SECTION 1.0: INTRODUCTORY INFORMATION—LITTLE BRUTE RIGHT ANGLE PULLER
This instruction manual contains information on the operation and maintenance of the Little Brute Right Angle Puller (LBRA-7) designed by Fatigue
Technology Inc. (FTI) for use with the patented Split Sleeve Cold Expansion™ (SsCx™) process. To obtain optimum performance and many years of
trouble-free service, carefully follow maintenance procedures and operate the LBRA properly.
Read this manual before operating the LBRA, and retain the manual for future reference. If requested, FTI will provide this manual in the language of the
end-user.
The Little Brute Right Angle Puller is a compact, durable tool that enables coldworking in restricted access areas that are difficult or impossible to get to
with conventional tools.
•Is capable of cold expanding holes in restricted access areas up to 0.40-inch (10.16 mm) in diameter in aluminum and mild steel.
•Attaches to the Little Brute (LB) series of puller units. See the Little Brute Puller Unit Operations, Maintenance, and Repair Manual for additional
safety information.
•The Right Angle Puller alone weighs approximately 2.0 pounds (0.91 kg); with the Little Brute Puller Unit, it weighs approximately 12.0 pounds
(5.44 kg).
•Requires only 0.350-inch (8.89 mm) lateral clearance (see Figure 3.0-1).
•Head can rotate 360 degrees on the puller unit.
•Has a maximum pull force of 3,400 pounds (maximum generated by the Little Brute Puller Unit).
•The LBRA-10 is capable of much more pull force than the LBRA-7 and is physically larger. For high-force applications, an LBRA-10 may be better
suited. This manual only covers the LBRA-7 and does NOT apply to the LBRA-10.
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 2
SECTION 2.0: SAFETY
Safe operation of the LBRA is of paramount concern. Along with standard shop safety practices (eye protection, safe handling of high-pressure equipment,
etc.), the following items are peculiar to the LBRA/puller unit assembly:
1.Wear eye protection when operating the puller unit.
2.Disconnect the air supply when:
Maintenance is to be performed
Hydraulic hose is disconnected
PowerPak is not in use
3.Disconnect the LB Puller Unit from the PowerPak before attaching the LBRA.
4.Set the maximum operating pump pressure to 4,250 psi (29.31 MPa). Refer to the FT-200 PowerPak Operations, Maintenance, and Repair
Manual.
5.In the event of a ruptured or leaking hydraulic hose, IMMEDIATELY RELEASE THE TRIGGER AND DISCONNECT THE AIR LINE at the air
coupler from the PowerPak. Never use your hands to grasp a leaking hose under pressure. The force of escaping hydraulic fluid could cause serious
injury.
6. Keep hands away from the nosecap assembly while holding the nosecap against the workpiece.
7.Release the puller unit trigger when the mandrel clears the workpiece or becomes stuck.
8.The Little Brute end cap must always be in place while in use. Injury may occur if the end cap is removed during operation.
9.Before operating the pump, tighten all hose connections using the proper tools. Do not over-tighten the connections. Connections need only be
tightened securely and leak-free. Over-tightening may cause premature thread failure or high-pressure fittings to split at pressures lower than their
rated capacities.
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 3
10. Operators must read this manual in its entirety before using the Little Brute Right Angle Puller. Eye and ear protection must be worn while operating
the Little Brute. Three safety stickers on the Little Brute Puller Unit series act as a reminder to these instructions. The symbols are shown in Figure
2.0-1.
11. Do not use in potentially explosive atmospheres.
Read manual before using Always wear eye protection Always wear ear protection
Figure 2.0-1
Safety Stickers
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 4
Hydraulic Hose Safety
1. Inspect the hydraulic hose for signs of wear (cuts, abrasions, or kinks) to the outer shell material. Pump clean oil through the entire length.
Pressurize the hose and check for leaks at the crimped connectors, between the hose material and the fitting, and between the fitting and the coupler.
2.DO NOT attempt to disconnect the hydraulic hose while it is under pressure.
DO NOT expose hoses to potential hazards, such as extreme heat or cold, sharp surfaces, or heavy impact.
DO NOT allow hoses to kink, twist, curl, or bend so tightly that the oil flow within the hose is blocked or reduced. Periodically inspect the hose for
wear or damage that could cause premature failure of the hose and possibly result in injury. Damaged hoses must be replaced immediately.
DO NOT use the hose to move attached equipment.
DO NOT remove the strain reliever from hoses.
3.Hose strain relievers must be placed around hose fittings during use. Hoses with damaged strain relievers must be replaced immediately.
4.Hose material and coupler seals must be compatible with hydraulic fluid that meets the requirements of MIL-PRF-5606.
5.Hoses must not come in contact with toxic materials, such as creosote-impregnated objects and some paints. Keep couplers and hoses clean and free
of paint. Hose deterioration due to chemical degradation may cause the hose to fail under pressure. Damaged hoses must be replaced immediately.
6.Before operating the PowerPak, make sure all hose connections are tightened securely. DO NOT over-tighten.
7.If hoses require replacement, contact the FTI Sales Department.
IMPORTANT: FTI completed a risk assessment on this unit at our factory. Any modifications done by a third party or the final user are excluded from
that risk assessment.
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 5
SECTION 3.0: LBRA-7 SPECIFICATIONS AND DIMENSIONS
Figure 3.0-1
LBRA-7 Dimensions
Table 3.0-1
LBRA-7 Specifications
Model Number LBRA-7
Right Angle
Width [W]
0.80"
Adapter Length
[L]
5.55"
Frontside
Clearance [F]
3.0"
Maximum Pull
Force
3,400 Pounds
Minimum Edge
Distance
0.350"
Max Stackup:
4-0-N to 8-1-N
0.840"
Max Stackup:
8-2-N to 12-3-N
0.715"
Mandrel and Nosecap Selection
The LBRA uses special LBRA mandrels and nosecaps.
Refer to the FTI Tooling Catalog.
Nosecaps: Section 2.3.40
Mandrels: Section 2.3.22
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 6
SECTION 4.0: ASSEMBLY OF THE LBRA-7 ONTO A LITTLE BRUTE PULLER
To install the LBRA-7 onto the Little Brute puller:
CAUTION: Before attempting any maintenance operations on the puller unit disconnect the PowerPak from the air supply or disconnect the puller
from the PowerPak or hand pump.
1.Remove all tooling from the barrel end of the Little Brute.
2.Using a spanner wrench, loosen the lock ring on the back of the Little Brute and remove the endcap (Figure 4.0-1). A large flat screwdriver fits into
the slot on the back of the piston to keep it from rotating.
Figure 4.0-1
Little Brute Puller Unit, Endcap Removed
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 7
3. Ensure the threaded adapter, LB-D10, is attached to the piston rod of the LB puller unit (Figure 4.0-2). Tighten securely while using a large flat
screwdriver on the back of the Little Brute to keep the piston from rotating.
Figure 4.0-2
Little Brute Puller Unit and Threaded Adapter
LB-D10 Threaded Adapter
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 8
4. Thread the LBRA rod into the threaded adapter while using a large flat screwdriver on the back of the Little Brute to keep the piston from rotating
(Figure 4.0-3 - Top). Once the LBRA rod is fully threaded onto the unit, thread the LBRA end cap onto the male threads on the Little Brute Puller
Unit barrel. Re-install the Little Brute endcap and tighten the lock ring securely with a pinwrench. THE ENDCAP MUST BE IN PLACE DURING
OPERATION. The installation is now complete.
5. See Little Brute Manual for operation and use of assembled tooling.
Figure 4.0-3
LBRA-7, Installation Diagram
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 9
SECTION 5.0: ASSEMBLY AND MAINTENANCE
CAUTION: Before attempting any maintenance operations on the puller unit disconnect the PowerPak from the air supply or disconnect the puller
from the PowerPak or hand pump.
Refer to Figure 6.0-1 for identification of the components.
5. 1 Disassembly
1.To disassemble the LBRA-7, first remove it from the Little Brute. If a nosecap is mounted, take it off as well.
2.Remove the retaining ring (9) using retaining ring pliers (Figure 5.1-1). The end cap (10) can now be removed along with the O-ring (7) and
washer (8).
Figure 5.1-1
Retaining Ring Removal
3.Remove the two screws in the left half of the housing. The left housing can now be removed and the internal parts accessed for maintenance.
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 10
5.2 Cleaning and Lubrication
The puller requires routine checking and periodic preventative maintenance to ensure safe, trouble-free operation. No special maintenance is required. The
following maintenance actions are suggested.
1.Periodically clean the outer surfaces of the unit. Keep all hose connections free of dirt and grime. Doing so will dramatically extend the life of
pumps and puller seals.
2.The internal moving parts should be periodically lubricated with Mobil-HP or equivalent grease to ensure smooth operation and extend the life of
the unit (Figure 5.2-1).
Figure 5.2-1
Greased Internals
3.Whenever the puller unit is to be stored for any length of time, maintain a thin coat of 10-weight oil on the outside surfaces to prevent rusting.
Grease
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 11
5.3 Replacing Parts/Repair
If parts need replacing or the unit needs repair, please contact FTI’s Sales Department. FTI will work with the operator to try to troubleshoot over the phone,
but a return of the LBRA unit may be required.
5.4 Reassembly
1.Replace all internal components into the right half housing.
2.Attach the left housing half using the two screws.
3. Install the end cap (10), followed by the O-ring (7) and washer (8). Ensure that the O-ring and washer are fully seated all the way down.
4.Install the retaining ring (9) using retaining ring pliers. The O-ring must be compressed to fit the retaining ring on, so it may be necessary to tap
the retaining ring with a blunt pin until the ring is fully snapped into the groove.
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 12
SECTION 6.0: ILLUSTRATED PARTS BREAKDOWN
Adiagram is provided in Figure 6.0-1 and parts list in Table 6.0-1. The Little Brute Right Angle Puller Unit is compact and tight, and as a result, it could be
difficult to open and repair. Please contact FTI for any assistance.
Figure 6.0-1
LBRA-7 Illustrated Parts Breakdown
UNCONTROLLED IF PRINTED

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: [phone] Fax: [phone]
568209-REV C 13
Table 6.0-1
LBRA-7 Parts List
Item Number
Quantity
Part
Number Description
LBRA-7
LBRA-7-PC-12
LBRA-7-BH-1
LBRA-7-PC-8
1
1
1
-
1
5295-001
Housing Sub-Assembly
-
-
1
-
5295-002
2
1
1
1
1
5300-001
Pin, Roller
3
1
1
1
1
5299-001
Roller
4
1
1
1
1
5298-001
Adapter, Puller
5
1
-
1
-
5294-001
Adapter, Mandrel Link
-
1
-
-
5294-002
-
-
-
1
5294-003
6
1
1
1
1
5305-001
Chain
7
1
1
1
1
1046-120
O-Ring
8
1
1
1
1
5301-001
Washer, LBRA Tension
9
1
1
1
1
1045-366
Ring, External Retaining
10
1
1
1
1
5304-001
LBRA End Cap
11
2
2
2
2
1045-367
Dowel Pin
12
1
1
1
1
1009-185
Caution Label
13
1
1
1
1
1009-255
Pressure Label
14
1
1
1
1
1199-452
Case
15
1
1
1
1
1009-293
FTI Label
16
1
1
1
1
1009-307
LBRA-7 Label
17
1
1
1
1
2720-114
Manual, LBRA-7
18
1
1
1
1
1166-001
Label, CE
UNCONTROLLED IF PRINTED

E.C. DECLARATION OF CONFORMITY
Manufacturer: Fatigue Technology Inc.
401 Andover Park East
Seattle, WA 98188-7605
Telephone: [phone]
Fax: [phone]
Responsible Person in E.C.: Jean-Michel Derisson
4 rue d’Austerlitz
31490 Léguevin
FRANCE
Telephone: [phone]
Fax: [phone]
The undersigned declares that the machinery described:
Type:
Serial Number:
Conforms to the following directives:
Council Directive 2006/42/EC (the Machinery Directive)
ISO 11148-1 Hand-Held Non-Electric Power Tools – Safety Requirements – Part 1
ISO 4413 Hydraulic fluid power – General rules and safety requirements for
systems and their components
ISO 4414 Pneumatic fluid power – General rules and safety requirements for
systems and their components
And complies with the relevant health and safety requirements.
4/25/19
Jeff Sageman Date
Logistics Manager
FATIGUE TECHNOLOGY INC.
401 Andover Park East
Seattle, Washington 98188-7605
USA
