fuji impulse P-200 User manual

POLY
SEA
LER
PC-200
5
3
6
7
8
10
9
4
2
1
19110 P-200 lever set 1set
18887 P-200 lever R, L 1set
19120 P-200 lever knob 1
19180
B tight, pan-head screw 4X16 2/set
18200 P-200 center pin φ5X14 1
110400 P-200 pressure lever spring 2/set
110500 P-200 lever pivot bracket 1set
17500 P-200 silicone rubber 7x210 1
19100 P-200 lever pivot set 1set
19130 P-200 lever receiver 1
18100 P-200 switch lever 1
17900 P-200 fulcrum pin φ6X43 1
18883 P-200 return spring SUS 1
19170 B1 tapping screw 4X12 2/set
18885 P-200 frame set 1set
18886 Lamp cover (red) # 1
18881 SUS pan-head screw 4X6 # 2/set
18300 P-200 base set 1set
110800 Rubber feet # 4/set
19210 S tight pan-head screw 4X16 # 4/set
18800 P-200 fluoro glass sheet retainer 1set
18860 Fluoro glass sheet retainer locks # 4/set
18820 P-200 electrode bracket 1set
- Power cord # 1
- P-200 transformer 1
- Timer Assy # 1
18730 Timer dial # 1
- P-200 noise filter 1
110100 Rubber collar 1
110120 Transformer holder 2/set
110110 Cord hole plug # 1
133427 Noise filter insulation sheet # 1
130106 P-300 lever set 1set
130100 P-300 lever R, L 1set
130200 P-300 lever knob 1
-
S tight, pan-head screw 5X16 -
-
S tight, pan-head screw 4X25 -
130500 P-300 pressure lever spring 2/set
17040 P-300 lever pivot bracket 1set
17400 P-300 silicone rubber 9.5x310 1
130812 P-300 lever pivot set 1set
130800 P-300 lever receiver 1
130900B P-300 switch lever 1
131000 P-300 fulcrum pin φ8X55 1
131100 P-300 return spring SUS 1
- Flat-head screw 4X12 -
131314B P-300 frame set 1set
18886 Lamp cover (red) # 1
18881 SUS pan-head screw 4X6 # 2/set
131820 P-300 base set 1set
110800 Rubber feet # 4/set
19210 S tight pan-head screw 4X16 # 4/set
132100 P-300 fluoro glass sheet retainer 1set
18860 Fluoro glass sheet retainer locks # 4/set
132510 P-300 electrode bracket 1set
- Power cord # 1
- P-300 transformer 1
- Timer Assy # 1
18730 Timer dial # 1
- P-300 noise filter 1
136010 Transformer holder 1
110110 Cord hole plug # 1
134000 Lever bracket spacer φ4X12 1
133427 Noise filter insulation sheet # 1
No. Code Sales Unit Parts Name No. Code Sales Unit
Parts Name
19150 PC-200 lever set 1set
19140 PC-200 lever R, L 1set
110600 PC-200 cutter guide 1
110700 Cutter knob 1
17800 Cutter blade 1
18000 PC-200 sponge pad 1
18840 PC-200 fluoro glass sheet retainer 1
No. Code Sales Unit Parts Name
15005 Sarcon sheet 6x220 for P/PC-200 2/set
17005 Sarcon sheet 6x320 for P/PC-300 2/set
39411 Glass tape 13mmx5M # 5m roll
39412 Glass tape13mmx10M # 10m roll
15006B PS-210/P-200 fluoro glass sheet 10/set
17110B P-300/PS-310 fluoro glass sheet 10/set
17700 Microswitch # 1
59001 Heating element P-200-2 10/set
59003 Heating element P-300-2 10/set
59002 P-200 fusing heating element 10/set
59004 P-300 fusing heating element 10/set
No. Code Sales Unit Parts Name
135155 PC-300 lever set 1set
135100 PC-300 lever R, L 1set
135200 PC-300 cutter guide 1
110700 Cutter knob 1
17800 Cutter blade 1
48300 PC-300 sponge pad 2/set
135600 PC-300 fluoro glass sheet retainer 1
No. Code Sales Unit Parts Name
Parts Table P-200 Parts Table P-300 Parts Table PC-200
Parts Table PC-300
Routine Maintenance Parts
220V
110V
220V
110V
Thank you for purchasing the poly
sealer. Please read this manual
carefully before using the product.
GENERAL PARTS DESCRIPTION
POLY SEALER
INSTRUCTION MANUAL
P-200
PC-200
P-300
PC-300
Pressure lever
Silicone rubber
Pressure lever
Cutter guide
Power cord
Timer dial
Heater lamp cover
Fluoro glass sheet
retainer locks
Fluoro glass sheet
retainer locks
Heater lamp cover
Fluoro glass sheet retainer Fluoro glass sheet retainer
Timer dial
SPECIFICATIONS
AC 110V/ 220V 50/60Hz
250W
2mm
200mm
(W)72 X (L)310 X (H)180mm
2.2kg
Power source
Power consumption
Seal width
Seal length
Machine dimension
Machine weight
AC 110V/ 220V 50/60Hz
380W
2mm
300mm
(W)82 X (L)430 X (H)240mm
4kg
Model P-200, PC-200 P-300, PC-300
Cutter knob
1 6
1 3
,
3
2
4
5
6
13
14
14
17
18 20
20
19
21
7
8
8
12
9
10
11
22
25
26
27
28
30
37
38
39
12
,
41
1
1
6
3
3
2
4
5
6
13
14
14
17
18 20
20
19
21
7
8
8
9
12
10
11
22
25
26
27
28
30
38
39
40
41
12
,
,
16
15
23
24
35
36
P-200 / PC-200
EXPLODED PARTS VIEW
P-300 / PC-300
EXPLODED PARTS VIEW
A
P-200
PC-200
P-300
PC-300
The plug in the right illustration is for 110V machine. 220V
sealer is installed with a different plug.
In both cases, if the plug does not fit to the power outlet,
please replace the plug.
※Some machines may use another plugs not indicated
on this manual.
51
52
53
54
55
56
2 7
51 55
51
52
53
54
55
56
2 7
51 55
34 26
,34 26 ,
A
A
A
2
2
4
3
40
5
9
11 8
10
3
7
6
3
51
51
1
22
21
52
55
53
54
2
6
7
4
5
11
9
8
10
55
54
22 56
53
52
3
3
9
3
4
5
3
2
1
6
7
13
8
11
10
10
8
11
9
3
4
67
40
5
22 56
17
23
35
16
15
12
25
24
14
38
28 30
27
37
41
34
20
19
18
39
36
22 21
26
13
25
14
28 30
17
23
35
16
36
12
25
24
39
26
38
18
19
20
27
34
41
15
Y5890 2015.04Z 206E* The parts with # mark are common parts for all P series.
http://www.fujiimpulse.jp/english/

POLY
SEA
LER
PC-200
5
3
6
7
8
10
9
4
2
1
Caution
Caution
Caution
REPLACEMENT OF ROUTINE
MAINTENANCE PARTS
PROPER USE OF THE SEALER
FLUORO GLASS SHEET REPLACEMENT PC-200, PC-300
HEATING ELEMENT REPLACEMENT
SILICONE RUBBER REPLACEMENT
CUTTER BLADE REPLACEMENT
Caution
REPLACEMENT OF
PC-200, PC-300
1 2
3 4
5
CUTTER OPERATION WITH PC-200 AND PC-300
NICHROME WIRE CUTTING
(1)
(2)
2 mm heating element
Fusing heating
element (Round shape)
Keep the pressure lever up
when you replace parts.
Be careful of cutter blade on
PC-200, PC-300. It will be
EXPOSED when the lever is
up.
Make sure you unplug the sealer
before replacing any parts.
With a flathead screwdriver, turn the 4 points
(P-300, PC-300 : 6 points) screw slots on the
fluoro glass sheet retainer 1/4
counterclockwise.
Remove the retainer and damaged fluoro glass
sheet.
Then place the new fluoro glass sheet to be
centered over the heating element.
Put the retainer over it and secure the 4 points
(P-300, PC-300 : 6 points) screw slots 1/4
clockwise. When replacing the parts of PC-200/300,
take a sufficient care to the edge of a cutter.
Heating elememt
Fluoro glass
sheet retainer
Fluoro glass
sheet
Lock
Open Lock
Open
Remove the fluoro glass sheet , and then
the screw take out the heating element.
The glass tape and Sarcon sheet are
under the heating element and are routine
maintenance parts. Replace them when
necessary.
Hook one end of the new heating element
to the electrode, and fasten the other end to
the frame with the screw .
Loosen the screw fastening the
silicone rubber to the crimp plate
and pull the rubber out.
Be careful of the cutter blade while
replacing other components.
Lift the pressure lever and loosen the screw
(B tight, phillips round-head 3X8).
Replace the cutter blade with a new one.
Pressure lever
Cutter guide
Sponge pad
B tight, phillips round-head 3X8
Cutter blade
Cutter knob
For standard sealing with the 2-mm heating element,
skip the above procedures and start here.
Insert the electric power
plug fully into the wall
outlet.
Set the heating time with the timer dial.
Adjust the heating time depending on the
type and thickness of the bag to be
sealed.
Place the edge of the bag
on the sealing surface and
lower the pressure lever.
When you lower the pressure lever the
heat lamp comes on indicating that
heating impulse has started.
The lamp will go out when the impulse
heating is completed.
Do not release.
The PC-200 and PC-300 come with a cutter.
After the procedures from 1~3 (and during
operation 4~5), slide the cutter knob
forward and back to cut off the edge of the
bag.
The cutter knob should move toward the
timer dial and then be returned to its start
position before lifting the pressure lever.
After the lamp is turned off, wait for 2-3
seconds unit you hear the beep. Then
release the pressure lever and remove
the bag.
Following this procedure will ensure
longer parts life and quality seals.
Over 15A
BEEP!
For fusing heating element cutting
and sealing, first remove the 2mm
heating element attached to sealer
and replace it with the nichrome
wire.
With the fusing heating element, the
temperature gets hotter than with
the standard sealing operation.
Add the glass tape (accessory) to
the silicone rubber.
Microswitch
Power
White
White
White
Yellow
Yellow
Transformer
Heater
lamp
Heater
timer
Heater
Noise filter /
safety circuit
unit
Black
Red
Red
Red
Black
Black
C
NO
110V 220V
Cutter knob
