SCENICVIEW P996-1
Farbbildschirm
Colour monitor
Betriebsanleitung
Operating Manual
Deutsch
English
TCO'99
Ausgabe Juni 2004
June 2004 edition
Downloaded from ManualMonitor.com Manuals

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards
Association.
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.
Dieses Handbuch wurde erstellt von
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright © Fujitsu Siemens Computers GmbH 2004
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards
Association.
All rights, including rights of translation, reproduction by printing, copying or similar methods,
even of parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
This manual was produced by
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Downloaded from ManualMonitor.com Manuals

A26361-K967-Z100-1-5E19, Edition 1 English
Contents
Introduction........................................................................................................................................1
Notational conventions...............................................................................................................1
Important notes .................................................................................................................................2
Safety notes...............................................................................................................................2
Cleaning ....................................................................................................................................3
Transport ...................................................................................................................................3
X-ray radiation ...........................................................................................................................3
Power cable...............................................................................................................................4
Energy Star Guidelines..............................................................................................................4
CE marking................................................................................................................................4
FCC Class B Compliance Statement.........................................................................................5
Declaration of Conformity ..........................................................................................................5
Disposal and recycling...............................................................................................................6
Checking the contents of the consignment ........................................................................................6
Installing an ergonomic video workstation..........................................................................................7
Assembling the monitor base ............................................................................................................8
Connecting the monitor......................................................................................................................8
Operation of the monitor..................................................................................................................10
Switching the monitor on..........................................................................................................10
Switching the monitor off .........................................................................................................10
Notes on power management..................................................................................................11
Changing the monitor settings .................................................................................................12
Notes on ergonomic colour adjustment....................................................................................17
Technical data .................................................................................................................................18
VESA-DDC-compatible VGA interface.....................................................................................18
Preset operating modes...........................................................................................................19
Pin assignment D-SUB............................................................................................................19
Tilting and turning area ............................................................................................................20
Troubleshooting...............................................................................................................................20
Error messages on the screen.................................................................................................21
Downloaded from ManualMonitor.com Manuals

Downloaded from ManualMonitor.com Manuals

A26361-K967-Z100-1-5E19, Edition 1 English - 1
Introduction
Your new SCENICVIEW P996-1 monitor supplies you with a high-quality colour image with high
resolution and ergonomic refresh rates. It possesses a whole range of useful features and functions,
e.g.:
●19" (46 cm) high-resolution CRT (0.25 mm dot pitch)
●automatic scanning of all horizontal frequencies from 30 to 96 kHz and all refresh rates
(vertical frequencies) from 50 to 160 Hz
●digital screen controller with microprocessor for storing 16 different display modes
●freely adjustable colour alignment for matching the screen colours to the colours of various
input and output devices
●convenient operation via integrated OSD (On-Screen-display) menu
●VESA-DDC compatibility
●power management for reducing power consumption by up to 95 % when the computer system
is not in use
●compliance with the latest ergonomic standards (ISO 9241-3)
●compliance with the recommendations in accordance with TCO ’99
This operating manual contains important information you require to start up and run your monitor.
The monitor interacts closely with the graphics card (screen controller) of your computer. The
monitor processes the data supplied to it by the screen controller. The screen controller/the
associated driver software is responsible for setting the modes (resolution and refresh rate).
Target group
You don't need to be an "expert" to perform the operations described here. Do, however, read the
"Important notes" chapter in the operating manual of the computer and in this operating manual.
In the event of any problems occurring, please contact your sales outlet or our help desk.
Additional information
Details of how you set the resolution and refresh rate are provided in the documentation on your
screen controller/the associated driver software.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!
Pay particular attention to text marked with this symbol. Failure to observe this warning
endangers your life, destroys the device, or may lead to loss of data.
i
Supplementary information, remarks, and tips follow this symbol.
►Text which follows this symbol describes activities that must be performed in the order shown.
"Quotation marks" indicate names of chapters or terms.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
2 - English A26361-K967-Z100-1-5E19, Edition 1
Important notes
!
In this chapter you will find information regarding safety which is essential to take note of
with your monitor.
Safety notes
This device complies with the relevant safety regulations for data processing equipment, including
electronic office machines for use in an office environment. If you have any questions, contact your
sales outlet or our help desk.
●If the device is brought into the installation site from a cold environment, condensation can
form. Before operating the device, wait until it is absolutely dry and has reached approximately
the same temperature as the installation site.
●During installation and before operating the device, please observe the instructions on
environmental conditions in the "Technical data" chapter as well as the instructions in the
"Installing an ergonomic video workstation" chapter.
●To ensure adequate ventilation the monitor may only be operated with the monitor foot
installed.
●The colour monitor must not be exposed to strong magnetic fields (e.g. caused by magnetic
paper clip holders or loudspeakers). Strong magnetic fields could result in a permanent blotchy
image.
●The monitor is automatically degaussed when switched on. This results in a magnetic field
around the metal edge of the picture tube, which may damage the data on data carriers
nearby. Therefore, never keep magnetic data carriers near the monitor.
●The device automatically sets itself to the correct voltage within the range from 220 V to 240 V.
Ensure that the local mains voltage lies within these limits.
●The device must be installed in such a way that the user has good access to the appliance
socket.
●The ON/OFF switch does not disconnect the device from the mains voltage. To completely
disconnect the mains voltage, remove the power plug from the socket.
●Lay all cables so that nobody can stand on them or trip over them. When attaching the device,
observe the relevant notes in the "Connecting the monitor" chapter.
●No data transfer cables should be connected or disconnected during a thunderstorm.
●Please ensure that no objects (e.g. necklaces, paperclips etc.) or liquids can get into the
interior of the device (this may cause an electrical shock or short circuit).
●In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign
matter), switch off the unit, disconnect the power plug and contact your sales outlet or our help
desk.
●Only qualified technicians should repair the device. Unauthorised opening and incorrect repair
may greatly endanger the user (electric shock, fire risk).
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
A26361-K967-Z100-1-5E19, Edition 1 English - 3
●Tampering with the device, in particular adjusting the high voltage or installing a different type
of CRT tube, may result in a large amount of X-ray radiation being emitted. Devices modified
in this way no longer comply with their licence and may not be used.
●You may set only those resolutions and refresh rates specified in the "Technical data" chapter.
Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or
our help desk.
●Use a screen saver with moving images and activate the power management for your monitor
to prevent still images from "burning in".
●Keep this operating manual together with your device. If you pass on the device to third
parties, you should include this manual.
Cleaning
●Always pull out the power plug before you clean the monitor.
●Do not clean any interior parts yourself, leave this job to a service technician.
●Do not use any cleaning agents that contain abrasives or may corrode plastic.
●Ensure that no liquid will run into the system.
●Ensure that the ventilation areas of the monitor are free.
●When cleaning the surface of the screen, always use a soft, slightly damp cloth in order to
avoid scratching the glass.
Wipe the monitor casing with a dry cloth. If the monitor is particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
Transport
●When transporting the monitor ensure that it is not exposed to strong magnetic fields.
●Transport the monitor with care and only in its original packaging or another corresponding
packaging fit to protect it against knocks and jolts.
●Above all, never drop the monitor. If the CRT is damaged, there is a risk of implosion!
X-ray radiation
This device complies with the German X-ray regulations (Röntgenverordnung - RöV). The local
dosage emitted is less than 1 µSv/h (micro-Sievert per hour) at a distance of 0.1m.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
4 - English A26361-K967-Z100-1-5E19, Edition 1
Power cable
To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary
to replace the original cable set.
●The female/male receptacles of the cord set must meet CEE-22 requirements.
●The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the
outer sheath or on the insulation of one of the inner conductors.
●For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.
For devices which sit on the floor, only SJT type cable sets may be used.
●The cable set must be selected according to the rated current for your device.
Energy Star Guidelines
The Fujitsu Siemens colour monitor SCENICVIEW P996-1 is designed to
conserve electricity by dropping to less than 1 W when it goes OFF mode.
With this new power management the SCENICVIEW P996-1 qualifies for
the U.S. Environmental Protection Agency's (EPA) Energy Star
Computers award.
The EPA estimates that computer equipment uses 5 % percent of all business electricity and that
this is growing rapidly. If all desktop computers and peripherals enter a low-power mode when not in
use, the overall savings in electricity could amount to $ 2 thousand million annually. These savings
could also prevent the emission of 20 million tons of carbon dioxide into the atmosphere - the
equivalent of 5 million automobiles.
As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product
meets the Energy Star guidelines for energy efficiency.
CE marking
The shipped version of this device complies with the requirements of the EEC
directives 89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage
directive".
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
A26361-K967-Z100-1-5E19, Edition 1 English - 5
FCC Class B Compliance Statement
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital device,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-
Causing Equipment Regulations. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in strict accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between equipment and the receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused
by unauthorised modifications of this equipment or the substitution or attachment of connecting
cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The
correction of interference caused by such unauthorised modification, substitution or attachment will
be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC rules.
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Product name: Colour CRT Monitor
Trade name: Fujitsu Siemens Computers Inc.
Model number(s): SCENICVIEW P996-1
Name of responsible party: Siemens Information and Communication
Products LLC
3860 N. First Street
San Jose, CA 95134-1702
U.S.A.
Contact person: Schroettle-Henning, Bernd
Phone No.: [phone]
Fax No.: [phone]
We, Siemens Information and Communication Products LLC, hereby declare that the equipment
bearing the trade name and model number specified above was tested confirming to the applicable
FCC Rules under the most accurate measurement standards possible, and that all the necessary
steps have been taken and are in force to assure that production units of the same equipment will
continue to comply with the Commissions requirements.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
6 - English A26361-K967-Z100-1-5E19, Edition 1
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The CRT contains no
cadmium
The device may be taken back after use to be recycled, provided that it is returned in a condition
that is the result of normal use. Any components not reclaimed will be disposed of in an
environmentally acceptable manner.
We herewith declare that it will be possible to repair any device marked
with the eco-label for at least 5 years after production of that device has
discontinued.
If you have any questions on disposal, please contact your local office, our help desk, or:
Fujitsu Siemens Computers GmbH
Recyclingcenter
D-33106 Paderborn
Tel.: ++ 49 5251 - 818 010/ Fax: ++ 49 5251 - 818 015
Checking the contents of the consignment
►Unpack all the individual parts.
►Remove any plastic caps from the plugs for the cables in the consignment.
►Check the delivery for damage incurred during transportation.
►Check whether the delivery agrees with the details in the delivery note.
The complete shipment comprises:
– one monitor with data cable
– one power cable
– one monitor base
– one Warranty Booklet
– this operating manual
Should you discover that the delivery does not correspond to the delivery note, notify your local
sales outlet immediately.
i
It is recommended not to throw away the original packaging material. Keep it for future
transportation.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
A26361-K967-Z100-1-5E19, Edition 1 English - 7
Installing an ergonomic video workstation
Before you set up your equipment, you should select a suitable position for working at the monitor.
Please observe the following advice when installing a video workstation.
1
600 mm 600 mm
1
22
1 = Windows
Avoid direct and reflected glare.
Avoid glare from electric
lighting. 1 = Edge of desk
2 = Permissible reaching
sector
Position the keyboard where it
is easiest to reach.
30°
30°
65°
65°
0°
60°
1
22
1
2
1 = Preferable viewing sector
2 = Permissible viewing sector
Position the monitor for
optimum viewing. The viewing
distance to the monitor should
be approximately 50 cm.
Keep ventilated areas clear. 1 = approx. 90° and more
2 = approx. 90°
Remember to maintain correct
posture.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
8 - English A26361-K967-Z100-1-5E19, Edition 1
Assembling the monitor base
Your monitor is shipped with a base which allows you to rotate and tilt the monitor to the best
position.
Attach the base as follows:
►Lay the monitor with the display downwards
on a soft surface.
►Fit the base so that its hooks slot into the
recesses on the monitor.
►Slide the base forward in the direction of
the arrow until it clicks into position.
►Place the monitor in an upright position.
!
To ensure adequate ventilation the monitor may only be operated with the monitor foot
installed.
Connecting the monitor
Information on the computer connections is contained in the operating manual for your computer.
!
Observe the safety precautions in the "Important notes" chapter in this operating manual.
Do not cover the ventilation openings of the monitor.
If you are assembling monitors beside each other, there must be a minimum distance of
30 cm between monitors of the same constructional type, to avoid image distortion. With
different monitors, the distance must be increased, if necessary.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
A26361-K967-Z100-1-5E19, Edition 1 English - 9
►Be sure that the monitor and the computer are switched off.
1 = Power connector
2 = Data cable
!The computer power plug must be pulled out!
The data cable is permanently attached to the monitor. It has a 15-pin D-SUB connector for the
monitor port of the computer.
►Connect the 15-pin connector of the data cable to the (active) monitor port on the computer
and secure the plug-in connection by tightening the safety screws.
i
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is usually active.
►Plug the power cable supplied into the power connector of the monitor.
►Plug the power cable into the monitor connector at the rear of the computer.
►Plug the power connector of the computer into a properly grounded mains outlet.
i
When you start working with your monitor for the first time you should install the
appropriate graphics drivers for your application software. Details of how to do this are
provided in the documentation on your graphics card/the associated driver software.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
10 - English A26361-K967-Z100-1-5E19, Edition 1
Operation of the monitor
1 = Buttons for the OSD menu
(On-Screen-display)
2 = Power indicator
3 = ON/OFF switch
Switching the monitor on
►Drücken Sie den Ein-/Ausschalter (3).
The power indicator (2) lights up green when the computer is switched on.
i
If your computer has a power management function (energy-saving mode), you should
read the "Notes on power management" of the monitor in this chapter.
When you start your system, several mode changes will usually be carried out when
various programmes are called automatically (different settings for resolution and image
refresh rate). Do not be confused by the unusual displays. They are not error messages.
Switching the monitor off
►Drücken Sie den Ein-/Ausschalter (3).
The power indicator (2) is dark.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
A26361-K967-Z100-1-5E19, Edition 1 English - 11
Notes on power management
If your computer is equipped with power management, the monitor can support this function fully.
Here the monitor does not distinguish between the individual energy-saving modes of the computer
(standby mode, suspend mode and OFF mode), as it is capable of immediately switching into the
mode with the highest energy-saving effect.
Stage ON Energy-saving mode
Power indicator lights green flashes green
Function the monitor is working
normally
the screen is dark
Power consumption normal w90 W reduced to q2 W
If your computer detects inactivity (no input) it sends an appropriate signal to the monitor to reduce
the power consumption. The power indicator of the monitor changes colour to indicate the status
change.
If there is still no input, power consumption is further reduced (OFF mode).
Once an input is made at the computer the screen contents are redrawn and full power is restored.
The length of the individual stages is determined by the power management system of the
computer. For detailed information on how energy-saving mode operates refer to the operating
manual or technical manual of the computer.
i
The service life of your monitor will be extended if the OFF mode is switched to after
30 minutes at the earliest (setting in screen saver or in your computer's BIOS setup).
When the monitor is switched to OFF mode by the power management system a power
consumption of up to 2 W is maintained to feed the circuit for redrawing the screen
contents.
Downloaded from ManualMonitor.com Manuals

Colour Monitor SCENICVIEW P996-1
12 - English A26361-K967-Z100-1-5E19, Edition 1
Changing the monitor settings
The monitor display is adjusted with the buttons of the control panel.
Menu
Exit
1234
1 = Exit button 2 = Arrow buttons 3 = Menu button 4 = ON/OFF switch
Menu button The menu button switches on the OSD menu and activates the selected function.
65 When the menu is activated, mark the symbol for the topic or function you want to
set with the buttons 6and 5.
When the menu is not activated, these buttons have not function.
34 When the menu is activated, set the values for the selected function with the
buttons 3and 4.
When the menu is not activated, you can display the setting window for brightness
and contrast directly with the buttons 3and 4.
Exit button The Exit button deactivates the OSD menu or returns you from a submenu to its
superior menu.
Setting functions with OSD menu
To make a setting for a function, perform the following steps:
►Press the Menu button to activate the OSD menu.
The OSD menu is displayed on the screen.
On the left-hand side of the OSD menu the symbols for the individual topics
are displayed. On the right-hand side of the OSD menu the respective
functions are displayed which belong to the individual topics.
►Select the symbol for the topic that contains the desired function with the buttons 6or 5.
►Press the Menu button to select the marked topic.
Downloaded from ManualMonitor.com Manuals
