Fujitsu fi-4530C Manual

Operator's Guide
fi-4530C Image Scanner
P3PC-E577-01EN

fi-4530CImage Scanner Operator's Guide i
CONTENTS
Chapter1 BASIC SCANNER OPERATIONS............................ 1
1.1 Turning the Scanner ON .................................................... 2
1.2 Loading Documents on the ADF for Scanning ................ 3
1.3 Scanning Documents ......................................................... 7
1.4 How to use the Scanner Driver.......................................... 9
Chapter2 SCANNING VARIOUS TYPES OF DOCUMENTS. 25
2.1 Scanning double sided Documents................................ 26
2.2 Scanning Documents with different Widths .................. 28
2.3 Scanning thin Documents ............................................... 29
2.4 Scanning Documents longer than A3 size ..................... 31
2.5 Saving scanned Images in PDF Format ......................... 34
2.6 Excluding a Color from the Image (dropout color)........ 42
2.7 Skipping blank Pages....................................................... 44
2.8 Detecting Double-Feeds................................................... 46
2.9 Correcting the skewed Documents................................. 48
Chapter3 DAILY CARE .......................................................... 51
3.1 Cleaning Materials and Locations requiring Cleaning.. 52
3.2 Cleaning the ADF.............................................................. 54

ii
Chapter4 REPLACING CONSUMABLES .............................. 59
4.1 Consumable and Replacement Cycle............................. 60
4.2 Replacing the Pad ASSY.................................................. 66
4.3 Replacing the Pick Roller................................................. 70
Chapter5 TROUBLESHOOTING............................................ 79
5.1 Removing Jammed Documents ...................................... 80
5.2 Remedying Common Troubles........................................ 82
5.3 Items to check before contacting the agent where you
bought the scanner .......................................................... 97
5.4 Checking Labels on the Scanner .................................... 99
Chapter6 DOCUMENT SPECIFICATIONS
FOR THE ADF ...................................................... 101
6.1 Document Size................................................................ 102
6.2 Document Quality ........................................................... 103
6.3 Maximum ADF Capacity................................................. 106
6.4 Area not to be perforated............................................... 107
6.5 Double-feed Detection Conditions................................ 108
Chapter7 SCANNER SPECIFICATIONS ............................. 111
7.1 Basic Specifications....................................................... 112
7.2 Installation Specifications ............................................. 114
7.3 External Dimensions ...................................................... 116

fi-4530CImage Scanner Operator's Guide iii
APPENDIX Before using the [Scan] or the [Send to] button ...... AP-1
GLOSSARY GLOSSARY OF TERMS............................................... GL-1
INDEX ...................................................................................................... IN-1

iv

1
fi-4530CImage Scanner Operator's Guide 1
Chapter1
BASIC SCANNER OPERATIONS
This chapter describes basic scanner operations.
In this chapter Windows XP screenshots are illustrated.
The screens and operations may differ slightly if the OS you are using is not Windows XP.
Also, when FUJITSU TWAIN32 is updated the screens and operations noted in this chapter will
differ slightly.
1.1 Turning the Scanner ON......................................................................................... 2
1.2 Loading Documents on the ADF for Scanning .................................................... 3
1.3 Scanning Documents ............................................................................................. 7
1.4 How to use the Scanner Driver.............................................................................. 9

2
1.1 Turning the Scanner ON
1. Press the power button on the operator panel.
The scanner is turned ON, and the green LED on the operator panel lights.
During the initialization, the indication of the Function No. display changes as follows:
“8”->"P" -> "0" -> "1"
The indication "1" means that the operator panel is in the ready status.
■ Power Save Mode
The Power Save mode keeps the scanner in a low-powered state if no operation is performed on the
scanner for 15 minutes after it has been turned ON. The scanner is automatically switched to the
Power Save mode.
In the Power Save mode, the indication of the Function No. display on the operator panel goes out,
while the green LED is kept lit.
To return the scanner from the Power Save mode, perform one of the following operations:
•Load documents on the ADF paper chute.
•Press any button on the operator panel.
The scanner will be turned OFF when pressing down the power button for two seconds.
•Execute a command from the scanner driver.
HINT
To turn the scanner OFF, hold the power button down for two seconds.
Power button

1.2 Loading Documents on the ADF for Scanning
fi-4530CImage Scanner Operator's Guide 3
BASIC SCANNER OPERATIONS
1
1.2 Loading Documents on the ADF for Scanning
1. Align the edges of the documents.
1) Confirm that all the documents have the same width.
2 ) Check the number of the sheets in the document stack.
The standard number of sheets that can be loaded on the scanner is as follows:
•A4-size paper or smaller that makes a document stack of 10mm or less (100 sheets
at 64 g/m2)
•A3-size paper or smaller that makes a document stack of 5mm or less (50 sheets at
64 g/m2)
2. Fan the documents as follows:
1) Lightly grip both ends of the documents with both hands, and bend the documents as fol-
lows.
2 Hold the documents firmly with both hands and bend them back as follows so that the
bent section rises up in the middle of the stack as shown below.
3 Repeat steps 1) to 3) a couple of times.
4 Rotate documents 90 degrees, and fan again.
10mm

4
3. Align the top of the documents.
4. Load the documents on the ADF paper chute.
Set the documents face-down in the ADF paper chute (so that the side to be scanned faces
towards the ADF paper chute).
HINT
Set the documents so that the stack will be lower than the line mark.
Load the documents facing the ADF
paper chute.(face down)
A

1.2 Loading Documents on the ADF for Scanning
fi-4530CImage Scanner Operator's Guide 5
BASIC SCANNER OPERATIONS
1
5. Adjust the side guides to the width of the documents.
Move the side guides so that they touch both sides of the documents.
If there is any clearance between the side guides and the edges of documents, the scanned
image may be skewed.
HINT
Before loading pull out the ADF paper chute extension according to the
lengths of the documents.
Extension
Side guides

6
6. Start up the scanner application and scan the documents.
For details on how to scan documents using the ScandAll 21 application, refer to "1.3 Scan-
ning Documents" on page 7.
HINT
The stacker prevents document sheets from dropping after they were
scanned.
Use the stacker as follows:
1. Lift up the stacker towards you by inserting your fingertips into the
handle on the scanner.
2. Lift the paper stop and swing forward by inserting your fingertips into
the indentations on the stacker.
handle
Indentation

1.3 Scanning Documents
fi-4530CImage Scanner Operator's Guide 7
BASIC SCANNER OPERATIONS
1
1.3 Scanning Documents
1. Load documents on the scanner's ADF paper chute.
For details about loading documents, refer to "1.2 Loading Documents on the ADF for Scan-
ning" on page 3.
2. Start up ScandAll 21.
Select [Start] - [Program] - [Scanner Utility for Microsoft Windows] - [ScandAll 21].
⇒This starts up ScandAll 21.
3. Select the scanner to use.
Select [Select Source] from the [Scan] menu.
⇒The [Select Source] dialog box appears.
Select "FUJITSU fi-4530Cdj" (for Windows 95 and WindowsNT 4.0, select “FUJITSU
TWAIN 32”) and click the [Select] button.
4. Click the [Scan To View] button on the tool bar.
⇒The [TWAIN Driver] dialog box (for setting the scan conditions) appears.

8
5. Set the scan resolution, paper size, etc., and click the [Scan] button.
For details on settings in the [TWAIN Driver] dialog box, refer to the "FUJITSU TWAIN 32
Scanner Driver Help" on the Setup CD-ROM.
⇒The images of scanned documents are displayed on the [ScandAll 21] window.
For details on different types of scanning, refer to "2 SCANNING VARIOUS TYPES OF
DOCUMENTS" on page 25.
For details on functions and operations of ScandAll 21, refer to "ScandAll 21 Help".

1.4 How to use the Scanner Driver
fi-4530CImage Scanner Operator's Guide 9
BASIC SCANNER OPERATIONS
1
1.4 How to use the Scanner Driver
■ FUJITSU TWAIN32 Scanner Driver
FUJITSU TWAIN32 Scanner Driver is designed for scanning documents with FUJITSU image
scanner fi series by using application software that complies with the TWAIN standard.
The following describes the procedure with examples of ScandAll 21 for ordinary scanning by
using this driver software.
1. Procedure for Basic Scanning Operation
1. Startup the application.
From the [Start] menu, select [Programs]-[Scanner Utility for Microsoft Window] and
click [ScandAll 21].
2. Select your scanner on the window below.
Select [Select Source] from the [Scan] menu.
3. Select the scanner to use, then click the [Select] button.
Select
•[FUJITSU fi-4530C] for FUJITSU TWAIN32 V9
or
•[FUJITSU TWAIN32] for FUJITSU TWAIN32 V8
then click the [Select] button.

10
4. Load the documents on the scanner.
Methods for loading documents vary depending on the type of the scanner.
For details, refer to "fi-4530C Operator's Guide" on the Setup CD-ROM.
5. Open the TWAIN Driver window.
Select [Scan To View] from the [Scan] menu.
6. Configure settings for scanning and click the [Scan] button.
For details about the settings on this window, refer to "Setting Window for FUJITSU
TWAIN32 Scanner Driver" on page 12.
HINT
ScandAll 21 provide scanning methods as follows:
•[To View...] :Displays scanned images on the window.
•[To File...:] :Saves scanned images as files (*.BMP, *.TIF, *.JPG).
•[To FTP...:] :Transfers scanned images to a FTP server.
•[To Adobe PDF...:] :Saves scanned images as PDF files.
(*Adobe Acrobat must be installed beforehand.)
•[To Microsoft &SharePoint Portal Server...] :Transfers scanned images to
Microsoft Share Point Portal Server.
•[To Mail...] :Launches mailer software and attaches scanned images to e-
mail.
For details, refer to "ScandAll 21 Help".

1.4 How to use the Scanner Driver
fi-4530CImage Scanner Operator's Guide 11
BASIC SCANNER OPERATIONS
1
7. The images of scanned documents are displayed on the [ScandAll 21] window.
Depending on the settings of application software, images may not displayed.
For details, refer to the documentation or Help file of your application.
e.x.) When you select [To File...] from the [Scan] menu of ScandAll 21, images of
scanned documents are not displayed on the window.
8. Save the scanned images.
Select [Save As...] from the [File] menu to save the scanned images.
IF you wish to start another scanning, return to the procedure 4.
9. End the application.
Select [Exit] from the [File] menu.

12
2. Setting Window for FUJITSU TWAIN32 Scanner Driver
You can perform settings for the FUJITSU TWAIN32 Scanner Driver on this window.
The following describes the main setting items.
•For details on each functions, refer to "FUJITSU TWAIN32 Scanner Driver Help"
(appears by pressing [Help] or [F1] button).
•Depending on the type of your scanner, available setting items or range of setting
values vary.
Resolution
Specifies the resolution of scanning.
It can be specified by selecting a default value from the list or customizing (specify any
resolution in 1 dpi unit).
By marking the [Predefine] checkbox, you can select one from three predefined set-
tings as [Normal], [Fine], [Super Fine] to scan documents instead of setting details by
yourself.
Otherwise, you can change the details of the predefined settings on the [Resolution Set-
ting] window, which appears when you click on the [...] button.
Scan Type
Specifies the feeding method (Flatbed/ADF), the side(s) to be scanned (Front Side,
Back Side, Duplex) or details of Long page (the size of documents longer than A3).
Paper Size
Select the size of documents to be scanned from this list.
Windows for customizing the paper size will appear when you click on [...] besides the
list. You can save any document size as a customized setting (up to three) or for chang-
ing the order of the paper size in the list.

1.4 How to use the Scanner Driver
fi-4530CImage Scanner Operator's Guide 13
BASIC SCANNER OPERATIONS
1
Image Mode
Specifies the image type for the scanned documents.
[Scan] button
Starts scanning documents with the current settings.
[Preview] button
Documents are scanned preliminarily before the actual scanning.
You can confirm the image of the documents in the preview window.
[Close] button
Saves the current settings and closes this window.
[Reset] button
Used to undo changes of settings.
[Help] button
Opens the "FUJITSU TWAIN32 Scanner Driver Help" window. The window also
opens by pushing the [F1] key.
[About...] button
Opens an information window about the FUJITSU TWAIN32 Scanner Driver's ver-
sion.
[Option...] button
You can set up the details of optional functions on the window below.
Black & White Documents are scanned in binary (black and white).
Halftone Documents are scanned through halftone process-
ing in black and white.
Grayscale Documents are scanned with 256 gradations of
black and white.
Color Documents are scanned colored. For this mode, you
can select 24 bit Color, 256Color or 8 Color.

14
[Rotation] tab
Select this tab when setting image rotation, detection of document size, etc.
[Job/Cache] tab
Select this tab when setting cache mode, job controls, double-feed detection, blank
page skipping, etc.
[Generic] tab
Select this tab to change the unit displayed on the Setting Window for the FIJITSU
TWAIN32 Scanner Driver. (Millimeters, Inches, and Pixels are available)
[Startup] tab
Select this tab for setting the Scanner Operation Panel.
(Displayed only when using the scanner of supported type.)
[Filter] tab
Select this tab for setting the image processing filter(s).
Page Edge Filler: Fills up the margins of the scanned documents with a selected color.
[Compression] tab
Select this tab for setting the compression rate of JPEG Transfer.
(Displayed only when using a scanner that supports JPEG Transfer.)
[Imprinter (Endorser)] tab
Select this tab for configuration of the Imprinter option (sold separately).
(Displayed only when the scanner is equipped with the Imprinter option.)
[Advance...] button
Click this button for settings of the advanced image processing.
You can set Edge Extract, Gamma Pattern, White Level Follower, Dropout Color,
Reverse, etc.
[Config...] button
Click this button for configuring the Setting Files.
You can save the changed settings as a Setting File. From next scanning, the settings
are quickly changed by using these Setting Files.
For details of each function, refer to the "FUJITSU TWAIN32 Scsnner Driver Help".

1.4 How to use the Scanner Driver
fi-4530CImage Scanner Operator's Guide 15
BASIC SCANNER OPERATIONS
1
■ FUJITSU ISIS Scanner Driver
FUJITSU ISIS Scanner Driver is designed for scanning documents with FUJITSU image scanner fi
series by using application software that complies with The ISIS standard.
The following describes the procedure with examples of QuickScan for ordinary scanning by using
this driver software.
The procedure may vary depending on your application.
If you use an application other than QuickScan, please refer to its Guide or Help for further
information.
1. Procedure for Basic Scanning Operation
1. Startup the application.
From the [Start] menu, select [Programs]-[QuickScan] and click [QuickScan].
2. Select your scanner on the window below.
Select [Scan] - [Select Scannerc] on the menu bar.
3. Select the scanner to use, then click the [OK] button.
4. Select [Scan] - [New Batch] on the menu bar.
