Fi-7300NX Daily Care and Consumable Replacement Guide
This section describes how to clean the scanner.
Cleaning Materials
ATTENTION
In order to use the cleaning materials safely and correctly, read the precautions on each product thoroughly.
Do not use aerosol spray or spray that contains alcohol. Paper dust blown up by strong air from the spray
may enter inside the scanner which may cause the scanner to fail or malfunction.
Also note that sparks generated by static electricity may cause a fire.
The inside of the ADF becomes very hot when the scanner is being used. Before you start cleaning the inside
of the ADF, make sure to turn off the power, unplug the power cable and wait for at least 15 minutes for the
inside of the ADF to cool down.

For more Information about the cleaning materials, contact the distributor/dealer where you purchased this product.
Or, make an Inquiry by referring to the contact Information at the Contact for Inquiries section In Safety Precautions
bundled with this product.
Location and Frequency
The Inside of the scanner (ADF) needs to be cleaned regularly for every certain number of sheets scanned. The scanner
records the number of sheets scanned so that you can check the number of sheets scanned after you cleaned it last.
The procedure to check the number of sheets scanned is as follows.
1. On the touch screen, press -> [Cleaning & Maintenance] -> [Consumable counters].
2. On the [Consumable counters] screen, check the value for [After cleaning].
oWhen the background color of the counter is yellow
It is about time to clean the scanner.
oWhen the background color of the counter is red
It is time to clean the scanner. Clean the scanner.
ATTENTION
Cleaning cycles may vary depending on the condition of the documents. Also, cleaning must be performed more
frequently when the following types of documents are scanned:
Smooth-faced documents such as coated paper
Documents with printed text/graphics that almost cover the entire surface
Chemically-treated documents such as carbonless paper
Documents containing a large amount of calcium carbonate
Documents written in lead pencil
Documents on which the toner Is not sufficiently fused

Cleaning the Outside of the Scanner
Scanner
The scanner including the ADF paper chute (feeder) and the stacker should be cleaned with either a piece of dry
cloth, a cloth moistened with Cleaner F1/mild detergent, or a sheet of Cleaning Wipe.
Touch screen
To avoid the surface of the touch screen becoming dirty, clean it regularly by gently wiping dirt and dust off with
a soft, dry cloth.
Clean the touch screen with care. Do not rub or tap the surface with hard objects as doing so may damage the
surface.
ATTENTION
To avoid deformation and discoloration, never use paint thinner or any other organic solvents.
Be careful not to let any moisture or water inside the scanner during cleaning.
It may take a long time to dry if an excessive amount of Cleaner F1/mild detergent is used. Use only a small
amount. Wipe off the cleaner completely to leave no residue on the cleaned parts.
ATTENTION
Do not wipe the touch screen with a damp cloth.
Dust on the surface may become stuck between the touch screen and the scanner, causing the touch screen to
malfunction.

Cleaning the Inside of the Scanner (ADF) with Cleaning Paper
The Inside of the ADF can be cleaned with a sheet of Cleaning Paper moistened with Cleaner F1.
As the scanner continues to feed the documents, paper dust will accumulate Inside the ADF and it may cause scanning
errors. Cleaning should be performed approximately every 5,000 sheets scanned. Note that this guideline varies
depending on the types of documents you scan. For Instance, It may be necessary to clean the scanner more frequently
when you scan documents on which the toner is not sufficiently fused.
1. Turn on the scanner.
2. On the touch screen, press -> [Cleaning & Maintenance] -> [Cleaning] -> [Cleaning Paper].
The [Cleaning Paper] screen is displayed.
3. Spray the Cleaning Paper with Cleaner F1.
4. Pull out the chute extension according to the length of the Cleaning Paper.
5. Adjust the stacker according to the length of the Cleaning Paper.
6. Load the Cleaning Paper in the ADF paper chute (Feeder).
ATTENTION
Do not use water or mild detergent to clean the ADF.
It may take a long time to dry if an excessive amount of Cleaner F1 is used. Use only a small amount.
ATTENTION
Do not start scanning with an Image scanning application during cleaning.

7. Adjust the side guides to the width of the Cleaning Paper.
Move the side guides so that there is no space between the side guides and the Cleaning Paper.
Otherwise, the Cleaning Paper may be fed skewed.
8. On the touch screen, press the [Start] button on the [Cleaning Paper] screen.
The Cleaning Paper is fed and ejected onto the stacker.
9. Clear the sheet counter after cleaning.
a. On the touch screen, press -> [Cleaning & Maintenance] -> [Consumable counters].
b. On the [Consumable counters] screen, press the [Clear] button for [After cleaning].

Cleaning the Inside of the Scanner (ADF) with a Cloth
The Inside of the ADF can be cleaned with a piece of cloth moistened with Cleaner F1, or a sheet of Cleaning Wipe.
As the scanner continues to feed the documents, paper dust will accumulate Inside the ADF and it may cause scanning
errors. Cleaning should be performed approximately every 5,000 sheets scanned. Note that this guideline varies
depending on the types of documents you scan. For Instance, it may be necessary to clean the scanner more frequently
when you scan documents on which the toner is not sufficiently fused.
1. Turn off the scanner, unplug the power cable and wait for at least 15 minutes.
2. Open the ADF.
ATTENTION
Do not use water or mild detergent to clean the ADF.
It may take a long time to dry if an excessive amount of Cleaner F1 Is used. Use only a small amount. Wipe
off the cleaner completely to leave no residue on the cleaned parts.
The Inside of the ADF becomes very hot when the scanner is being used.
Before you start cleaning the Inside of the ADF, make sure to turn off the power, unplug the power cable and wait
for at least 15 minutes for the Inside of the ADF to cool down.
When the ADF is open. It might close accidentally. Be careful not to get your fingers caught.

3. Clean the following locations with a cloth moistened with Cleaner F1, or a sheet of Cleaning Wipe.

Brake Roller (x 2)
Remove the brake roller from the scanner.
Gently wipe off any dirt or dust along the grooves, taking care not to damage the roller surface.
Pick Roller (x 2)
Gently wipe off any dirt or dust along the grooves as you rotate the roller manually, taking care not to damage
the roller surface. Make sure that it is wiped properly because black residue on the rollers will affect the feeding
performance.
Plastic Idler Roller (x 4)
Gently wipe dirt and dust off the roller, taking care not to damage the roller surface. Make sure that it is wiped
properly because black residue on the rollers will affect the feeding performance.
Be careful not to damage the sponge that is attached to the plastic idler roller.
Glass (x 2)
Gently wipe dirt and dust off the surface of the glass sections.
Ultrasonic Sensor (x 2) / Document Sensor (x 8)
Gently wipe dirt and dust off the surface of the ultrasonic and document sensors.
ATTENTION
Vertical streaks may appear on images if the glass is dirty.

Feed Roller (x 2)/Eject Roller (x 2)
The power must be turned on to rotate the feed/eject rollers for cleaning.
a. Plug in the power cable and turn on the scanner.
b. On the touch screen, press -> [Cleaning & Maintenance] -> [Cleaning] -> [Cleaning Wipe].
The [Cleaning Wipe] screen is displayed.
c. Open the ADF.
ATTENTION
Do not start scanning with an image scanning application during cleaning.
When the ADF is open, it might close accidentally. Be careful not to get your fingers caught.

d. On the touch screen, press the [Start] button on the [Cleaning Wipe] screen.
The feed/eject rollers rotate a certain amount simultaneously.
If you press and hold the [Start] button, the feed/eject rollers rotate continuously.
e. Put a piece of cloth moistened with Cleaner F1 or a sheet of Cleaning Wipe against the surface of the
rotating feed/eject roller, and wipe horizontally to clean dirt and dust off the whole surface.
Make sure that it is wiped properly because black residue on the rollers will affect the feeding
performance.
4. Close the ADF.
5. Clear the sheet counter after cleaning.
a. On the touch screen, press -> [Cleaning & Maintenance] -> [Consumable counters].
b. On the [Consumable counters] screen, press the [Clear] button for [After cleaning].
Be careful not to touch the rollers with your hand while they are rotating.
Be careful not to get your fingers caught when closing the ADF.
ATTENTION
Confirm that the ADF is closed properly. Otherwise, documents may not be fed into the ADF.

Cleaning the Carrier Sheet
The Carrier Sheet should be cleaned with either a piece of dry cloth, a cloth moistened with Cleaner F1 /mild detergent,
or a sheet of Cleaning Wipe.
Gently wipe dirt and dust off the surface and the Inside of the Carrier Sheet.
As you keep using the Carrier Sheet, dirt and dust will accumulate on the surface and the Inside.
Clean it regularly because it may result in scanning errors.
ATTENTION
Make sure that the Carrier Sheet Is not creased.
To avoid deformation and discoloration, never use paint thinner or any other organic solvents.
Do not use force to rub against the Carrier Sheet because it may be damaged or deformed.
After cleaning the Inside of the Carrier Sheet with a cloth moistened with Cleaner F1/mild detergent or a
sheet of Cleaning Wipe, do not close the Carrier Sheet until It Is completely dry.
The Carrier Sheet should be replaced approximately every 500 scans.
For Information on purchasing the Carrier Sheets, contact the distributor/dealer where you purchased this product.
Or, make an Inquiry by referring to the contact Information at the Contact for Inquiries section in Safety Precautions
bundled with this product.

Replacing the Consumables
This section explains how to replace the consumables for the scanner.
Consumables and Replacement Cycles
Consumables need to be replaced periodically. It is recommended that you keep a stock of new consumables and
replace them before it reaches the end of the consumable life. Also, the scanner records the number of sheets scanned
for each consumable (brake roller and pick roller), which allows you to determine when to replace the consumables.
The procedure to check the number of sheets scanned is as follows.
1. On the touch screen, press -> [Cleaning & Maintenance] -> [Consumable counters].
2. On the [Consumable counters] screen, check the [After Replacing the Brake Roller] and
[After Replacing the Pick Roller] counters.
oWhen the background color of the counter is yellow
It is about time to replace the brake roller or pick roller.
oWhen the background color of the counter is red
It is time to replace the brake roller or pick roller. Replace the brake roller or pick roller.
The inside of the ADF becomes very hot when the scanner is being used.
Before you replace the consumables, make sure to turn off the power, unplug the power cable and wait for at least
15 minutes for the inside of the ADF to cool down.

Note that the suggested replacement cycles are guidelines for using A4 (80 g/m2[20 lb.]) wood-free or wood-containing
paper, as these cycles vary depending on the type of documents scanned and how often the scanner is used and
cleaned.
For information on purchasing the consumables, contact the distributor/dealer where you purchased this product. Or,
make an inquiry by referring to the contact information at the Contact for Inquiries section in Safety Precautions
bundled with this product.
Replacing the Brake Roller
Replace the brake roller in following procedure.
1. Turn off the scanner, unplug the power cable and wait for at least 15 minutes.
2. Remove all documents From the ADF paper chute (feeder).
3. Open the ADF.
4. Remove the brake roller.
a. Hold both ends of the cover, and open it in the direction of the arrow.
HINT
Only use the specified consumables.
When the ADF is open, it might close accidentally. Be careful not to get your fingers caught.

b. Lift the right side of the roller First, then pull out the shaft from the slot on the left.

5. Remove the brake roller From Its shaft.
6. Attach a new brake roller on the shaft.
Insert the protrusion on the shaft into the slot.
7. Attach the shaft.

a. Insert the left end of the shaft into the hole In accordance with the hole shape, and then attach the
right side of the shaft.

b. Close the brake roller cover.
8. Close the ADF.
9. Plug in the power cable and turn on the scanner.
10. Clear the brake roller counter.
a. On the touch screen, press -> [Cleaning & Maintenance] -> [Consumable counters].
b. On the [Consumable counters] screen, press the [Clear] button for [After Replacing the Brake Roller].
ATTENTION
Confirm that the brake roller is installed properly. Otherwise, paper jams or other feeding errors may occur.
Be careful not to get your fingers caught when closing the ADF.

Replacing the Pick Roller
Replace the pick roller in following procedure.
1. Turn off the scanner, unplug the power cable and wait for at least 15 minutes.
2. Remove all documents from the ADF paper chute (feeder).
3. Remove the ADF paper chute (feeder).
Hold both ends of the ADF paper chute (feeder), then lift it in the direction of arrow 1 and pull it out in the
direction of arrow 2.
4. Open the ADF.
5. Remove the pick roller.
a. Open the sheet guide by lifting the tab.
When the ADF is open, it might close accidentally. Be careful not to get your fingers
caught.

b. Rotate the bushing on the shaft in the direction of the arrow.
c. Hold the bushing on the shaft to lift up the shaft end, pull the other shaft end out of the slot, and then lift
up the pick roller to remove it.
ATTENTION
Be careful not to touch the gear near the bushing on the shaft because it has grease over it.
