YF2.8A-SA2 / YF4A-SA2 YF8A-SA2 / YF16A-SA2
9CCTV LENSES
YF2.8A-SA2 / YF4A-SA2 YF8A-SA2 / YF16A-SA2
For Security
1/3˝ FIXED
Auto Iris Fixed Focal Length Lens (DC Type)
For Security
NEAR
FAR
YF***A-SA2
JAPAN
FUJI PHOTO OPTICAL CO., LTD.
1:1.*/***mm
IRISCONTROLCABLE
(CONNECTOR:MINIPLUG/E4-192J,CHUOMUSEN)
130+30
0
YF2.8A-SA2
YF4A-SA2B
L
φ32
φ35
1-32UNF
24
27.5
φ4
φ15.4
35 F.f12.5(INAIR)
L=35.6 mm
L=36 mm
1:1**/**mm
FUJI PHOTO OPTICAL CO., LTD.
JAPAN
YF**A-SA2
FAR
NEAR
130+30
0 
IRISCONTROLCABLE
(CONNECTOR:MINIPLUG/E4-192J,CHUOMUSEN)
35
27.5
24
1-32UNF
φ35
φ32
φ4
35 F.f12.5(INAIR)
φ15.4
Unit : mm
Model YF2.8A-SA2 YF4A-SA2B YF8A-SA2 YF16A-SA2
Focal Length 2.8mm 4mm 8mm 16mm
F1.3 〜T90 (*1) F1.2 〜T360 (*2) F1.3 〜T90 (*1) F1.4 〜T90 (*1)
Auto (Not Incorporating Amplifier) (*3)
Manual
96° 15´ ×71° 51´ 65° 21´
×49° 27´ 33° 24´ ×25° 22´ 17° 04´ ×12° 50´
71° 51´ ×53° 45´ 49° 27´
×37° 15´ 25° 22´ ×19° 09´ 12° 50´ ×9° 39´
∞〜0.1m (from Front of Lens)
∞〜0.5m (from Front of Lens)
241mm ×157mm 132mm ×99mm 71mm ×53mm 153mm ×115mm
157mm ×110mm 99mm ×73mm 53mm ×40mm 115mm ×86mm
8.11mm (in air) 8.62mm (in air) 8.81mm (in air) 10.3mm (in air)
CS Mount
Approx. 50g Approx. 40g Approx. 40g Approx. 35g
166mm (from Image Plane) 727mm (from Image Plane) -147mm (from Image Plane) 80mm (from Image Plane)
Drive Coil 200Ω
Damping Coil 600Ω
22mA (Max.) at 4V DC
Iris Range
Operation Iris
Focus
1/3˝
1/4˝
1/3˝
1/4˝
Angle of View
(H ×V)
Object
Dimensions
at M.O.D.
(H ×V)
Focusing Range
Back Focal Distance
Filter Thread
Mount
Mass
Exit Pupil Position
Coil Resistance
Current Consumption
(*1) Equivalent to F90
(*2) Equivalent to F360
(*3) When power is turned off, iris will automatically be closed.
【WIRING】<Available Model>
Long Cable Type ( =330mm)
YF2.8A-SA2L
YF4A-SA2LB
YF8A-SA2L
YF16A-SA2L
Unit : mm
Open
Toward
Open
Lens
Drive
Coil
Damping
Coil
RED
BLK
BLU
WHT
2
4
1
3
Connector
E4-151J/192J (CHUOMUSEN)
