FSR TC-WC1 User manual

TC-WC1
In Table Wireless Charger
FSR Inc.
244 Bergen Boulevard, Woodland Park, NJ 07424
Phone: [phone] · Fax: [phone]
Order Desk: 1-800-332-FSR1
Web: www.fsrinc.com · E-mail: [email protected] IT1650
P wer Pr ducts Gr up
TC-WC1
FEATURES
FEATURES
DESCRIPTION
DESCRIPTION
DIMENSIONS
DIMENSIONS
ORDERING TABLE
ORDERING TABLE
• Convenient Simple Installation
• Water Resistant
• Anti-Skid Surface
• Fast Charging
• Available in Black or White
• Aluminum Bezel
• Output: 10W ( 5V-1A; 9V-1.2A)
Qi Standard: Version WPC1.2
• Charging Distance: 0-.313” (0-8mm)
• Charging Efficiency: 75% max
• Warranty: 2 years
• Charging Area:1 coil
• Material: Aluminum Alloy, ABS
Package contains
• Wireless charging pad
• 48” (1.2 meter) USB cable
• User Manual
• With or without adaptive fast charge wall charger
(See ordering table)
The TC-WC1 “In Table” Wireless Charger is compatible with
all Qi Standard Devices and will fast charge any Samsung
device with wireless adaptive fast charging as long as the unit
is powered by an adaptive fast charge power supply. FSR
provides these power supplies with certain models (See
ordering table). The unit mounts through a hole cut in the
table and is easily secured from under the table with the
supplied threaded collar. The TC-WC1 is offered in Black or
White to blend with the décor.
18000 TC-WC1-B K CHARGER WITH POWER SUPP Y
18001 TC-WC1-B K-NPS CHARGER W/O POWER SUPP Y
18002 TC-WC1-WHT CHARGER WITH POWER SUPP Y
18003 TC-WC1-WHT-NPS CHARGER W/O POWER SUPP Y
SPECIFICATIONS
SPECIFICATIONS
3.15” DIA MIN
3.25” DIA MAX HOLE
3.53” OUTER
RING DIA
.725” - 1.375”
MAX THICKNESS
.039” - .675”
MIN THICKNESS

TC-WC1
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
244 Bergen Boulevard, Woodland Park, NJ 07424
Phone: [phone] · Fax: [phone]
Web: www.fsrinc.com · E-mail: [email protected]
MADE IN
THE USA
Specifications are subject
to change without notice.
1. DETERMINE TC-WC1 LOCATION AND DRILL HOLE.
3.15” DIA (80mm) MIN
3.25” DIA (83mm) MAX
2. INSERT TC-WC1 INTO HOLE.
3. SECURE TC-WC1 WITH COLLAR. USE INCLUDED SPANNING TOOL TO SECURE TIGHTLY.
TC-WC1
COLLAR
ORIENT COLLAR FOR APPLICABLE THICKNESS.
.039” - .675”
.725” - 1.375”
4. MAKE CONNECTIONS AS REQUIRED.
TO TC-WC1
5. LAY DEVICE ON TOP OF CHARGER TO CHARGE DEVICE.
TC-WC1
DEVICE
OUTPUT: 5V-1A; 9V-1.2A
QI STANDARD: VersionWPC1.2
CHARGING DISTANCE: 0-8mm
CHARGING EFFICIENCY: 75% MAX
To charge all Qi standard compatible devices,
connect to any USB charger. To fast charge
Samsung devices with adaptive fast wireless
charging, connect to an adaptive fast charge
wall charger (provided with some phone models).
Included Spanning
Tightening Tool
for final tightening.
