PRIMERGY BX922 S2
Server Blade
Options Guide
Edition March 2011

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected]ujitsu.com.
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2011 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability. The right to technical modification is reserved.
All hardware and software names used are trademarks of their respective manufacturers.
–The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
–No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

BX922 S2 Options Guide
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

OptionsGuide BX922 S2
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-
SATA storage interfaces. Please note that the usage and operation conditions
differ depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

BX922 S2 Options Guide
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– USB Flash Module (UFM)
– CSS (Customer Self Service)
– Replacing the lithium battery

OptionsGuide BX922 S2

BX922 S2 Options Guide
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 9
1.3 Extensions and conversions . . . . . . . . . . . . . . . . . 11
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 13
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 17
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1 Opening the Server Blade . . . . . . . . . . . . . . . . . . . 21
4.1.1 Removing the Server Blade from the system unit . . . . . . . . 22
5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1 Installing a second processor . . . . . . . . . . . . . . . . . 25
6 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1 Expanding/replacing main memory . . . . . . . . . . . . . . 34
7 Mezzanine cards . . . . . . . . . . . . . . . . . . . . . . . . 37
7.1 Population rules for mezzanine cards . . . . . . . . . . . . 39
7.2 Installing mezzanine cards . . . . . . . . . . . . . . . . . . 47
8 HDD/SSD Module . . . . . . . . . . . . . . . . . . . . . . . . 51

OptionsGuide BX922 S2
Contents
8.1 Installing a HDD/SSD module . . . . . . . . . . . . . . . . . . 52
9 USB Flash Module (UFM) . . . . . . . . . . . . . . . . . . . . 59
9.1 Installing a UFM . . . . . . . . . . . . . . . . . . . . . . . . . 59
10 Trusted Platform Module (TPM) . . . . . . . . . . . . . . . . . 61
10.1 Installing a TPM . . . . . . . . . . . . . . . . . . . . . . . . . 61
11 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
11.1 Closing the server blade . . . . . . . . . . . . . . . . . . . . 67
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

BX922 S2 Options Guide 9
1 Preface
The PRIMERGY BX922 S2 server blade is an Intel-based dual-socket server
blade. It is ideal for use in data centers belonging to enterprises or Internet
service providers, and makes an excellent large application server, terminal
server for compute-intensive applications or DBMS server.
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
1.2 Documentation overview
IPRIMERGY manuals are available in PDF format on the
ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the
ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system.html).
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
For the Japanese market please use the URL:
http://primeserver.fujitsu.com/primergy/manual.html.

10 OptionsGuide BX922 S2
Preface
More information on your PRIMERGY BX922 S2 server blade can be found in
the following documents:
– "Quick Start Software - Quick Installation Guide" DVD booklet (only included
as a printed copy with the ServerView Suite)
– "Safety Notes and Regulations" manual
"安全上の注意 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "PRIMERGY ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for the Japanese market
– System Board D2861 for BX922 S2 Technical Manual
– D2861 BIOS Setup Utility for PRIMERGY BX922 S2 server blade reference
manual
– "PRIMERGY BX922 S2 Server Blade Operating Manual"
– "PRIMERGY BX922 S2 Server Blade Options Guide"
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

BX922 S2 Options Guide 11
Preface
1.3 Extensions and conversions
Second processor
If only one processor is installed in your server blade, you can add a second
processor to it. You may only use processors of the same type. The second
processor must have the same clock frequency as the first.
Main memory expansion
The system board has a total of 12 slots for memory modules. Of these, 6 slots
are for CPU 1 and 6 slots for CPU 2.
In total, the system board supports up to 192 GB main memory. Memory
modules with a capacity of 1 GB, 2 GB, 4 GB, 8 GB or 16 GB can be used.
Both registered DDR 3 memory modules (RDIMM) and unbuffered DDR 3
memory modules (UDIMM) are permitted. However, you must not use a mixture
of these two module types.
IYou can find detailed information on the main memory in the technical
manual for the D2861 system board.
Optional I/O modules (mezzanine cards)
The server blade has two slots for expansion boards (known as mezzanine
cards), which can each provide two Fibre Channel connections or four
additional Ethernet connections.
You can choose from the following I/O modules:
– 8 Gbit/s Fibre Channel mezzanine card with 2 port (PCIe x8)
– 1 Gbit/s Ethernet mezzanine card with 4 ports (PCIe x4)
– 40 Gbit/s Infiniband mezzanine card with 2 ports (PCIe x8)
– 10 Gbit/s Ethernet mezzanine card with 2 ports (PCIe x8)
– CNA mezzanine card with 2 ports (CNA MEZZCARD 10Gbit 2PORT)
Solid State Disk module (SSD)/HDD (option)
The server blade can be equipped with two HDD/SSD modules. They are
controlled by the ICH10R part of the Intel chipset.

12 OptionsGuide BX922 S2
Preface
USB Flash Module (UFM) (option)
The system board is equipped with a UFM slot by the manufacturer.
This module can be used as optional memory for software (e.g. VMware) or as
a software dongle.
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the system BIOS (see Operating Manual).
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.

BX922 S2 Options Guide 13
Preface
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

14 OptionsGuide BX922 S2
Preface

BX922 S2 Options Guide 15
2Procedure
VCAUTION!
●The activities described in this manual must be performed by
engineers, service personnel or technical specialists.
●Equipment repairs must be performed by qualified staff.
●Any failure to observe the guidelines in this manual, and any
unauthorized opening or improper repairs could endanger the user
(through electric shock, fire hazards) or damage the equipment.
●Please note that any unauthorized opening of the device will result in
the invalidation of the warranty and exclusion from all liability.
ÊFirst of all, carefully read the safety instructions in chapter "Safety
instructions" on page 17 and following.
ÊMake sure that you have all necessary manuals (see "Documentation
overview" on page 9); print out the PDF files if required.
Most importantly, you will need the operating manual for the server blade.
ÊShut down the server blade properly, switch it off, and remove it from the
system unit as described in chapter "Preparation" on page 21.
ÊCarry out the expansion or upgrade of your server blade as described in the
pertinent chapter.
IInstallation and removal of hot-plug components is described in the
server blade operating manual.
ÊClose the server blade, re-insert it in the system unit and switch it on as
described in chapter "Completion" on page 67 and following.
ÊStart the operating system and make the appropriate configuration if
necessary (see operating manual).

16 OptionsGuide BX922 S2
Procedure
Information
For the latest information on optional products provided for the BX922 S2 server
blade see the configurator of the server:
https://sp.ts.fujitsu.com/dmsp/docs/cnfgbx922s2.pdf
(for the EMEA market)
http://primeserver.fujitsu.com/primergy/system.html
(for the Japanese market)

BX922 S2 Options Guide 17
3 Safety instructions
IThe following safety instructions are also provided in the manual "Safety
Notes and Regulations" or " 安全上のご注意 ".
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office
environment.
If you have any questions as to whether you can set up the device in your
particular environment, please contact your sales outlet or our customer service
centre.
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
●Before installing/removing internal options to/from the server, turn off
the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the power outlet. Failure to do so
can cause electric shock.
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.

18 OptionsGuide BX922 S2
Safety instructions
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.
For the Japanese market it is not required to transport the device in
its original packaging.
Installation and operation
VCAUTION!
●Observe the notes on installation and operation in the operating
manual of your respective basic unit.
●When installing the server blade in the basic unit, beware of the
energy hazard at the midplane contacts. A short circuit on these
contacts can damage the system.
●Data cables must be adequately shielded to avoid interference.
●The EN 50173 and EN 50174-1/2 standards apply for LAN cabling.
The minimum requirement is the use of a category 5 screened LAN
cable for 10/100 Mbit/s Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements of the specification ISO/IEC 11801 must
also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the operating manual for the
device.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
●Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids get
inside the unit (electric shock hazard, short circuit).
●In emergencies (e.g. damaged casing, control elements or power
cables, penetration of liquids or foreign bodies), switch off the device
immediately, unplug it from the grounded power outlets, and contact
your customer service team.
●Proper operation of the system (in accordance with IEC 60950/DIN
EN 60950) is only ensured if the casing is completely assembled and
the rear covers for the installation openings have been put in place
(electric shock, cooling, fire protection, interference suppression).

BX922 S2 Options Guide 19
Safety instructions
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and
telecommunications terminal equipment.
If you install other extensions, you might damage the system or
violate these safety regulations.
You can find out which system extensions are suitable from the
customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed or exchanged by authorized, qualified
personnel. The hot-pluggable/hot-swappable components are
exceptions to this rule.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
VCAUTION!
●Only set the resolutions and refresh rates specified in the operating
manual for your monitor. Otherwise, you may damage the monitor. If
you are in any doubt, contact your sales outlet or customer service
center.
Batteries
VCAUTION!
●Incorrect replacement of batteries may lead to a risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the technical manual for the
system board).
●Do not throw batteries into the trash can.
●Batteries must be disposed of in accordance with local regulations
concerning special waste.
●Replace the lithium battery on the system board in accordance with
the instructions in the technical manual for the system board.
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). In addition, the marking is provided with
the chemical symbol of the heavy metal decisive for the classification
as a pollutant:
Cd Cadmium

20 OptionsGuide BX922 S2
Safety instructions
Hg Mercury
Pb Lead
Modules with Electrostatic-Sensitive Devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, you must always observe the
following points:
●Switch off the system and remove the power plugs from the power outlets
before installing or removing components with ESDs.
●You must always discharge static build-up (e.g. by touching a grounded
object) before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Wear a suitable grounding cable that connects you to the external chassis
of the system unit.
●Always hold components with ESDs at the edges or at the points marked
green (touch points).
●Do not touch any connectors or conduction paths on an ESD.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).
