FujiFilm FRENIC5000G11S Series Manual

CONTENTS
Chapter 1 Specifications
1. Standard Specifications .......................................................................................... 1-2
1.1 Three-phase 230V FRENIC5000G11S Series ................................................... 1-2
1.2 Three-phase 460V FRENIC5000G11S Series ................................................... 1-3
1.3 Three-phase 230V FRENIC5000P11S Series
(for variable torque load) .................................................................................... 1-4
1.4 Three-phase 460V FRENIC5000P11S Series
(for variable torque load) ..................................................................................... 1-5
2. Common Specifications .......................................................................................... 1-6
2.1 Outline of common specifications ....................................................................... 1-6
2.2 Protective functions........................................................................................... 1-10
2.3 Function settings ............................................................................................... 1-11
3. Wiring Diagram ..................................................................................................... 1-19
3.1 Wiring diagram before shipment from factory ................................................... 1-19
3.2 Basic wiring diagram ......................................................................................... 1-24
3.3 Wiring diagram using options............................................................................ 1-29
4. Terminal ................................................................................................................ 1-33
4.1 Terminal functions ............................................................................................. 1-33
4.2 Main circuit and control circuit terminals ........................................................... 1-37
4.2.1 Terminal block arrangement ...................................................................... 1-37
4.2.2 Main circuit terminal................................................................................... 1-38
4.2.3 Control circuit terminal ............................................................................... 1-41
Chapter 2 Operation
1. Frequency Control Operation ................................................................................. 2-2
1.1 Types of frequency control signal........................................................................ 2-2
1.2 Accuracy and resolution...................................................................................... 2-3
2. KEYPAD panel ........................................................................................................ 2-4
3. Function Explanation .............................................................................................. 2-6
3.1 Fundamental Functions ...................................................................................... 2-6
3.2 Extension Terminal Functions ........................................................................... 2-16
3.3 Control Functions of Frequency ........................................................................ 2-26
3.4 Motor Parameters ............................................................................................. 2-31
3.5 High Performance Functions ............................................................................ 2-33
3.6 Alternative Motor Parameters ........................................................................... 2-42
4. Standard RS-485 Interface ................................................................................... 2-44
4.1 Outline ............................................................................................................... 2-45
4.1.1 Features ..................................................................................................... 2-45
4.1.2 Function overview ...................................................................................... 2-45
4.2 Transmission specification ................................................................................ 2-45
4.3 Connection ........................................................................................................ 2-45
4.3.1 Connection method.................................................................................... 2-45
4.3.2 RS-485....................................................................................................... 2-46
4.3.3 Example of connection of FRENIC5000G11S/P11S series ...................... 2-46
4.3.4 Example of noise prevention...................................................................... 2-47
Contents.p65 07.8.9, 21:07Page 1 AdobePageMaker6.5J/PPC

ii Contents
4.4 Transmission method ........................................................................................ 2-47
4.4.1 Transmission frame .................................................................................... 2-47
4.4.2 Field description......................................................................................... 2-53
4.4.3 Procedure on the host side ........................................................................ 2-54
4.4.4 Example of communication........................................................................ 2-56
4.4.5 Communication error ................................................................................. 2-57
4.5 Functions specific for communication ............................................................... 2-61
4.5.1 Command data .......................................................................................... 2-61
4.5.2 Operation command data .......................................................................... 2-61
4.5.3 Function data ............................................................................................. 2-62
4.5.4 Monitoring data .......................................................................................... 2-63
4.6 Function data format ......................................................................................... 2-64
4.6.1 List of function data format ........................................................................ 2-64
4.6.2 Data format specification ........................................................................... 2-67
4.7 Changeover of communications ....................................................................... 2-69
4.7.1 Changeover method for communication valid/invalid ................................. 2-70
4.7.2 Link function (operation selection) ............................................................. 2-70
4.7.3 Coexistence of link (option) and RS-485 communication .......................... 2-70
4.8 Response Time ................................................................................................. 2-70
4.8.1 Response interval time .............................................................................. 2-70
4.8.2 Time of receiving preparation completion .................................................. 2-71
4.9 Function ............................................................................................................ 2-71
4.10 Troubleshooting ................................................................................................. 2-72
4.11 Appendix ........................................................................................................... 2-73
4.11.1 Communication level converter ................................................................. 2-73
4.11.2 ASCII code list .......................................................................................... 2-73
4.11.3 Example of a control program ................................................................... 2-74
5. Using Lifetime Forecast Functions ........................................................................ 2-75
5.1 Contents of lifetime forecast functions .............................................................. 2-75
5.2 How to check lifetime forecast information ........................................................ 2-75
5.3 Measuring conditions of lifetime........................................................................ 2-76
Chapter 3 Peripheral Equipment
1. Inverter Input Current .............................................................................................. 3-2
2. Circuit Breakers and Magnetic Contactors ............................................................. 3-3
3. Wire Size ................................................................................................................. 3-4
3.1 FRENIC5000G11S/P11S Series ........................................................................ 3-4
3.2 Allowable current of insulation wire ..................................................................... 3-8
4. Braking Unit and Braking Resistor ........................................................................ 3-10
5. Braking Unit and Braking Resistor (10% ED) ....................................................... 3-12
6. Rated Sensitive Current of GFCI .......................................................................... 3-14
7. Input Circuit Noise Filter (EMC Compliance Filter) ............................................... 3-15
8. Output Circuit Noise Filter (OFL- -2/4) .......................................................... 3-16
9. Output Circuit Noise Filter (OFL- -4A) .......................................................... 3-18
Contents.p65 07.8.9, 21:07Page 2 AdobePageMaker6.5J/PPC

Contents iii
10. DC REACTOR (DCR) ........................................................................................... 3-20
11. AC Reactor (ACR)................................................................................................. 3-21
12. Ferrite Ring for Reducing Radio Noise (ACL) ....................................................... 3-23
13. Power Regenerative PWM Converter (RHC) ........................................................ 3-23
Chapter 4 Optimal Type Selection
1. Inverter and Motor Selection ................................................................................... 4-2
1.1 Motor output torque characteristics .................................................................... 4-2
1.2 Selection procedure ............................................................................................ 4-4
1.3 Selection calculation expressions ....................................................................... 4-6
1.3.1 Load torque during constant speed running ................................................ 4-6
1.3.2 Acceleration and deceleration time calculation............................................ 4-7
1.3.3 Heat energy calculation of braking resistor.................................................. 4-9
1.3.4 Appendix (calculation for other than in SI Unit) ......................................... 4-10
2. Braking Unit and Braking Resistor Selection ........................................................ 4-11
2.1 Selection procedure .......................................................................................... 4-11
2.2 Notes on selection ............................................................................................ 4-11
2.3 Optional fan unit ................................................................................................ 4-11
Chapter 5 Option
1. Options .................................................................................................................... 5-2
1.1 Optional control cards ......................................................................................... 5-2
1.2 Other exclusive options ....................................................................................... 5-2
1.3 Datailed specifications ........................................................................................ 5-3
2. Optional Peripheral Equipment ............................................................................. 5-14
2.1 Optional peripheral equipment.......................................................................... 5-14
2.2 Specifications and dimensions ......................................................................... 5-15
Chapter 6 Application Idea
1. Setting Items and Applications................................................................................ 6-2
2. FRENIC5000G11S/P11S Series ............................................................................ 6-4
2.1 Using with Aeration Tank Blowers ....................................................................... 6-4
2.2 Using with Multi-storied Automated Warehouses ............................................... 6-6
2.3 Using with Automated Parking Garages ............................................................. 6-8
2.4 Using with Vertical Circulation type Parking Facility .......................................... 6-10
2.5 Using with Bread Dough Mixers ........................................................................ 6-12
2.6 Using with Commercial-use Washing Machines ............................................... 6-14
2.7 Using with Belt Conveyors ................................................................................ 6-16
2.8 Using with Grinding Machines .......................................................................... 6-18
2.9 Using with Fans for Air Conditioning Unit (1) .................................................... 6-20
2.10 Using with Fans for Air Conditioning Unit (2) .................................................... 6-22
2.11 Using with Cold/Warm Water Pumps ................................................................ 6-24
2.12 Using with Line/Inverter Changeover Operation ............................................... 6-26
Contents.p65 07.8.9, 21:07Page 3 AdobePageMaker6.5J/PPC

iv Contents
Chapter 7 Glossary
1. Standard Specifications .......................................................................................... 7-2
2. Common Specificationds ........................................................................................ 7-4
Chapter 8 Appendix
Appendix 1. Advantageous Use of Inverters (with regard to Electrical Noise) .............. 8-2
1.1 Effect of inverters on other devices ..................................................................... 8-2
1.1.1 Effect on AM radios ..................................................................................... 8-2
1.1.2 Effect on telephones .................................................................................... 8-2
1.1.3 Effect on proximity limit switches ................................................................. 8-2
1.1.4 Effect on pressure sensors .......................................................................... 8-2
1.1.5 Effect on position detectors
(pulse generators; PGs, or pulse encoders) ................................................ 8-2
1.2 Noise ................................................................................................................... 8-2
1.2.1 Inverter noise ............................................................................................... 8-2
1.2.2 Types of noise .............................................................................................. 8-3
1.3 Noise prevention measures ................................................................................ 8-5
1.3.1 Noise prevention treatments prior to installation .......................................... 8-5
1.3.2 Implementation of noise prevention measures ............................................ 8-5
1.3.3 Specific examples ........................................................................................ 8-8
Appendix 2. Effect on Insulation of General-purpose
Motor Driven with 460V Class Inverter.................................................. 8-11
2.1 Operating principle of inverter ........................................................................... 8-11
2.1.1 Main circuit configuration of inverter .......................................................... 8-11
2.1.2 Control method of inverter ......................................................................... 8-11
2.2 Generating mechanism of surge voltages ........................................................ 8-11
2.3 Effect of surge voltages .................................................................................... 8-12
2.4 Countermeasures against surge voltages ........................................................ 8-12
2.4.1 Method to use motors with enhanced insulation........................................ 8-12
2.4.2 Method to suppress surge voltages ........................................................... 8-12
2.5 Regarding existing equipment .......................................................................... 8-13
2.5.1 In case of motor being driven with 400V class inverter ............................. 8-13
2.5.2 In case of existing motor driven newly with 400V class inverter ................ 8-13
Appendix 3. Example Calculation of Energy Savings .................................................. 8-14
2.1 Calculating condition ......................................................................................... 8-14
2.2 Calculation of shaft driving power ..................................................................... 8-14
2.3 Calculation of energy savings ........................................................................... 8-14
Appendix 4. Inverter Generating Loss .......................................................................... 8-15
Contents.p65 07.8.9, 21:07Page 4 AdobePageMaker6.5J/PPC

1-1
Chapter 1
Specifications
1
Contents
1. Standard Specifications ....................................................................................... 1-2
1.1 Three-phase 230V FRENIC5000G11S Series ................................................... 1-2
1.2 Three-phase 460V FRENIC5000G11S Series ................................................... 1-3
1.3 Three-phase 230V FRENIC5000P11S Series (for variable torque load)............ 1-4
1.4 Three-phase 460V FRENIC5000P11S Series (for variable torque load)............ 1-5
2. Common Specifications ....................................................................................... 1-6
2.1 Outline of common specifications ....................................................................... 1-6
2.2 Protective functions........................................................................................... 1-10
2.3 Function settings ............................................................................................... 1-11
3. Wiring Diagram ................................................................................................... 1-19
3.1 Wiring diagram before shipment from factory ................................................... 1-19
3.2 Basic wiring diagram......................................................................................... 1-24
3.3 Wiring diagram using options........................................................................... 1-29
4. Terminal ............................................................................................................... 1-33
4.1 Terminal functions ............................................................................................. 1-33
4.2 Main circuit and control circuit terminals ........................................................... 1-37
4.2.1 Terminal block arrangement ...................................................................... 1-37
4.2.2 Main circuit terminal ................................................................................... 1-38
4.2.3 Control circuit terminal ............................................................................... 1-41
Chapter01J(P1˜5).p65 07.8.9, 19:10Page 1 AdobePageMaker6.5J/PPC

1-2
Chapter 1
1. Standard Specifications
1. Standard Specifications
1.1 Three-phase 230V FRENIC5000G11S Series
Item Specifications
Type FRN■■■■■■G11S-2UX F25 F50 001 002 003 005 007 010 015 020 025 030 040 050 060 075 100 125
Nominal applied motor HP 1/4 1/2 12357.5101520253040506075100125
Rated capacity *1) kVA 0.6 1.2 2.0 3.2 4.4 6.8 9.9 13 18 23 29 36 46 58 72 86 113 138
Rated voltage *2) V 3-phase 200V/50Hz 200, 220, 230V/60Hz
Output Rated current *3) A 1.5 3.0 5.0 8.0 11 17 25 33 46 59 74 87 115 145 180 215 283 346
ratings Overload capability 150% of rated current for 1min. 150% of rated current for 1min.
200% of rated current for 0.5s 180% of rated current for 0.5s
Rated frequency Hz 50, 60Hz
Phases, Voltage, Frequency 3-phase 200 to 230V 50/60Hz
3-phase 200 to 220V/50Hz (220 to 230V/50Hz) *11)
200 to 230V/60Hz
Voltage / frequency variations Voltage : +10 to –15% (Voltage unbalance *4) : 2% or less) Frequency :+5 to –5%
Momentary voltage dip capability When the input voltage is 165V or more, the inverter can be operated continuously.
Input *5) When the input voltage drops below 165V from rated voltage, the inverter can be operated for 15ms .
ratings The smooth recovery method is selectable.
Rated current *6) (with DCR) 0.94 1.6 3.1 5.7 8.3 14.0 19.7 26.9 39.0 54.0 66.2 78.8 109 135 163 199 272 327
A(without DCR) 1.8 3.4 6.4 11.1 16.1 25.5 40.8 52.6 76.9 98.5 117 136 168 204 243 291 - -
Required power supply
capacity *7) kVA 0.4 0.6 1.1 2.0 2.9 4.9 6.9 9.4 14 19 23 28 38 47 57 69 95 114
Maximum frequency 50 to 400Hz
Setting Base frequency 25 to 400Hz
Starting frequency 0.1 to 60Hz, Holding time: 0.0 to 10.0s
Carrier frequency *8) 0.75 to15kHz
0.75 to 10kHz
Output Accuracy (Stability) •Analog setting : ±0.2% of Maximum frequency (at 25±10°C (77±50°F))
frequency •Digital setting : ±0.01% of Maximum frequency (at –10 to +50°C (14 to 122°F))
Setting resolution •Analog setting : 1/3000 of Maximum frequency ex.) 0.02Hz at 60Hz, 0.04Hz at 120Hz, 0.15Hz at 400Hz
•Digital setting : 0.01Hz at Maximum frequency of up to 99.99Hz (0.1Hz at Maximum frequency of 100Hz and above)
•LINK setting : Selects from the following two items.
• 1/20000 of Maximum frequency ex.) 0.003Hz at 60Hz, 0.006Hz at 120Hz, 0.02Hz at 400Hz
• 0.01Hz (Fixed)
Voltage / freq. (V/f) characteristic Adjustable at base and maximum frequency, with AVR control : 80 to 240V
Torque boost Torque boost can be set, using Function code F09 and A05.
0.0 : Automatic (for constant torque load)
Control 0.1 to 0.9 : Manual (for variable torque load) *9)
1.0 to 1.9 : Manual (for propotional speed torque load)
2.0 to 20.0: Manual (for constant torque load)
Starting torque 200% (with Dynamic torque-vector control selected)
180% (with Dynamic torque-vector control selected)
Braking torque *10) 150% 100% 20% 10 to 15%
Standard Time s 10 5 5 No limit
Duty cycle
%ED 10 5 353232 No limit
Standard Braking torque 150% 100%
Using
Time s 90 45 45 45 30 20 10 8 10
Braking Duty cycle
%ED 37 22 18 10 7 5 5 5 10
options 10%ED Braking torque 150% *12)
Time s 90 45 30 20 10
Duty cycle
%ED 10 10 10
DC injection braking Starting frequency: 0.1 to 60.0Hz Braking time: 0.0 to 30.0s Braking level: 0 to 100% of rated current
*Inverter restarts at the starting frequency when operation command is input while braking is operating.
*DC injection braking does not operate at the time of change-over from forward to reverse operation.
*
DC injection braking does not operate when frequency setting is decreased while operation command (FWD, REV) is being input.
Enclosure (IEC 60529) IP 40 IP 00 ( IP 20 : Option )
Cooling method Natural cooling Fan cooling
-UL/cUL -Low Voltage Directive -EMC Directive -TÜV (up to 30HP)
Standards -IEC 61800-2 (Ratings, specifications for low voltage adjustable frequency a.c. power drive systems)
-IEC 61800-3 (EMC product standard including specific test methods)
Weight lbs 4.9 4.9 5.5 8.4 8.4 8.4 13 13 22 22 23 23 64 79 97 101 154 254
(kg) (2.2) (2.2) (2.5) (3.8) (3.8) (3.8) (6.1) (6.1) (10) (10) (10.5) (10.5) (29) (36) (44) (46) (70) (115)
NOTES: *1) Inverter output capacity (kVA) at 230V. Rated capacity reduces when power supply voltage decreases.
*2) Output voltage cannot exceed the power supply voltage.
*3) Current derating may be required in case of low impedance loads such as high frequency motor.
*4) Use a DC REACTOR (DCR) when the voltage unbalance exceeds 2%. (This value is equivalent to FUJI’s conventional allowable value.)
Voltage unbalance (%) = Max. voltage [V] – Min. Voltage [V] x 67 (Conforming to EN61800-3 (5.2.3))
Three-phase average voltage[V]
*5) Tested at standard load condition (85% load).
*6) This value is under FUJI original calculation method.
*7) When power-factor correcting DC REACTOR (DCR) is used.
*8) When inverter is operating at a carrier frequency of 10kHz or higher, the inverter may automatically reduce the carrier frequency to 8kHz for protecting inverter.
*9) When torque boost is set at 0.1, starting torque of 50% or more can be obtained.
*10) With a nominal applied motor, this value is average torque when the motor decelerates and stops from 60Hz. (It may change according to motor loss.)
*11) Order individually.
*12) Applicable to 10%ED when using options (standard)
Chapter01J(P1˜5).p65 07.8.9, 19:10Page 2 AdobePageMaker6.5J/PPC

1-3
Chapter 1
1. Standard Specifications
1
1.2 Three-phase 460V FRENIC5000G11S Series
Item Specifications
Type FRN■■■■■■G11S-4UX F50 001 002 003 005 007 010 015 020 025 030 040 050 060 075 100 125 150 200 250 300 350 400 450 500 600
Nominal applied motor HP 1/2 12357.5101520253040506075100125150200250300350400450500600
Rated capacity *1) kVA 1.1 1.9 2.8 4.1 6.8 9.9 13 18 22 29 34 45 57 69 85 114 134 160 192 231 287 316 396 445 495 563
Rated voltage *2) V 3-phase 380, 400, 415V/50Hz 380, 400, 440, 460V/60Hz
Output Rated current *3) A 1.5 2.5 3.7 5.5 9 13 18 24 30 39 45 60 75 91 112 150 176 210 253 304 377 415 520 585 650740
ratings Overload capability 150% of rated current for 1min. 150% of rated current for 1min.
200% of rated current for 0.5s 180% of rated current for 0.5s
Rated frequency Hz 50, 60Hz
Phases, Voltage, Frequency 3-phase 380 to 480V 50/60Hz 3-phase 380 to 440V/50Hz 380 to 480V/60Hz *4)
Voltage / frequency variations Voltage : +10 to –15% (Voltage unbalance *5) : 2% or less) Frequency :+5 to –5%
Momentary voltage dip capability When the input voltage is 310V or more, the inverter can be operated continuously.
Input *6) When the input voltage drops below 310V from rated voltage, the inverter can be operated for 15ms .
ratings The smooth recovery method is selectable.
Rated current *7) (with DCR)
0.82 1.5 2.9 4.2 7.1 10.0 13.5 19.8 26.8 33.2 39.3 54 67 81 100 134 160 196 232 282 352 385 491 552 624 704
A(without DCR) 1.8 3.5 6.2 9.2
14.9 21.5 27.9 39.1 50.3 59.9 69.3 86 104 124150 -----------
Required power supply
capacity *8) kVA 0.6 1.1 2.1 3.0 5.0 7.0 9.4 14 19 24 28 38 47 57 70 93 111 136 161 196 244 267 341 383 433 488
Maximum frequency 50 to 400Hz
Setting Base frequency 25 to 400Hz
Starting frequency 0.1 to 60Hz, Holding time: 0.0 to 10.0s
Carrier frequency *9) 0.75 to 15kHz 0.75 to 10kHz
Output Accuracy (Stability) •Analog setting : ±0.2% of Maximum frequency (at 25±10°C (77±50°F))
frequency •Digital setting : ±0.01% of Maximum frequency (at –10 to +50°C (14 to 122°F))
Setting resolution •Analog setting : 1/3000 of Maximum frequency ex.) 0.02Hz at 60Hz, 0.04Hz at 120Hz, 0.15Hz at 400Hz
•Digital setting : 0.01Hz at Maximum frequency of up to 99.99Hz (0.1Hz at Maximum frequency of 100Hz and above)
•LINK setting : Selects from the following two items.
• 1/20000 of Maximum frequency ex.) 0.003Hz at 60Hz, 0.006Hz at 120Hz, 0.02Hz at 400Hz
• 0.01Hz (Fixed)
Voltage / freq. (V/f) characteristic Adjustable at base and maximum frequency, with AVR control : 320 to 480V
Torque boost Torque boost can be set, using Function code F09 and A05.
0.0 : Automatic (for constant torque load)
Control 0.1 to 0.9 : Manual (for variable torque load) *10)
1.0 to 1.9 : Manual (for propotional speed torque load)
2.0 to 20.0: Manual (for constant torque load)
Starting torque 200% (with Dynamic torque-vector control selected) 180% (with Dynamic torque-vector control selected)
Braking torque *11) 150% 100% 20% 10 to 15%
Standard Time s 55 No limit
Duty cycle
%ED 5353232 No limit
Standard Braking torque 150% 100%
Using
Time s 45 30 20 10 8 10
Braking Duty cycle
%ED 22 18 10 7 5 5 5 10
options 10%ED Braking torque 150% *13)
Time s 45 30 20 10
Duty cycle
%ED 10 10 10 10
DC injection braking Starting frequency: 0.1 to 60.0Hz Braking time: 0.0 to 30.0s Braking level: 0 to 100% of rated current
*Inverter restarts at the starting frequency when operation command is input while braking is operating.
*DC injection braking does not operate at the time of change-over from forward to reverse operation.
* DC injection braking does not operate when frequency setting is decreased while operation command (FWD, REV) is being input.
Enclosure (IEC 60529) IP 40 IP 00 ( IP 20 : Option )
Cooling method
Natural cooling Fan cooling
-UL/cUL -Low Voltage Directive -EMC Directive -TÜV (up to 30HP)
Standards -IEC 61800-2 (Ratings, specifications for low voltage adjustable frequency a.c. power drive systems)
-IEC 61800-3 (EMC product standard including specific test methods)
Weight lbs 4.9 5.5 8.4 8.4 8.4 14 14 22 22 23 64 75 86
88 106 154 154 221 221 309 309 551 551 794 794
(kg) (2.2) (2.5) (3.8) (3.8) (3.8) (6.5) (6.5) (10) (10) (10.5) (10.5)
NOTES: *1) Inverter output capacity (kVA) at 460V. Rated capacity reduces when power supply voltage decreases.
*2) Output voltage cannot exceed the power supply voltage.
*3) Current derating may be required in case of low impedance loads such as high frequency motor.
*4) When the input voltage is 380 to 398V/50Hz or 380 to 430V/60Hz, the tap of the auxiliary transformer must be changed.
*5) Use a DC REACTOR (DCR) when the voltage unbalance exceeds 2%. (This value is equivalent to FUJI’s conventional allowable value.)
Voltage unbalance (%) = Max. voltage [V] – Min. Voltage [V] x 67 (Conforming to EN61800-3 (5.2.3))
Three-phase average voltage[V]
*6) Tested at standard load condition (85% load).
*7) This value is under FUJI original calculation method.
*8) When power-factor correcting DC REACTOR (DCR) is used.
*9) When inverter is operating at a carrier frequency of 10kHz or higher, the inverter may automatically reduce the carrier frequency to 8kHz for protecting inverter.
*10) When torque boost is set at 0.1, starting torque of 50% or more can be obtained.
*11) With a nominal applied motor, this value is average torque when the motor decelerates and stops from 60Hz. (It may change according to motor loss.)
*12) Consult with Fuji Electric.
*13) Applicable to 10%ED when using options (standard)
(100) (100) (140) (140) (250) (250) (360) (360) (70)(70)(48)(40)(39)
23
(29) (34)
Chapter01J(P1˜5).p65 07.8.9, 11:53Page 3 AdobePageMaker6.5J/PPC

1-4
Chapter 1
1. Standard Specifications
1.3 Three-phase 230V FRENIC5000P11S Series (for variable torque load)
Item Specifications
Type FRN■■■■■■P11S-2UX 007 010 015 020 025 030 040 050 060 075 100 125 150
Nominal applied motor HP 7.5 10 15 20 25 30 40 50 60 75 100 125 150
Rated capacity *1) kVA 8.8 12 17 22 27 31 46 58 72 86 113 138 165
Rated voltage *2) V 3-phase 200V/50Hz 200, 220, 230V/60Hz
Output Rated current *3) A 22 29 42 55 67 78 115 145 180 215 283 346 415
ratings Overload capability 110% of rated current for 1min
Rated frequency Hz 50, 60Hz
Phases, Voltage, Frequency 3-phase 200 to 230V 50/60Hz
3-phase 200 to 220V/50Hz (220 to 230V/50Hz) *11) 200 to 230V/60Hz
Voltage / frequency variations Voltage : +10 to –15% (Voltage unbalance *4) : 2% or less) Frequency :+5 to –5%
Momentary voltage dip capability When the input voltage is 165V or more, the inverter can be operated continuously.
Input *5) When the input voltage drops below 165V from rated voltage, the inverter can be operated for 15ms .
ratings The smooth recovery method is selectable.
Rated current *6) (with DCR) 19.7 26.9 39.0 54.0 66.2 78.8 109 135 163 199 272 327 400
A(without DCR) 40.8 52.6 76.9 98.5 117 136 168 204 243 291 - - -
Required power supply
capacity *7) kVA 6.9 9.4 14 19 23 28 38 47 57 69 95 114 139
Maximum frequency 50 to 120Hz
Setting Base frequency 25 to 120Hz
Starting frequency 0.1 to 60Hz, Holding time: 0.0 to 10.0s
Carrier frequency *8) 0.75 to 15kHz 0.75 to 10kHz 0.75 to 6kHz
Output Accuracy (Stability) •Analog setting : ±0.2% of Maximum frequency (at 25±10°C (77±50°F))
frequency •Digital setting : ±0.01% of Maximum frequency (at –10 to +50°C (14 to 122°F))
Setting resolution •Analog setting : 1/3000 of Maximum frequency ex.) 0.02Hz at 60Hz, 0.04Hz at 120Hz
•Digital setting : 0.01Hz at Maximum frequency of up to 99.99Hz (0.1Hz at Maximum frequency of 100Hz and above)
•LINK setting : Selects from the following two items.
•1/20000 of Maximum frequency ex.) 0.003Hz at 60Hz, 0.006Hz at 120Hz
•0.01Hz (Fixed)
Voltage / freq. (V/f) characteristic Adjustable at base and maximum frequency, with AVR control : 80 to 240V
Torque boost Torque boost can be set, using Function code F09 and A05.
0.0 : Automatic (for constant torque load)
Control 0.1 to 0.9 : Manual (for variable torque load) *9)
1.0 to 1.9 : Manual (for propotional speed torque load)
2.0 to 20.0 : Manual (for constant torque load)
Starting torque 50%
Braking torque *10) 20% 10 to 15%
Standard Time s No limit
Duty cycle
%ED No limit
Standard Braking torque 100% 75%
Using
Time s 15 7 8 10
Braking Duty cycle
%ED 3.5 3.5 4 10
options 10%ED Braking torque 100% *12)
Time s 15 7
Duty cycle
%ED 10 10 10 7
DC injection braking Starting frequency: 0.1 to 60.0Hz Braking time: 0.0 to 30.0s Braking level: 0 to 100% of rated current
*Inverter restarts at the starting frequency when operation command is input while braking is operating.
*DC injection braking does not operate at the time of change-over from forward to reverse operation.
* DC injection braking does not operate when frequency setting is decreased while operation command (FWD, REV) is being input.
Enclosure (IEC 60529) IP 40 IP 00 ( IP 20 : Option )
Cooling method Fan cooling
-UL/cUL -Low Voltage Directive -EMC Directive -TÜV (up to 30HP)
Standards -IEC 61800-2 (Ratings, specifications for low voltage adjustable frequency a.c. power drive systems)
-IEC 61800-3 (EMC product standard including specific test methods)
Weight lbs 13 13 13 22 22 23 64 64 79 97 101 154 254
(kg) (5.7) (5.7) (5.7) (10) (10) (10.5) (29) (29) (36) (44) (46) (70) (115)
NOTES: *1) Inverter output capacity (kVA) at 230V. Rated capacity reduces when power supply voltage decreases.
*2) Output voltage cannot exceed the power supply voltage.
*3) Current derating may be required in case of low impedance loads such as high frequency motor.
*4) Use a DC REACTOR (DCR) when the voltage unbalance exceeds 2%. (This value is equivalent to FUJI’s conventional allowable value.)
Voltage unbalance (%) = Max. voltage [V] – Min. Voltage [V] x 67 (Conforming to EN61800-3 (5.2.3))
Three-phase average voltage[V]
*5) Tested at standard load condition (85% load).
*6) This value is under FUJI original calculation method.
*7) When power-factor correcting DC REACTOR (DCR) is used.
*8) When inverter is operating at a carrier frequency of 10kHz or higher, the inverter may automatically reduce the carrier frequency to 8kHz for protecting inverter.
*9) When torque boost is set at 0.1, starting torque of 50% or more can be obtained.
*10) With a nominal applied motor, this value is average torque when the motor decelerates and stops from 60Hz. (It may change according to motor loss.)
*11) Order individually.
*12) Applicable to 10%ED when using options (standard)
Chapter01J(P1˜5).p65 07.8.9, 11:53Page 4 AdobePageMaker6.5J/PPC

1-5
Chapter 1
1. Standard Specifications
1
1.4 Three-phase 460V FRENIC5000P11S Series (for variable torque load)
Item Specifications
Type FRN■■■■■■P11S-4UX 007 010 015 020 025 030 040 050 060 075 100 125 150 200 250 300 350 400 450 500 600 700 800
Nominal applied motor HP 7.5 10 15 20 25 30 40 50 60 75 100 125 150 200 250 300 350 400 450 500 600 700 800
Rated capacity *1) kVA 10 13 18 24 29 35 48 60 72 89 119 140 167 201 242 300 330 386 414 517 589 668 764
Rated voltage *2) V 3-phase 380, 400, 415V/50Hz 380, 400, 440, 460V/60Hz
Output Rated current *3) A
12.5 16.5 23 30 37 44 60 75 91 112 150 176 210 253 304 377 415 520 585 650 740 840 960
raitings Overload capability 110% of rated current for 1min
Rated frequency Hz 50, 60Hz
Phases, Voltage, Frequency
3-phase 380 to 480V 50/60Hz 3-phase 380 to 440V/50Hz 380 to 480V/60Hz *4)
Voltage / frequency variations Voltage : +10 to –15% (Voltage unbalance *5) : 2% or less) Frequency :+5 to –5%
Momentary voltage dip capability When the input voltage is 310V or more, the inverter can be operated continuously.
Input *6) When the input voltage drops below 310V from rated voltage, the inverter can be operated for 15ms .
ratings The smooth recovery method is selectable.
Rated current *7) (with DCR)
10.0 13.5 19.8 26.8 33.2 39.3 54 67 81 100 134 160 196 232 282 352 385 491 552 624 704 792 880
A(without DCR)
21.5 27.9 39.1 50.3 59.9 69.3 86 104 124 150 - ------------
Required power supply
capacity *8) kVA 7.0 9.4 14 19 24 28 38 47 57 70 93 111 136 161 196 244 267 341 383 433 488 549 610
Maximum frequency 50 to 120Hz
Setting Base frequency 25 to 120Hz
Starting frequency 0.1 to 60Hz, Holding time: 0.0 to 10.0s
Carrier frequency *9) 0.75 to 15kHz 0.75 to 10kHz 0.75 to 6kHz
Output Accuracy (Stability) ·Analog setting : ±0.2% of Maximum frequency (at 25±10°C (77±50°F))
frequency ·Digital setting : ±0.01% of Maximum frequency (at –10 to +50°C (14 to 122°F))
Setting resolution ·Analog setting : 1/3000 of Maximum frequency ex.) 0.02Hz at 60Hz, 0.04Hz at 120Hz
·Digital setting : 0.01Hz at Maximum frequency of up to 99.99Hz (0.1Hz at Maximum frequency of 100Hz and above)
·LINK setting : Selects from the following two items.
•1/20000 of Maximum frequency ex.) 0.003Hz at 60Hz, 0.006Hz at 120Hz
•0.01Hz (Fixed)
Voltage / freq. (V/f) characteristic Adjustable at base and maximum frequency, with AVR control : 320 to 480V
Torque boost Torque boost can be set, using Function code F09 and A05.
0.0 : Automatic (for constant torque load)
Control 0.1 to 0.9 : Manual (for variable torque load) *10)
1.0 to 1.9 : Manual (for propotional speed torque load)
2.0 to 20.0 : Manual (for constant torque load)
Starting torque 50%
Braking torque *11) 20% 10 to 15%
Standard Time s No limit
Duty cycle
%ED No limit
Standard Braking torque 100% 75%
Using
Time s 15 7 8 10
Braking Duty cycle
%ED 3.5 3.5 4 10
options 10%ED Braking torque 100% *13)
Time s 15 7
Duty cycle
%ED 10 10 7
DC injection braking Starting frequency: 0.1 to 60.0Hz Braking time: 0.0 to 30.0s Braking level: 0 to 100% of rated current
*Inverter restarts at the starting frequency when operation command is input while braking is operating.
*DC injection braking does not operate at the time of change-over from forward to reverse operation.
* DC injection braking does not operate when frequency setting is decreased while operation command (FWD, REV) is being input.
Enclosure (IEC 60529) IP 40 IP 00 ( IP 20 : Option )
Cooling method Fan cooling
-UL/cUL -Low Voltage Directive -EMC Directive -TÜV (up to 30HP)
Standards -IEC 61800-2 (Ratings, specifications for low voltage adjustable frequency a.c. power drive systems)
-IEC 61800-3 (EMC product standard including specific test methods)
Weight lbs 13 13 13 22 22 23 64 64 75 86 88 106 154 154 221 221 309 309 309 551 551 794 794
(kg)
(6.1) (6.1) (6.1) (10) (10) (10.5) (29) (29) (34) (39) (40) (70) (70) (100) (100) (140) (140) (140) (250) (250) (360) (360)
NOTES: *1) Inverter output capacity (kVA) at 460V. Rated capacity reduces when power supply voltage decreases.
*2) Output voltage cannot exceed the power supply voltage.
*3) Current derating may be required in case of low impedance loads such as high frequency motor.
*4) When the input voltage is 380 to 398V/50Hz or 380 to 430V/60Hz, the tap of the auxiliary transformer must be changed.
*5) Use a DC REACTOR (DCR) when the voltage unbalance exceeds 2%. (This value is equivalent to FUJI’s conventional allowable value.)
Voltage unbalance (%) = Max. voltage [V] – Min. Voltage [V] x 67 (Conforming to EN61800-3 (5.2.3))
Three-phase average voltage[V]
*6) Tested at standard load condition (85% load).
*7) This value is under FUJI original calculation method.
*8) When power-factor correcting DC REACTOR (DCR) is used.
*9) When inverter is operating at a carrier frequency of 10kHz or higher, the inverter may automatically reduce the carrier frequency to 8kHz for protecting inverter.
*10) When torque boost is set at 0.1, starting torque of 50% or more can be obtained.
*11) With a nominal applied motor, this value is average torque when the motor decelerates and stops from 60Hz. (It may change according to motor loss.)
*12) Consult with Fuji Electric.
*13) Applicable to 10%ED when using options (standard)
(48)
Chapter01J(P1˜5).p65 07.8.9, 11:53Page 5 AdobePageMaker6.5J/PPC

1-6
Chapter 1
2. Common Specifications
NOTE : ( ) or < > in the “Remarks” column indicates the abbreviation of terminal function assigned to digital input terminals X1 to X9 and
transistor output terminals Y1 to Y5C.
2. Common Specifications
2.1 Outline of common specifications
Control Control method
F42, A09
Operation method F02
H30 to H39
Frequency setting F01
(Frequency command)
C05 to C19
H31 to H39
F01
C21 to C28
Jogging operation C20
F02
Running status signal E20 to E23
F36
E24, E25
F31
F35
Acceleration/ F07, F08
Deceleration time E10 to E15
H07
Active drive H19
Frequency limiter F15, F16
•V/f control (Sinusoidal PWM control)
•Dynamic torque-vector control (Sinusoidal PWM control)
•Vector control with PG ...G11S only
•KEYPAD operation :
Forward or reverse operation by
FWD
or
REV
key
Stopping by
STOP
key
• Digital input signal operation :
FWD·STOP command, REV·STOP command, Coast-to-stop
command, etc.
• LINK operation :
• RS-485 (standard)
• Various Bus interface is available. (Option)
• T-Link (FUJI private link) • Devicenet • CAN open
• Profibus-DP • Modbus Plus
• Interbus-S •JPCN1
• KEYPAD operation :
∨
or
∨
key
• External potentiometer : Variable resistor (1 to 5kΩ 1/2W)
•Analog input : External voltage or current input
0 to +10Vdc (0 to +5Vdc)
4 to 20mAdc
:Reversible operation by polarized signal can be
selected.
0 to ± 10Vdc (0 to ± 5Vdc)
: Inverse mode operation can be selected by
digital input signal (IVS).
0 to +10Vdc → 10 to 0Vdc (terminal 12)
4 to 20mAdc → 20 to 4mAdc (terminal C1)
• UP/DOWN control :
Output frequency increases when UP signal is ON, and
decreases when DOWN signal is ON.
• Multistep frequency selection :
Up to 16 different frequencies can be selected by digital input signal.
• Pulse train input : 0 to 100kp/s
• Digital signal (parallel) :
12-bit parallel (12-bit binary) signal can be input.
• LINK operation : RS-485 (standard) (RS-485FGABus)
(Option) • T-Link (FUJI private link)
• Profibus-DP
• Interbus-S
• Modbus Plus
• Devicenet
Programmed PATTERN operation : Max. 7 stages
This operation can be performed by KEYPAD opration (
FWD
,
REV
key) or digital input signal (FWD or REV).
Transistor output : RUN, FAR, FDT, OL, LU, TL, etc.
(4 points) (4 output types are selectable)
Relay output : • Same as transistor output.
(2 points) • Alarm output (for any fault)
Analog output : Output frequency, Output current,
(1 point) Output voltage, Output torque, etc.
Pulse output : Output frequency, Output current,
(1 point) Output voltage, Output torque, etc.
0.01 to 3600s
Four kinds of acceleration and deceleration times can be set
independently, and the desired time is selected by combining
digital input signal (2 points).
Selects acceleration/deceleration pattern from the following 4 types.
• Linear
• S-curve (weak)
• S-curve (strong)
• Non-linear (for variable torque load)
When the acceleration time reaches 60s, the motor output torque
is automatically reduced to rated torque. Then the motor operation
mode is changed to torque limiting operation.
High and Low frequency limiters can be preset.
Option card (PG/Hz) required.
Switching between KEYPAD operation and
digital input signal operation is enabled by
pressing STOP key and RESET key at the
same time.
(LE)
• Connect to terminals 13, 12, and 11.
• Set Function code at ”F01: 1".
• Potentiometer is required separately.
0 to +5Vdc, 0 to ± 5Vdc input is enabled
when Func. code 17 (Gain for frequency
setting) is set at 200.0%.
(UP, DOWN)
(SS1, SS2, SS4, SS8)
Option card (PG/SY) required.
Option card (DIO) required.
(LE)
Option card for open networks
<STG1, STG2, STG4, TU, TO>
• To enter jogging operation mode:
•Press
STOP
key and
∨
key at the
same time.
•Digital input signal : (JOG)
*During jogging operation, an indicator at
“JOG” is lit on the LCD monitor.
Coast-to-stop is selectable by Function code “H11”.
(RT1, RT2)
The acceleration time is automatically
extended up to 3 times.
Item Explanation Remarks Func. code
(Reversible
operation)
(Inverse
operation)
Chapter01J(P6˜18).p65 07.8.9, 19:11Page 6 AdobePageMaker6.5J/PPC

1-7
Chapter 1
2. Common Specifications
1
NOTE : ( ) or < > in the “Remarks” column indicates the abbreviation of terminal function assigned to digital input terminals X1 to X9 and
transistor (relay) output terminals Y1 to Y4 (Y5A, Y5C).
Control Bias frequency F18
Gain for frequency F17
setting
Jump frequency control C01 to C04
Rotating motor pick up H09
(Flying start)
Auto-restart after F14
momentary power failure
H13 to H16
Line/Inverter
E01 to E09
changeover operation E20 to E24, H13
Slip compensation P09
A18
Droop operation H28
Torque limiting F40, F41
E16, E17
Torque control H18
PID control H20 to H25
F01
C05 to C19
H21
Automatic deceleration F41, E17
Second motor's setting A01 to A18
Energy saving operation H10
Fan stop operation H06
Universal DI
Universal DO
Bias frequency can be preset.
Gain for frequency setting can be preset. (0.0 to 200.0%)
ex.) Analog input 0 to +5Vdc with 200% gain results in
Maximum frequency at 5Vdc.
Jump frequency (3 points) and its common jump hysteresis width
(0 to 30Hz) can be preset.
A rotating motor(including inverse rotating mode) can be smoothly
picked up without stopping the motor. (speed search method)
Automatic restart is available without stopping motor after a
momentary power failure. (speed search method)
When "Smooth recovery" mode is selected, the motor speed drop
is held minimum.
Controls switching operation between line power and inverter.
The inverter has sequence function inside.
•The inverter output frequency is controlled according to the load
torque to keep motor speed constant.
•When the value is set at "0.00" and "Torque-vector" is set at "active", the
compensation value automatically selects the Fuji standard motor.
Slip compensation can be preset for the second motor.
The motor speed droops in proportional to output torque.(-9.9 to
0.0Hz) ...G11S only
When the motor torque reaches a preset limiting level, this function
automatically adjusts the output frequency to prevent the inverter
from tripping due to an overcurrent.
Torque limiting 1 and Torque limiting 2 can be individually set, and
are selectable with a digital input signal.
Output torque (or load factor ) can be controlled with an analog
input signal (terminal 12).
This function can control flowrate, pressure, etc. (with an analog feedback signal.)
••
••
• Reference signal
•KEYPAD operation (
∨
or
∨
key) :
Setting freq. / Maximum freq. X 100 [%]
•Voltage input (terminal 12 and V2) : 0 to 10Vdc / 0 to 100%
•Current input (terminal C1) : 4 to 20mAdc / 0 to 100%
•Reversible operation with polarity (terminal 12) :
0 to ± 10Vdc / 0 to ±100%
•Reversible operation with polarity (terminal 12 + V1) :
0 to ± 10Vdc / 0 to ± 100%
•Inverse mode operation (terminal 12 and V2) : 10 to 0Vdc / 0 to 100%
•Inverse mode operation (terminal C1) : 20 to 4mAdc / 0 to 100%
•PATTERN operation : Setting freq. / Maximum freq. X 100 [%]
•DI option input : • BCD...Setting freq. / Maximum freq. X 100 [%]
• Binary...Full scale / 100%
•Multistep frequency setting : Setting freq. / Maximum freq. X 100 [% ]
•RS-485 : Setting freq. / Maximum freq. X 100 [%]
••
••
• Feedback signal
•Terminal 12 (0 to 10Vdc / 0 to 100%, or 10 to 0Vdc / 0 to 100% )
•Terminal C1 (4 to 20mAdc / 0 to 100%, or 20 to 4mAdc / 0 to 100%)
Torque limiter 1 (Braking) is set at "F41: 0".
(Setting of Torque limiter 2 (Braking) is same.)
• In deceleration :
The deceleration time is automatically extended up to 3 times for
tripless operation even if a braking resistor is not used.
• In constant speed operation :
Based on regenerative energy, the frequency is increased, and
tripless operation is active.
This function is used for two motors switching operation.
• The second motor's V/f characteristics (base and maximum frequency),
rated current, torque boost, electronic thermal relay, etc. can be preset.
• The second motor's circuit parameter can be preset, and torque-
vector control can be applied to both motors.
This function minimizes inverter and motor losses at light load.
• This function detects temperature inside inverter to stop cooling
fans for silent operation and extending the fans' lifetime.
•On/off status of cooling fans is output.
Transmits to main controller of LINK operation
Outputs command signal from main controller of LINK operation.
Item Explanation Remarks Func. code
When the sum of setting frequency and bias
frequency is minus value, the output
frequency rise can be delayed. (No reverse
running is performed.)
(STM)
The inverter searches the motor speed, and
smoothly returns to setting frequency.
Even if the motor circuit is temporarily opened,
the inverter operates without a hitch.
(SW50, SW60)
<SW88, SW52-1, SW52-2>
Slip compensation value can be manually
set from 0.01 to 5.00Hz instead of 0.0 for
FUJI standard motor.
P11S series doesn't have this function.
(TL2/TL1)
• Torque polarity selectable. (Hz/TRQ)
• P11S series doesn't have this function.
• PID control is selected by "H20". (Hz/PID).
• Reference signal selection is made by "F01".
In "F01", "8: UP/DOWN control 1", "9: UP/
DOWN control 2", and "11: Pulse train
input" cannot be used for the reference
signal of PID control.
• Terminal V1 is optional.
• Terminal V2: EN only
• Feedback signal selection is made by "H21".
When the deceleration time is extended to
longer than three times the setting time, the
inverter trips.
(M2/M1)
<SWM2>
<FAN>
(U-DI)
<U-DO>
Chapter01J(P6˜18).p65 07.8.10, 10:37Page 7 AdobePageMaker6.5J/PPC

1-8
Chapter 1
2. Common Specifications
Control Zero speed control
Positioning control
Synchronized operation
Protection Overload
Overvoltage
Surge protection
Undervoltage
F14
Input phase loss
Overheating
Short-circuit
Ground fault
Motor overload F10 to F12
A06 to A08
(Overload early warning)E33 to E35
DB resistor overheating F13
Output phase loss
detection
Motor protection by H26, H27
PTC thermistor
Auto reset H04, H05
Condition Installation location
(Installation
and
operation) Ambient temperature
Ambient humidity
Altitude
Vibration
Storage condition
A motor with PG and option card (OPC-
G11S-PG) are necessary. (ZERO)
P11S series doesn't have this function.
Option card (PG/SY) required
Option card is required.
230V : 400Vdc, 460V : 800Vdc
• Line voltage : 5kV
• Between power line and ground : 7kV (1.2/50µs)
230V : 200Vdc, 460V : 400Vdc
•
Operation details are selected by Function code F14.
• 30HP or smaller inverter
• 40HP or larger inverter
• Thermal time constant (0.5 to 75.0
minutes) can be preset for a special motor.
• External singnal is used for changeover.
Related transistor output : OL
<OL1, OL2>
• The inverter stops electricity discharge
operation, to protect the DB resistor.
Then, usually inverter displays "OU trip".
• Connects the relay output to the terminal
THR, to protect the DB resistor.
Then, usually the inverter displays "OH trip".
Number of Auto reset times and reset
interval can be preset.
Pollution degree 2 when complying with Low
Voltage Directive is needed.
*
When altitude is 6600ft (2000m) or higher,
interface circuit should be isolated from main
power lines, to comply with Low Voltage Directive.
The stopped motor holds its rotor angle. For a rotating motor, the
rotor angle is held after deceleration.
The SY option card can be used for positioning control by
differential counter method.
This function controls the synchronized operation between 2 axes with PGs.
Protects the inverter by electronic thermal and detection of inverter temperature.
Detects DC link circuit overvoltage, and stops the inverter.
Protects the inverter against surge voltage between the main
circuit power line and ground.
Detects DC link circuit undervoltage, and stops the inverter.
Phase loss protection for power line input
Protects the inverter by detection of inverter heat sink temperature.
Short-circuit protection for inverter output circuit
• Ground fault protection for inverter output circuit (3-phase current
detection method)
• Zero-phase current detection method
• The inverter trips, and then protects the motor.
• Electronic thermal overload relay can be selected for standard
motor or inverter motor
• The second motor's electronic thermal overload relay can be
preset for 2-motor changeover operation.
• Before the inverter trips, outputs OL(Overload early warning)
signal at a preset level.
• Prevents DB resistor overheating by internal electronic thermal
overload relay. (10HP or smaller for G11S, 15HP or smaller for
P11S)
•Prevents DB resistor overheating by external thermal overload
relay attached to DB resistor. (15HP or larger for G11S, 20HP or
larger for P11S)
When the inverter executes auto-tuning, detects each phase
impedance imbalance (and stops the inverter).
When the motor temperature exceeds allowable value, the inverter
trips automatically.
When the inverter is tripped, it resets automatically and restarts.
• Indoor use only.
• Free from corrosive gases, flammable gases, oil mist, dusts, and
direct sunlight.
-10 to +50˚C (14 to +122˚F) (For inverters of 30HP or smaller, remove the
ventilation covers when operated at temperature of 40˚C (104˚F)or above.)
5 to 95%RH (non-condensing)
33ft (1000m) or less. Applicable to 9800ft (3000m) with power
derating (-10% / 33ft (1000m))
3mm (vibration amplitude) at 2 to less than 9Hz
9.8m/s2 at 9 to less than 20Hz
2m/s2 at 20 to less than 55Hz (2m/s2 at 9 to less than 55Hz : G11S
125HP, P11S 150HP or more)
1m/s2 at 55 to less than 200Hz
• Temperature : -25 to +65°C (-13 to +149°F)
• Humidity : 5 to 95%RH (No-condensing)
Item Explanation Remarks Func. code
E46
E45
Languages for the LCD monitor are
selectable.
English, German, French, Spanish, Italian,
Japanese
• Operation monitor
Two types of monitoring is selectable by "E45".
• Displays operation guidance
• Bargraph
• Output frequency (before slip
compensation) [%]
• Output current [A]
• Output torque [%]
• Alarm monitor
When the inverter trips, displays the alarm.
Item Explanation Remarks Func. code Explanation Func. code
LCD monitor
LED monitor
Indication Operation mode
(Running)
The following items can be displayed
by function setting.
• Output frequency 1 (Before slip
compensation) [Hz]
• Output frequency 2 (After slip
compensation) [Hz]
• Setting frequency [Hz]
• Output current [A]
• Output voltage [V]
• Motor synchronous speed [r/min]
• Line speed [m/min]
• Load shaft speed [r/min]
• Torque calculation value [%]
• Input power [kW]
• PID reference value
• PID reference value (remote)
• PID feedback value
• Trip history
Cause of trip of the
last 4 trips can be
retained and
displayed. (Even
when main power is
off, data is retained.)
• PG feedback value
is displayed when
PG option is used.
E43
F01
C30
Operation monitor & Alarm monitor
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 8 AdobePageMaker6.5J/PPC

1-9
Chapter 1
2. Common Specifications
1
Indication Stopping
Trip mode
Selected setting value or output
value
Displays the cause of trip by codes
as follows.
• OC1 (Overcurrent during
acceleration)
• OC2 (Overcurrent during
deceleration)
• OC3 (Overcurrent running at
constant speed)
• EF (Ground fault)
• Lin (Input phase loss)
• FUS (Fuse blown)
• OU1 (Overvoltage during
acceleration)
• OU2 (Overvoltage during
deceleration)
• OU3 (Overvoltage running at
constant speed)
• LU (Undervoltage)
• OH1 (Overheating at heat sink)
• OH2 (External thermal relay tripped)
• OH3 (Overtemperature at inside air)
• dBH (Overheating at DB circuit)
• OL1 (Motor1 overload)
• OL2 (Motor2 overload)
• OLU (Inverter unit overload)
• OS (Overspeed)
• PG (PG error)
• Er1 (Memory error)
• Er2 (KEYPAD panel communica-
tion error)
• Er3 (CPU error)
• Er4 (Option communication error)
• Er5 (Option error)
• Er6 (Operation procedure error)
• Er7 (Output phase loss error,
impedance imbalance)
• Er8 (RS-485 error)
• Trip history
Cause of trip of the last
4 trips can be retained
and displayed. (Even
when main power is off,
data are retained.)
Selectable from the following 7 indications.
••
••
• Function setting
•
Displays function codes and its data or data code.
• Changes the data value.
••
••
• Operation condition monitoring
•Output frequency (before slip compensation)
[Hz]
• Output current [A]
• Output voltage [V]
• Torque calculation value [%]
• Setting frequency [Hz]
• Operation condition
• FWD or REV (Forward or reverse running)
• IL (Current limiting)
• VL or LU (Voltage limiting or stopped by
undervoltage)
• TL (Torque limiting)
• Motor synchronous speed [r/min]
• Load shaft speed [r/min]
• Line speed [m/min]
• PID reference value
• PID feedback value
• Driving torque limiter setting value [%]
• Braking torque limiter setting value [%]
••
••
• Tester function (I/O check)
Displays on/off status of digital input and
output signals, level of analog input and
pulse output signals.
•Digital I/O : ■ (ON), ■■ (OFF)
• Analog I/O: [V] , [mA], [H], [p/s]
••
••
• Maintenance data
• Operation time [h]
• DC link circuit voltage [V]
• Temperature at inside air [°C]
• Temperature at heat sink [°C]
• Maximum current [A]
• Main circuit capacitor life [%]
• Control PC board life [h]
• Cooling fan operation time [h]
• Communication error times (KEYPAD)
• Communication error times (RS-485)
• Communication error times (Option)
• ROM version (Inverter)
• ROM version (KEYPAD)
• ROM version (Option)
••
••
• Load factor calculation
• Measurement time [s]
• Maximum current [A]
• Effective current [A]
• Average braking power [%]
••
••
• Alarm data
Dispalys operation data immediately before
a trip occurs.
• Output frequency (before slip compensation)
[Hz]
• Output current [A]
• Output voltage [V]
• Torque calculation value [%]
• Setting frequency [Hz]
• Operation condition
• FWD or REV (Forward or reverse
running)
• IL (Current limiting)
• VL or LU (Voltage limiting or stopped by
undervoltage)
• TL (Torque limiting)
• Operation time [h]
• DC link circuit voltage [V]
• Temperature at inside air [°C]
• Temperature at heat sink [°C]
• Communication error times (KEYPAD)
• Communication error times (RS-485)
• Communication error times (Option)
• Digital input terminal condition (Remote)
•
Digital input terminal condition (Communication)
• Transistor output terminal condition
• Trip history code
• Multiple alarm exist
••
••
• Data copy
• Function code (data and data code) is
stored in one inverter and is copied to
another inverter *.
* Copying is only available to the inverter
of the same series, same voltage class,
and same capacity .
Item Explanation Remarks Func. code Explanation Func. code
E44 Function setting & monitor
Charge lamp When the DC link circuit voltage is higher than 50V, the charge lamp is ON.
LCD monitor
LED monitor
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 9 AdobePageMaker6.5J/PPC

1-10
Chapter 1
2. Common Specifications
2.2 Protective functions
1) Retaining alarm signal when auxiliary controll power supply is not used :
If the inverter power supply is cut off while an internal alarm signal is being output, the alarm signal cannot be retained.
2) To issue the RESET command, press the
RESET
key on the KEYPAD panel or connect terminals RST and CM and disconnect them afterwards.
3) Fault history data is stored for the past four trips.
*) ▲▲ : By function code setting, alarm output can be disabled.
Function Description
LED monitor
Alarm output Func. code
(30Ry) *)
Overcurrent protection
(Short-circuit)
(Ground fault)
Overvoltage protection
Incoming surge
protection
Undervoltage
protection
Input phase loss
protection
Overheat protection
Electronic thermal
overload relay
(Motor protection)
Fuse blown
Stall prevention
(Momentary
overcurrent limitation)
Active drive
External alarm
input
Overspeed protection
PG error
Alarm output
(for any fault)
Alarm reset command
Alarm history memory
Storage of data on
cause of trip
Memory error
KEYPAD panel
communication error
CPU error
Option
communication error
Option error
Operation
procedure error
Output phase loss
error
RS-485 communication
error
• Stops running to protect inverter from an overcurrent resulting from
overload.
• Stops running to protect inverter from an overcurrent due to a short-circuit
in the output circuit.
• Stops running to protect inverter from an overcurrent due to a ground
fault in the output circuit.
• Stops running to protect inverter from an overcurrent resulting from ground fault
in the output circuit by detecting zero-phase current. (30kW or larger model only)
• The inverter stops when it detects an overvoltage in the DC link circuit.
(230V : 400Vdc or more, 460V : 800Vdc or more)
•
Protection is not assured if excess AC line voltage is applied inadvertently.
• Protects the inverter against surge voltage between the main circuit power line and ground.
• Protects the inverter against surge voltage in the main circuit power line.
• The inverter may be tripped by some other protective function.
• Stops the inverter when the DC link circuit voltage drops below undervoltage level.
(230V series : 200V DC or less, 460V series : 400V DC or less)
• Alarm signal is not output even if the DC link circuit voltage drops, when “F14 : 3 to 5” is selected.
• The inverter is protected from being damaged when open-phase fault occurs.
• Stops the inverter when it detects excess heat sink temperature in case of cooling fan failure or
overload.
• Stops the inverter when it detects an abnormal rise in temperature in the inverter unit caused by
insufficient ventilation in cubicles or an abnormal ambient temperature.
• Stops the inverter when it detects an abnormal rise in temperature inside the inverter.
• When the built-in or external braking resistor overheats, the inverter stops discharging and running.
•
Function data appropriate for the resistor type (built-in/external) must be set. (G11S: 10HP or smaller only)
• This function stops the inverter by detecting an inverter overload.
• This function stops the inverter by detecting an overload in a standard
motor or inverter motor.
•
When a blown fuse is detected, the inverter stops running. (40HP or larger model only)
• When an output current exceeds the limit during acceleration, this function lowers output frequency
to prevent the occurrence of an OC1 trip.
• The stall prevention function can be disabled.
• During running in which acceleration is 60s or longer, this function increases the acceleration time to
prevent the occurrence of an OLU trip.
• The acceleration time can be prolonged up to three times the preset time.
• The inverter stops on receiving external alarm signals.
• Use THR terminal function (digital input).
• Stops the inverter when the output frequency exceeds the rated maximum frequency by 20%.
• If disconnection occurs in pulse generator circuits, the inverter issues an alarm.
• The inverter outputs a relay contact signal when the inverter issued an
alarm and stopped.
• An alarm-stop state of the inverter can be cleared with the RESET key or
by a digital input signal (RST).
• Store up to four instances of previous alarm data.
• The inverter can store and display details of the latest alarm history data.
• The inverter checks memory data after power-on and when the data is written. If a memory error is
detected, the inverter stops.
• If an error is detected in communication between the inverter and KEYPAD when the Keypad panel
is being used, the inverter stops.
• When operated by external signals, the inverter continues running. The alarm output (for any fault) is
not output. Only Er2 is displayed.
• If the inverter detects a CPU error caused by noise or some other factor, the inverter stops.
• If a checksum error or disconnection is detected during communication, the inverter issues an alarm.
• If a linkage error or other option error is detected, the inverter issues an alarm.
Er6 is indicated only when the inverter is forcedly stopped by [STOP1] or [STOP2] operation in E01 to
E09 (Set value: 30 or 31)
If an unbalance of output circuits is detected during auto-tuning, this function issues an alarm (and
stops the inverter).
• If an RS-485 communication error is detected, the inverter issues an alarm.
During acceleration
During deceleration
While running at constant
speed
Groung fault
During acceleration
During deceleration
While running at constant speed
Motor 1 overload
Motor 2 overload
• Output terminals:
30A, 30B, and 30C
• Use the RST terminal
function for signal input.
• Even if main power
input is turned off, alarm
history and trip-cause
data are retained.
F14
F13
F10 to F12
A06 to A08
F40, F41
E16, E17
H12
F36
F02
––
NOTES :
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 10 AdobePageMaker6.5J/PPC

1-11
Chapter 1
2. Common Specifications
1
2.3 Function settings
The function marked can be set while the inverter is running. Other functions must be set while the inverter is
stopped.
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
Setting can be made so that
a set value cannot be easily
changed by KEYPAD panel
operation.
Sets the operation
command input method.
Sets the maximum output
frequency for motor 1.
Sets the base frequency for
motor 1.
Sets the output voltage at
the Base frequency 1 “F04”.
Sets the output voltage at the
Maximum frequency 1 “F03”.
During deceleration, Coast-
to-stop can be selected by
setting of “H11”.
Torque boost for motor 2
can also be set by “A05”.
Selection fo motor 2 can
also be made by “A06”.
Level setting for motor 2 can
also be made by “A07”.
Setting for motor 2 can also
be made by “A08”.
Not provided with models
15HP or larger.
Not provided with models
20HP or larger.
For detailed setting
procedure, see “H13” to
“H16”.
Minus bias setting is possible.
-- 0
-- 0
-- 0
Hz 1 60
Hz 1 60
V1
230:(230V class)
460:(460V class)
V1230:(230V class)
460:(460V class)
s0.01 6.0 20.0
s 0.01 6.0 20.0
- 0.1 G11S : 2.0
P11S : 2.0
-- 1
A 0.01 Motor rated
current
min 0.1 5.0 10.0
-- 1
-- 0
-- 0
-- 0
-- 0
Hz 1 70
Hz 1 0
% 0.1 100.0
Hz 0.1 0.0
Hz 0.1 0.0
% 1 0
s 0.1 0.0
F00 Data protection F00 DATA PRTC 0:Data change enable
1:Data protection
F01 Frequency command 1 F01 FREQ CMD 1 0 : KEYPAD operation (
∨
or
∨
key)
1:
Voltage input (terminal 12) (0 to 10Vdc, 0 to 5Vdc)
2:Current input (terminal C1) (4 to 20mAdc)
3:Voltage and current input (terminals 12 and C1)
4:Reversible operation with polarity
(terminal 12) (0 to ± 10Vdc)
5:Reversible operation with polarity
(terminal 12 and V1) (0 to ± 10Vdc)
6:Inverse mode operation (terminal 12)
(+10 to 0Vdc)
7:Inverse mode operation (terminal C1)
(20 to 4mAdc)
8:UP/DOWN control 1 (initial freq. = 0Hz)
9:UP/DOWN control 2 (initial freq. = last value)
10 : PATTERN operation
11 : DI option or Pulse train input
F02 Operation method F02 OPR METHOD 0 : KEYPAD operation (
FWD
or
REV
or
STOP
key)
1:External signal input (digital input)
(Operation by FWD or REV command)
F03 Maximum frequency 1 F03 MAX Hz-1 G11S : 50 to 400Hz
P11S : 50 to 120Hz
F04 Base frequency 1 F04 BASE Hz-1 G11S : 25 to 400Hz
P11S : 25 to 120Hz
F05 Rated voltage 1 F05 RATED V-1 0V : The output voltage in proportion to the power
supply voltage is set.
(at Base frequency 1 ) 80 to 240V : AVR active (230V)
320 to 480V : AVR active (460V)
F06 Maximum voltage 1 F06 MAX V-1 80 to 240V : AVR active (230V)
(at Maximum frequency 1) 320 to 480V : AVR active (460V)
F07 Acceleration time 1 F07 ACC TIME1 0.01 to 3600s
F08 Deceleration time 1 F08 DEC TIME1 0.01 to 3600s
F09 Torque boost 1 F09 TRQ BOOST1 0.0 : Automatic (for constant torque load)
0.1 to 0.9 : Manual (for variable torque load)
1.0 to 1.9 : Manual (for proportional torque load)
2.0 to 20.0 : Manual (for constant torque load)
F10 Electronic (Select) F10 ELCTRN OL1 0 : Inactive
thermal 1 : Active (for 4-pole standard motor)
overload relay 2 : Active (for 4-pole inverter motor)
F11 for motor 1 (Level) F11 OL LEVEL1 Approx. 20 to 135% of rated current of the inverter
rated current, in Ampere
F12 (Thermal time constant) F12 TIME CNST1 0.5 to 75.0 min
F13 Electronic thermal F13 DBR OL G11S [10HP or smaller]
overload relay 0 : Inactive
(for braking resistor) 1 : Active (for built-in braking resistor)
2 : Active (for external braking resistor)
[15HP or larger]
0 : Inactive
P11S [15HP or smaller]
0 : Inactive
2 : Active (for external braking resistor)
[20HP or larger]
0 : Inactive
F14 Restart mode (Select) F14 RESTART 0 : Inactive (Trip and alarm when power failure occurs.)
after momentary 1 : Inactive (Trip, and alarm when power recovers.)
power failure 2 : Inactive (Deceleration stop, and alarm)
3:
Active (Smooth recovery by continuous operation mode)
4:Active (Momentarily stops and restarts at output
frequency of before power failure)
5:Active (Momentarily stops and restarts at
starting frequency)
F15 Frequency (High) F15 H LIMITER G11S : 0 to 400Hz P11S : 0 to 120Hz
F16 limiter (Low) F16 L LIMITER G11S: 0 to 400Hz P11S : 0 to 120Hz
F17 Gain (for frequency F17 FREQ GAIN 0.0 to 200.0%
setting signal)
F18 Bias frequency F18 FREQ BIAS G11S: -400.0 to 400.0Hz P11S : -120.0 to 120.0Hz
F20 DC brake(Starting freq.) F20 DC BRK Hz 0.0 to 60.0Hz
F21 (Braking level) F21 DC BRK LVL G11S : 0 to 100% P11S : 0 to 80%
F22 (Braking time) F22 DC BRK t 0.0 (DC brake inactive), 0.1 to 30.0s
Fundamental Functions
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 11 AdobePageMaker6.5J/PPC

1-12
Chapter 1
2. Common Specifications
The function marked can be set while the inverter is running. Other functions must be set while the inverter is
stopped.
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
F23 Starting frequency (Freq.) F23 START Hz 0.1 to 60.0Hz
F24 (Holding time) F24 HOLDING t 0.0 to 10.0s
F25 Stop frequency F25 STOP Hz 0.1 to 6.0Hz
F26 Motor sound (Carrier freq.) F26 MTR SOUND 0.75-15kHz 0.75-10kHz 0.75-6kHz
G11S -75HP 100HP –
P11S -30HP 40-100HP 125HP
F27 (Sound tone) F27 MTR TONE 0 : Level 0
1: Level 1
2: Level 2
3: Level 3
F30 FMA (Voltage adjust) F30 FMA V-ADJ 0 to 200%
F31 (Function) F31 FMA FUNC 0 : Output frequency 1 (Before slip compensation)
1: Output frequency 2 (After slip compensation)
2: Output current
3: Output voltage
4: Output torque
5: Load factor
6: Input power
7: PID feedback value
8: PG feedback value
9: DC link circuit voltage
10 : Universal AO
F33 FMP (Pulse rate) F33 FMP PULSES 300 to 6000 p/s (at full scale)
F34 (Voltage adjust) F34 FMP V-ADJ 0% : Pulse rate output (50% duty)
1 to 200% : Voltage adjust : 2670 p/s (duty adjust)
F35 (Function) F35 FMP FUNC 0 : Output frequency 1 (Before slip compensation)
1: Output frequency 2 (After slip compensation)
2: Output current
3: Output voltage
4: Output torque
5: Load factor
6: Input power
7: PID feedback value
8: PG feedback value
9: DC link circuit voltage
10 : Universal AO
F36 30RY operation mode F36 30RY MODE 0 : The relay(30) excites on trip mode
1: The relay(30) excites on normal mode
F40 Torque limiter 1 (Driving) F40 DRV TRQ 1 G11S : 20 to 200, 999% (999: No limit) *2)
P11S : 20 to 150, 999% (999: No limit)
F41 (Braking) F41 BRK TRQ 1 G11S : 0 (Automatic deceleration control),
20 to 200, 999% (999: No limit) *2)
P11S : 0 (Automatic deceleration control),
20 to 150, 999% (999: No limit)
F42 Torque vector control 1 F42 TRQVECTOR1 0 : Inactive
1: Active
Sets the frequency at stopping.
*In case of VT use, carrier
frequency should be adjusted
depending on capacity
Four types of tone can be
selected.
This setting is effective when
the carrier frequency "F26" is
set at 7kHz or lower.
This selection can be made
at 7kHz or higher, but the
tone does not change.
About 0 and 1
Percent indication based on
inverter rated voltage
About 0 and 1
Hz 0.1 0.5
s 0.1 0.0
Hz 0.1 0.2
kHz 1 2
-- 0
% 1100
-- 0
p/s 1 1440
% 1 0
-- 0
-- 0
% 1999
% 1999
-- 0
1:Output frequency 2
0:Output frequency 1
Setting
value
KEYPAD
panel Slip compensation
amount
Inverter
M
1:Output frequency 2
0:Output frequency 1
Setting
value
KEYPAD
panel Slip compensation
amount
Inverter
M
Extension Terminal Functions
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
E01 X1 terminal function E01 X1 FUNC Selects from the following items.
E02 X2 terminal function E02 X2 FUNC
E03 X3 terminal function E03 X3 FUNC
E04 X4 terminal function E04 X4 FUNC
E05 X5 terminal function E05 X5 FUNC
E06 X6 terminal function E06 X6 FUNC
E07 X7 terminal function E07 X7 FUNC
E08 X8 terminal function E08 X8 FUNC
E09 X9 terminal function E09 X9 FUNC
0: [SS1]
1:Multistep freq. select (1 to 4bit) [SS2]
2:(16 steps) [SS4]
3: [SS8]
4:4 steps of ACC/DEC time [RT1]
5:selectioin (1 to 2bit) [RT2]
6: 3-wire operation stop command [HLD]
7: Coast-to-stop command [BX]
8: Alarm reset [RST]
9: Trip command (External fault) [THR]
10 : Jogging operation [JOG]
11 : Freq. set. 2 / Freq. set. 1 [Hz2/Hz1]
12 : Motor 2 / Motor 1 [M2/M1] 12: Switches motor
parameters to motor 2
when this signal is on.
-- 0
-- 1
-- 2
-- 3
-- 4
-- 5
-- 6
-- 7
-- 8








Chapter01J(P6˜18).p65 07.8.9, 11:53Page 12 AdobePageMaker6.5J/PPC

1-13
Chapter 1
2. Common Specifications
1
The function marked can be set while the inverter is running. Other functions must be set while the inverter is
stopped.
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
13 : DC brake command [DCBRK]
14 : Torque limiter 2 / Torque limiter 1
[TL2/TL1]
15 : Switching operation between line and inverter
(50Hz) [SW50]
16 : Switching operation between line and inverter
(60Hz) [SW60]
17 : UP command [UP]
18 : DOWN command [DOWN]
19 : Write enable for KEYPAD [WE-KP]
20 : PID control cancel [Hz/PID]
21 : Inverse mode changeover (terminals 12 and C1)
[IVS]
22 : Interlock signal for 52-2 [IL]
23 : TRQ control cancel [Hz/TRQ]
24 : Link enable (Bus, RS-485) [LE]
25 : Universal DI [U-DI]
26 : Pick up start mode [STM]
27 : SY-PG enable [PG/Hz]
28 : Synchronization command [SYC]
29 : Zero speed command [ZERO]
30 : Forced stop command [STOP1]
31 : Forced stop command with Deceleration time 4
[STOP2]
32 : Pre-exciting command [EXITE]
E10 Acceleration time 2 E10 ACC TIME2 0.01 to 3600s
E11 Deceleration time 2 E11 DEC TIME2
E12 Acceleration time 3 E12 ACC TIME3
E13 Deceleration time 3 E13 DEC TIME3
E14 Acceleration time 4 E14 ACC TIME4
E15 Deceleration time 4 E15 DEC TIME4
E16 Torque limiter 2 (Driving) E16 DRV TRQ 2 G11S : 20 to 200%, 999% (999: No limit) *2)
P11S : 20 to 150%, 999% (999: No limit)
E17 (Braking) E17 BRK TRQ 2 G11S: 0 (Automatic deceleration control),
20 to 200%, 999% (999: No limit) *2)
P11S : 0 (Automatic deceleration control),
20 to 150%, 999% (999: No limit)
E20 Y1 terminal function E20 Y1 FUNC Selects from the following items.
E21 Y2 terminal function E21 Y2 FUNC
E22 Y3 terminal function E22 Y3 FUNC
E23 Y4 terminal function E23 Y4 FUNC
E24 Y5A,Y5C terminal function E24 Y5 FUNC
0: Inverter running [RUN]
1: Frequency equivalence signal [FAR]
2: Frequency level detection [FDT1]
3: Undervoltage detection signal [LU]
4: Torque polarity [B/D]
5: Torque limiting [TL]
6: Auto-restarting [IPF]
7: Overload early warning [OL1]
8: KEYPAD operation mode [KP]
9: Inverter stopping [STP]
10 : Ready output [RDY]
11 : Line/Inv changeover (for 88) [SW88]
12 : Line/Inv changeover (for 52-2) [SW52-2]
13 : Line/Inv changeover (for 52-1) [SW52-1]
(11 to 13: For Line/Inverter changeover operation)
14 : Motor 2 / Motor 1 [SWM2]
15 : Auxiliary terminal (for 52-1) [AX]
16 : Time-up signal [TU]
17 : Cycle completion signal [TO]
18 : Stage No. indication 1 [STG1]
19 : Stage No. indication 2 [STG2]
20 : Stage No. indication 4 [STG4]
(16 to 20: For PATTERN operation)
21 : Alarm indication 1 [AL1]
22 : Alarm indication 2 [AL2]
23 : Alarm indication 4 [AL4]
24 : Alarm indication 8 [AL8]
(21 to 24: For Alarm signal output)
25 : Fan operation signal (for 40HP and above) [FAN]
26 : Auto-resetting [TRY]
27 : Universal DO [U-DO]
28 : Overheat early warning [OH]
29 : Synchronization completion signal [SY]
30 : Lifetime alarm [LIFE]
31 : 2nd Freq. level detection [FDT2]
32 : 2nd OL level early warning [OL2]
33 : Terminal C1 off signal [C1OFF]
34 : Speed existence signal [DNZS]
E25 Y5 RY operation mode E25 Y5RY MODE 0 : Inactive (Y5 Ry excites at "ON signal" mode.)
1: Active (Y5 Ry excites at "OFF signal" mode.)
s 0.01 6.00 20.00
s 0.01 6.00 20.00
s 0.01 6.00 20.00
s 0.01 6.00 20.00
s 0.01 6.00 20.00
s 0.01 6.00 20.00
% 1999
% 1999
-- 0
-- 1
-- 2
-- 7
-- 10
--
0
15, 16: When 15 or 16 is turned
on, the operation smoothly
changes to commercial
power operation at 50 or
60Hz, without stopping the
motor.
From 50Hz power line : (SW50)
From 60Hz power line : (SW60)
17, 18 : "F01" must be set at
"8: UP/DOWN
control 1" or "9: UP/
DOWN control 2".
20 :When this signal is on,
PID control is canceled
and KEYPAD operation
is effective.
23 :When this signal is on,
torque control is canceled.
27 : PG/Hz is option.
28 : SY is option.
29 : ZERO is option.
32 : EXITE is option.
F07
F08
F40, F41
29 : SY is option.
34: DNZS is option.
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 13 AdobePageMaker6.5J/PPC

1-14
Chapter 1
2. Common Specifications
The function marked can be set while the inverter is running. Other functions must be set while the inverter is
stopped.
Control Functions of Frequency
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
C01 Jump (Jump freq. 1) C01 JUMP Hz 1 G11S : 0 to 400Hz P11S : 0 to 120Hz
C02 frequency(Jump freq. 2) C02 JUMP Hz 2
C03 (Jump freq. 3) C03 JUMP Hz 3
C04 (Hysteresis) C04 JUMP HYSTR 0 to 30Hz
C05 Multistep (Freq. 1) C05 MULTI Hz-1 G11S : 0.00 to 400.00Hz P11S : 0.00 to 120.00Hz
C06 frequency (Freq. 2) C06 MULTI Hz-2
C07 setting (Freq. 3) C07 MULTI Hz-3
C08 (Freq. 4) C08 MULTI Hz-4
C09 (Freq. 5) C09 MULTI Hz-5
C10 (Freq. 6) C10 MULTI Hz-6
C11 (Freq. 7) C11 MULTI Hz-7
C12 (Freq. 8) C12 MULTI Hz-8
C13 (Freq. 9) C13 MULTI Hz-9
C14 (Freq.10) C14 MULTI Hz10
C15 (Freq.11) C15 MULTI Hz11
C16 (Freq.12) C16 MULTI Hz12
C17 (Freq.13) C17 MULTI Hz13
C18 (Freq.14) C18 MULTI Hz14
C19 (Freq.15) C19 MULTI Hz15
C20 JOG frequency C20 JOG Hz G11S : 0.00 to 400.00Hz P11S : 0.00 to 120.00Hz
C21 PATTERN operation C21 PATTERN 0 : Active (Mono-cycle operation, and then stops.)
(Mode select) 1 : Active (Continuous cyclic operation during
operation command is effective.)
2: Active (Mono-cycle operation, and after
continues at the latest setting frequency.)
Hz 1 0
Hz 1 0
Hz 1 0
Hz 1 3
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 0.00
Hz 0.01 5.00
-- 0
Function Setting range Unit Min. Factory setting Remarks
Code Name LCD monitor unit 30HP 40HP
E30 FAR function (Hysteresis) E30 FAR HYSTR 0.0 to 10.0 Hz
signal
E31 FDT1 function (Level) E31 FDT1 LEVEL G11S : 0 to 400 Hz P11S : 0 to 120 Hz
E32 signal (Hysteresis) E32 FDT HYSTR 0.0 to 30.0 Hz
E33 OL1 function(Mode select) E33 OL1 WARNING 0 : Thermal calculation
signal 1 : Output current
E34 (Level) E34 OL1 LEVEL G11S : Approx. 5 to 200% of rated current
P11S : Approx. 5 to 150% of rated current
E35 (Timer) E35 OL TIMER 0.0 to 60.0s
E36 FDT2 function (Level) E36 FDT2 LEVEL G11S : 0 to 400Hz P11S : 0 to 120Hz
E37 OL2 function (Level) E37 OL2 LEVEL G11S : Approx. 5 to 200% of rated current
P11S : Approx. 5 to 150% of rated current
E40 Display coefficient A E40 COEF A -999.00 to 999.00
E41 Display coefficient B E41 COEF B -999.00 to 999.00
E42 LED Display filter E42 DISPLAY FL 0.0 to 5.0s
E43 LED Monitor (Function) E43 LED MNTR 0 : Output frequency 1 (Before slip compensation)
1: Output frequency 2 (After slip compensation)
[Hz]
2: Setting frequency [Hz]
3: Output current [A]
4: Output voltage [V]
5: Motor synchronous speed [r/min]
6: Line speed [m/min]
7: Load shaft speed [r/min]
8: Torque calculation value [%]
9: Input power [kW]
10 : PID reference value
11 : PID reference value (remote)
12 : PID feedback value
E44 (Display at STOP mode) E44 LED MNTR2 0 : Setting value
1: Output value
E45 LCD Monitor (Function) E45 LCD MNTR 0 :Displays operation guidance
1:Bar graph
(Output freq., Output current, and Output torque)
E46 (Language) E46 LANGUAGE 0 :Japanese
1:English
2:German
3:French
4:Spanish
5:Italian
E47 (Contrast) E47 CONTRAST 0 (Soft) to 10 (Hard)
E20 to E24: 1
E20 to E24: 2
E20 to E24: 7
About 0 and 1
Selects items displayed on
the LED monitor when
inverter is stopping.
Indicates based on inverter
rated current.
Hz 0.1 2.5
Hz 1 60
Hz 0.1 1.0
-- 0
A 0.01 Motor rated
current
s 0.1 10.0
Hz 1 60
A0.01 Motor rated
current
- 0.01 0.01
-0.01 0.00
s 0.1 0.5
-- 0
-- 0
-- 0
-- 1
-- 5
1:Output frequency 2
0:Output frequency 1
Setting
value
KEYPAD
panel Slip compensation
amount
Inverter
M
Chapter01J(P6˜18).p65 07.8.9, 11:53Page 14 AdobePageMaker6.5J/PPC
