RIGHT 2 PCS
TOOLS NEEDED (INCLUDED) :
T.1 ALLEN KEY (Included)
NUMBER OF PEOPLE TO INSTALL :
ASSEMBLY TIME :
RECOMMENDED 1 to 2 Persons 10 to 20 MINUTES
PRE ASSEMBLY INSTRUCTIONS:
1 Do not throw away packaging materials until the assembly is complete. Part might be
accidentally thrown away.
ASSEMBLY INSTRUCTION :
STEP 1 :
1. a
Lay End Frame (B) on the floor with holes facing up. Use the packaging material to protect
1. a
Lay End Frame (B) on the floor with holes facing up. Use the packaging material to protect
End frame against the floor to avoid scratches.
1.b Attach the Top (A), DETAIL 1, Legs can be used on the either side.
1.c Insert the 3pcs of Allen Head Bolt (H1) and tighten it with the Allen Key (T1), DETAIL 2
1.d Attach the other End frame (B) on the other end follow Step 1.b, then follow Step 1.c
DETAIL
1
A
B
DETAIL
2
B
A
A
B
T1
H1
ASSEMBLY IS COMPLETE
Let the Ottoman stand.
CARE & MAINTENANCE
: Use mild detergent and water to clean. Store in dry, covered area
when not in use and at the end of the season. Occassionally check the nuts and bolts and re tighten if
when not in use and at the end of the season. Occassionally check the nuts and bolts and re tighten if
needed.
Please contact one of Our Product Specialists for assembly assistence of questions at 1-800-537-8484
or email [email protected]. Specialists are available weekdays 8:00 a.m. to 8:00 p.m. EST or
Saturday 9:30 a.m. to 6:00 p.m.
