Fujitsu Siemens Computers D1132 User manual

SYSTEMBAUGRUPPE D1132
SYSTEMBAUGRUPPE D1132SYSTEMBAUGRUPPE D1132
SYSTEMBAUGRUPPE D1132
SYSTEM BOARD D1132
SYSTEM BOARD D1132SYSTEM BOARD D1132
SYSTEM BOARD D1132
TECHNISCHES HANDBUCH
TECHNISCHES HANDBUCHTECHNISCHES HANDBUCH
TECHNISCHES HANDBUCH
TECHNICAL MANUAL
TECHNICAL MANUALTECHNICAL MANUAL
TECHNICAL MANUAL

Sie haben ...
... technische Fragen oder Probleme?
Wenden Sie sich bitte an:
• einen unserer Servicepartne
r
• Ihren zuständigen Vertriebspartne
r
• Ihre Verkaufsstelle
Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:
http://www.fujitsu-siemens.com
Is there ...
... any technical problem or other
question you need clarified?
Please contact:
• one of our service partners
• your sales partne
r
• your sales outlet
The latest information on our products, tips, updates, etc., can be found on the Internet under:
http://www.fujitsu-siemens.com

Is there ...
... any technical problem or other
question you need clarified?
Please contact:
• Our Hotline:
Mo-Fr: 8 a.m. - 6 p.m.
Sat: 9 a.m. - 2 p.m.
Tel.: ++49 (0) 180 3777 005
• your sales outlet
The latest information on our products, tips, updates, etc., can be found on the Internet under:
http://www.fujitsu-siemens.com.
diese Seite in die Additional Technical Manuals 3777-005 is extra für OEM-Kunden

Dieses Handbuch wurde auf Recycling-Papier gedruckt.
This manual has been printed on recycled paper.
Ce manuel est imprimé sur du papier recyclé.
Este manual ha sido impreso sobre papel reciclado.
Questo manuale è stato stampato su carta da riciclaggio.
Denna handbok är tryckt på recyclingpapper.
Dit handboek werd op recycling-papier gedrukt.
Herausgegeben von/Published by
Fujitsu Siemens Computers GmbH
Bestell-Nr./Order No.: A26361-D1132-Z120-1-7419
A26361-D1132-Z120-1-7419A26361-D1132-Z120-1-7419
A26361-D1132-Z120-1-7419
Printed in the Federal Republic of Germany
AG 0100 01/00
A26361-D1132-Z120-1-7419
SYSTEMBAUGRUPPE D1132
SYSTEM BOARD D1132 TECHNISCHES HANDBUCH TECHNICAL MANUAL

Systembaugruppe
D1132
System Board D1132
Technisches Handbuch
Technical Manual
Deutsch
Elih
En
g
lish
Ausgabe Januar 2000
January 2000 edition

Copyright ãFujitsu Siemens Computers GmbH 2000
Intel, Pentium und Celeron sind eingetragene Warenzeichen und MMX und OverDrive sind
Warenzeichen der Intel Corporation, USA.
Microsoft, MS, MS-DOS und Windows sind eingetragene Warenzeichen der Microsoft
Corporation.
PS/2 und OS/2 Warp sind eingetragene Warenzeichen von International Business Machines,
Inc.
Magic Packet ist ein eingetragenes Warenzeichen von Advanced Micro Devices, Inc.
Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen
der jeweiligen Inhaber und werden als geschützt anerkannt.
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.
Intel, Pentium and Celeron are registered trademarks and MMX and OverDrive are
trademarks of Intel Corporation, USA.
Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.
Magic Packet is a registered trademark of Advanced Micro Devices, Inc.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
All rights, including rights of translation, reproduction by printing, copying or similar methods,
even of parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved. Delivery subject to availability.
Right of technical modification reserved.

A26361-D1132-Z120-3-7419
Contents
Introduction........................................................................................................................................1
Notational conventions ..............................................................................................................1
Important notes .................................................................................................................................1
Information on boards................................................................................................................2
Features............................................................................................................................................3
Interfaces and connectors .........................................................................................................4
Temperature monitoring / system monitoring.............................................................................6
LAN port....................................................................................................................................7
Resource table ..........................................................................................................................8
PCI bus interrupts......................................................................................................................8
Settings with switches .......................................................................................................................9
Recovering System BIOS - switch 2........................................................................................10
Write protection for floppy disks - switch 3...............................................................................10
Add-on modules..............................................................................................................................11
Installing / removing processor................................................................................................12
Upgrading main memory..........................................................................................................13
Installing network board with WOL...........................................................................................14
Replacing the lithium battery....................................................................................................14
Glossary..........................................................................................................................................15

A26361-D1132-Z120-3-7419 English - 1
Introduction
i
This system board is available in different configuration levels. Depending on the
hardware configuration of your device, it may be that you cannot find several options in
your version of the system board, even though they are described.
You may find further information in the description "BIOS Setup".
Further information to drivers is provided in the readme files on hard disk or on the supplied drivers
diskettes or on the "Drivers & Utilities" or "ServerStart" CD.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!Pay particular attention to texts marked with this symbol. Failure to observe this warning
endangers your life, destroys the system, or may lead to loss of data.
i
Supplementary information, remarks and tips follow this symbol.
Ê Texts which follow this symbol describe activities that must be performed in the order shown.
ËThis symbol means that you must enter a blank space at this point.
Ú
ÚÚ
ÚThis symbol means that you must press the Enter key.
Texts in this typeface are screen outputs.
Texts in this bold typeface are the entries you make via the keyboard.
Texts in italics indicate commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being emphasized.
Important notes
Store this manual close to the device. If you pass on the device to third parties, you should also
pass on this manual.
!Be sure to read this page carefully and note the information before you open the device.
You cannot access the components of the system board without first opening the device.
How to dismantle and reassemble the device is described in the Operating Manual
accompanying the device.
Please note the information provided in the chapter "Safety" in the Operating Manual of
the device.
Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore
essential to observe the instructions in the chapter "Add-on modules“-"Replacing the
lithium battery“.

Important notes
2 - English A26361-D1132-Z120-3-7419
The shipped version of this board complies with the requirements of the EEC
directive 89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical PC configuration.
When installing the board, refer to the specific installation information in the
Operating Manual or Technical Manual of the receiving device.
Connecting cables for peripherals must be adequately insulated to avoid interference.
!Components can become very hot during operation. Make sure you do not touch
components when making extensions to the system board. There is a danger of burns!
i
The warranty is invalidated if the device is damaged during the installation or
replacement of system expansions. Information on which system expansions you can
use is available from your sales outlet or the customer service center.
Information on boards
To prevent damage to the system board or the components and conductors on it, please take great
care when you insert or remove boards. Take care above all to ensure that extension boards are
slotted in straight without damaging components or conductors on the system board, or any other
components, for example EMI spring contacts.
Be especially careful with the locking mechanisms (catches, centering pins etc.) when you replace
the system board or components on it, for example memory modules or processors.
Never use sharp objects (screwdrivers) for leverage.
Boards with electrostatic sensitive devices (ESD) are identifiable by the
label shown.
When you handle boards fitted with ESDs, you must observe the following
points under all circumstances:
• You must always discharge yourself (e.g. by touching a grounded
object) before working.
• The equipment and tools you use must be free of static charges.
• Pull out the power plug before inserting or pulling out boards containing
ESDs.
• Always hold boards with ESDs by their edges.
• Never touch pins or conductors on boards fitted with ESDs.

Features
A26361-D1132-Z120-3-7419 English - 3
Features
The components and connectors marked do not have to be present on the system board.
• System board in micro ATX format
• PGA 370 Celeron processor with 66 MHz Front Side Bus for PGA 370 socket
Celeron processors support MMX technology. Size and frequency of first-level cache and second-
level cache are depending on the processor used.
• Intel chipset 440BX / PIIX4E
• Intel 82559 LAN controller (10/100 Mbit/s) with RJ45 interface
WOL with Magic Packetäis supported, as is booting from LAN with Bootix LAN InCom or Intel
LSA.
• Fujitsu Siemens system monitoring and temperature monitoring
• 2 DIMM slots for 16 to 512 Mbyte main memory (SDRAM memory modules)
• Flash BIOS
• Energy saving functions: ACPI and APM.
• Security functions:
− Chipcard reader interface
− Detection of unauthorized opening of the housing
− Simple error detection and correction in the main memory with an ECC
− System, Setup and Keyboard password
− parallel and serial ports can be deactivated
− Floppy disk write-protection
− Virus warning function for the boot hard disk
− Virus protection function for the flash BIOS and the EEPROMs on the memory modules
• 1 AGP slot, 2 PCI slots, 1 ISA/PCI slot (shared)
AGP and PCI slots support 3.3 V main and auxiliary voltages.
• IDE hard disk controller connected to PCI bus for up to four IDE drives
(e.g. IDE hard disk drives, ATAPI CD-ROM drives)
The IDE hard disk controller are ultra DMA33 mode capable and support PIO modes 0-4.
• Floppy disk drive controller (possible formats: 720 Kbyte, 1.44 Mbyte, 2.88 Mbyte)
• The system board supports booting from a 120 Mbyte IDE floppy disk drive.
• 1 external parallel interface (ECP- and EPP-compatible)
• 1 external serial port (16C550 compatible with FIFO)
• 1 internal chipcard reader interface As an alternative this interface can also be used as a
second serial port (16C550 compatible with FIFO). This port does not support the ring indicator
signal.
• 1 internal WOL interface
• 2 external PS/2 interfaces for keyboard and mouse
• 2 external USB ports (USB = Universal Serial Bus)
• Real-time clock/calendar with integrated battery backup

Features
4 - English A26361-D1132-Z120-3-7419
Interfaces and connectors
ISA
PCI 1 PCI 2 PCI 3
AGP
DIMM 1
DIMM 2
413 6
25
7
1 = Serial port 1
2 = PS/2 mouse port
3 = PS/2 keyboard port
4 = Parallel port
5 = USB port 2
6 = USB port 1
7 = LAN port
The components and connectors marked do not have to be present on the system board.

Features
A26361-D1132-Z120-3-7419 English - 5
ISA
PCI 1 PCI 2 PCI 3
AGP
DIMM 1
DIMM 2
12 34567
8
11
12
13
14
10 9
1= I
2C outside temperature senso
r
2 = Serial chipcard reader interface or serial
port 2
3 = Power supply
4 = Floppy disk drive
5 = IDE drives 3 and 4 (secondary)
6 = Wake On LAN
7 = Connector for front panel
8 = IDE drives 1 and 2 (primary)
9 = USB chipcard reade
r
10 = ON/OFF switch
11 = Fan 1 (controlled and monitored)
12 = Fan 2 (monitored)
13 = Power supply monitoring
14 = Cover monitoring
The components and connectors marked do not have to be present on the system board.

Features
6 - English A26361-D1132-Z120-3-7419
Temperature monitoring / system monitoring
One goal of temperature and system monitoring is to reliably protect the computer hardware against
damage caused by overheating. In addition, any unnecessary noise is also to be prevented with a
reduced fan speed, and information is to be provided on the system state. The cover monitoring
protects the system from unauthorized opening.
The temperature and system monitoring are controlled by an onboard controller developed by
Fujitsu Siemens.
The following functions are supported:
Temperature monitoring:
Measurement of the processor temperature, measurement of the system temperature with an
onboard temperature sensor, measurement of the device temperature with an optional temperature
sensor (AUX).
Temperature control:
The temperature is controlled with the fan speed and/or by reducing the clock frequency of the
processor. The clock frequency of the processor is dependent on the setting in the BIOS setup.
Temperature-dependent processor speed control enables a reduced fan speed, decreasing noise.
Fan monitoring:
Fans that are no longer available, blocked or sticky fans are detected. Blocked or sticky fans are
operated with 12 V pulse voltage. Fans removed while the system is switched off are signaled by
the Display news LED when the system is switched on again and processed by the BIOS or the
application.
Fan control:
The fans are regulated according to temperature (exception: auxiliary fan (AUX)).
Sensor monitoring:
A fault or removal of a temperature sensor is detected. In this case all fans affected by this sensor
run at maximum speed to achieve the greatest possible protection of the hardware. Temperature
sensors removed while the system is switched off are signaled by the Display news LED and
processed by the BIOS or the application.
Cover monitoring:
Unauthorized opening of the cover is detected, even when the system is switched off. However, this
will not be indicated until the system is operating again.
Voltage monitoring:
The voltages 12 V, 5 V and the CMOS battery are monitored.

Features
A26361-D1132-Z120-3-7419 English - 7
With hardware monitoring - regardless of the operating system and processor - the advantages
compared to conventional software monitoring are clear:
− suitable for all operating systems and processor types
− no additional load on processor (performance)
− optimum reliability, even if process faults or faults are present in the operating system
− optimum noise reduction
Three different operating modes are available and can be configured in BIOS Setup -System
Management.
LAN port
This system board is equipped with the Intel 82559 LAN controller as an option. This LAN controller
supports the transfer speeds 10 Mbit/s and 100 Mbit/s. The LAN controller is equipped with a 3
Kbyte transmission and receiving buffer (FIFO) and supports the WOL function through Magic
Packetä.
It is also possible to boot a device without its own boot hard disk via LAN. Here Bootix LAN BootP
and Intel PXE are supported.
The LAN RJ45 connector is equipped with a yellow and a green LED (light emitting diode).
12
1 = Yellow indicator
2 = Green indicator
Green a connection exists (e. g. to a hub).
Yellow Link Mode: the LAN connection is active.
WOL mode: a Magic PacketTM is being received.

Features
8 - English A26361-D1132-Z120-3-7419
Resource table
assigned
IRQ possible IRQ Possible Address (hex) Possible DMA
Keyboard IRQ1
Serial interface COM1 3
403F8, 02F8 03E8, 02E8
Serial port COM2 3
402E8, 02F8 03E8, 03F8
Floppy disk drive controller IRQ6 2
Parallel interface LPT1 5, 7 0278, 0378, 03BC 0, 1, 3
RTC IRQ8
USB controller PnP
Mouse controller IRQ12
Numeric processor IRQ13
IDE controller 1 IRQ14 01F0-01F7
IDE controller 2 IRQ15 0170-0177
LAN PnP
"assigned IRQ" = interrupts assigned as shipped
"Possible IRQ" = these interrupts can be used for your particular application
"Possible address" = this address can be used for your particular application
"Possible DMA" = these DMAs can be used for your particular application
PCI bus interrupts
The following table shows which PCI bus interrupts on the system board are assigned.
PCI bus interrupt Component on system board:
A
APCI bus slot 1 AGP slot
B PCI bus slot 2
C PCI bus slot 3
D USB controller
D LAN controlle
r

Settings with switches
A26361-D1132-Z120-3-7419 English - 9
Settings with switches
ISA
PCI 1 PCI 2 PCI 3
AGP
DIMM 1
DIMM 2
OPEN / OFF
ON
1234
Switch 1 = must be set to off
Switch 2 = System BIOS recovery (RCV) Switch 3 = Write protection for floppy disks
Switch 4 = reserved
i
The clock frequency of the processor is set automatically. It cannot be changed manually.

Settings with switches
10 - English A26361-D1132-Z120-3-7419
Recovering System BIOS - switch 2
Switch RCV enables recovery of the old system BIOS after an attempt to update has failed. To
restore the old system BIOS you need a Flash BIOS Diskette (please call our customer service
center).
On The System BIOS executes from floppy drive A: and the inserted "Flash-BIOS-
Diskette" restores the System BIOS on the system board.
Off Normal operation (default setting).
Write protection for floppy disks - switch 3
Switch 3 is used to define whether floppy disks can be written or deleted in the floppy disk drive. To
write and delete floppy disks, the write-protection in BIOS Setup must be disabled (in menu Security,
the field Diskette Write must be set to Enabled).
On The floppy disk drive is write-protected.
Off Read, write and delete floppy disks is possible (default setting).

Add-on modules
A26361-D1132-Z120-3-7419 English - 11
Add-on modules
!For all steps described in this chapter pull the power plug out of the power outlet!
Even when you have run down the device, parts of the device (e. g. memory modules,
AGP and PCI extension boards) are still energized. Should this be the case, the voltage
indicator LED glows or flashes.
ISA
PCI 1 PCI 2 PCI 3
AGP
DIMM 1
DIMM 2
6
7
12345
8
1 = ISA slot
2 = PCI slots 1, 2, 3
3 = AGP slot
4 = Voltage indicator LED
5 = Lithium battery
6 = Slot for processor with heat sink
7 = Location bank 1 for main memory
8 = Location bank 2 for main memory
i
AGP and PCI slots support 3.3 V main and auxiliary voltages.

Add-on modules
12 - English A26361-D1132-Z120-3-7419
Installing / removing processor
32
1
A
45
32
1
A
45
The heat sink is mounted on the processor with a clip.
Ê Lift the heat sink off the processor.
Ê Push the lever in the direction of the arrow (1) and lift it as far as it will go (2).
Ê Remove the old processor from the socket (3).
Ê Insert the new processor in the socket so that the angled corner of the processor matches the
coding on the socket (A) with regard to the position (4).
!The angled corner of the processor may be covered by the heat sink. In this case let
yourself be guided by the marking in the rows of pins on the underside of the processor.
Ê Push the lever back down so that it snaps into place.
