Mainboard D1808
You have purchased one of the most powerful Intel Xeon®-based workstation solutions in a standard
SSI EEB v3.5 form factor.
Based on the Intel® 5000X chipset, the D1808 features some state-of-the-art technologies such as
dual/single 1333 and 1066 MHz FSB Dual-Core Xeon® Processor 5100 Series support, multiple
PCI-Express buses, quad channel DDR2 FB-DIMM memory design, onboard Dual-Port PCI-Express
Gigabit Ethernet, SATA ports, SAS ports and multiple USB2.0 (Universal Serial Bus) ports.
i
The programme Acrobat Reader must be installed to be able to open the manuals. You will
find the programme on the CD-ROM directory: utls/acrobat.
For more details please read the according readme.txt files.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!indicates information which is important for your health or for preventing physical damage.
i
indicates additional information which is required to use the system properly.
►Text which follows this symbol describes activities that must be performed in the order shown.
This symbol indicates that you must press the Enter key.
Text in this typeface indicates screen outputs.
Text in this bold typeface indicates the entries you make via the keyboard.
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters or terms.
A26361-D1808-Z120-1-7619, edition 1 1

Mainboard D1808
Important notes
With the mainboard installed you must open the system to access the mainboard. How to dismantle
and reassemble the system is described in the operating manual accompanying the system.
Connecting cables for peripherals must be adequately shielded to avoid interference.
!
Observe the safety notes in the operating manual of your system.
Incorrect replacement of the lithium battery may lead to a risk of explosion.
Components can become very hot during operation. Ensure you do not touch components
when making extensions to the mainboard. There is a danger of burns!
The shipped version of this board complies with the requirements of the EEC directive
89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical PC configuration.
When installing the board, refer to the specific installation information in the manual for
the receiving device.
i
The warranty is invalidated if the system is damaged during the installation or replacement
of expansions. Information on which expansions you can use is available from your sales
outlet or the customer service centre.
Information about boards
To prevent damage to the mainboard, the components and conductors on it, please take great care
when you insert or remove boards. Take great care to ensure that extension boards are slotted in
straight, without damaging components or conductors on the mainboard, or any other components,
for example EMI spring contacts.
Remove the plug from the mains outlet so that system and mainboard are totally disconnected from
the mains voltage.
Be careful with the locking mechanisms (catches, centring pins etc.) when you replace the
mainboard or components on it, for example memory modules or processors.
Never use sharp objects (screwdrivers) for leverage.
Boards with electrostatic sensitive devices (ESD) are identifiable by the label shown.
When you handle boards fitted with ESDs, you must, under all circumstances,
observe the following:
●You must always discharge static build up (e.g. by touching a grounded object)
before working.
●The equipment and tools you use must be free of static charges.
●Remove the power plug from the mains supply before inserting or removing
boards containing ESDs.
●Always hold boards with ESDs by their edges.
●Never touch pins or conductors on boards fitted with ESDs.
2 A26361-D1808-Z120-1-7619, edition 1

Mainboard D1808
Hardware Specifications
Processors
●Dual LGA771 sockets
●Supports one or two Dual-Core Intel®
Xeon® Processors 5100 Series
●1333/1066MHz Front-Side Bus
●VRD11.0 compliant voltage regulation
design
Integrated Mass Storage Port
●Six ESB2 integrated SATA2 ports up to 3
Gbit/s with SATA RAID 0,1, 10 and 5
●One bus-master UDMA ATA100/66/33
Parallel IDE channel support up to 2
ATA/ATAPI compliant devices
Chipset
●Intel® 5000X Greencreek MCH chipset
(North Bridge)
●Intel® 6321ESB I/O Controller
(South Bridge)
●Winbond W83627EHF Super I/O chip
Integrated SAS (Serial Attached SCSI)
●LSI 1068E SAS Controller with 8 ports
at PCI-E x4 interface of ESB2
●Supports RAID0 (Integrated Striping, IS),
RAID1 (Integrated Mirroring, IM) and
RAID1E (Integrated Mirroring Enhanced,
IE)
●Supports Hot Swapping, SMART and Hot
Spare Disks
Expansion Slots
●One X16 PCI-Express high-performance
Graphics slot with x16 signal
●One X8 PCI-Express slot with x4 signal
●One X16 PCI-Express slot with x4 signal
●Two PCI-X 64-bit 133/100/66MHz (3.3-
Volt) slots
●One PCI 32-bit 33MHz (5-Volt) slot
●Total of six usable slots
Integrated LAN
●Intel® 82563EB Gilgal Dual-Port PCI-
Express Gigabit Ethernet with ASF2.0
System Hardware Monitoring
●Total five 4-pin fan headers with
tachometer monitoring and PWM control
●Chassis intrusion header
●Temperature and voltage monitoring
Memory
●Eight 240-pin 1.8-Volt DDR2-667/533
FB-DIMM sockets
●Quad channel memory bus
●Supports ECC memory
Up to 32GB of DDR2 FB-DIMM modules
BIOS
●Phoenix TrustedCore BIOS 8Mbit Flash
●Supports ACPI 2.0, PnP, DMI 2.0
●Auto configuration of mass storage
devices
●Multiple boot options
●Power Management: ACPI S1, S3, S4 and
S5 modes
IEEE
●Texas Instruments TSB43AB22A Ctrl.
●Two ports 400Mbit
Trusted Platform Management (TPM)
●Infineon SLB9635TT 1.2
Other Integrated I/O Interfaces
●One floppy connector for up to two drives
●One UART serial port connector
●One ECP/EPP/SPP parallel connector
●Eight USB2.0 ports (4 USB ports via
header)
●PS/2 mouse & keyboard ports
A26361-D1808-Z120-1-7619, edition 1 3

Mainboard D1808
Integrated Audio
●Intel ESB2 HDA compliant audio link
●Realtek ALC888 CODEC
●Line-in, Line-out, Mic-in rear vertical jacks
and a front panel audio header
●One 4-pin CD-ROM audio input header
●One 4-pin Auxiliary header
Form Factor
●SSI EEB 3.5 footprint AT03 (12”x13”)
●EEB V3.51 power connectors
●Rear I/O
– Stacked PS/2 mouse and keyboard
connectors
– One parallel connector
– One serial connector
– Four USB2.0 connectors
– Two GbE RJ45 connector
– Stacked audio connector for MIC,
Line_out and Line_in.
– SPDIF
– IEEE1394
Regulatory
●FCC Class B (Declaration of Conformity)
●European Community CE (Declaration of
Conformity)
i
Fujitsu Siemens Computers reserves the right to add support or discontinue support for
any OS with or without notice.
Software Specifications
OS (Operating System) Support
●Microsoft Windows XP Professional
●Microsoft Windows XP Professional X64 Edition
●Red Hat Enterprise Linux 5.0 (not certified)
●SuSE Linux Enterprise Desktop/Server 10.0 (not certified)
●Other distributions of Linux pending validation
i
Fujitsu Siemens Computers reserves the right to add support or discontinue support for
any OS with or without notice.
4 A26361-D1808-Z120-1-7619, edition 1

Mainboard D1808
Board Diagram
The above picture is purely representative. Due to engineering updates and new board revisions,
certain components may change and or be repositioned. The picture above may or may not look
exactly like the board you received.
The following page includes details on the vital components of this motherboard.
A26361-D1808-Z120-1-7619, edition 1 5

Choose Proper Parts for Your System
Choose Proper Parts for Your System
Before you installing a system with this motherboard, make sure your major system parts meet the
following basic guidelines and requirements:
Central Processor Unit (CPU) Considerations
●Process Type and Package
D1808 supports Dual-Core Intel® Xeon® Processors 5100 Series in FC-LGA6 package for
LGA771 socket.
●Front Side Bus (FSB)
The processor host bus, or called Front Side Bus (FSB), auto-operates at 1333/1066 MHz.
Choose Dual-Core Intel® Xeon® Processors 5100 Series with 1333 or 1066 MHz FSB for
D1808.
●Single/Dual Processor System
D1808 board supports one or two Dual-Core Intel® Xeon® Processors.
Single Processor System:
When only install a single processor on D1808, the processor must be installed in the CPU0
socket.
Dual Processor System:
D1808 supports dual processor configurations only in which both processors operate with the
same FSB frequency, core frequency, and have the same internal cache sizes. Mixing
processors operating at different FSB frequency, core frequency, or cache sizes may cause
system non-operation or damages on processors and/or the motherboard.
Memory Considerations
●Memory Type
D1808 supports up to eight 240-pin 1.8-Volt DDR2-667/533 ECC FB-DIMM modules.
●Memory Installation
D1808 is based on Intel®’s 5000X Greencreek chipset, which supports 144-bit wide quad
memory channels in memory interleaved scheme. System requires minimum one memory to
boot up the system.
For further information see "Installing the Memory" chapter.
6 A26361-D1808-Z120-1-7619, edition 1

Choose Proper Parts for Your System
Power Supply Considerations
●Power connectors
D1808 is powered by a split plane PSU with four +12V-rails and 700W continuous power. One rail
is for each processor, one for systemboard and one for peripherals (e.g. HHDs, add. 6-pin graphics
connector). There are three power connectors on this motherboard as listed below.
EPS/12V Power Connectors
++12V_CPU0
+12V_CPU0
+12V_CPU1
+12V_CPU1 GND
GND
GND
GND
24-pin baseboard power connector 8-pin CPU power connector
(split CPU power planes)
4-pin additional baseboard power connector
By following SSI EEB v3.51 specifications, D1808 is designed with two separate voltage
regulator circuits to provide the power for both onboard processors in separate power rail.
Using a power supply with a combined CPU power plane from the CPU power connector is not
allowed and may cause the system to fail to power up or damage to the power supply.
!
To avoid system damage take care not to mix connector P19 and P20.
The system board requires P20 with two black and two yellow wires
as additional power connector.
Additional information see chapter “Installing Power Supply”
A26361-D1808-Z120-1-7619, edition 1 7

Board Installation
Board Installation
Overview Mainboard D1808
DIMM 1
DIMM 2
DIMM 1
DIMM 3
DIMM 4 DIMM 5
DIMM 6
DIMM 7
DIMM 8
PCI-E x16 (x16)
PCI-E x8 (x4)
PCI-E x16 (x4)PCI-E x16 (x4)
PCI32
PCI-X 133
PCI-X 133
AUXIN
CD IN
J15
P17
PCI FAN
JP8
JP7
SATA 5
SATA 4
SATA 3
SATA 2
FAN 2
E50 JP1
LSI 1068E
SATA1
SATA0
1394
J84
J85
ESB2
CPU1
CPU0
CPU0 FAN
CPU1 FAN
8P POWER
MCH
4P POWER
J35 J7
24P POWER
2
3
PS/2PS/2
JP10
LAN2
1394
JP10
LAN1
SPDIF
AUD
Rear FAN
JP19
BIOS
JP15
JP17
JP16
Parallel
Serial
LAN2
USBx2
USBx2
JP23
JP14
SAS3
LAN
Gilgal
SAS
4
FLOPPY
IDE
1
21 20 19 18
17
16
7
9
9
14
13
15
10876
54
12
11
SAS2
SAS1
SAS0
SAS
5
SAS
6
SAS
7
1 = PS/2 Wakeup Enable/Disable (PS2 PWR) 12 = Clear CMOS Switch (CMOS)
2 = LCD Header (LCD) 13 = SAS Disable (SAS DIS)
3 = Front Panel Header (FP) 14 = PCI-X Clock (PCIXCLK)
4 = Front USB Header (FRNT USB) 15 = Chassis Intrusion Header (INTR)
5 = IEEE 1394 Header (FRNT1394 – grey) 16 = Front Panel Audio Header (AUDIO – yellow)
6 = Floppy Connector (FDD) 17 = CD-IN (CD)
7 = SAS (SAS0...3: white, S AS4...7: blue) 18 = AUX-IN (AUX)
8 = IDE Connector (PRIMARY IDE) 19 = LAN Enable/Disable (NIC0/1)
9 = SATA (SATA0-3: black, SATA4-5: grey) 20 = BIOS Write Protect (PROT)
10 = Internal Buzzer Enable (BUZ) 21 = PC2004 PSU Connector (PC2004)
11 = BIOS Recovery (RCV)
8 A26361-D1808-Z120-1-7619, edition 1

Board Installation
Fan Connector (FANx)
Pin 1
Pin 4
Pin1: GND
Pin2: +12V Power
Pin3: Tachometer
Pin4: Fan PWM (speed) Control
This 4-pin fan connector supports tachometer monitoring.
There are five 4-pin fan connectors on D1808. Use these connectors to connect chassis and
processor cooling fans to your motherboard. Cooling fans can keep the system stable and
reliable for its product’s life.
Chassis Intrusion (INTR)
Pin Signal
1 Presence Detection
2 Case Open
3 GND
Pin 1
PC2004 PSU Connector (PC2004)
There are two connectors available for CD audio and AUX audio. Both connectors are 4-pin.
See the illustration below for pinouts.
Pin Signal
1 n.c.
2 PSU Fan Control
3 n.c.
4 PSU Fan Pulse
5 n.c.
6 n.c.
7 n.c.
8 n.c.
Pin 1
A26361-D1808-Z120-1-7619, edition 1 9

Board Installation
CD-In and AUC-IN (CD / AUX)
There are two connectors available for CD audio and AUX audio. Both connectors are 4-pin.
See the illustration below for pinouts.
Pin Signal
1 Audio_L
2 Audio_GND
3 Audio_GND
4 Audio_R
Front Panel Header (FP)
Normally, a chassis has some control or signal wires can be connected onto a motherboard for hard
drive LED, Power LED, power button, and reset button;
The front panel header has been implemented on D1808 for such purposes.















Signal Pin Pin Signal
GND 1 2 SPEAKER_OUT_L
SLP_LED_Anode 3 4 Key
Key 5 6 GND
PWR_LED_Anode 7 8 SPEAKER_OUT_H
PWR_LED_Anode 9 10 n.c.
GND 11 12 n.c.
+3.3V 13 14 Key
MSG_LED_Cathode 15 16 n.c.
Key 17 18 SCSI_LED_Cathode
+3.3V 19 20 SCSI_LED_Cathode
HD_LED_Cathode 21 22 n.c.
GND 23 24 Key
PWR_Button_L 25 26 GND
SLP_Button_L 27 28 GND
RESET_L 29 30 GND
10 A26361-D1808-Z120-1-7619, edition 1

Board Installation
LCD Header (LCD)







Signal Pin Pin Signal
n.c. 1 2 GND
n.c. 3 4 GND
Key 5 6 RFU
LAN Action 7 8 LAN Link
HD aktiv 9 10 Alert
Message 11 12 Sleep
Power 13 14 VDD
Front USB with Chipcardreader support (FRNT USB - black)






Signal Pin Pin Signal
Key 1 2 CCR on
Power 3 4 Power
USB4- 5 6 USB5-
USB4+ 7 8 USB5+
GND 9 10 GND
Key 11 12 n. c.
HDA compliant Front Panel Audio Header (AUDIO - yellow)





Signal Pin Pin Signal
PORT1-L
1 2
Analog GND
PORT1-R 3 4 Presence Detect
PORT2-R 5 6 PORT1 Sens Return
Jack Sens Send 7 8 Key
PORT2-L 9 10 PORT2 Sens Return
IEEE 1394 Header (FRNT1394 – grey)





Signal Pin Pin Signal
TPA+
1 2
TPA-
GND 3 4 GND
TPB+ 5 6 TPB-
P12VP 7 8 P12VP
Key 9 10 GND
A26361-D1808-Z120-1-7619, edition 1 11

Board Installation
Jumper Example
OPEN - Jumper OFF Without jumper cover
CLOSED - Jumper ON With jumper cover
To indicate the location of pin-1
Clear CMOS Switch (CMOS)
3 1

(Default)

(clear)
Use CMOS jumper, if you have forgotten your system/setup password or
need to clear system BIOS settings.
●Power off the system and disconnect power supply from AC source
●Use jumper cap to close Pin 2 and Pin 3 for several seconds
to clear CMOS
●Put jumper cap back to it’s original position closing Pin1 and Pin 2
Reconnect the power supply at AC source and power on the system
Internal Buzzer Enable (BUZ)
 Open – disables internal Buzzer (Default)
 Closed – enables internal Buzzer
LAN Enable/Disable (NIC0/1)
 Close Pin 1 and 2 – NIC is enabled (Default)
 Close Pin 2 and 3 – NIC is disabled
SAS Disable (SAS DIS)
 Open – SAS Controller is enabled (Default)
 Closed – SAS Controller is disabled
PS/2 Wakeup Enable/Disable (PS2 PWR)
 Close Pin-1 and 2 no PS/2 device wakeup
 Close Pin- 2 and 3 – enables PS/2 device wakeup (Default)
BIOS Write Protect (PROT)
 Open – FWH can be written (Default)
 Closed – FWH write protection
12 A26361-D1808-Z120-1-7619, edition 1
