ACCESSORIES: HD & SD ENG/EFP
THREE-MODE FINE
FOCUS
By shifting the sensitivity from
the wide side to the telephoto
side of the focus range, this
control provides more precise
focusing
for studio
or sports
productions.
A. CFC-990
Flex Cable
B. FMM-3B/6B
Manual Module
C. ZMM-6
Manual Module
D. EBF-1 Focus Cable
E. MCA-6
F. ERD-20A-A02
Zoom Demand
G. FSP-13G
Focus Positional
Module
H. EPD-4A-E02
I. CZH-14
Focus Handle
J. CFH-11
Focus Handle
K. MCA-7
Mounting Clamp
L.
EPD-20A-A01/A02
Focus Demand
M. ERD-10A-D01
Zoom Demand
N. ALH-117A-02A
Support for
HA36x /A36x
HA42x
ROTATING CONTROL ANGLEMOD
INFINITY
CONVENTIONAL
TYPE
9 PIN CONNECTOR
SA-206-A-005
SERIAL DIGITAL
REMOTE CONTROL
BY PC
Remote control of zoom, focus
and iris for Digipower lenses is
possible via serial digital link,
providing accurate positioning
for virtual studio and other
applications requiring digital
precision.
A. B.
F. G.
L.
I. J.
E.
H.
D.
M.
K.
C.
VTR
Switch
Zoom Speed
Control Knob
One Shot
Preset
Indicator
One Shot
Preset Switch
Quickzoom
Switch
Return
Switch
Quickzoom
Switch
Reverse
Switch
Focus/Iris
Control Select
Switch
Focus/Iris
Control Knob
Thumb
Ring
*New Digital features only available on ERM/ERD-M/S.
ERD-10A-D01
DIGI ZOOM DEMAND*
N.
Note: ERD-20A-A02 (F) and EPD-20A-A02 (L)
replace the ERD-T22 and EPD-2CA.
STANDARD REAR CONTROL KITS
FMM-6B
FMM-3B 12 PIN
ERD-10A-D01
MCA-7 MCA-6B
CFH-11
CFC-12-990
FMM-6B
FMM-3B
CFC-12-990
MCA-7 MCA-7
CZH-14
CFH-11
CFC-12-990
ZMM-6
SS-13A Servo Focus/Servo Zoom
For use with ERD type lenses.
*Specify camera type
**FMM-3C for use on HA36x, HA42x and HA25x
FMM-6B
FMM-3B
12 PIN
ERD-20A-A02
MCA-7MCA-7
CFH-11
CFC-12-990
3 PIN
FSP-13G
12 PIN
ERD-20A-A02
MCA-7
EPD-21A-A01/A02
MCA-7
12 PIN
12 PIN
ERD-20A-A02
MCA-7 MCA-7
EPD-21A-A01/A02
MM-11 Manual Focus/Manual Zoom
Not available on HA42x, HA36x and A36x
MS-11 Manual Focus/Servo Zoom SS-11 Servo Focus/Servo Zoom
Not available on HA42x, HA36x and A36
12 PIN
12 PIN
ERD-10A-D01
MCA-6BMCA-6B
EPD-4A-E02
EBF-1
FSP-13G
EBF-1
12 PIN
3 PIN
ERD-10A-D01
EPD-4A-E02
MCA-6B MCA-6B
12 PIN
12 PIN
ERD-10A-D01
ESB-6A-D12
SE-210A-R15
MCA-6B
MCA-6B
EEC-13
MS-11D Manual Focus/Servo Zoom
For use with RM/ZM type lenses.
SS-13D Servo Focus/Servo Zoom
For use with RD/ZD type lenses.
SS-11D Servo Focus/Servo Zoom
For use with RM/ZM type lenses.
SS-14S Servo Focus/Servo Zoom
For use with RD/ZD type lenses.
DIGI POWER REAR CONTROL KITS
MOUNTING SYSTEM
Fujinon has replaced the “cone”
shaped mounting system with the
“tooth” system. The cone type may
still be ordered as a special order.
New Style
MCA-7
Old Style
MCA-1A
(Discontinued)
** FMM-6B
FMM-3C
** FMM-6B
FMM-3C
** FMM-6B
FMM-3C
*RD contain
servos for
zoom and
focus.
Zoom Ratio/Format 25X / 2/3"
Focal Length 11.5 to 288 mm
(2X) 23 to 576 mm
Maximum Relative 1:2.0 (11.5 ~ 206 mm)
Aperture 1:2.8 (288 mm)
Maximum Photometric 1:2.1 (11.5 ~ 206 mm)
Aperture T-No. 1:2.9 (288 mm)
Angular Field of View
16:9 Aspect Ratio
M.O.D. from Image Plane 2.51m
M.O.D. from Front of Lens 2.2m
Object Dimensions
at M.O.D.
Filter Size ø 107m P=1 (On Barrel)
Dia ø x Length (w/o Hood) ø110 x 265 mm
Weight (w/o Hood) 2.8 kg
Features Inner Focus / Quick Zoom / Inner Focus
11.5 mm45° 16’ x 26° 23’
288 mm1° 54’ x 1° 04’
(2X) 23 mm23° 33’ x 13° 22’
576 mm0° 57’ x 0° 32’
11.5 mm1740 x 978 mm
288 mm70 x 39 mm
(2X) 23 mm870 x 489 mm
576 mm35 x 20 mm
HA25x11.5BE RD*
Extender
