FujiFilm FinePix Z1 User manual

Battery release catch
Indicators
Z1
Z1
FGS-507103-FG
BL00457-200(1) E
A. Loading the battery
B. Charging the battery
1. Plug the AC power adapter
connector into the “DC IN 5V”
socket on the cradle.
2. Plug the AC power adapter
into a power outlet.
3. Check that the camera is
turned off. Set the camera in
the cradle.
4. The indicator lamp lights red
and battery charging begins.
When charging is completed,
the indicator lamp turns off.
Hold the battery so that the indicators are aligned. Push the battery
release catch aside while loading the battery. Check that the battery is
firmly held in place.
1. Align the gold marking on the
xD-Picture Card slot with the
gold contact area on the xD-
Picture Card™ and push the
card firmly all the way into the
slot.
Close the battery cover.
2. Open the lens cover.
Lit red
Gold marking
Gold contact area
C. Setting up the camera
1
D. Taking pictures
Bebeep
Click
1. Set the Mode switch to “q”.
2. Press the shutter button down halfway to
adjust the focus.
3. Press the shutter button down fully to take
a picture. The camera makes a “Click”
sound and takes the picture.
E. Viewing pictures
1. Press the “w” button.
2. Press the “d” or “c” to move
through your images.
1
2 3
Flash
Shutter button
Self-timer lamp
Speaker
Indicator lamp
Cradle connection
socket
Microphone
Lens
Photography mode
Movie mode
Mode switch
Photography mode
Playback mode
(Playback) button
W(Wide zoom) button
DISP (Display) / BACK button
Battery release
catch
Battery cover
MENU/OK button
4-direction abdc button
T(Tele zoom) button
Strap mount
LCD monitor
xD-Picture Card slot
Battery compartment
Photo mode ( ) button
d/ Macro button
c/ Flash button
a/ Low light view button
a/ Erase button
b/ Self-timer button
POWER switch /
Lens cover
Camera Controls
Picture Taking
Refer to Owner’s Manual for more detailed instructions
Still images that can be viewed on the FinePix Z1
You can use this camera to view still images recorded on the FinePix
Z1 or still images (excluding some uncompressed images) recorded
on a FUJIFILM digital camera that supports xD-Picture Card.
33. You can select your preferred
date format.
Press “d” or “c” to select the
date order, Year, Month, Day,
Hour or Minute.
Press “a” or “b” to correct the
setting.
Press the “MENU/OK” button
after you complete the setting.
✽Refer to owner’s manual for
date/time setup.
1 2
DATD A T E TE T IMEM E
SETSET CANCELC A N C E L
2007 2 0 0 7
2006 2 0 0 6
2004 2 0 0 4
2003 2 0 0 3
20052 0 0 5
YYY M M DD D11 21 0 0
A M
1 2 3
4
2

A.Install Software
A.Install Software
B.Connect a Camera to PC
B.Connect a Camera to PC
C.Save Images
C.Save Images
Viewing images on your PC
9.
FinePixViewer starts up automatically.
Windows 98/98 SE/Me/2000 Professional
The “Found New Hardware” help message appears in the
bottom-right corner of your screen. This message will close
when the settings are completed. No action is required.
FinePixViewer starts up automatically.
Windows XP
For more information
Refer to “How to use FinePixViewer” in the HELP menu, or chapter 5
and 6 in the Owner’s Manual, or visit Fujifilm “Q&A Search” in the
following website.
(http://home.fujifilm.com/products/digital/ )
For Macintosh users, refer to chapter 5 and 6 in the Owner’s Manual.
3. Turn your camera off.
4. Plug the USB cable (mini-B) into the cradle USB socket.
5. Plug the AC power adapter connector into the “DC IN 5V”
socket on the cradle and then plug the AC power adapter into
the power outlet.
6. Turn your PC on.
7. Connect the PC to the cradle using the USB cable (mini-B).
8. Set the camera in the cradle.
Press the “POWER” button on the cradle to turn the power
on.
USB socket
PC
A. Install Software
Do not connect the camera to your PC until the software
installation is completed.
1. Turn on your PC and start up Windows.
●
! Users of Windows 2000 Professional or Windows XP should log in
by using a system administrator account (e.g. “Administrator”).
2. Quit all other active applications until no applications are
shown in the taskbar.
3. Load the enclosed CD-ROM into the CD-ROM drive. The
installer starts up automatically.
4. The Setup screen appears.
Click the [Installing
FinePixViewer] button.
5. After installation completed, press [Close] button.
B. Connect the Camera to your PC
1. Load an xD-Picture Card containing photographed images
into your camera.
2. Press the “w” button for about 1 second to turn the camera
on in Playback mode.
Select “¶” DSC in “ò” USB MODE in the “˜” SET-UP
menu (Refer to “USING THE SET-UP SCREEN” in the
owner’s manual).
DSCD S C
OKO K
SETS E T
NTSC N T S CN T S C NTSC
1
3
2
ENGLISHE N G L I S H
D S C
C. Save Images
1. The Save Image Wizard starts up. Click the [Start]button.
2. Check that the files are downloaded from the camera to your
PC and that a folder with the date is created.
Ex. \My Documents \ My Pictures \ 2005_0324
D. View Images
1. Click the [Show List of Images]
button.
2. Select “Preview” in the View menu to display an enlarged image.
