FTS CHARPYCOOL User manual

LOW-TEMPERATURE BATH OPERATOR’S MANUAL
FTS S YSTEMS C HARPY C OOL ™
Specimen Temperature Conditioning Bath

Rev 001, 01/12 i
© SP Scientific 2012
Copyright © 2012 SP Scientific. All marks herein are used under license.
All brand or product names mentioned may be trademarks or registered trademarks of their respective
companies.
Part Number 100006072
Rev 001, 01/12
Original Instructions
The U.S. English version of this document is the original instructions.
All other languages are a translation of the original instructions.
SP Scientific
815 State Route 208
3538 Main Street
Gardiner, NY 12525 USA Stone Ridge, NY 12484
USA
[phone]
[phone]
SP Scientific Service
[phone]
SP Scientific Service Fax
[phone]
Website
http://www.spscientific.com/
This Low-Temperature Bath Operator’s Manual contains confidential and proprietary information of SP
Scientific and may be used only by a recipient designated by and for purposes specified by SP Scientific.
Reproduction of, dissemination of, modifications to, or the creation of derivative works from this Low-
Temperature Bath Operator’s Manual, by any means and in any form or manner, is expressly prohibited,
except with the prior written permission of SP Scientific. Permitted copies of this document must retain all
proprietary notices contained in the original.
The information in this document is subject to change without prior notice. Always confirm with SP
Scientific that you are using the most current version of this document. SP Scientific is free to modify any
of its products and services, in any manner and at any time, notwithstanding the information contained in
this document.
THE CONTENTS OF THIS DOCUMENT SHALL NOT CONSTITUTE ANY WARRANTY OF ANY KIND,
EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE OR GIVE RISE TO ANY
LIABILITY OF SP SCIENTIFIC, ITS AFFILIATES OR ITS SUPPLIERS.
The terms and conditions governing the use of this Low-Temperature Bath Operator’s Manual shall
consist of those set forth in written agreements with SP Scientific.

ii Rev 001, 01/12
© SP Scientific 2012
Important Symbols
WARNING! INJURY OR EVEN
DEATH MAY RESULT IF A
RECOMMENDATION MARKED
WITH THIS SYMBOL IS NOT
HEEDED.
CRUSH HAZARD. KEEP HANDS
CLEAR WHEN OPERATING DOOR.
ELECTRIC SHOCK DANGER!
USE APPROPRIATE CAUTION
TO AVOID INJURY OR DEATH.
CORROSIVE CHEMICAL. WEAR
SUITABLE GLOVES, SAFETY
GLASSES, AND PROTECTIVE
CLOTHING.
BURN DANGER! POTENTIALLY
HOT SURFACE. USE
APPROPRIATE CAUTION.
PROPERTY CAUTION! TO PREVENT
DAMAGE TO CHAMBER EQUIP-
MENT AND/OR LOAD, ADHERE TO
PROCEDURES MARKED BY THIS
SYMBOL.
DO NOT STORE FLAMMABLE
MATERIALS IN CHAMBER.
PRACTICAL OPERATING TIP.
THESE RECOMMENDATIONS
STREAMLINE UNIT OPERATION
AND PREVENT COMMON
OPERATOR ERRORS.
WEAR SAFETY GLASSES.
EXPLOSIVE MATERIALS HAZARD!
KEEP OBJECTS AWAY FROM HEAT.
Safety Warnings
Always transport the unit with care. Sudden jolts or drops may damage the refrigeration system.
Always observe all warning labels.
Always turn off the unit and disconnect the line cord from the available power source prior to performing anyservice or maintenance procedures.
Always turn off the unit and disconnect the line cord from the available power source prior to moving the unit.
Always empty the reservoir / reservoir prior to moving the unit.
Never operate equipment with damaged line cords.
Never operate the unit without cooling fluid in the reservoir.
Never remove warning labels.
Never operate damaged or leaking equipment.

Rev 001, 01/12 iii
© SP Scientific 2012
Warranty Information
FTS Systems CharpyCool™ low temperature baths are warranted by SP Scientific to be free of defects in material and
workmanship when operated under normal conditions as specified in the instructions provided in this manual. Please
take this opportunity to locate the serial tag on your new FTS Systems CharpyCool™ and record the information below
for future reference. SP Scientific also recommends that you complete and return your unit’s warranty registration card.
Model Number
Serial Number
Part Number
Limited Warranty
SP Scientific (the “Company”) shall warrant each of its products against defects in material or workmanship for a period
of 12 months from the date of shipment provided that the product is used in a reasonable manner under appropriate
conditions and consistent with the applicable operating instructions.
The obligation of the Company shall be, at its option, to repair or replace, without charge any parts that prove to be
defective within the warranty period, if the purchaser notifies the Company promptly in writing of such defect. No
product shall be returned to the Company without prior approval of the Company.
This limited warranty shall cover the costs of parts and labor to repair or replace all defective product(s) at the Seller’s
factory. For all products installed by the Company and located within the Company service travel areas, this warranty
shall cover transportation charges to ship the product to and from the Company’s factory and/or the costs of travel,
room and board if the Company’s employees conduct repair at the Buyer’s location. In lieu of repair or replacement at
the Company’s factory, the Company may, in its discretion, authorize a third party to perform the repair or replacement
at the Buyer’s location, and at the Company’s sole expense.
The Company shall not be responsible for labor charges payable with respect to persons other than Company
employees. Replacement or repair of parts pursuant to this warranty shall not in any way extend the original warranty
period. The Company shall not be responsible for any unauthorized repairs, replacements or product modifications, nor
will it be responsible for any product failures resulting from such unauthorized repairs, replacements or product
modifications negligently or otherwise made by persons other than Company employees or authorized representatives
of the Company. The buyer shall assume transportation charges to ship the product to and from the Company’s factory
and the costs of travel, room and board if the Company’s employees conduct repair at the Buyer’s location within the
warranty period if the product was not installed by the Company’s and/or is not located within the Company’s service
travel areas.
THE COMPANY DOES NOT MAKE AND EXPRESSLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, WITH
RESPECT TO THE SALE, INSTALLATION, DESIGN OR USE OF ITS PRODUCTS. ADDITIONALLY, THE
COMPANY SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF OR
ANY DEFECTS IN ITS PRODUCTS.
The Company’s employees are available to provide general advice to customers concerning the use of the Company’s
products; however, oral representations are not warranties with respect to particular products or their uses and may not
be relied upon if they are inconsistent with the relevant product specifications for the items set forth herein.
Notwithstanding the above, the terms and conditions set forth in the Company’s formal sales contracts shall be
controlling and supersede any inconsistent terms contained herein, and any changes to such contracts must be made
in writing and signed by an authorized executive of the Company.
WARNING! THE DISPOSAL AND/OR EMISSION OF SUBSTANCES USED IN CONNECTION WITH
THIS EQUIPMENT MAY BE GOVERNED BY VARIOUS FEDERAL, STATE OR LOCAL
REGULATIONS. ALL USERS OF THIS EQUIPMENT ARE URGED TO BECOME FAMILIAR WITH
ANY REGULATIONS THAT APPLY IN THE USERS AREA CONCERNING THE DUMPING OF
WASTE MATERIALS IN OR UPON WATER, LAND OR AIR AND TO COMPLY WITH SUCH
REGULATIONS.

iv Rev 001, 01/12
© SP Scientific 2012

Rev 001, 01/12 v
© SP Scientific 2012
Contents
Important Symbols...............................................................................................................................................ii
Safety Warnings...................................................................................................................................................ii
Warranty Information .......................................................................................................................................... iii
Introduction .................................................................................................................1
Overview..............................................................................................................................................................1
Key Features...................................................................................................................................................1
Key Benefits....................................................................................................................................................2
CharpyCool™ Overview ......................................................................................................................................2
Installation...................................................................................................................3
Initial Inspection...................................................................................................................................................3
Installation............................................................................................................................................................4
Air Flow Considerations...................................................................................................................................4
Ambient Conditions .........................................................................................................................................4
Services and Utilities.......................................................................................................................................4
Installing the Magnetic Stirrer and Vortex Breaker ..........................................................................................5
Operation ....................................................................................................................7
Overview..............................................................................................................................................................7
Operation.............................................................................................................................................................7
Powering On....................................................................................................................................................7
The Solo Controller .........................................................................................................................................8
Display and Indicators.....................................................................................................................................8
Adjusting Bath Temperature............................................................................................................................8
Magnetic Stirrer...............................................................................................................................................9
Powering Off....................................................................................................................................................9
Restarting.............................................................................................................................................................9
Fluid..........................................................................................................................11
Fluid Options and Selected Properties...............................................................................................................11
Fluid Filling.........................................................................................................................................................12
Magnetic Stirrer.............................................................................................................................................12
Maintenance .............................................................................................................13
Cleaning.............................................................................................................................................................13
Condenser.....................................................................................................................................................13
Bath System..................................................................................................................................................13

Contents
FTS Systems CharpyCool™
vi Rev 001, 01/12
© SP Scientific 2012
Compressor Safeties .........................................................................................................................................14
Refrigerant Types and Properties..................................................................................................................14
Refrigeration System.....................................................................................................................................14
Voltage..........................................................................................................................................................15
Accessories...............................................................................................................17
Charpy Rack Accessories, CRA-4 and CRA-8...................................................................................................17
Lifting Charpy Racks Using the Lifting Handle ..............................................................................................17
Appendix A: Troubleshooting....................................................................................19

Rev 001, 01/12 1
© SP Scientific 2012
Chapter
1
Introduction
Overview The FTS Systems CharpyCool™ delivers rapid cooling capabilities, as well as
continuous operation at temperatures as low as -112 °F (-80 °C). Built to provide you
with years of smooth, quiet and reliable operation, the FTS Systems CharpyCool™
packs both performance and innovation into a compact, bench-top design.
Utilizing a liquid medium, the FTS Systems CharpyCool™ rapidly and thoroughly
chills samples without the use of expendables such as dry ice or liquid nitrogen
(N2(liq)).
The FTS Systems CharpyCool™ includes temperature control and also includes a
variable speed-controlled magnetic stirrer to provide more accurate temperature
control and uniformity. The CharpyCool™ features an air-cooled refrigeration system
and stainless steel reservoir.
THE FLUID AND INNER WALLS OF THE RESERVOIR CAN REACH TEMPERATURES BELOW
-130 °F (-90 °C). EXTREMELY LOW TEMPERATURES CAN CAUSE SERIOUS AND
IMMEDIATE DAMAGE TO SKIN. THE ABSENCE OF FROST IN UNITS EQUIPPED WITH THE
FROST ISOLATING WARMING LOOP SHOULD NOT BE MISTAKEN AS AN INDICATION OF
WARM TEMPERATURE. DESPITE THE ABSENCE OF FROST, THE TEMPERATURE OF THE
RESERVIOR FLUID AND WALLS MAY BE DANGEROUSLY LOW.
THE FTS SYSTEMS CHARPYCOOL™ IS NOT INTENDED FOR USE WITH EXTREMELY
FLAMMABLE FLUIDS SUCH AS ISOPENTANE (C5H12).
Key Features
Quiet operation.•
Mechanically refrigerated, no expendable refrigerants utilized.•
Compact, bench-top design with 4 or 8 liter stainless steel reservoir.•
Lift-off lid for easy bath access.•

Introduction
FTS Systems CharpyCool™
2 Rev 001, 01/12
© SP Scientific 2012
Key Benefits
Easy bath access.•
Liquid medium to increase temperature uniformity and stability.•
CharpyCool™ Overview
The FTS CharpyCool™ is designed for cooling Charpy samples. This unit includes a
cascade refrigeration system and an on/off breaker switch. The CharpyCool™ also
features the Solo microprocessor controller, which provides precise temperature
control within ± 0.18 °F (± 0.1 °C) across the full operating temperature range of
-112 °F to 86 °F (-80 °C to 30 °C).1
When powered on, the CharpyCool™’s refrigeration system will activate. After
approximately two (2) minutes, the green Chill light illuminates to indicate that the
second stage compressor is active.
The FTS CharpyCool™ is also equipped with a solid-state variable speed-controlled
magnetic stirrer to provide more accurate temperature control and uniformity.
1The FTS Systems CharpyCool™ offers continuous operation at temperatures as low as -112 °F (-80 °C). Lowest possible
temperatures may be dependent upon the selected bath fluid, as well as ambient conditions and airflow.
CharpyCool™
Breaker Switch
“Chill”
Indicator LED
Lift-Off Reservoir Lid
Fluid Stir Control Dial
Solo Microprocessor
Controller

Rev 001, 01/12 3
© SP Scientific 2012
Chapter
2
Installation
Initial Inspection
Your FTS Systems CharpyCool™ low-temperature bath was carefully packed and
thoroughly inspected before leaving the SP Scientific factory. However, in the unlikely
event that shipping damage has occurred, retain all packing material and contact your
freight carrier immediately.
DO NOT ACCEPT DAMAGED SHIPMENTS FROM A CARRIER WITHOUT A SIGNED
NOTIFICATION OF DAMAGES.
Upon receiving your shipment, inspect all contents of your equipment for damage.
Uncrate and/or unwrap the unit. Carefully remove all packing material from the unit
and inspect for visible damage. Check packing material for small accessory items and
retain shipping carton and packing material if possible. Inspect the inside of the unit
and related parts for visible damage and leaks. Check for visible liquid at or near the
base of the unit. The reservoir should be clean and dry.
If concealed damage or loss is discovered, contact the freight carrier immediately.2
Keep all contents, packing material and related paperwork intact until a written report
is obtained.
Note: SP Scientific will cooperate in the matter of collecting your claim, but is not responsible
for the collection or free replacement of the material. When possible, replacement parts will be
shipped and invoiced to you, making them a part of your claim.
2“Concealed damage or loss” refers to damage or loss that does not become apparent until the merchandise has been
unpacked and inspected. Should damage or loss be discovered, you may make a written request for inspection by the carrier's
agent within 15 days of the delivery date. You may then file a claim with the freight carrier or SP Scientific, depending on the
terms of your shipment. If your shipment was “FOB Destination” file your claim with SP Scientific and include the inspection
report and any other supporting documents. If your shipment was “FOB Shipping Point” file your claim with the freight carrier
and include the inspection report and any other supporting documents.

Installation
FTS Systems CharpyCool™
4 Rev 001, 01/12
© SP Scientific 2012
Installation
The FTS Systems CharpyCool™ is designed for bench-top installation in a laboratory
environment. The unit should be installed on a firm, level surface in a location that is
convenient for both operation and service.
NEVER PLACE THE UNIT IN AN AREA WHERE EXCESSIVE HEAT, MOISTURE OR CORROSIVE
MATERIALS ARE PRESENT.
Air Flow Considerations
The FTS Systems CharpyCool™ is equipped with an air-cooled refrigeration system.
Air is pulled from the left side of the unit to cool the refrigeration system components
and then exits the rear panel. When positioning your system, ensure that it is located
on a firm, level surface in an area that provides adequate air circulation.
Inadequate airflow will degrade the unit’s cooling capacity and in extreme cases may
result in compressor failure. A minimum of six (6) inches of clearance on all sides of
the unit is required to ensure proper airflow and avoid damage to the refrigeration
system.
Ambient Conditions
For best low-temperature operation, consider that the ideal ambient temperature for
your FTS Systems CharpyCool™ is approximately 72 °F (22 °C). Higher ambient
temperatures will limit the system’s ability to achieve its ultimate low temperature.
NEVER OPERATE THE FTS SYSTEMS CHARPYCOOL™ IN AN AREA WITH AN AMBIENT
TEMPERATURE ABOVE 90 °F (32 °C).
Services and Utilities
The FTS Systems CharpyCool™’s serial tag, which is located on the unit’s back
panel, provides the unit serial number, and electrical requirements. Ensure that the
voltage, phase, frequency and amperage listed on the serial tag match your facility’s
available power supply (e.g., as a minimum the power outlet you intend to use must
meet the requirements listed on the serial tag).
CAUTION! IF YOU ARE UNSURE ABOUT THE AVAILABLE ELECTRICAL VOLTAGE SUPPLY IN
YOUR FACILITY, CONSULT A QUALIFIED ELECTRICIAN.
Prior to connecting your FTS Systems CharpyCool™ to the available electrical supply,
ensure that the Main Power switch is in the Off position. You may connect the unit to
the available electrical supply at this time.

FTS Systems CharpyCool™
Installation
Rev 001, 01/12 5
© SP Scientific 2012
Installing the Magnetic Stirrer and Vortex Breaker
The FTS CharpyCool™ is equipped with a solid-state variable speed-controlled
magnetic stirrer and a vortex breaker to provide more accurate temperature control
and uniformity. To install the magnetic stirrer and vortex breaker:
Remove the packaging washers from the inside of the stainless steel1. reservoir and from the bottom of the magnetic stirrer. These washers are
placed on the magnetic components of the unit for shipping purposes only
and are intended to be removed prior to operation.
Place the magnetic stirrer, magnet side down, into the center of the reservoir.2. (Pushing the edges of the stirring mechanism beyond the black gasket at the
top of the reservoir may require some force.) As you lower the magnetic
stirrer into place, be careful not to bend or tweak the metal temperature probe
that hangs inside the reservoir.
Note: The screws on top of the magnetic stirrer should not come in contact with the
sides of the bath as you place the magnetic stirrer into the reservoir. If they do, retract
them using your fingers or a screwdriver.
Packaging Washer in Reservoir
Packaging Washer on Bottom of
Magnetic Stirrer
Temperature
Probe
Reservoir (Top View)
Magnetic Stirrer (Bottom View)

Installation
FTS Systems CharpyCool™
6 Rev 001, 01/12
© SP Scientific 2012
Once the stirrer assembly is in place, adjust the four holding screws by hand3. so that each screw lightly touches the side of the reservoir. Then, use a
screwdriver to further extend each screw so that the stirrer is held snugly in
place in the center of the reservoir. Be sure that all screws are extended to
the same length; this will keep the stirrer assembly centered in the bath.
Hold the vortex breaker by its metal handle (a small tab, bent 90° at the tip)4. and place it into the reservoir so that it rests evenly on top of the magnetic
stirrer. (Pushing the edges of the vortex breaker beyond the black gasket at
the top of the reservoir may require some force.)
Magnetic Stirrer in Reservoir
Holding Screws
Holding Screws
Temperature Probe
Reservoir (Top View)
Reservoir (Top View)
Magnetic Stirrer and Vortex Breaker
Assembled in Reservoir
Vortex Breaker Handle
Temperature Probe

Rev 001, 01/12 7
© SP Scientific 2012
Chapter
3
Operation
Overview The FTS CharpyCool™ offers a continuous display of temperatures in 0.1 degree
increments and is capable of controlling temperatures within ± 0.18 °F (± 0.1 °C)
across the equipment’s full operating temperature range.
Operation
Powering On
Note: Before powering on and cooling, install the magnetic stirrer and vortex breaker (as
described in Chapter 2) and fill the reservoir with fluid (as described in Chapter 4).
To activate the refrigeration system:
Toggle the on/off breaker switch to the On position.1.
Main Breaker

Operation
FTS Systems CharpyCool™
8 Rev 001, 01/12
© SP Scientific 2012
The Solo Controller
The CharpyCool™ includes a proportional-integral-derivative (PID) microprocessor
controller. The Solo controller features a bright, two-line, two-color, seven segment
LED readout.
Display and Indicators
Process Value (PV) Display
Displays the current fluid temperature in the bath.
Set Value (SV) Display
Displays the desired fluid temperature.
Adjusting Bath Temperature
Press the Up and/or Down buttons to increase and decrease the fluid1. temperature shown on the SV Display.
Press the Set button to select the displayed value.2.
Set Button
Process Value (PV)
Display
Set Value (SV) Display
Rotate Button
Up Button
Down Button
Status Indicator Area

FTS Systems CharpyCool™
Operation
Rev 001, 01/12 9
© SP Scientific 2012
Magnetic Stirrer
To operate the magnetic stirrer:
Activate the magnetic stirrer by rotating the Fluid Stir Control Dial clockwise.1.
Adjust the rotational speed of the stirrer by turning the Fluid Stir Control Dial2. clockwise (to increase the speed) and/or counterclockwise (to decrease the
speed).
To deactivate the stirrer, rotate the Fluid Stir Control Dial counterclockwise.3.
The magnetic stirrer may be turned on or off at any time for procedural purposes, but
in general, the unit should not be operated without stirring. If the reservoir fluid is not
agitated, the fluid may exhibit thermal variations. SP Scientific recommends setting
the Fluid Stir control dial to its maximum speed at all times for optimal operation and
performance.
Note: Do not operate the magnetic stirrer without fluid in the reservoir.
Powering Off
To power off the CharpyCool™:
Toggle the on/off breaker switch to the Off position.1.
The green indicator light will turn off and the CharpyCool™’s refrigeration2. system compressor(s) will stop.
Note: When the CharpyCool™ is not in use, ensure that the bath reservoir lid is closed to
prevent evaporation of the cooling fluid.
Restarting Due to the nature of the refrigeration system and its compressor, the CharpyCool™
should never be restarted immediately after it is powered off. SP Scientific
recommends waiting approximately five (5) minutes between shutting down and
restarting the CharpyCool™.
Fluid Stir Control Dial

Operation
FTS Systems CharpyCool™
10 Rev 001, 01/12
© SP Scientific 2012

Rev 001, 01/12 11
© SP Scientific 2012
Chapter
4
Fluid
Selecting a fluid or fluid mixture for use in your FTS Systems CharpyCool™ is the
single most important decision to be made. Always select a fluid that is appropriate for
the temperature and/or temperature range at which you will operate your system.
Improperly selected fluid can result in damage to both your process and your
equipment.
Refer to the following table for a list of fluids that may be used with the FTS Systems
CharpyCool™.
CAUTION: BEFORE USING ANY FLUID PRODUCT, READ THE CURRENT PRODUCT
MATERIAL SAFETY DATA SHEET AND ANY PRECAUTIONARY STATEMENTS ON THE
PRODUCT PACKAGE. FOLLOW ALL APPLICABLE PRECAUTIONS AND DIRECTIONS.
Fluid Options and Selected Properties
Fluid Temperature Range
(°C) Flammability Toxicity Dielectric
3M™ Novec™ 7000
3
-120 to 30
None
Very Low
High
Methanol
-80 to 0
Medium
Low
Low
Glycol/Water 60/40
-30 to 60
Low
Low
Low
Glycol/Water/Methanol 60/30/10
-50 to 30
Low
Low
Low
Ethanol
-60 to 0
Medium
Medium
Low
Syltherm XLT (HT-30)
-60 to 200
Low
Very Low
High
Silicone 1.0
-55 to 200
Low
Very Low
High
Galden D02
-50 to 160
None
Very Low
Very High
D80
-65 to 70
None
Very Low
Very High
1.8
-40 to 100
None
Very Low
Very High
Fluorinert PF -5050
-80 to 20
None
Very Low
Very High
PF-5060
-75 to 65
None
Very Low
Very High
FC-77
-50 to 75
None
Very Low
Very High
FC-72
-80 to 35
None
Very Low
Very High
FC-40
-10 to 140
None
Very Low
Very High
3Before using this product, read the current product Material Safety Data Sheet and any precautionary statements on the
product package. Follow all applicable precautions and directions.

Fluid
FTS Systems CharpyCool™
12 Rev 001, 01/12
© SP Scientific 2012
Fluid Filling
While operating at or above ambient temperature (approximately 72 °F or 22 °C), fill
the reservoir with your selected fluid until the fluid is about 1 inch below the gasket.
If you add fluid while the system is at a sub-ambient temperature and you fail to drain
fluid before returning the system to room temperature, the fluid may expand and
overflow the fluid reservoir.
Notes: Fluids will typically contract when cooled and expand when heated.
The gasket at the top of the fluid reservoir does not provide a liquid tight seal.
If the fluid reservoir chamber is overfilled, the liquid will flow over the rim of the fluid
reservoir into the polyurethane insulation. Organic solvents will attack, dissolve and/or
render ineffective the chamber insulation. When the insulation is saturated with
solvent, the CharpyCool™ may be unable to reach its maximum low temperature.
IF THE RESERVOIR IS OVERFILLED, THE FLUID MAY OVERFLOW THE RESERVOIR RIM AND
SEEP INTO THE POLYURETHANE INSULATION. ORGANIC SOLVENTS WILL ATTACK AND
DAMAGE THIS INSULATION MATERIAL, RENDERING THE INSULATION INEFFECTIVE.
WITHOUT ADEQUATE INSULATION, THE CHARPYCOOL™ WILL NOT REACH MAXIMUM LOW
TEMPERATURES.
Magnetic Stirrer
You may switch on your magnetic stirrer once the reservoir has been properly filled
with fluid. The magnetic stirrer must be on for the system to operate properly. Refer to
the magnetic stirrer operation section of the previous chapter for additional
information.
Note: Do not operate the magnetic stirrer without fluid in the reservoir. Be sure the stirrer is
turned off before emptying fluid from the reservoir.
