Fujitsu FTP-631MCL301 User manual

FTP-631MCL301/302
■OVERVIEW
This thermal printer (driven by 24 VDC) and cutter provide high
speed printing for 3-inch wide paper (85 mm). This printer is small in
size, light weight, and has low power consumption. The print head is
designed with open construction for easy maintenance.
This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, label printers, measuring devices and
medical equipment.
Inadditiontotheinterfaceboard,adrivingLSI(MCU+GateArray)is
also available.
■HIGHLIGHTS
• Ultra high speed printing
It can print at 100 mm/s (800 dotlines/s) by using Fujitsu
Components' unique head drive control system.
• Auto cutter
Full or partial cutting is available by normal or reverse rotation of
the motor (command set).
• Low power consumption
The peak current for head driving is approximately 5.2 A (at 50
mm/s printing speed, 50% printing ratio).
• Easy head access
Head-open construction makes head maintenance easy,
especially for head cleaning.
• Paper auto loading function
The thermal paper can be loaded without head-up lever
operation.
• High resolution
8 dots/mm head provides clear print output.
• Selectable paper paths
Front or rear insertion types are available.
FTP-631MCL302 can print onpaperthicknessesofupto 150 µm.
24V DRIVE, ULTRA HIGH SPEED LINE THERMAL PRINTER
3” MECHANISM, WITH AVAILABLE CUTTER
FTP-631MCL301/302 shown after
assembly with FTP-631CT001cutter
FTP-621DCL012
FTP-621CU102, FTP-633GA101
1

2
FTP-631MCL301/302
■DESIGNATION
Part number
Front paper insertion type
Rear paper insertion type (supports thick paper)
FTP-631MCL301
FTP-631MCL302
FTP-631CT001
FTP-621DCL012
FTP-621CU102
FTP-633GA101
Item
Printer mechanism
Micro Controller Unit
Gate Array
LSI
Interface board
Cutter
Printing method Thermal-sensitive line dot method
Dot structure 640 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 80 mm
Number of columns 53 columns/line (maximum)—Alphanumeric KANA
Maximum printing speed 800 dot lines/s (100 mm/s) maximum
JIS ANK : 128 International characters : 130
Character types Semi-graphic : 63 ASCII small characters : 31
Download : 384
24 ×12 dots, (3.0 ×1.5 mm), 53 columns
32 ×16 dots, (4.0 ×2.0 mm), 40 columns
24 ×24 dots, (3.0 ×3.0 mm), 26 columns
32 ×32 dots, (4.0 ×4.0 mm), 20 columns
Interface 1) Centronics standard 2) Bus interface*1
Cutting method Guillotine method
Cutting type Full-cut or partial cut (command set)
Minimum cut length 20 mm
Paper thickness 65 to 150 µm
■GENERAL SPECIFICATIONS
SpecificationsItem
Character composition, dimensions (H×W),
Number of columns (standard)
Cutter
(Continued)

3
FTP-631MCL301/302
24 VDC ±5%, average:*2
0.33 (1.72) A (at 25 mm/s printing speed, 25% printing ratio)
For head 0.64 (2.58) A (at 50 mm/s printing speed, 25% printing ratio)
2.37 (4.29) A (at 100 mm/s printing speed, 25% printing ratio)
( ): Peak
For motor 24 VDC ±5%, 1.0 A maximum
For logic 5 VDC ±5%, 0.5 A maximum
Weight Mechanism with cutter: approx. 540 g. Interface board: approx. 100 g
Mechanism + cutter 132 (W) ×60 (D) ×71.0 (H) mm (excluding connector)
Interface board 140 (W) ×89 (D) ×24.0 (H) mm
Pulse durability : 1 ×108pulse/dot (using Fujitsu Takamisawa's standard
driving method)
Wear resistance: 50 km (at 25% printing ratio)
Cutter Cutting life: 3 ×105times
Operating temperature +5 to +40°C*3
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60°C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)
Detection Paper out/Mark detect By photointerrupter (command set)
Head-up By microswitch
Paper width 85 mm
1 ply paper in roll : FTP-030P0020
Thicker paper in roll : FTP-030PJ102*4
SpecificationsItem
(Continued)
Power supply
Dimensions
Thermal head
Life
Environmental
conditions
+0
–1
*1: The data to be printed is automatically read out by the printer driver equipment memory (host system frame
memory). The communication is parameter transfer.
*2: At 25°C, maximum applied voltage, minimum head resistance, specified paper, stable printing ratio.
*3: Temperature range for guaranteed printing density. It can operate at 0 to +40°C.
*4: Printer mechanism FTP-631MCL302 is to be used.
*5: Please contact us for other thermal papers.
Recommended thermal sensitive
paper*5

4
FTP-631MCL301/302
■DIMENSIONS
Printer mechanism with cutter
Unit: mm
JAPAN
68 (At cutter open)
60
35.5 (Mounting hole)
40.5
12
7.5 (300)
71
(76)
<FTP-631MCL301>
<FTP-631MCL302>
Paper insertion
Y-Y SECTION
11.8
Y Y
2-M3 Burring
25.4
Mounting screw
2.5 (Mounting hole)
52.1 (Center of paper & connector)
106.2 (Mounting hole) 132
21.9
14.2
315
94.8
Paper insertion
Note: All dimensions are nominal value.

5
FTP-631MCL301/302
Interface board
Unit: mm
CN3 CN4 CN9 CN2
CN5 CN6 CN1 CN10
CN11
CN7
Height of devices side
Height of solder side
17
5
139.7
129.6
113.1
22.9
73.7
14.0
(5.1)
88.9
78.8
(5.1)
(5.1)
14.0 31.8 15.3 88.9 (5.1)
(5.1)
28.0
25.4
4—ø3.6
23.6
1.6
■INTERFACE, COMMAND, OPTIONS
Please refer to the FTP-621DCL002/012 DATA SHEET for Interface, Command, and Options.
