Frymaster 45 Building instructions

45 Series Gas Fryers
Service and Parts Manual

DANGER
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE, OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY, OR DEATH. READ THE
INSTALLATION, OPERATING, AND SERVICE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
DANGER
FOR YOUR SAFETY, DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE
LIQUIDS OR VAPORS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
DANGER
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE
EVENT THE USER SMELLS GAS. THIS INFORMATION SHALL BE OBTAINED BY
CONSULTING THE LOCAL GAS SUPPLIER.
THIS EQUIPMENT IS TO BE INSTALLED IN COMPLIANCE WITH THE BASIC
PLUMBING CODE OF THE BUILDING OFFICIALS AND CODE ADMINISTRATORS
INTERNATIONAL, INC. (BOCA) AND THE FOOD SERVICE SANITATION MANUAL OF
THE FOOD AND DRUG ADMINISTRATION.
COMPUTERS
FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference, and 2) This device must accept any
interference received, including interference that may cause undesired operation. While this device is
a verified Class A device, it has been shown to meet the Class B limits.
CANADA
This digital apparatus does not exceed the Class A or B limits for radio noise emissions as set out by
the ICES-003 standard of the Canadian Department of Communications.
Cet appareil numerique n’emet pas de bruits radioelectriques depassany les limites de classe A et B
prescrites dans la norme NMB-003 edictee par le Ministre des Communcations du Canada.
DANGER
THIS PRODUCT CONTAINS CHEMICALS KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER AND/OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
Operation, installation, and servicing of this product could expose you to airborne
particles of glasswool or ceramic fibers, crystalline silica, and/or carbon monoxide.
Inhalation of airborne particles of glasswool or ceramic fibers is known to the State
of California to cause cancer. Inhalation of carbon monoxide is known to the State
of California to cause birth defects or other reproductive harm.
FRYMASTER FRYERS EQUIPPED WITH LEGS ARE FOR PERMANENT
INSTALLATION. FOR MOVEABLE OR PORTABLE INSTALLATION, FRYMASTER
OPTIONAL EQUIPMENT CASTERS MUST BE USED.
QUESTIONS??? CALL 1-800-551-8633.

45 SERIES GAS FRYERS SERVICE AND PARTS MANUAL
TABLE OF CONTENTS
i
CHAPTER 1: Service Procedures
1.1 Functional Description................................................................................................... 1-1
Pilot Ignition System...................................................................................................... 1-1
Control Options.............................................................................................................. 1-1
Interface Boards ............................................................................................................. 1-1
Thermostats and Temperature Probes............................................................................ 1-3
1.2 Accessing Fryers for Servicing...................................................................................... 1-4
1.3 Checking the Burner Manifold Gas Pressure................................................................. 1-4
1.4 Adjusting the Pilot Flame............................................................................................... 1-5
1.5 Cleaning the Gas Valve Vent Tube................................................................................ 1-6
1.6 Adjusting Burner Ceramic Target Spacing and Alignment ........................................... 1-6
1.7 Calibrating the Thermostat Control................................................................................ 1-6
1.8 Replacing Fryer Components......................................................................................... 1-7
1.8.1 Replacing the Controller or Computer........................................................................... 1-7
1.8.2 Replacing the Operating Thermostat.............................................................................. 1-8
1.8.3 Replacing the Temperature Probe.................................................................................. 1-8
1.8.4 Replacing the Hi-Limit Thermostat in Fryers with Thermostat Controls...................... 1-9
1.8.5 Replacing the Hi-Limit Thermostat in Fryers with Other Than Thermostat Controls. 1-10
1.8.6 Replacing the Heat Mode Indicator Light in Fryers with Thermostat Controls .......... 1-10
1.8.7 Replacing the Power or Melt Cycle Switch in Fryers with Thermostat Controls........ 1-11
1.8.8 Replacing the Melt Cycle Timer in Fryers with Thermostat Controls......................... 1-11
1.8.9 Replacing Burner Ceramic Targets.............................................................................. 1-12
1.8.10 Replacing the Gas Valve.............................................................................................. 1-12
1.8.11 Replacing the Pilot Assembly or Thermopile.............................................................. 1-13
1.8.12 Replacing the Frypot.................................................................................................... 1-14
1.9 Troubleshooting and Problem Isolation....................................................................... 1-15
1.9.1 Ignition Failures ........................................................................................................... 1-16
1.9.2 Improper Burner Functioning....................................................................................... 1-17
1.9.3 Improper Temperature Control .................................................................................... 1-18
1.9.4 Computer-Related Problems ........................................................................................ 1-19
1.9.5 Filtration Problems....................................................................................................... 1-20
1.9.6 Leakage Problems ........................................................................................................ 1-22
1.9.7 Basket Lift Malfunctions.............................................................................................. 1-22
1.9.8 Interpretation of Digital Controller Lights................................................................... 1-29
1.10 Troubleshooting Guides............................................................................................... 1-29
1.10.1 Troubleshooting the 24 VAC Circuit in Units without Interface Boards..................... 1-30
1.10.2 Troubleshooting the 24 VAC Circuit in Units without Interface Boards..................... 1-31
1.10.3 Troubleshooting the Gas Valve.................................................................................... 1-33
1.10.4 Troubleshooting the Thermostat .................................................................................. 1-34
1.10.5 Troubleshooting the Temperature Probe...................................................................... 1-35
Probe Resistance Chart................................................................................................. 1-36
1.11 Wiring Diagrams.............................................................................................................1-38

ii
CHAPTER 2: Parts List
Accessories...................................................................................................................................2-1
Basket Lift Assemblies and Component Parts.............................................................................2-2
Bell Crank Basket Lift.............................................................................................................2-2
Modular Basket Lift.................................................................................................................2-3
Burner Assembly Component Parts.............................................................................................2-4
Cabinet Assemblies and Component Parts...................................................................................2-6
Fryer and Spreader Cabinet Assembly Components...............................................................2-6
Filter Magic II Cabinet Components.......................................................................................2-8
Casters, Legs, and Associated Hardware ...................................................................................2-10
Component Shield and Filter Box Assemblies and Component Parts.......................................2-11
Control Panel Assemblies, Flue Caps, Top Caps, and Related Items........................................2-14
Controller Assemblies (Thermostat Controllers).......................................................................2-16
Controller Assemblies (Other than Thermostat Controllers).....................................................2-18
Door Assembly...........................................................................................................................2-19
Drain and Filtration System Components..................................................................................2-20
Filter Magic II Square Drain Components ............................................................................2-20
FM45 Drain Valve Assembly................................................................................................2-21
MJ45 Drain Valve Assembly.................................................................................................2-21
Filter Magic II Filter Pan Assembly......................................................................................2-22
Filter Magic II Filter Pump/Motor Assemblies and Associated Components.......................2-23
Frypot Assemblies and Component Parts ..................................................................................2-24
Oil Return Handle Assembly.....................................................................................................2-26
Oil Return Plumbing..................................................................................................................2-27
Power Shower Assembly ...........................................................................................................2-28
Temperature Probes, High-Limits, and Related Components....................................................2-29
Wiring Assemblies, Wiring Harnesses, Cables, and Cable Assemblies....................................2-30
Miscellaneous Electrical Components .......................................................................................2-32

45 SERIES GAS FRYERS SERVICE AND PARTS MANUAL
CHAPTER 1: SERVICE PROCEDURES
1-1
1.1 Functional Description
The 45 Series fryers contain a welded steel (stainless or cold rolled) frypot that is directly heated by
gas flames that are diffused evenly over its lower surface by ceramic targets.
The flames originate from orifices in a U-shaped burner manifold positioned beneath the frypot. The
orifice diameters differ for natural and propane gas as indicated in the table below (see Page 2-5 for a
complete list of available orifices).
Gas Inches Millimeters
Natural 0.057 1.45
Propane 0.034 0.86
45 Series Orifice Sizes (0-1999 ft/609 m)
Gas flow to the manifold is regulated by an electromechanical gas valve. This series of fryers is
equipped with a 24-volt gas valve and all models use a pilot ignition system.
PILOT IGNITION SYSTEM
The pilot ignition system is comprised of the pilot orifice, pilot hood, and a thermopile. The pilot
serves two purposes. The first is to light the burner, the second is to heat the thermopile. In opera-
tion, the thermopile is in contact with the pilot flame and generates millivolts. The millivolt output
passes through a normally closed high-limit switch and energizes the gas valve pilot coil, which in
turn opens the pilot valve. If the pilot flame is extinguished, voltage is lost to the gas valve pilot coil
and the pilot valve closes. A separate 24-volt circuit, activated by the fryer ON/OFF switch, pro-
vides voltage through the thermostat or controller to the gas valve main coil, which opens the main
valve. The gas valve is constructed so that the main valve will not open if the pilot valve is not open.
The pilot flame must be manually lit (either with a match or with an optional built-in piezo igniter)
when the fryer is first placed into operation.
Controlling Thermostat
or
Controller
24 VAC
Transformer
High-Limit
Thermostat
Thermopile
Pilot Coil
Main Coil
Gas Valve
Line Voltage
Line Voltage
The Pilot System
ON/OFF
Switch
Pilot

1-2
CONTROL OPTIONS
45 Series fryers may be equipped with thermostat controllers, analog controllers, digital controllers,
basket lift timers, or Computer Magic III computers.
In fryers equipped with thermostat controls, the fryer and melt cycle are turned on and off by means
of rocker switches and the temperature is set by means of a knob connected directly to the frypot-
mounted thermostat. These units have no interface board. In this type of unit, when the melt cycle
switch is placed in the ON position, the fryer stays in the melt cycle mode until the switch is manu-
ally placed in the OFF position, even if the frypot is at setpoint temperature.
Fryers equipped with other types of controllers have an interface board located in the component
shield behind the control panel.
INTERFACE BOARDS
The interface board provides the link between the controller/computer and the fryer’s individual
components without requiring excessive wiring, and allows the controller to execute commands from
one central point. When built, depending upon the configuration of the particular fryer, any one of
three different boards may be used. Regardless of the particular board installed when the fryer was
built, P/N 806-3548 is the universal replacement part.
INTERFACE BOARDS 806-3548, 806-5490, AND 806-7505
NOTES:
1. RELAYS K1 AND K2 ARE FOR BELL CRANK BASKET LIFTS. THEY ARE NOT PRESENT ON
BOARDS 806-5490 (U.S. AND NON-CE EXPORT UNITS W/O BASKET LIFTS) OR 806-7501
(CE UNITS, WITH OR WITHOUT BASKET LIFTS).
2. RESISTORS R1, R10, AND R15 ARE NOT USED ON ANY OF THE THREE BOARDS.
3. RESISTORS R11 AND R12 ARE NOT USED ON 806-5490 BOARDS.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 1
2
3
4
5
6
7
8
9
10
11
12

1-3
Test Meter
Setting Pins Results
12 VAC Power to Controller 50 VAC Scale 1 and 3 of J2 12-18
24 VAC Power 50 VAC Scale 24 VAC Terminals 22-28
24 VAC Power to Gas Valve 50 VAC Scale 6 on J1 and GROUND 22-28
120 VAC Power 250 VAC Scale 7 and 12 of J1 110-125
Probe Resistance* R x 1000 OHMS 2 and 3 of J1 **
FREQUENTLY USED TEST POINTS FOR 45 SERIES INTERFACE BOARDS
** Disconnect 15-Pin harness from controller before testing probe circuit.
** See Probe Resistance Chart at end of chapter.
Four LEDs, arranged across the top of the boards and identified in the table below, are provided to
assist in troubleshooting.
GV Indicates 24 VAC to the gas valve
AL Indicates open Drain Safety Switch (if installed)
24V Indicates 24 VAC from transformer
COMP Indicates 12 VAC to computer
45 SERIES INTERFACE BOARD
LED DIAGNOSTIC LIGHTS
Every board contains one heat relay (K3), and may contain two basket lift relays (K1 and K2). As
shipped from the factory, fryers with bell crank basket lifts will have relays K1, K2, and K3. All
other factory-original fryers will have boards with only relay K3.
THERMOSTATS AND TEMPERATURE PROBES
Different types of thermostats are used in 45 Series fryers, depending on the fryers’ configuration.
Fryers equipped with Thermostat Controls have an adjustable controlling (operating) thermostat.
The temperature at which the thermostat opens and closes is adjusted by physically changing the set-
ting of the thermostat itself by means of an attached knob. When new, the Fenwal controlling ther-
mostat used in 45 Series fryers is sensitive to one-degree changes in temperature.
CAUTION
Fenwal thermostats are used in a number of Frymaster™ products. The thermostat
for the 45 Series is 4 inches long. Do not use 3-inch Fenwal thermostats in 45 Series
fryers.
Fryers equipped with all other type controls have a temperature probe. In these units, the probe
resistance varies directly with the temperature. That is, as the temperature rises, so does resistance at
a rate of approximately 2 ohms for every 1º (F or C). Circuitry in the controller monitors the probe
resistance and controls burner firing when the resistance exceeds or falls below programmed
temperatures (setpoints). The temperatures are programmed by means of a keypad on the face of the
controller.
All 45 Series fryers are equipped with a high-limit thermostat.In the event that the fryer fails to
properly control the oil temperature, the high-limit thermostat prevents the fryer from overheating to
the flash point. The high-limit thermostat acts as a normally closed power switch that opens when

1-4
exposed to temperatures in the range of 425ºF to 450ºF (218ºC to 232ºC). The high-limit thermostat
is the same for CE and Non-CE applications, but the terminals for attaching it to Robertshaw and
Honeywell gas valves differ. When a replacement high-limit thermostat is ordered, make sure the kit
appropriate for the valve in use is ordered.
1.2 Accessing Fryers for Servicing
DANGER
Moving a fryer filled with cooking oil/shortening may cause spilling or splattering of
the hot liquid. Follow the draining instructions in Chapter 4 of the 45 Series Gas
Fryer Installation and Operation Manual before attempting to relocate a fryer for
servicing.
1. Shut off the gas supply to the unit. Unplug the power cord(s). Disconnect the unit from the gas
supply.
2. Remove any attached restraining devices.
3. Relocate the fryer for service accessibility.
4. After servicing is complete, reconnect the unit to the gas supply, reattach restraining devices,
and plug in the electrical cords.
1.3 Checking the Burner Manifold Gas Pressure
WARNING
This task should be performed by qualified service personnel only.
1. Ensure that the gas valve knob or button is in the OFF position.
2. Remove the pressure tap plug from the end of the manifold (see illustration below for location)
and connect a gas pressure-measuring device to the port.
Remove this plug and connect a gas
pressure-measuring device to the port.
3. Place the gas valve in the ON position then place the fryer power switch in the ON position.
When the burner lights and continues to burn, compare the pressure reading to that for the corre-
sponding gas in the tables on the following page.

1-5
Gas Pressure
Natural 3.5" W.C.
0.73 kPa
Propane 8.25" W.C.
2.05 kPa
Non-CE Standard
Burner Manifold Gas Pressures
Gas Pressure
(mbar)
Natural Gas Lacq
(G20) under 20 mbar 7,5
Natural Gas Gronique *
(G25) under 25 mbar 10
Natural Gas Gronique
(G20) under 20 mbar 10
Propane
(G31) under 37 or 50 mbar 20,6
CE Standard
Burner Manifold Gas Pressures
* Belgian G25 = 7,0 mbar
4. If the measured gas pressure does not match the appropriate pressure in the tables above, remove
the cap from the gas valve regulator and adjust to the correct pressure.
Robertshaw Valve
(Non-CE Units) Honeywell Valve (Non-CE Units) Honeywell Valve (CE Units)
Regulator Adjustment Screw Cap
5. Place the fryer power switch and the gas valve in the OFF position. Remove the fitting from the
pressure tap hole and reinstall the plug. Place the gas valve in the ON position, and check for and
eliminate any gas leaks. Place the gas valve in the OFF position.
1.4 Adjusting the Pilot Flame
1. On non-CE valves, remove the cap covering the pilot adjustment screw. On all valves, turn the
pilot adjustment screw counterclockwise to increase the length of the flame or clockwise to de-
crease the length of the flame. Adjust the flame to a length of 1 to 1½ inches (25 to 38mm).
Robertshaw Valve
(Non-CE Units) Honeywell Valve (Non-CE Units) Honeywell Valve (CE Units)
To access the pilot adjustment screw on
Non-CE valves, this cap must be removed. Pilot Adjustment Screw
2. On Non-CE valves, reinstall the pilot adjustment screw cap.

1-6
1.5 Cleaning the Gas Valve Vent Tube
1. Carefully unscrew the vent tube from the gas valve. NOTE: The vent tube may be straightened
for ease in removal.
2. Pass a piece of ordinary binding wire (.052 inch diameter) or equivalent through the tube to re-
move any obstruction.
3. Remove the wire, then blow through the tube to ensure it is clear.
4. Reinstall tube and bend it so that the opening is pointing downward.
1.6 Adjusting Burner Ceramic Target Spacing and Alignment
DANGER
Drain the frypot or remove the handle from the drain valve before proceeding further.
Proper spacing of the top edge of the burner ceramic targets is ¾ inch (13 mm) from the frypot side.
To adjust target spacing, bend the brackets to which they are attached away or toward the frypot to
the proper distance. (A length of board of the proper thickness is useful as a gauge to verify spacing
and alignment.)
1.7 Calibrating the Thermostat Control
NOTE: The fryer control panel must be hinged down from the control panel mounting frame to per-
form thermostat calibration. In order to hinge the control panel down, the thermostat knob must be
removed from its shaft. It is secured with a setscrew located opposite the index mark on the knob.
1. Fill the frypot to the lower OIL-LEVEL line with cooking oil/shortening. If solid shortening is
used, it must be pre-melted before starting the calibration procedure.
2. Ensure the fryer ON/OFF Switch is in the OFF position, then light the pilot. (Refer to Chapter 3
of the 45 Series Gas Fryer Installation and Operation Manual for detailed lighting instructions.)
3. Insert a good grade thermometer or pyrometer into the frypot so that it touches the thermostat
guard.
4. Loosen the setscrew and stop screw securing the ther-
mostat shaft extension to the flexible shaft. Remove the
extension to expose the slot in the end of the flexible
shaft.
5. Place the fryer ON/OFF switch in the ON position.
NOTE: If the burner does not light at this time, it
does not mean the thermostat is defective!
Use a small flat-tipped screwdriver to slowly turn the flexible shaft counterclockwise until the
burner lights. Turning the shaft counterclockwise causes the burner to light and clockwise
causes it to shut off.
Stop screw
Locking nut
Setscrew

1-7
6. When the cooking oil/shortening temperature reaches 325ºF (162ºC), turn the flexible shaft
slowly clockwise until the burner shuts off.
7. Allow the fryer to sit for a few minutes, then slowly turn the flexible shaft counterclockwise un-
til the burner lights.
8. Repeat steps 6 and 7 at least three times to ensure an accurate setting is obtained. The Thermo-
stat Control is considered to be properly calibrated when the burner lights as the cooking
oil/shortening cools to 325ºF (162ºC)—not when the burner shuts off as the temperature rises.
9. Once the calibration point of 325ºF (162ºC) is determined, allow the burner to cycle on and off at
least 3 times to be sure it will light at the calibrated temperature.
10. After the calibration is complete, place the fryer power switch in the OFF position and disconnect
the fryer from the electrical supply.
11. Carefully replace the thermostat shaft extension, ensuring that the stop screw is pointed straight
up. Tighten the stop screw and locking nut and the setscrew, being careful not to rotate the flexi-
ble shaft.
CAUTION
The thermostat flexible shaft must not be rotated while installing the thermostat
shaft extension!
When handling the thermostat, do not rotate the shaft more than two turns in either
direction. Doing so will cause damage to the thermostat.
12. Close the fryer control panel and replace the screws the upper corners.
13. Reinstall the thermostat knob with its pointer aligned with the 325ºF (162ºC) index mark on the
temperature dial.
14. Reconnect the fryer to the electrical supply.
1.8 Replacing Fryer Components
1.8.1 Replacing the Controller or Computer
1. Disconnect the fryer from the electrical power
supply.
2. Unscrew the two control panel screws. The
control panel is hinged at the bottom and will
swing open from the top.
3. Unplug the fryer wiring harness from the back
of the controller/computer and disconnect the
grounding wire.
Unplug
harness
Disconnect
grounding wire

1-8
4. Remove the controller/computer by lifting it from the hinge slots in the fryer control panel frame.
5. Reverse the procedure to install a new controller/computer.
1.8.2 Replacing the Operating Thermostat
CAUTION
The thermostat must be calibrated after installation is complete. Refer to Section 1.7
for calibration instructions.
When handling the thermostat, do not rotate the shaft more than two turns in either
direction. Doing so will cause damage to the thermostat.
1. Disconnect the fryer from the electrical supply and drain the frypot.
2. Loosen the setscrew securing the thermostat knob and remove the knob. Remove the screws from
the upper left and right corners of the control panel. The control panel is hinged at the bottom and
will swing open from the top.
3. Disconnect the 9-Pin connector and remove the control panel from the fryer by disengaging its
tabs from the hinge slots in the mounting frame.
4. Loosen the setscrews securing the flexible shaft
to the thermostat shaft and slip the flexible shaft
off the thermostat shaft.
5. Remove the flexible shaft guide by removing
the two sheet metal screws securing it to the up-
per frame.
6. Disconnect the thermostat leads from Pin 14 in
the 20-pin terminal block and from the gas valve
terminal.
NOTE: If the fryer is configured with a melt cycle, the thermostat leads will be connected to the
melt cycle timer motor or PC board rather than to the terminal block and gas valve. Disconnect
the leads from the motor or PC board if this is the case.
7. Unscrew the thermostat from the frypot and remove.
5. Apply Loctite™ PST56765 thread sealant or equivalent to the replacement thermostat threads.
9. Reverse steps 1 through 7 to install the replacement.
1.8.3 Replacing the Temperature Probe
1. Disconnect the fryer from the electrical supply.
2. Drain the frypot.
Loosen these setscrews and slip the
flexible shaft off the thermostat shaft.

1-9
3. Remove the screws from the upper left and
right corners of the control panel. The panel is
hinged at the bottom and will swing open from
the top.
4. Unplug the wiring harness from the back of
the controller and disconnect the grounding
wire.
5. Remove the controller from the fryer by lifting
it from the hinge slots in the control panel
frame.
6. Remove the two screws from the base of the interface board mounting bracket.
7. Disconnect the 12-pin plug from the back of the interface board and lay the board in the left end
of the compartment with all other wires still connected.
8. Remove the 12-volt transformer from the component shield and lay it in the left end of the com-
partment with wires still connected.
9. Using a pin-pusher, remove the temperature probe wires (pins 1 and 2) from the 12-pin plug dis-
connected in step 7.
10. Unscrew the temperature probe from the frypot and remove.
5. Apply Loctite™ PST56765 thread sealant or equivalent to new probe threads.
12. Reverse steps 1 through 10 to install the replacement probe.
1.8.4 Replacing the High-Limit Thermostat in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical supply.
2. Drain the frypot.
3. Loosen the setscrew securing the thermostat knob and remove the knob. Remove the screws from
the upper left and right corners of the control panel. The control panel is hinged at the bottom and
will swing open from the top.
4. Disconnect the 9-Pin connector and remove the control panel from the fryer by disengaging its
tabs from the hinge slots in the mounting frame.
6. Disconnect the high-limit thermostat leads from the gas valve pilot coil.
7. Unscrew the high-limit thermostat from the frypot and remove.
8. Apply Loctite™ PST56765 thread sealant or equivalent to the replacement thermostat threads.
Unplug
harness
Disconnect
grounding wire

1-10
9. Reverse steps 1 through 7 to install the replacement.
1.8.5 Replacing the High-Limit Thermostat in Fryers with Other Than Thermostat
Controls
1. Disconnect the fryer from the electrical power
supply.
2. Drain the frypot.
3. Remove the screws from the upper left and
right corners of the controller panel. The con-
troller is hinged at the bottom and will swing
open from the top.
4. Unplug the wiring harness and disconnect the
grounding wire from the the controller.
5. Remove the controller from the fryer by lifting it from the hinge slots in the fryer control panel
frame.
6. Remove the two screws from the base of the interface board mounting bracket.
7. Disconnect the 12-pin plug from the back of the interface board and lay the board in the right end
of the compartment with all other wires still connected.
8. Remove the 12-volt transformer and lay it in the right end of the compartment with wires still
connected.
9. Remove the high-limit thermostat wires from the gas valve pilot coil and pull them up through
the control shield.
10. Unscrew the high-limit thermostat from the frypot and remove.
9. Apply Loctite™ PST56765 thread sealant or equivalent to the replacement thermostat’s threads
and screw it into the frypot.
12. Attach the appropriate terminals (furnished in the replacement thermostat kit) to the thermostat
leads.
13. Reverse steps 1 through 9 to complete installation of the replacement thermostat.
1.8.6 Replacing the Heat Mode Indicator Light in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical supply.
2. Loosen the setscrew securing the thermostat knob and remove the knob. Remove the screws
from the upper left and right corners of the control panel. The control panel is hinged at the bot-
tom and will swing open from the top.
Unplug
harness
Disconnect
grounding wire

1-11
3. Disconnect the 9-pin connector and remove the control panel from the fryer by disengaging its
tabs from the hinge slots in the mounting frame.
4. Carefully press the light out from the back of the control panel. Disconnect one wire at a time
and reconnect it to the replacement light until all wires are transferred.
5. Carefully press the light back into the control panel.
6. Reverse steps 1-3 to reassemble the fryer.
1.8.7 Replacing the Power or Melt Cycle Switch in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical supply.
2. Loosen the setscrew securing the thermostat knob and remove the knob. Remove the screws
from the upper left and right corners of the control panel. The control panel is hinged at the
bottom and will swing open from the top.
3. Disconnect the 9-pin connector and remove the control panel from the fryer by disengaging its
tabs from the hinge slots in the mounting frame.
4. Using a flat-tipped screwdriver, disconnect the chrome bezel from the tabs on the switch and
press the switch out from the front.
5. Carefully press the new switch back into the chrome bezel, making sure the tabs on the switch
engage the slots in the bezel.
6. Disconnect one wire at a time from the old switch and reconnect it to the new switch until all
wires have been transferred.
7. Reverse steps 1-3 to reassemble the fryer.
1.8.8 Replacing the Melt Cycle Timer in Fryers with Thermostat Controls
NOTE: In early 1999, PC board melt cycle timers replaced melt cycle timer motors in new fryers.
1. Disconnect the fryer from the electrical supply.
2. Loosen the setscrew securing the thermostat knob and remove the knob. Remove the screws from
the upper left and right corners of the control panel. The control panel is hinged at the bottom and
will swing open from the top.
3. Remove the screws securing the timer motor (or the PC board timer bracket) to the fryer (see il-
lustration on Page 2-11).
4. Remove one wire at a time and reconnect it to the replacement PC board timer until all wires
have been transferred.
5. Reverse steps 1-3 to reassemble the fryer.

1-12
1.8.9 Replacing Burner Ceramic Targets
DANGER
Drain the frypot or remove the handle from the drain valve before proceeding further.
1. Disconnect fryer from electrical and gas supplies.
2. On FM45 fryers, remove square-drain sections as necessary to expose burner.
3. Disconnect the wires from the gas valve terminal block, marking each wire to facilitate recon-
nections.
4. Remove the high-limit thermostat wires from the gas valve pilot coil.
5. Disconnect the pipe union collar at the right side of the gas valve.
6. Remove the burner heat shield hanger screws at the front of the burner and remove the heat
shield.
7. Remove the burner hanger screws and lower the front of the main burner. Pull it forward to
clear the rear burner hanger, then lower the burner to the floor.
8. Raise the front of the fryer enough to slide the burner from under the fryer cabinet.
9. To replace only the ceramic targets, straighten the target locking tabs with a pair of needle nose
pliers or a screwdriver, and slide the target up and off the bracket. Slide the replacement target
onto the bracket and bend the locking tabs down.
To replace the entire target assembly, use a ½-inch (13mm) box end wrench to remove the two
brass orifices that hold the assembly to the burner manifold. Position the new assembly and re-
place the orifices.
WARNING
Use extreme care to prevent cross-threading and stripping when reinstalling the
brass orifices.
10. Reverse steps 1-8 to reinstall the burner assembly. Check spacing and alignment of targets in
accordance with Section 1.5.
1.8.10 Replacing the Gas Valve
DANGER
Drain the frypot or remove the handle from the drain valve before proceeding further.
1. Disconnect fryer from electrical and gas supplies

1-13
2. Disconnect the wires from the gas valve terminal block, marking each wire to facilitate recon-
nections.
3. Remove the high-limit thermostat wire from the gas valve pilot coil.
4. Disconnect the pilot gas line fitting from the gas valve.
5. Disconnect the pipe union collars to the left and right of the gas valve and remove the valve.
6. Remove the pipe fittings from the old gas valve and install on the replacement valve, using Loc-
tite™ PST56765 or equivalent pipe thread sealant on threads.
7. Reverse steps 1-5 to install the replacement gas valve.
1.8.11 Replacing the Pilot Assembly or Thermopile
DANGER
Drain the frypot or remove the handle from the drain valve before proceeding further.
1. Remove the burner assembly in accordance with steps 1-8 of Section 1.8.9.
2. To replace only the thermopile:
a. Bend the clip at the bottom of the pilot as-
sembly and press the thermopile out of the
pilot assembly from the top.
b. Disconnect the thermopile fitting from the
gas valve pilot coil.
c. Reverse steps a and b to install the re-
placement thermopile.
3. To replace the complete pilot assembly:
a. Disconnect the pilot tubing from the bottom of the pilot assembly.
b. Remove the screw from the pilot mounting bracket to release the pilot assembly.
c. Disconnect the thermopile fitting from the gas valve pilot coil.
d. Reverse steps a through c to install the replacement pilot assembly.
4. Reinstall the burner assembly by reversing steps 1-8 of Section 1.8.9.
Bend clip to release
thermo
p
ile.

1-14
1.8.12 Replacing the Frypot
1. Drain the frypot.
2. Remove all accessories (e.g., frypot covers, basket lift arms, etc.) from the fryer.
3. Disconnect the fryer from gas and electrical supplies.
4. Remove the screws from the top cap above the control panel and lift it up and off the fryer(s).
5. If the fryer is equipped with other than a Thermostat Control, skip to Step 10.
6. Loosen the setscrew securing the Thermostat Knob to the thermostat flexible shaft and remove
the knob. Remove the screws from the upper left and right corners of the control panel. Discon-
nect the 9-Pin connector and remove the control panel from the fryer.
7. Loosen the setscrews securing the flexible
shaft to the thermostat shaft and slip the flexi-
ble shaft off the thermostat shaft.
8. Remove the flexible shaft bracket from the
fryer by removing the two sheet metal screws
securing it to the upper frame.
9. Disconnect the thermostat leads from Pin 14
in the 20-pin terminal block and from the gas
valve terminal. Mark each wire to facilitate
reconnection. Skip to Step 14.
NOTE: If the fryer is configured with a melt cycle, the thermostat leads will be connected to
the melt cycle timer motor rather than to the terminal block and gas valve. Disconnect the leads
from the motor if this is the case.
CAUTION
When handling the thermostat, do not rotate the shaft more than two turns in either
direction. Doing so will cause damage to the thermostat.
10. For fryers equipped with other than Thermo-
stat Controls, remove the screws from the up-
per left and right corners of the control panel.
Unplug the wiring harness from the back of
the controller and disconnect the grounding
wire. Remove it from the fryer by lifting it
from the hinge slots in the fryer control frame.
11. Remove the two screws from the base of the
interface board bracket.
12. Disconnect the 12-pin plug from the back of
the interface board. Use a pin pusher to re-
move the temperature probe leads (pins 1 and
Loosen these setscrews and slip
flexible shaft off the thermostat shaft.
Unplug
harness
Disconnect
grounding wire

1-15
2) and the high-limit thermostat leads (pins 6 and 8) from the plug. Leave all other wires con-
nected. Leave the interface board lying on the shield.
13. Remove the louvered frame above the control panel opening.
14. Remove the screws securing the component shield to the fryer.
15. Disconnect the wires from components in component shield and mark to facilitate reconnection.
16. Disconnect the wires from the gas valve terminal block. Mark each wire to facilitate reconnec-
tion.
17. Remove the cover from the safety drain switch, disconnect the wires from the switch, and pull
them out of the switch box.
18. Pull up and forward on the component shield to clear the rear mounting stud on the front of the
frypot and remove it from the fryer by rotating its right side up and to the left.
19. Disconnect the pipe union on the right side of the gas valve.
20. On FM45 fryers, remove the section of square drain from the drain valve of the frypot to be re-
moved.
21. Remove the frypot hold down bracket.
22. Remove the screws from the flue cap sides and back and lift it clear of the fryer(s).
23. Remove the oil return line from the front of the frypot to be removed.
24. Lift the complete frypot assembly (frypot, burner, gas valve, and flue) from the fryer cabinet.
25. Transfer the burner heat shield and burner to the replacement frypot.
26. Remove the drain valve, thermostat or temperature probe, and high-limit thermostat and install
on replacement frypot.
CAUTION
Before installing the thermostat/temperature probe, high-limit thermostat, and drain valve
on the replacement frypot, clean their threads and apply Loctite™ PST56765 thread
sealant or equivalent to the threads.
27. Reverse steps 1-25 to reassemble the fryer.
1.9 Troubleshooting and Problem Isolation
Because it is not feasible to attempt to include in this manual every conceivable problem or trouble
condition that might be encountered, this section is intended to provide technicians with a general
knowledge of the broad problem categories associated with this equipment, and the probable causes
of each. With this knowledge, the technician should be able to isolate and correct any problem en-
countered.

1-16
Problems you are likely to encounter can be grouped into seven broad categories:
1. Ignition failures
2. Improper burner functioning
3. Improper temperature control
4. Computer-related problems
5. Filtration problems
6. Leakage problems
7. Basket Lift malfunctions.
The probable causes of each category are discussed in the following sections. A series of Trouble-
shooting Guides (decision trees) is also included at the end of the chapter to assist in identifying
some of the more common problems.
1.9.1 Ignition Failures
Ignition failures occur when the 24VAC power supply to the gas valve is interrupted, when the gas
supply is interrupted, or when the pilot flame is extinguished.
Solid-state controllers indicate ignition failure by illuminating the heat light and trouble light simul-
taneously. All other controllers give no specific indication of an ignition failure.
There are three primary reasons for ignition failure, listed in order of probability:
1. Problems related to the gas and/or electrical power supplies
2. Problems related to the electronic circuits
3. Problems related to the gas valve.
PROBLEMS RELATED TO THE GAS AND/OR ELECTRICAL POWER SUPPLIES
The main indicators of this are that an entire battery of fryers fails to light and/or there are no indi-
cator lights illuminated on the fryer experiencing ignition failure. Verify that the quick disconnect
hose is properly connected, the fryer is plugged in, the main gas supply valve is open, and the circuit
breaker for the fryer electrical supply is not tripped.
PROBLEMS RELATED TO THE ELECTRONIC CIRCUITS
If gas and electrical power are being supplied to the fryer, the next most likely cause of ignition fail-
ure is a problem in the 24 VAC circuit of the pilot system. If the fryer is equipped with a Filter
Magic II filtration system, first verify that the drain valve is fully closed. (The valve is attached to a
microswitch that must be closed for power to reach the gas valve. Often, although the valve handle
appears to be in the closed position, the microswitch is still open.) If the valve is fully closed, or the
fryer does not have a filtration system, refer to the troubleshooting guides TROUBLESHOOTING THE
24 VAC CIRCUIT.
PROBLEMS RELATED TO THE GAS VALVE
If the problem is not in the 24 VAC circuit of the pilot system, it is most likely in the gas valve itself,
but before replacing the gas valve refer to TROUBLESHOOTING THE GAS VALVE on page 1–33.
