Fuji Electric MONITOUCH TS Series User manual

Record of Revisions
Reference numbers are shown at the bottom left corner on the back cover of each manual.
Printing Date Reference No. Revised Contents
April, 2013 2022NE0 First edition

Preface
Thank you for selecting the Techno Shot series (TS series).
For correct set-up of the TS series, you are requested to read through this manual to understand more about the
product.
The manuals shown below are related manuals for the TS series. Refer to them as necessary.
For further details about controllers (PLCs, temperature controllers, etc.), refer to the manual issued by each
controller manufacturer.
Manual Name Contents Reference No.
TS Series Training Manual Screen configuration procedures using V-SFT
version 5 are explained with examples.
1203NE
TS Series Connection Manual Connecting the TS series with controllers and
setting their communication parameters are
explained.
2203NE
V8 Series Reference Manual The functions and instructions of the V8 series are
explained.
1055NE
V8 Series Reference: Additional Functions Additional functions and operations of the V8
series that are available with V-SFT version
5.1.0.0 and later are explained.
1060NE
V Series Macro Reference An overview of macros as well as macro editor
operations and macro command descriptions are
explained in detail.
1056NE
V8 Series Operation Manual Information related to the operations of V-SFT
version 5, such as software composition, editing
procedure or limitations, is explained.
1058NE
Notes:
1. This manual may not, in whole or in part, be printed or reproduced without the prior written consent of
Hakko Electronics Co., Ltd.
2. The information in this manual is subject to change without prior notice.
3. Windows and Excel are registered trademarks of Microsoft Corporation in the United States and other
countries.
4. All other company names or product names are trademarks or registered trademarks of their
respective holders.
5. If the specifications of the software do not correspond with the contents of this manual, the software
specifications have priority.

Notes on Safe Usage of TS Series
In this manual, you will find various notes categorized under the following levels with the signal words “DANGER”
and “CAUTION”.
Note that there is a possibility that the item listed with may have serious ramifications.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury and could cause property damage.
•Never use the output signal of the TS series for operations that may threaten human life or damage the
system, such as signals used in case of emergency. Please design the system so that it can cope with the
malfunctions of a touch switch. A malfunction of a touch switch will result in machine accident or damage.
•Turn off the power supply when you set up the unit, connect new cables or perform maintenance or
inspections. Otherwise, electrical shock or damage may occur.
•Never touch any terminals while the power is on. Otherwise, electric shock may occur.
•The liquid crystal in the LCD panel is a hazardous substance. If the LCD panel is damaged, do not ingest
the leaked liquid crystal. If the liquid crystal spills on skin or clothing, wash off thoroughly with soap.
•Never disassemble, recharge, deform by pressure, short-circuit, reverse the polarity of the lithium battery,
nor dispose of the lithium battery in fire. Failure to follow these conditions will lead to explosion or ignition.
•Never use a lithium battery that is deformed, leaks, or shows any other signs of abnormality. Failure to
follow these conditions will lead to explosion or ignition.
CAUTION
DANGER

•Check the appearance of the unit when it is unpacked. Do not use the unit if any damage or deformation is
found. Failure to do so may lead to fire, damage or malfunction.
•For use in a facility or for a system related to nuclear energy, aerospace, medical, traffic equipment, or
mobile installations, please consult your local distributor.
•Operate (or store) the TS series under the conditions indicated in this manual and related manuals. Failure
to do so could cause fire, malfunction, physical damage or deterioration.
•Understand the following environmental limits for use and storage of MONITOUCH. Otherwise, fire or
damage to the unit may result.
- Avoid locations where there is a possibility that water, corrosive gas, flammable gas, solvents, grinding
fluids or cutting oil can come into contact with the unit.
- Avoid high temperature, high humidity, and outside weather conditions, such as wind, rain or direct
sunlight.
- Avoid locations where excessive dust, salt, and metallic particles are present.
- Avoid installing the unit in a location where vibration or physical shock may be transmitted.
•Equipment must be correctly mounted so that the main terminal of the TS series will not be touched
inadvertently. Otherwise, an accident or electric shock may occur.
•Check periodically that terminal screws on the power supply terminal block and nuts are firmly tightened.
Loosened screws or nuts may result in fire or malfunction.
•Tighten terminal screws on the power supply terminal block equally to a torque of 0.5 to 0.6 N•m (5 to
6 kgf•cm). Improper tightening of screws may result in fire, malfunction, or other serious trouble.
•Tighten the nuts on the TS series equally to the specified torque. Excessive tightening may distort the panel
surface. Loose tightening may cause the unit to come off, malfunction or be short-circuited.
•The TS series has a glass screen. Do not drop or give physical shock to the unit. Otherwise, the screen
may be damaged.
•Connect the cables correctly to the terminals of the TS series in accordance with the specified voltage and
wattage. Over-voltage, over-wattage, or incorrect cable connection could cause fire, malfunction or damage
to the unit.
•Be sure to establish a ground of the TS series. The FG terminal must be used exclusively for the unit with
the level of grounding resistance less than 100 Ω. Otherwise, electric shock or a fire may occur.
•Prevent any conductive particles from entering into the TS series. Failure to do so may lead to fire, damage,
or malfunction.
•Do not attempt to repair the TS series at your site. Ask Hakko Electronics or the designated contractor for
repair.
•Do not repair, disassemble or modify the TS series. Hakko Electronics Co., Ltd. is not responsible for any
damages resulting from repair, disassembly or modification of the unit that was performed by an
unauthorized person.
•Do not use a sharp-pointed tool when pressing a touch switch. Doing so may damage the screen.
•Only experts are authorized to set up the unit, connect the cables or perform maintenance and inspection.
•Lithium batteries contain combustible material such as lithium or organic solvents. Mishandling may cause
heat, explosion or ignition resulting in fire or injury. Read related manuals carefully and handle the lithium
battery correctly as instructed.
•Do not press two or more positions on the screen at the same time. If two or more positions are pressed at
the same time, the switch located between the pressed positions may be activated.
•Take safety precautions during such operations as setting change during running, forced output, start, and
stop. Any misoperation may cause unexpected machine motions, resulting in machine accident or damage.
•In facilities where a failure of the TS series could lead to accident threatening human life or other serious
damage, be sure that the facilities are equipped with adequate safeguards.
•At the time of disposal, the TS series must be treated as industrial waste.
•Before touching the TS series, discharge static electricity from your body by touching grounded metal.
Excessive static electricity may cause malfunction or trouble.
CAUTION

[General Notes]
•Never bundle control cables nor input/output cables with high-voltage and large-current carrying cables such
as power supply cables. Keep these cables at least 200 mm away from the high-voltage and large-current
carrying cables. Otherwise, malfunction may occur due to noise.
•When using the TS series in an environment where a source of high-frequency noise is present, it is
recommended that the FG shielded cable (communication cable) be grounded at its ends. However, the cable
may be grounded only at one end if this is necessary due to unstable communication conditions or for any
other reason.
•Plug connectors or sockets of the TS series in the correct orientation. Failure to do so may lead to damage or
malfunction.
•Do not use thinners for cleaning because they may discolor the TS series surface. Use alcohol commercially
available.
•If a data receive error occurs when the TS series and the counterpart (PLC, temperature controller, etc.) are
started at the same time, read the manual for the counterpart unit and remove the error correctly.
•Avoid discharging static electricity on the mounting panel of the TS series. Static charges can damage the unit
and cause malfunctions. Otherwise, malfunction may occur due to noise.
•Avoid prolonged display of any fixed pattern. Due to the characteristic of liquid crystal displays, an afterimage
may occur. If prolonged display of a fixed pattern is expected, use the auto OFF function of the backlight.
[Notes on LCD]
Note that the following conditions may occur under normal circumstances.
•The response time, brightness and colors of the TS series may be affected by the ambient temperature.
•Tiny spots (dark or luminescent) may appear on the display due to the liquid crystal characteristics.
•Each unit varies slightly with respect to brightness and colors.
