AMILO Pro
V3525 / V3545 Edition
Your gateway to mobile workingPages 3
The AMILO Pro V3525 / V3545 Editions are professional companions for the price-conscious, casual user. These
notebooks are the ultimate balance of valuable performance and best-in-class mobility at very attractive prices.
These AMILO Pro V Editions offer a crisp 15.4-inch WXGA display and ergonomic working.
The combination of AMILO Pro V3545 Edition with a large-diagonal 15.4-inch display and the latest NVIDIA®GeForce®
Go 7300 graphics deliver the convenience of display brilliance and outstanding graphics.
Ideal for users working both on the road and in the office, it features a built-in optical disk drive, modem, LAN and
WLAN. The built-in UMTS module offers you unlimited freedom of connectivity wherever you are.
Mobility
Valuable mobility at reasonable price
Excellent price / performance ratio fits suiting all budgets
Ready configured and constantly enhanced with latest technology
Convenient technology for mobile working
Power-saving and high performance Intel® Core™ Duo or
Intel® Core™ 2 Duo Processor
Ideal connectivity through built-in UMTS (optional),
Wireless LAN, LAN and modem
Ease of use through built-in DVD writer
Ergonomics and flexibility in- and outside the office
Enjoy the viewing quality of brilliant
15.4-inch WXGA-TFT display
Full-size keyboard for ergonomic working
4 x USB (2.0) ports for easy connectivity to all
peripherals and external storage devices
Robustness on the move
Mechanical and function stability through extensive quality tests
German quality standards
RoHS compliant for environmental friendly working
Award-winning best-in-class manufacturing

Data Sheet ⏐Issue: June 2007⏐AMILO Pro V3525/V3545 Edition Page 2 / 3
System AMILO Pro V3545 Edition AMILO Pro V3525 Edition
Processor
Intel Celeron M Processor up to 520 up to 520
Second level cache 1024 1024
Front side bus (FSB) 533 MHz 533 MHz
Intel® Core™ Duo Processor up to T2450 up to T2450
Second level cache 2 MB 2 MB
Front side bus (FSB) 533 MHz 533 MHz
Intel® Core™2 Duo Processor up to T7600 up to T7600
Second level cache 4096 MB 4096 MB
Front side bus (FSB) 667 MHz 667 MHz
Chipset
Northbridge Intel 945PM Intel 945GM
Southbridge ICH 7-M ICH 7-M
Memory
DIMM slots (533, 667 MHz support) 2 2
DDR2-533 SDRAM, 533 MHz up to 2 GB up to 2 GB
BIOS
BIOS Flash EPROM Phoenix First BIOS Phoenix First BIOS
Interfaces
SIM card slot 1 1
Type I/II PC Card slot 1 1
3in1 Card Reader (SD, MMC and memory stick) 1 1
USB 2.0 4 4
S-Video out (TV-out) 1 1
VGA 1 1
Modem RJ-11 1 1
LAN RJ-45 1 1
Audio-in (line-in / microphone) 1 1
Audio-out (line-out / headphone) 1 1
DC-in 1 1
Kensington Lock 1 1
Port Replicator interfaces (optional): - -
Modem on board
56K V.92 modem MDC1.5 x x
LAN on board
built-in 10/100/1000 Mbps Marvell 88E8055 x x
Wireless Technologies (WLAN)
Import and usage according to country-specific regulations.
Dual band antenna
Intel PRO/Wireless 3945 a/b/g x x
Integrated UMTS (HSDPA 1.8 Mb/s), also supported GPRS and EDGE optional optional
Bluetooth
Bluetooth V2.0 optional optional
Audio
Stereo speakers x x
Sound chip RealTek ALC861 RealTek ALC861
Internal microphone x x
Keyboard and pointing device
Keyboard 85 keys, 19mm pitch,
2.5mm key stroke 85 keys, 19mm pitch, 2.5mm key stroke
Touchpad with two mouse buttons with two mouse buttons
Launch keys 2 keys 2 keys
Status LED x x
Graphics
Intel GMA 950 with 256-bit graphics core with dynamic video memory
technology up to 224MB, 32-bit color depth - x
NVidia GeForce Go 7300 128 MB VRAM (up to 512 MB Turbo Cache) x -
Direct X9 x x
Pixelshader 2.0 x x
DualView (Windows XP and Windows Vista) x x
Display
15.4-inch TFT WXGA / 1280 x 800 pixel x x
Max. resolution for external displays 1600 x 1200 / true color / 85 Hz 1600 x 1200 / true color / 85 Hz
* for made4you customizing projects only
Hard disk drives (internal) *
S.M.A.R.T. - -
60 GB S-ATA 150 (5400 rpm) x x
80 GB S-ATA 150 (5400 rpm) x x
120 GB S-ATA 150 (5400 rpm) x x
160 GB S-ATA 150 (5400 rpm) x x
* 1 Gbyte equals one billion bytes, when referring to hard disk drive
capacity; accessible capacity may vary, also depending on used software
and tool.
** for made4you customizing projects only
Fixed drives
Super Multi DVD writer (incl DVD RAM, 8x double layer support) x x
More information in specific Data Sheet:
http://www.fujitsu-siemens.com/optical_drives/

Data Sheet ⏐Issue: June 2007⏐AMILO Pro V3525/V3545 Edition Page 3 / 3
Manageability
Supported Standard
WMI / CIM / WBEM - -
PXE x x
BootP - -
Security
Physical security
Kensington Lock support x x
System Security
Norton Internet Security Symantec x x
User Security
User and supervisor BIOS password x x
Hard disk password x x
* for made4you customizing projects only
Power supply
1st Li-Ion battery 6 cell 4400 mAH (48 Wh) x x
First battery * (Mobile Mark 2002) [up to] 3 h 4 h
AC adapter 20V/65W Adapter
Rated voltage (AC input) 100 - 240 V
Rated frequency 50 - 60 Hz
DC output 20 V, 3.25 A or 4.5 A
x x
Dynamic charge supported (rapid charge) x x
* Battery life may vary depending on product model, configuration,
applications, power management settings and features utilized. Battery
recharge time depends on usage.
** for made4you customizing projects only
Operating temperatures
Relative humidity (non-condensing) 20% - 85% 20% - 85%
Ambient temperature 5° - 35° C 5° - 35° C
Dimensions / Weight
Dimensions (H x W x D) 24~34 x 355 x 255 mm 24~34 x 355 x 255 mm
Weight* 2.8 kg 2.8 kg
* Weight may vary depending on actual configuration
Certificates
CE according to EU Directives 89/336/EEC (EMC)
73/23/EEC (Product safety) x x
CE according to 99/5/EEC (R&TTE) x x
CE! (Wireless) x (with integrated WLAN) x (with integrated WLAN)
CE (Emission/Immunity) x x
R&TTE x x
CB Generic Report x x
CB (Safety) x x
RoHS x x
WHQL x x
TBR21 x x
Operating System
Microsoft Windows XP Professional x x
Microsoft Windows Vista™ x x
Software (compatibility / preinstalled)
Adobe Acrobat Reader x x
Driver and Utility DVD (DUDVD) x x
Easy Guide on-line user documentation x x
Nero x (with combo or DVD RW drive) x (with combo or DVD RW drive)
Norton Internet Security (incl. Firewall) on DUDVD (for Windows XP only) x x
Bluetooth Toshiba Stack 4.x x x
UMTS watcher x (with UMTS) x (with UMTS)
Accessories (order number)
AC-adapter S26391-F321-L400 S26391-F321-L400
Case
Prestige case midi S26391_F119-
L60
Prestige case top L
S26391-F119-L64
Prestige case top L
S26391-F119-L64
Prestige case midi S26391_F119-
L60
Prestige case top L
S26391-F119-L64
Prestige case top L
S26391-F119-L64
Port Replicator S26391-F6007-L100 S26391-F6007-L100
Battery S26391-F6007-L100 (6 cells) S26391-F6007-L100 (6 cells)
http://www.fujitsu-siemens.com/accessories/
This Data Sheet describes the highest configurations. The product is offered in fixed configurations which vary from country to country and edition to edition.
