Fujitsu LIFEBOOK E734 User manual

System
Operating Manual
FUJITSU LIFEBOOK E734
FUJITSU LIFEBOOK E744
FUJITSU LIFEBOOK E754

Congratulations on your purchase of an innovative
product from Fujitsu.
The latest information about our products, tips, updates etc. can be found
on the Internet at: "http://www.fujitsu.com/fts/"
You can find driver updates at: "http://support.ts.fujitsu.com/download"
Should you have any technical questions, please contact:
• our Hotline/Service Desk (see the Service Desk list or visit:
"http://support.ts.fujitsu.com/contact/servicedesk")
• Your sales partner
• Your sales office
We hope you enjoy working with your new Fujitsu system!

Published by / Contact address in the EU
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
"http://www.fujitsu.com/fts/"
Copyright
©Fujits
u Technology Solutions GmbH 2014. All rights reserved.
Publication Date
02/2014
Order No.: A26391-K371-Z320-1-7619, edition 1

FUJITSU LIFEBOOK E734
FUJITSU LIFEBOOK E744
FUJITSU LIFEBOOK E754
Operating Manual
Innovative technology 7
Ports and controls 9
Important notes 14
First-time setup of your device 17
Working with the notebook 20
Security functions 51
Connecting external devices 57
Removing and installing components
during servicing 63
Settings in BIOS Setup Utility 71
Troubleshooting and tips 73
Technical data 81
Manufacturer’s notes 83
Index 84

Remarks
Information on the product description meets the design specifications of Fujitsu and
is provided for comparison purposes. Several factors may cause the actual results to
differ. Technical data is subject to change without prior notification. Fujitsu rejects any
responsibility with regard to technical or editorial mistakes or omissions.
Trademarks
Fujitsu, the Fujitsu logo and LIFEBOOK are registered trademarks of Fujitsu Limited
or its subsidiaries in the United States and other countries.
Microsoft and Windows are trademarks or registered trademarks of the Microsoft
Corporation in the United States and/or other countries.
Adobe Reader is a trademark of Adobe Systems Incorporated.
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
Made under license from DTS Licensing Limited. DTS and the symbol are registered trademarks and
& DTS Boost is a trademark of DTS, Inc. Product contains software. © DTS, Inc. All rights reserved.
All other trademarks specified here are the property of their respective owners.
Copyright
No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.
No part of this publication may be saved or transferred by any electronic means
without the written approval of Fujitsu.

Contents
Contents
Innovative technology ................................................................. 7
Furtherinformation ...................................................................... 7
Notational conventions .................................................................. 8
Ports and controls ..................................................................... 9
Importantnotes ........................................................................ 14
Safetynotes ............................................................................ 14
Additional safety notes for devices with radio components . . . . . ............................. 14
Energysaving .......................................................................... 15
Energy saving under Windows ....................................................... 15
Travelling withyournotebook ............................................................ 15
Beforeyoutravel ................................................................... 15
Notebook: transporting ............................................................... 16
Cleaningthenotebook .................................................................. 16
First-time setup of yourdevice ......................................................... 17
Unpacking and checking the device ...................................................... 17
Selectingalocat
ion ..................................................................... 18
Mains adapter connecting ............................................................... 18
Switchingonthedevice for the first time .................................................. 19
Working with the notebook ............................................................ 20
Statusindicators ........................................................................ 20
Switching on the notebook . . . . ........................................................... 22
Notebook: switching off .................................................................. 22
Keyboard ............................................................................... 23
Virtualnumerickeypad .............................................................. 25
Separate number block . . . ........................................................... 26
Key combinations ................................................................... 26
Country and keyboard settings ....................................................... 28
Application keys ........................................................................ 28
Touchpadandtouchpad buttons .......................................................... 29
Movingthepointer .................................................................. 29
Selecting an item .................................................................... 29
Executing commands . . . . . ........................................................... 29
Dragging items ...................................................................... 30
LCDscreen ............................................................................ 30
Webcam ............................................................................... 31
Rechargeablebattery ................................................................... 32
Charging, caringforandmaintaining the battery ....................................... 32
Removingandinstallingthebattery ................................................... 32
Module ................................................................................. 34
Removing a module . . . . . . ........................................................... 35
Installing a module .................................................................. 35
Opticaldrive ............................................................................ 36
Handlingdata carriers ............................................................... 36
CD/DVD indicator ................................................................... 36
Inserting or removing adata carrier ................................................... 37
Manual removal (emergency removal) . . . . ............................................ 37
Removing and fittingthedustremovalcover (ventilation slotcover) ......................... 38
Using the power-management features ................................................... 40
Fujitsu 3

Contents
Memory cards .......................................................................... 41
Supported formats .................................................................. 41
Inserting the memorycard ........................................................... 41
Removingthememorycard .......................................................... 41
Loudspeakers and microphones . . ........................................................ 42
SIM card ............................................................................... 42
Inserting the SIM card ............................................................... 43
RemovingtheSIMcard .............................................................. 44
Wireless LAN/Bluetooth/UMTS/LTE radio components . . . .................................. 45
Switching the wireless components on and off ......................................... 45
SettingupWLAN access ............................................................ 45
AccessviaUMTS/LTE ............................................................... 46
EthernetandLAN ....................................................................... 46
YourPort Replicator ..................................................................... 47
Ports on thePortReplicator .......................................................... 47
Connecting the notebook to the Port Replicator . . . . . .................................. 48
Connecting the mains adapter to the Port Replicator . .................................. 49
Switching on the notebook via the port replicator . . . . . .................................. 49
Disconnecting the notebook from the Port Replicator .................................. 50
Securityfunctions ..................................................................... 51
Configuring the fingerprint sensor ........................................................ 51
Using theSecurity Lock ................................................................. 52
Configuring password protection in BIOSSetupUtility ...................................... 52
Protecting the BIOS Setup Utility (supervisor and user HDD passwords) . . ............... 53
Password protection for booting of the operating system . .............................. 54
Trusted Platform Module (TPM) (device-dependent) . . . . . .................................. 55
EnablingTPM ....................................................................... 55
Disabling TPM ...................................................................... 55
SmartCard reader ....................................................................... 56
Inserting the SmartCard ............................................................. 56
Connecting externaldevices ........................................................... 57
Connecting an external monitor . . ........................................................ 58
HDMI port .............................................................................. 59
Connecting USB devices ................................................................ 60
USBport withcharging function (Anytime USBcharge) ................................. 61
HowtoremoveUSBdevices correctly ................................................ 61
Connecting external audio devices . . . . . . ................................................. 62
Microphone port/Line In . . ............................................................ 62
Headphone port . . . . . ................................................................ 62
Removing and installing components during servicing . . . .............................. 63
Notes on installing and removing boards and components .................................. 63
Preparing to remove components ........................................................ 64
Installingand removing memoryexpansion ................................................ 64
Removinga cover ................................................................... 65
Removing memory modules . . ........................................................ 65
Installinga memorymodule .......................................................... 66
Attaching the cover .................................................................. 66
Removingandinstallingtheharddisk .................................................... 67
Removinga cover ................................................................... 67
Removinga harddisk ............................................................... 68
Installinga hard disk ................................................................. 69
4Fujitsu

Contents
Attaching the cover .................................................................. 70
Finishing component removal . ........................................................... 70
Settings in BIOS Setup Utility . . . ....................................................... 71
StartingtheBIOSSetup Utility ........................................................... 71
OperatingBIOSSetup Utility ............................................................. 71
ExitingBIOSSetupUtility ................................................................ 72
Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 72
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . . .............. 72
Load Setup Defaults – Copy Standard Entries . ........................................ 72
Discard Changes – Discard changes without exiting the BIOS Setup Utility . .............. 72
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 72
Save Changes and Power Off ....................................................... 72
Troubleshooting and tips .............................................................. 73
Help if problemsoccur ................................................................... 73
Restoring the hard disk contents under Windows . . ........................................ 74
The notebook’s date or time is incorrect ................................................... 74
Whencertaincharactersareentered on the keyboard, onlynumerals are written ............. 74
The notebook’s LCD screen remains blank . . . . ............................................ 75
The LCD screen is difficulttoread ........................................................ 75
The externalmonitorremains blank ...................................................... 75
The externalmonitorisblankorthe imageisunstable ..................................... 76
The notebook cannot be started . . . ....................................................... 76
The notebook stops working . . ........................................................... 77
The printer does not print . . . . . ........................................................... 77
The radio connection to a network does not work . . ........................................ 77
Acousticwarnings ....................................................................... 78
SmartCard reader is not recognised. . . . ................................................... 78
SmartCardPINforgotten ................................................................ 78
SmartCardlost ......................................................................... 78
Error messagesonthescreen ........................................................... 79
Technicaldata ......................................................................... 81
LIFEBOOK ............................................................................. 81
Rechargeablebattery ................................................................... 81
Mains adapter .......................................................................... 82
Manufacturer’snotes .................................................................. 83
Disposalandrecycling .................................................................. 83
Declarationsof Conformity ............................................................... 83
CEmarking ............................................................................ 83
Index .................................................................................. 84
Fujitsu 5

Contents
6Fujitsu

Innovative technology
Innovative technology
... and ergonomic design make your device a reliable and convenient companion.
The device boots very quickly, is ready for immediate use and offers a particularly
long operating time because of its high capacity battery.
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
Information on the connections and user components of your notebook
canbefoundin"Ports and controls", Page 9.
Further information
The Windows drivers for your device can be found on our Internet site.
The factory installation of your device does not support any other operating
system. Fujitsu Technology Solutions accepts no liability whatsoever
if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products,
if they come within the scope of the delivery.
If you install other software products, pay attention to the operating
instructions of the manufacturer.
Fujitsu 7

Innovative technology
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font Indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" Indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://www.fujitsu.com/fts/"
• Names of CDs, DVDs and titles or designations for other materials,
e.g.: "CD/DVD Drivers & Utilities" or "Safety/Regulations" manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
8Fujitsu

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives
an overview of the indicators and ports of the device. Please familiarise yourself with
these components before you start to work with the device.
Front
LIFEBOOK E734:
10
1
3
1
7
5
8
9
11
7
2
5
6
4
1 = Microphone (optional)
2 = WebCam (optional)
3 = WebCam LED (optional)
4 = Touchpad
5 = Loudspeakers
6 = TouchStick (optional)
7 = Status indicators
8 = Application keys
9 = ON/OFF switch
10 = Fingerprint sensor (optional)
11 = Touchpad buttons
Fujitsu 9

Ports and controls
LIFEBOOK E744:
1
3
1
5
7
5
8
9
11
7
2
4
6
10
1 = Microphone (optional)
2 = WebCam (optional)
3 = WebCam LED (optional)
4 = Touchpad
5 = Loudspeakers
6 = TouchStick (optional)
7 = Status indicators
8 = Application keys
9 = ON/OFF switch
10 = Fingerprint sensor (optional)
11 = Touchpad buttons
10 Fujitsu

Ports and controls
LIFEBOOK E754:
1
3
1
5
7
5
8
9
11
7
2
4
6
10
1 = Microphone (optional)
2 = WebCam (optional)
3 = WebCam LED (optional)
4 = Touchpad
5 = Loudspeakers
6 = TouchStick (optional)
7 = Status indicators
8 = Application keys
9 = ON/OFF switch
10 = Fingerprint sensor (optional)
11 = Touchpad buttons
Left side
123 4 5 6 7 8
1 = DC input connector (DC IN)
2 = Ventilation slots
3 = LAN port
4 = Monitor port (VGA)
5 = DisplayPort
6 = USB port 3.0
7 = SmartCard reader (optional)
8 = Memory card slot
Fujitsu 11

Ports and controls
Right side
1 2 345 6
1 = Headphone port
2 = Microphone port
3 = USB port 3.0
4 = USB 3.0 port with charging function
(Anytime USB charge)
5 = Module bay with optical drive
6 = Security Lock device
Rear
1 2
1 = USB port 2.0 (LIFEBOOK E744/E754 only) 2 = HDMI port (LIFEBOOK E754 only)
12 Fujitsu

Ports and controls
Bottom
2
2
4
5
3
1
6
7
1 = Module release
2 = Battery release
3 = Port replicator port
4 = Battery compartment (SIM card
under the battery)
5 = Ventilation slot cover
6 = Memory service compartment
7 = Hard disk service compartment
Fujitsu 13

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed
when working with your notebook. Other notes also provide useful information
which will help you with your notebook.
Safety notes
SafetynotesNotes
Please follow the safety notes provided in the "Safety/Regulations" manual
as well as the safety notes given below.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in the "Technical data",
Page 81 and "First-time setup of your device", Page 17 before preparing your
notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the
section "Cleaning the notebook", Page 16.
Pay attention to the additional safety notes for devices with radio components
provided in the "Safety/Regulations" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 63.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Service Desk.
Additional safety notes for devices with
radio components
Radiocomponent :WirelessLAN:Bluetooth,safetynotes
If a radio component (Wireless LAN, Bluetooth, UMTS, LTE) is incorporated into your notebook,
you must be sure to observe the following safety notes when using your notebook:
• Switch off the radio components when you are in an aircraft or driving in a car.
• Switch off the radio components when you are in a hospital, an operating room or near a medical
electronics system. The transmitted radio waves can impair the operation of medical devices.
• Switch off the radio components when you let the device get near flammable
gases or into hazardous environments (e.g. petrol station, paintshops), as the
transmitted radio waves can cause an explosion or a fire.
For information on how to switch radio components on and off, see chapter
"Switching the wireless components on and off", Page 45.
14 Fujitsu

Important notes
Energy saving
NotesEnergyEnergysaving
Switch the notebook off when it is not in use. Switch off external, connected devices if you
are not using them. If you use the energy saving functions, the notebook uses less energy.
You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
Energy saving under Windows
►Make use of the power management features (see ""Using the power-management features",
Page 40").
Travelling with your notebook
MobileoperationNotesTr anspor tationNotebook
Please observe the points listed below when travelling with your notebook.
Before you travel
►Back up important data stored on your hard disk.
NotebookTravel,notebook
►Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorised third parties to receive data.
Information on activating data encryption is provided in the documentation
for your radio component.
►If you wish to use your notebook during a flight, first check with the flight
attendants if it is OK to do so.
When travelling in other countries
►If you are travelling abroad, check that the mains adapter can be operated with the
local mains voltage. If this is not the case, obtain the appropriate mains adapter for
your notebook. Do not use any other voltage converter!
►Check whether the local mains voltage and the power cable are compatible. If this is
not the case, buy a power cable that matches the local conditions.
►Enquire with the corresponding government office of the country you will be
travelling in as to whether you may operate the radio component integrated in
your notebook there (see also "CE marking", Page 83).
Fujitsu 15

Important notes
Notebook: transporting
Protect the notebook from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
►If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives.
TransportationNotebook
►Switch the notebook off.
►Unplug the mains adapter and all external devices from the power socket.
►Disconnect the mains adapter cable and the data cables for all external devices.
►Close the LCD screen.
►To protect against damaging jolts and bumps, use a notebook carrying
case to transport your notebook.
Cleaning the notebook
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household
cleaners and polishes can damage the markings on the keyboard and the
device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
The LCD screen very sensitive to scratches. Only clean the display
surface with a very soft, slightly damp cloth.
►Switch the notebook off.
CleaningNotesNotebookKeyboardTouchpadLCDscreenCrystalView display
►In order to prevent accidentially switching the device on, remove the power cable from the mains
adaptor and remove the battery (see "Removing and installing the battery", Page 32).
The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
To clean the keyboard and the touchpad, if available, you can use disinfectant wipes.
Ensure that no liquid enters the device.
16 Fujitsu
