Fujitsu FI-6130 User manual

for Fujitsu Scanners
Cleaning and Consumable Replacement Instructions
IManualnstruction
Versitec is a division of Cranel, Inc.
fi-6130 / fi-6230
fi-6140 / fi-6240

WARNING !!
TURN OFF SCANNER, DISCONNECT FROM POWER
AND
ALLOW TO COOL FOR AT LEAST 15 MINUTES
BEFORE SERVICING
Limitation of Liability
Before using this product, please read this manual carefully. If this
product is used incorrectly, unforeseen injury may occur.
Although best efforts have been made to ensure all information in this manual is correct,
Cranel Inc. assumes no liability to any party for any damage caused by errors or
omissions or by statements of any kind in this manual or future updates. Cranel Inc.
further assumes neither liability arising from the use of this product nor any liability for
incidental or consequential damages arising from the use of this manual. Cranel Inc.
disclaims all warranties regarding the information contained herein, whether expressed,
implied or statutory.
Kit Contents
Cleaning the Automatic Document Feeder
What to Clean
When to Clean
How to Clean
Using the Cleaning Paper
Cleaning the Flatbed
Replacing Consumables
Brake Roller
Pick Roller
Resetting Consumable Scan Counters
For inquiries during any of these procedures, contact:
Versitec Customer Support Center
1-800-224-3475

Kit Contents
Wipes Cleaning Sheets
Swabs V1 Cleaner
Pick Roller Brake Roller

Cleaning the Automatic Document Feeder
Open the ADF
Location of Parts to be Cleaned

Recommended Cleaning Interval
During normal use, the ADF is to be thoroughly cleaned
every 5,000 scans
* Scanning certain documents may require more frequent cleaning *
Some examples are:
Carbonless paper Handwritten documents
Paper with special coatings Glossy paper
Clean in direction of arrows using either
cotton swaps or wipes moistened with V1 cleaner
Pick Arm Rollers Feed, Eject, Pinch and Pick Rollers
Turn by hand to access entire roller
Glass
Glass can become hot during use
Allow to cool before cleaning
Break Roller
See Replacing Consumables section
for removal instructructions
Ultrasonic
Sensors

Using the Cleaning Paper
Cleaning paper is designed to remove loose dust and ink only.
Perform these steps between the manual cleanings described in
the previous section
Connect scanner to computer
and power on.
Apply V1 Cleaner to both sides
of cleaning paper and place in
paper chute.
Use any scanning software and
scan first side of cleaning paper.
Repeat process using opposite
side of cleaning paper.
Cleaning the Flatbed
Lift the document cover
Clean using wipes and V1 cleaner

Replacing Consumables
Brake Roller
(Recommended after 200,000 sheets or 1 year)
Squeeze tabs and pull down
brake roller cover.
Lift right side of brake roller
up and out to remove from
scanner
Remove brake roller from shaft
Install new roller. Make sure tab
on shaft fits into the slot on roller
Insert left end of shaft into hole
in scanner and right end of
shaft into slot. Close brake
roller cover.

Pick Roller
(Recommended after 200,000 sheets or 1 year)
Lift open sheet guide Rotate pick roller lever up
Lift out pick roller and shaft. Use a paper clip to lift tab on pick
roller and remove from shaft.
Install new roller. Slide pin on shaft
into slot in roller and click into place.
Insert left end of shaft into brass
bushing and drop gear into slot.
Rotate pick roller lever down and
snap into place Before closing sheet guide, you may need to gently depress center roller.

Resetting Pick Roller and Pad Assembly Counters
After changing consumables, you need to reset the scan counters
Click Start.
Go to Settings and
click on Control Panel
Once in the Control Panel window,
open Scanners and Cameras
Right Click on the scanner
and select properties
Click the Device Set tab
Click the clear buttons
to reset the brake and
pick roller counts
Click OK to finish
and write to EPROM

For inquiries on consumables, call Versitec at: 800.727.2635
