INTRODUCTION
Thank you for purchasing the fi-5120C / fi-5220C Duplex Color Scanner product.
This document describes how to handle fi-5120C / fi-5220C Duplex Color and basic operation methods. Before you start
using fi-5120C / fi-5220C Duplex Color be sure to thoroughly read this manual to ensure correct use.
This manual describes the scanning method using ScandAll 21. For users using ScandAll PRO, refer to the manual, "How
to use ScandAll PRO".
CONTENTS
●Copying of the contents of this manual in whole or in part and copying of the scanner application is
forbidden under the copyright law.
●The contents of this manual are subject to change without notice.
●PFU LIMITED. is not liable whatsoever for any damages resulting from use of this scanner and
procedures described in this manual, profit due to defects, and any claims by a third party.
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Regulatory Information (1)
1 2
FCC Declaration
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is located.
●Consult your dealer or an experienced radio/TV technician.
FCC warning:
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
ATTENTION
The use of a shielded interface cable is required to comply with the Class B limits of Part 15 of
FCC rules. The length of the AC cable must be 2 meters (6.6 feet) or less.
Canadian DOC Regulations
This digital apparatus does not exceed the Class B limit for radio noise emissions from digital apparatus set out in the
Radio interference Regulations of the Canadian Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.s
Le présent appareil numérique n'émet pas de parasites radioélectriques dépassant les limites applicables aux appareils
numériques de la classe B et prescrites dans le Règlement sur le brouillage radioélectrique dictées par le Ministère des
Communications du Canada.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Bescheinigung des Herstellers / Importeurs
Für den fi-5120C/fi-5220C wird folgendes bescheinigt:
●In Übereinsstimmung mit den Bestimmungen der EN45014(CE) funkentstört
●Maschinenlärminformationsverordnung 3. GPSGV: Der höchste Schalldruckpegel beträgt
70 dB (A) oder weniger, gemäß EN ISO 7779.
1 2
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Regulatory Information (2)
1 2
International ENERGY STAR Program
As an ENERGY STAR Partner, PFU LIMITED has determined that this product meets the ENERGY STAR guidelines for energy
efficiency.
The International ENERGY STAR Office Equipment Program is an international program that promotes energy saving
through the penetration of energy efficient computers and other office equipment. The program backs the development
and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are office equipment such as computers, monitors,
printers, facsimiles, copiers, scanners, and multifunction devices.Their standards and logos are uniform among
participating nations.
Use in High-safety Applications
This product has been designed and manufactured on the assumption that it will be used in office, personal, domestic,
regular industrial, and general-purpose applications. It has not been designed and manufactured for use in applications
(simply called "high-safety applications" from here on) that directly involve danger to life and health when a high degree of
safety is required, for example, in the control of nuclear reactions at nuclear power facilities, automatic flight control of
aircraft, air traffic control, operation control in mass-transport systems, medical equipment for sustaining life, and missile
firing control in weapons systems, and when provisionally the safety in question is not ensured. The user should use this
product with adopting measures for ensuring safety in such high-safety applications. PFU LIMITED assumes no liability
whatsoever for damages arising from use of this product by the user in high-safety applications, and for any claims or
compensation for damages by the user or a third party.
About the Use of Mercury
Lamp(s) inside this product contain mercury and must be recycled or disposed of according to
local, state, or federal laws.
To avoid unexpected injury, read the following carefully.
Doing the following actions may result in serious personal injuries:
●Do not put the substance contained in the lamp in your mouth as it has mercury.
●Do not incinerate, crush, or shred the lamps or scanner parts.
●Do not breathe the chemical liquid contained in the scanner lamps.
1 2
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Trademarks
Trademarks
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other
countries.
ISIS and QuickScan are trademarks or registered trademarks of EMC Corporation in the United States.
Adobe, the Adobe logo, and Acrobat are either registered trademarks of Adobe Systems Incorporated in the United States
and/or other countries.
Other product names are the trademarks or registered trademarks of the respective companies.
How Trademarks Are Indicated In This Manual
References to operating systems (OS) and applications are indicated as follows:
Windows 2000 Microsoft® Windows® 2000 Professional operating system
Windows XP Microsoft® Windows® XP Professional operating system (32/64-bit),
Microsoft® Windows® XP Home Edition operating system
Windows Server 2003 Microsoft® Windows Server® 2003 Standard Edition operating system (32/64-bit)
Windows Vista Microsoft® Windows Vista® Home Basic operating system (32/64-bit),
Microsoft® Windows Vista® Home Premium operating system (32/64-bit),
Microsoft® Windows Vista® Business operating system (32/64-bit),
Microsoft® Windows Vista® Enterprise operating system (32/64-bit),
Microsoft® Windows Vista® Ultimate operating system (32/64-bit)
Where there is no distinction between the different versions of the above operating system, the general term "Windows" is
used.
Adobe Acrobat Adobe® Acrobat ®
Where there is no distinction between the different versions of the above application, the general term "Adobe Acrobat" is
used.
The version of Adobe Acrobat provided with this product may change without notice. If the instructions described in this
manual differ from the actual displayed screen, refer to Acrobat's Help.
Manufacturer
PFU LIMITED
International Sales Dept., Imaging Bussines Division, Products Group
Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563, Japan
Phone: [phone]
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Note, Liability
BEFORE USING THIS PRODUCT, PLEASE READ THIS MANUAL CAREFULLY. IF THIS PRODUCT IS NOT USED CORRECTLY,
UNEXPECTED INJURY CAN OCCUR TO USERS OR BYSTANDERS.
Keep this manual in a safe place so that it can be easily referred to during use of this product.
While all efforts have been made to ensure the accuracy of all information in this manual, PFU assumes no liability to any
party for any damage caused by errors or omissions or by statements of any kind in this manual, its updates or supplements,
whether such errors are omissions or statements resulting from negligence, accidents, or any other cause. PFU further
assumes no liability arising from the application or use of any product or system described herein; nor any liability for
incidental or consequential damages arising from the use of this manual. PFU disclaims all warranties regarding the
information contained herein, whether expressed, implied, or statutory.
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
PREFACE (1)
1 2
Safety Precautions
This manual describes important details for ensuring the safe and correct use of this product. Thoroughly read this manual
before you start to use this product. In particular, be sure to read and fully understand the Safety Precautions described in
this manual before you use this product.
Also, store this manual in a safe place so that it can be easily referred to during use of this product.
Warning Indications Used In This Manual
WARNING
This indication alerts operators to an operation that, if not strictly observed, may result
in severe injury or death.
CAUTION
This indication alerts operators to an operation that, if not strictly observed, may result
in safety hazards to personnel or damage to equipment.
Symbols Used In This Manual
This manual uses the following symbols in the explanations in addition to the warning indications.
This symbol alerts operators to particularly important information. Be sure to read this
information.
This symbol alerts operators to helpful advice regarding operation.
A TRIANGLE symbol indicates that special care and attention is required.
The drawing inside the triangle shows the specific caution.
A CIRCLE with a diagonal line inside shows action which users may not perform.
The drawing inside or under the circle shows the specific action that is not allowed.
Outline characters on a colored background show instructions users should follow.
It may also include the drawing that shows the specific instruction.
1 2
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
PREFACE (2)
1 2
Screen Examples In This Manual
The screen examples in this manual are subject to change without notice in the interest of product improvement. If the
actual displayed screen differs from the screen examples in this manual, operate by following the actual displayed screen
while referring to the User's Manual of the scanner application you are using. The screenshots in this manual were
captured from the FUJITSU TWAIN32 scanner driver, ScandAll 21 Image Capturing Utility Software, FUJITSU ISIS scanner
driver, QuickScan™image capturing software and Adobe®Acrobat®.
Warning Label
The following picture shows the warning label used in this scanner.
High Temperature
The glass surface inside the ADF
becomes hot during the operation. Be
careful not to touch the glass surface
inside the ADF.
ATTENTION
Do NOT remove from the scanner, stain or scratch the warning labels.
About Maintenance
The user must not perform repairs on this scanner.
Contact the store where you purchased the scanner or an authorized FUJITSU Image Scanner service provider to have
repairs done on this product.
1 2
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Safety Precautions (1)
1 2 3 4
WARNING
Do not damage the AC cable.
A damaged AC cable may cause fire or electric shock. Do not place heavy objects on AC cables, or
pull, bend, twist, heat, damage or modify AC cables.
Do not use damaged AC cables or power plugs, or install any cables or power plugs to loose wall
sockets.
Use only specified AC cables and connector cables.
Use only specified AC cables and connector cables. Failure to use the correct cables might cause
electric shock and/or equipment failure.
Please do not use the AC cable provided with this scanner for other devices, since this might cause
equipment failure and other troubles or an electric shock.
Use this scanner only at the indicated power voltage. Do not connect
to multiple-power strips.
Use this scanner only at the indicated power voltage and current. Improper power voltage and
current might cause fire or electric shock. Do not connect to multiple-power strips.
Do not touch the AC cable with wet hands.
Do not touch the power plug with wet hands. Doing so can cause electric shock.
Wipe any dust from the power plug.
Wipe off any dust from metal parts on the power plug or metal fittings with a soft, dry cloth.
Accumulated dust can cause fire or electric shock.
Do not install the device in locations that has oil smoke, steam,
humidity, and dust.
Do not install the scanner in locations subject to oil smoke, steam, humidity, and dust. Doing so
might cause a fire or electric shock.
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Safety Precautions (2)
1 2 3 4
WARNING
Turn the scanner OFF if it is damaged.
If the scanner is damaged for any reason, turn the scanner off and unplug the power cable. Contact
the store where you purchased the scanner.
Do not use the scanner if there is a strange odor.
If you detect heat coming from the device or detect other problems such as smoke, strange smells or
noises, immediately turn off the scanner and disconnect its power plug. Make sure that any smoke
coming from it has stopped, before contacting the store where you bought the scanner or an
authorized FUJITSU scanner service provider.
Do not put liquids inside the scanner.
Do not insert or drop metal objects in to the scanner. Do not scan wet documents or documents with
paper clips or staples. Do not splash or allow the scanner to get wet.
If foreign objects (water, small metal objects, liquids, etc.) get inside the scanner, immediately turn
off the scanner and disconnect the power plug from the power outlet. Then, contact the store where
you bought the scanner or an authorized FUJITSU scanner service provider. Pay particular attention
to this warning in households where there are small children.
Do not touch the inside of the scanner unless necessary.
Do not take apart or modify the scanner. The inside of the scanner contains high-voltage
components. Touching these components might cause electric shock or fire.
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Safety Precautions (3)
1 2 3 4
CAUTION
Do not install the scanner on unstable surfaces.
Make sure that the scanner is installed on a flat, level surface and that none of its parts extend
beyond the surface top, such as a desk or table. Do not install the scanner on unstable surfaces.
Install the scanner on a level surface that is free of vibration to prevent it from falling.
Install the scanner on a strong surface that will support the weight of the scanner and other devices.
Firmly insert the power plug.
Firmly insert the power plug as far it can go into the power outlet.
Do not block the ventilation ports.
Do not block the ventilation ports. Blocking the ventilation ports generates heat inside of scanner,
which may result in fire or scanner failure.
Do not place heavy objects or stand on top of the scanner.
Do not place heavy objects on the scanner or use the scanner's surface top to perform other work.
Improper installation might cause injuries and equipment failure.
Do not use the scanner immediately after moving it from a cold place
into a warm room.
Do not use the device immediately after moving it from a cold place into a warm room.
Condensation may occur, which might lead to scanning errors. Let the device dry about one or two
hours before you use it.
Before moving the scanner, disconnect the power plug from the power
outlet.
Do not move the scanner with the power and interface cables connected as this can damage the
cables, which can later cause fire, electric shock as well as injury.
Before moving the scanner, be sure to disconnect the power plug from the power outlet, and all
other data cables. Make sure that the floor is free of any obstructions.
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Safety Precautions (4)
1 2 3 4
CAUTION
Protect the scanner from static electricity.
Install the scanner away from strong magnetic fields and other sources of electronic noise. Also,
protect the scanner against any static electricity, which can cause the scanner to malfunction.
Do not use aerosol sprays near the scanner.
Do not use aerosol sprays to clean the scanner. Aerosol sprays can blow dirt and dust inside the
scanner, resulting in scanner failure or malfunction.
Avoid any contact when scanner is in use.
Avoid touching any scanner mechanism during scanning since this may cause injuries.
Disconnect the power plug from the power outlet when the scanner is
not used for a long period of time.
When the scanner is not going to be used for a long period of time, be sure to disconnect the power
plug from the power outlet.
Do not install the scanner in direct sunlight.
Do not install the scanner under direct sunlight or near heating apparatus. Doing so might cause
excessive heat to build up inside the scanner, which can cause scanner trouble or even fire. Install
the scanner in a well-ventilated location.
Before moving the scanner, make sure the shipping lock is locked.
When moving the scanner, be sure to lock the shipping lock in order to prevent damages to the
scanner.
Be aware of the pick spring.
When you perform cleaning, make sure that the inside of the scanner is free of any foreign object,
and be careful not to get your hand or the cloth caught on the pick spring (metal part) as a
deformed pick spring (metal part) may cause injury.
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Chapter 1 NAMAES AND FUNCTIONS OF PARTS
This chapter describes the scanner parts and their functions.
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.1 Checking the Contents of the Scanner Package
When you open the scanner package, please handle the main unit and its attachments carefully.
Make sure it contains all the parts listed in the package contents list that is included in the package box.
If any parts are missing or defective, contact the dealer were you purchased the scanner or an authorized FUJITSU
scanner service provider
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.2 Names and Functions of Parts (1)
1 2 3 4
This section describes the scanner parts and their functions.
Front
No. Name Function
1ADF
(Automatic Document Feeder) It transports the document to the reading position automatically.
2ADF paper chute Holds in place the document pages / sheets that are fed into the ADF.
3Side Guide It is adjusted to the width of the paper in order not to scan skewed pages.
4ADF button Puch this button to open the ADF.
5Operator panel This panel consists of a Function No. display, four operating push buttons
and a LED.
6Stacker Scanned documents are ejected from the ADF onto this tray.
7Flatbed For scanning documents not the standard sizes
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.2 Names and Functions of Parts (2)
1 2 3 4
Rear
No. Name
1Security Slot
2Imprinter connector (fi-5120C only)
3SCSI Interface connector
4SCSI ID switch
5USB Interface connector
6DC Inlet
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.2 Names and Functions of Parts (3)
1 2 3 4
Inside
(for fi-5220C)
No. Name
1Document cover
2Document holding pad
3Document bed
4Shipping lock (located on base)
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.2 Names and Functions of Parts (4)
1 2 3 4
Removable Parts
Parts that can be removed from the scanner are displayed below.
No. Name
1Document cover (fi-5220C only)
2Pad ASSY
3Pick roller (can be removed)
4ADF paper shute
5Sheet guide
1 2 3 4
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
1.3 Functions of the operator panel
The operator panel is located on the right side of the scanner. This panel comprises of a Function Number display,
four buttons and a LED.
No. Name Function
1Function Number display Indicates the function Number and error status.
2Function Button Changes the Function activated by the Send to button (*).
3Send to Button Launches the linked application software (*).
4Scan Button
5Power Button Turns the scanner ON and OFF.
6LED Lights when the scanner is turned ON.
* About the settings on the launcher, refer to FUJITSU TWAIN32 scanner driver help.
Indications on the Function Number display
Indication Function
8 Blinks only one time upon turning on the scanner.
P Indicates that the scanner has been turned ON and is being initialized.
0 Indicates that initialization will soon end.
1Indicates that initialization has ended successfully. The scanner is now in "Ready
Status".
U
Indicates that a temporary error occurred when documents were being scanned. A
number appearing in alternation following the U (i.e., 1 or 2, etc.) refers to the type
of error.
To return the scanner to the ready status ("1"), press "Scan" or "Send to" button.
E
Indicates that a device (hardware) alarm has occurred during scanning of
documents. "E" and the alarm Number (0 to 9, A,c,d and F) will appear alternately.
To return the scanner to the ready status ("1"), press "Scan" or "Send to" button. If
this alarm occurs, turn the power off and on again. If the alarm continues after
turning the power on again, contact your service engineer.
All Rights Reserved Copyright 2006-2009 © PFU LIMITED

fi-5120C / fi-5220C Image Scanner Operator
Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP
Chapter 2 BASIC SCANNER OPERATIONS
This chapter describes basic scanner operations.
In this chapter Windows XP screenshots are illustrated. The screens and operations may differ slightly if the OS that you
are using is other than Windows XP.
Also, when FUJITSU TWAIN32 or FUJITSU ISIS is updated the screens and operations noted in this chapter will differ slightly.
All Rights Reserved Copyright 2006-2009 © PFU LIMITED
