Fujitsu Siemens Computers L19W-9 User manual

Monitor
Erste Schritte / Getting Started
Deutsch, English, Français,
Español, Português, Italiano,
Svenska, Nederlands, Dansk,
Suomi, Pycckий, Norsk, Eesti
keel, Ελληνικά, Lietuviškas,
Latviski, Polski, Slovensko,
Slovenský, Česky, Magyar,
Български, Română, Türkçe
19" wide LCD Monitor
Downloaded from ManualMonitor.com Manuals

Assembling the monitor base
Downloaded from ManualMonitor.com Manuals

Sie haben ...
... technische Fragen oder Probleme?
Wenden Sie sich bitte an
unseren Help Desk (siehe Garantieheft).
Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:
http://www.fujitsu-siemens.com
Are there ...
... any technical problems or other questions you need clarified?
Please contact
our Help Desk (see Warranty Booklet).
The latest information on our products, tips, updates, etc., can be found on the Internet under:
http://www.fujitsu-siemens.com
Downloaded from ManualMonitor.com Manuals

19" wide LCD Monitor
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Technical data
Dimensions and weight (LCD monitor)
Visible diagonals: 48 cm (19”)
Screen size : 408mm x 255mm
Dimensions (W x H x D)
incl. monitor base : 359 mm x 422 mm x 206 mm
Dimensions box (W x H x D): 505mm x 420 mm x 140 mm
Weight : unpacked/packed approx. 4.40 kg / 5.74 kg
Dot pitch : 0,2835 mm
Maximal resolution : 1440 x 900 pixels
Electrical data
Video: analogue, positiv, 0.7 Vpp, 75 Ω,
digital, DVI(optional)
Synchronisation : Seperate Synch. TTL, positive or negative
Horizontal frequency: 31 kHz …. 81 kHz
Refresh rate: 56 Hz …. 75 Hz
Maximum pixel rate: 165 MHz
Power supply: switches automatically
100 V – 240 V, 50 Hz – 60 Hz, 1.0 A max.
Total power consumption: < 50 W (power on)
< 1 W (power saving)
Environmental conditions
Environment class 3K3, IEC 721
Operating range: 5 °C …. 40°C
Humidity: 20 % …. 85 %
Condensation must be avoided.
Preset operating modes
The picture position and size have been set set to optimum values at the factory for the
operating modes listed above.
Display resolution Refresh rate Horizontal frequency
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
1440 x 900
1440 x 900
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
70 Hz
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60.0 kHz
64.0 kHz
79.9 kHz
56.0 kHz
70.6 kHz
Downloaded from ManualMonitor.com Manuals

Using the Display
Turning On the Display
Turn on the display before turning on the computer. When the power is on, the LED on the power
button lights blue and the screen image will appear after about 3 seconds. If the LED doesn’t light
blue or no image appears, please verify if the display is properly connected.
Function Controls
Hot key
&
Down / Decrease &
Up / Increase
OSD Off: Press ▼“Mute” and “recover”. (hold for 1.5 sec)
Press
▲open input select menu(dual model).
(hold for 1.5 sec)
OSD On: Use these buttons to select or adjust the values of the
selected function.
1,2 ▼▲
Power-Button lock Operating of ▼and ▲buttons at the same time for approx. 2
seconds.
3 MENU Hot key &
SELECT OSD Off: Open OSD. OSD On: Select function. (submenu)
4 AUTO Hot key &
EXIT OSD Off: Auto adjustment function. (hold for 1.5 sec) OSD On: Exits OSD.
5 POWER Power Switch Power On/Off
Blue-Operation mode / Orange-Power saving mode.
3,5 MENU &
POWER OSD lock function Operating of menu and power buttons at the same time
Downloaded from ManualMonitor.com Manuals

OSD Selection
After you press the MENU button to enter the OSD menu, use ▼▲ to select the items you want to
adjust. Then press the AUTO button. After the screen fonts turn from black to blue you may start to
make the adjustments. Just use ▼▲ to adjust the screen parameters as required. If no action is
taken for 30 seconds (default value but adjustable in OSD setup) after the setting, the system will
automatically save your settings and exit the OSD.
OSD Menu
Brightness/Contrast:
Brightness: Adjusts brightness by using the buttons ▼or ▲
Contrast: Adjusts contrast by using the buttons ▼or ▲
Black level: Adjusts black level by using the buttons ▼or ▲
Auto level: Auto level: Conducts auto level by using the button
MENU (start)
Image Adjust:
Auto Adjustment: Automatically selects the optimal settings for
image parameters (image position, phase, etc.) by using the
button MENU.
H- Position: Controls the picture’s horizontal position.
V- Position: Controls the picture’s vertical position.
Clock: Sets up the internal clock. Larger values make the
displayed image appear wider; smaller values make it appear
compressed.
Phase: Adjusts the internal clock’s time lag in order to optimize
the screen image.
Audio:
Adjusts the monitor speaker output volume and mute.
Downloaded from ManualMonitor.com Manuals

Colour:
This menu lets you select a preset color temperature (6500K,
9300K, Native) by pressing the OSD buttons ▼or ▲,changes to
the color temperature take immediate effect on screen.
If you wish to set individual color values, select the Custom
Colour option, then press the MENU button to select the red,
green and blue settings and set the desired value using the OSD
buttons ∨or ∧.The current settings are automatically saved
when you return to the previous level or exit the OSD menu.
OSD Setup:
Language: selects the language for the OSD menu by pressing
the OSD buttons ▼or ▲.
OSD H- Position: Controls the OSD menu’s horizontal position.
OSD V- Position: Controls the OSD menu’s vertical position.
OSD Timeout: Determines how long (in seconds) the OSD
menu waits before closing automatically after no action has
been performed.
Advanced:
Input select (optional): Selects input signal (Analogue,
Digital) by pressing the OSD buttons ▼or ▲, press MENU or
AUTO to confirm the selection.
DDC/CI: There is an optional OSD window(On/Off)
On: active; Off : inactive.
Resolution Notifier: With the function activated (On) a
message appears on the screen approx. 30 seconds if not
the optimum resolution 1280 x 1024 is settled. With the
function is deactivated (Off) no message appears.
Factory recall: Activating the factory settings
MENU: Start AUTO: Back
Information: Displaying monitor data:
monitor name, resolution, the horizontal and vertical
frequency
Note: Do not adjust the screen settings when animation is displayed and make sure to adjust the
settings in full screen mode.
Downloaded from ManualMonitor.com Manuals

Downloaded from ManualMonitor.com Manuals

19" Wide LCD Monitor
Erste Schritte
Getting Started
Deutsch
Magyar
Русский
English
Български
Norsk
Français
Română
Eesti keeles
Español
Türkçe
Ελληνικά
Português
WEEE
Lietuviškas
Italiano
Latviski
Svenska
Polski
Nederlands
Slovensko
Dansk
Slovenský
Suomi
Česky
Ausgabe September 2007
September 2007 edition
Downloaded from ManualMonitor.com Manuals

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards
Association.
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.
Keine Haftung für Inhalt und Druckfehler.
Copyright © Fujitsu Siemens Computers GmbH 2007
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association.
All rights, including rights of translation, reproduction by printing, copying or similar methods,
even of parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
No liability for content and printing error.
