Fujitsu Primergy RX100 S3 User manual

PRIMERGY
PRIMERGY RX100 S3
Server System
Options Guide
Susanne Däschlein
Fujitsu Siemens Computers GmbH München
81730 München
e-mail: email: [email protected]
Tel.: [phone]
Fax: (++49) 700 / 372 00000
U41617-J-Z156-1-76
Sprachen: En
Edition August 2005

Comments Suggestions Corrections
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2005 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

U41617-J-Z156-1-76 Options Guide
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Overview of the documentation . . . . . . . . . . . . . . . . . . 5
1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 7
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 8
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 17
5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2 Extending/replacing the main memory . . . . . . . . . . . . . 21
6 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 23
6.1 Installing an accessible 5.25-inch slimline drive . . . . . . . . . 23
7 Hard disks . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.1 Installing a second non-hot-plug hard disk . . . . . . . . . . . 27
8 Controller in the PCI slots . . . . . . . . . . . . . . . . . . . 29
8.1 Installing a controller . . . . . . . . . . . . . . . . . . . . . . 29
9 RemoteView components . . . . . . . . . . . . . . . . . . . 33
9.1 RemoteView Service Board S2 LP . . . . . . . . . . . . . . . 33
10 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 37
11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
11.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

U41617-J-Z156-1-76 Options Guide 5
1Introduction
The PRIMERGY RX100 S3 server is an Intel-based server for small and
medium-sized networks. The compact server casing (only one height unit) as
well as its scalability and security features make the PRIMERGY RX100 S3 the
perfect choice for operational areas data centers, Internet- and application-
hosting.
1.1 Overview of the documentation
IPRIMERGY manuals are available in PDF format on the ServerBooks CD
which is supplied in the ServerView Suite package for every server
system.
These PDF files can also be downloaded free of charge from the
Internet: at http://manuals.fujitsu-siemens.com you will find an overview
page with the online documentation available on the Internet. You can go
to the PRIMERGY Server documentation by clicking on “industry
standard servers”.
Concept and target groups
This Options Guide shows you how you can expand and upgrade the server.
IThe Operating Manual for the server describes how you install/remove
the hot-plug components.
The activities described in this manual may only be performed by technical
specialists.
Additional documentation about the server
The PRIMERGY RX100 S3 documentation comprises the following additional
manuals:
– “Quick Start Hardware - PRIMERGY RX100 S3” (poster)
– “Quick Start Software - PRIMERGY ServerView Suite” (poster)
– “Warranty” manual (print version delivered together with the system, PDF file
available on the ServerBooks CD)
– “Safety” manual (print version delivered together with the system, PDF file
available on the ServerBooks CD)
– “Ergonomics” manual (PDF file available on the ServerBooks CD)

6 Options Guide U41617-J-Z156-1-76
Overview of the documentation Introduction
– “Returning used devices” (PDF file available on the ServerBooks CD)
– “Helpdesk” (poster with worldwide helpdesk telephone numbers)
– “PRIMERGY RX100 S3 Serversystem Operating Manual” (PDF file
available on the ServerBooks CD)
– Technical Manual for the system board D2004 (PDF file available on the
ServerBooks CD)
– “BIOS Setup” manual (PDF file available on the ServerBooks CD)
– “ServerView Suite” includes the ServerStart CD, the ServerBooks CD and the
print version of the manual “PRIMERGY ServerView Suite - ServerStart”.
The PDF file of the manual is also available on the ServerBooks CD.
IIf you need a backup of the ServerBooks CD, send the details of your
server via email address: [email protected].
– “Global Array Manager Client Software User’s Guide” (PDF file available on
the ServerBooks CD)
– “Global Array Manager Server Software User’s Guide” (PDF file available on
the ServerBooks CD)
– “LSI SATA Software RAID User’s Guide” (PDF file available on the Server-
Books CD)
Further sources of information:
– Technical Manual on the relevant rack
– Manual on the monitor
– Manual on ServerView Server Management
– Manual on the RemoteView Remote Test and Diagnostics System
– Documentation on your operating system
– Information files on your operating system
(see also “Related publications” on page 47)

U41617-J-Z156-1-76 Options Guide 7
Introduction Extensions and conversions
1.2 Extensions and conversions
Extension of the main memory
The four slots for the main memory are suitable for unbuffered PC2-533
(PC2-4200) DDR2 SDRAM memory modules. The organization in two memory
banks, 1 and 2, permits rapid memory access with two-way interleaving.
If the memory modules are populated in pairs, each pair must consist of
identical memory modules (2-way interleaved mode).
Additional accessible drive
One 5.25-inch slimline bay is available for accessible drives.
Additional SATA hard disk drive
A second bay is available for SATA hard disk drives.
Additional controllers in the PCI slots
The system board offers 2 x PCI-X (64 Bit / 100 MHz) or 1x PCI-Express x4 and
2 x PCI-X (64 Bit / 100 MHz) slots by a riser card.
RemoteView Service Board S2 LP
The RemoteView Service Board S2 LP (RSB S2 LP) is a PCI board with a
completely independent system, i.e. it has its own operating system with Web
server and SNMP agents and can optionally be equipped with an external
power supply. The RSB S2 LP permits remote diagnosis for system analysis,
remote system configuration and remote restart even in the event of operating
system failure or hardware faults. It has its own LAN connection and its own
COM port. All the functions of the RSB S2 LP are thus available either via a LAN
or modem.

8 Options Guide U41617-J-Z156-1-76
Notational conventions Introduction
1.3 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands, menu items or software programs.
„Quotation marks“ indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.
Table 1: Notational conventions

U41617-J-Z156-1-76 Options Guide 9
2Procedure
VCAUTION!
The actions described in these instructions should only be performed by
technical specialists. Equipment repairs should only be performed by
service personnel. Any unauthorized opening and improper repairs could
expose the user to risks (electric shock, energy hazards, fire hazards)
and could also damage the equipment. Please note that any unautho-
rized opening of the device will result in the invalidation of the warranty
and exclusion from all liability.
ÊFirst of all please familiarize yourself with the safety instructions in the
section chapter “Safety notes” on page 11 et seqq. .
ÊEnsure that all required manuals (see “Additional documentation about the
server” on page 5) are available, printing out the PDF files if necessary. You
will definitely need the Operating Manual for the server and the Technical
Manual for the system board.
ÊShut down the server correctly, switch it off, pull out the power plug(s), and
open the server as described in the chapter “Preparation” on page 17 et
seqq. .
ÊExtend or upgrade your server as described in the relevant chapter.
IThe Operating Manual for the server describes how you
install/remove the hot-plug components.
ÊClose the server, connect it to the power outlet, and switch it on as described
in the chapter “Completion” on page 37 et seqq. .
ÊStart the operating system and, if necessary, configure it as required (see
the Operating Manual).

U41617-J-Z156-1-76 Options Guide 11
3 Safety notes
IThe following safety notes are also provided in the “Safety” manual.
This device complies with the relevant safety regulations for data processing
equipment.
If you have any questions about where you can set up the device, contact your
sales outlet or our customer service team.
VCAUTION!
The actions described in these instructions should only be performed by
technical specialists. Equipment repairs should only be performed by
authorized, qualified staff. Any unauthorized openings and improper
repairs could expose the user to risks (electric shock, energy hazards,
fire hazards) and could also damage the equipment. Please note that
any unauthorized openings of the device will result in the invalidation of
the warranty and exclusion from all liability.
Before operating the device
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.

12 Options Guide U41617-J-Z156-1-76
Safety notes
Installation and operation
VCAUTION!
●If the server is integrated in an installation that receives power from
an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial (public) power supply networks for
the type A connector.
●The server automatically sets itself to a voltage in the range of
100 V to 127 V or 200 V to 240 V. Make sure that your local voltage
is within this range.
●This device has a specially approved power cable and must only be
connected to a grounded insulated socket.
●The ON/OFF button does not disconnect the device from the mains
voltage. To completely disconnect it from the mains voltage, remove
the power plug from the insulated socket.
●Always connect the device and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
the central processing unit is still running but the peripheral device
(e.g. storage subsystem) has failed during a power outage.
●Data cables to peripheral devices must be adequately shielded.
●To the LAN wiring the requirements apply in accordance with the
standards EN 50173 and EN 50174-1/2. As minimum requirement
the use of a protected LAN line of category 5 for 10/100 MBps
Ethernet, and/or of category 5e for Gigabit Ethernet is considered.
The requirements of the specification ISO/IEC 11801 are to be
considered.
●Route the cables in such a way that they do not form a potential
hazard and that they cannot be damaged. When connecting up a
device, refer to the relevant notes in this manual.
●Never connect or disconnect data transmission lines during a storm
(lightning hazard).

U41617-J-Z156-1-76 Options Guide 13
Safety notes
VCAUTION!
●Make sure that no objects (such as bracelets or paper clips) fall into
or liquids spill into the device (risc of electric shock or short circuit).
●In emergencies (e.g. damaged casing, controls or cables, penetration
of liquids or foreign matter), switch off the device immediately, remove
the power plug and contact your sales outlet or customer service
team.
●Proper operation of the device (in accordance with IEC 60950/
EN 60950) is only ensured if the casing is completely assembled and
the rear covers for the installation openings have been put in place
(electric shock, cooling, fire protection, interference suppression).
●Only install system expansions that satisfy the requirements and
rules governing safety and electromagnetic compatibility and relating
to telecommunications terminal equipment. If you install other expan-
sions, you may damage the system or violate the safety regulations
and regulations governing RFI suppression. Information on which
system expansions are suitable can be obtained from the customer
service centre or your sales outlet.
●The components or parts marked with a warning label (e.g. lightning
symbol) may only be opened, removed or exchanged by authorized,
qualified personnel.
●The warranty expires if the device is damaged during the installation
or replacement of system expansions.
●You may only set those resolutions and refresh rates specified in the
„Technical data“ section of the monitor description. Otherwise, you
may damage your monitor. If you are in any doubt, contact your sales
outlet or customer service centre.

14 Options Guide U41617-J-Z156-1-76
Safety notes
Batteries
VCAUTION!
●Incorrect replacement of batteries may lead to a risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the technical manual for the
system board under “Related publications” on page 47).
●Replace the lithium battery on the system board in accordance with
the instructions in the technical manual for the system board (see
“Related publications” on page 47).
Notes on handling CDs and CD-/DVD-ROM drives
VCAUTION!
●Use only CDs in proper condition in the CD-/DVD-ROM drive of your
server to prevent data loss, damage to the device and injuries.
●Therefore, check each CD for damage, cracks, breakage etc. before
inserting it in the drive.
Please note that any additional labels applied may change the
mechanical properties of a CD and cause imbalance.
Damaged and imbalanced CDs can break at high drive speeds (data
loss).
Under certain conditions sharp-edged pieces of broken CDs can
penetrate the cover of the drive (damage to the device) and be thrown
out of the device (danger of injury, particularly on uncovered body
parts such as the face or neck).
IYou protect the CD-/DVD-ROM drive and prevent mechanical damage,
as well as premature wearing of the CDs, by observing the following
suggestions:
– Only insert the CDs in the drive when needed and remove them after
use.
– Store the CDs in suitable sleeves.
– Protect the CDs from exposure to heat and direct sunlight.

U41617-J-Z156-1-76 Options Guide 15
Safety notes
Note about the laser
The CD-/DVD-ROM drive
is classified for laser class 1according to IEC 60825-1.
VCAUTION!
The CD-/DVD-ROM drive contains a laser diode (LED). Sometimes the
LED produces a stronger laser beam than laser class 1. Direct view into
this laser beam is dangerous.
Never remove parts of the CD-/DVD-ROM drive assembly!
Modules with electrostatic-sensitive components:
Systems and components that might be damaged by electrostatic discharge
(ESD) are marked with the following label:
Figure 1: ESD label
When you handle components fitted with ESDs, you must observe the following
points under all circumstances:
●Remove the power plug from the power socket before inserting or removing
components containing ESDs.
●You must always discharge yourself of static charges (e.g. by touching a
grounded object) before working.
●The equipment and tools you use must be free of static charges.
●Only touch the components at the positions highlighted in green (touch
points).
●Do not touch any exposed pins or conductors on a component.
●Use a grounding cable designed for this purpose to connect yourself to the
system unit as you install components.

16 Options Guide U41617-J-Z156-1-76
Safety notes
●Place all components on a static-safe base.
IYou will find a detailed description for handling ESD components in the
relevant European or international standards (DIN EN 61340-5-1,
ANSI/ESD S20.20).

U41617-J-Z156-1-76 Options Guide 17
4 Preparation
VCAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 11
et seqq. .
4.1 Opening the server
ÊTerminate all applications and shut down the server correctly.
ÊIf your operating system has not switched off the server, press the on/off
button.
ÊPull all power connectors out of the power outlets.
ÊDisconnect all cables on the rear of the server.
Figure 2: Pulling the server out of the rack
ÊLoosen the two knurled screws (1) and pull the server as far as possible out
of the rack.
ÊPress the locking spring (1) on both sides and carefully pull the server
outward.
ÊPull the server out of the rails and place it on a table, for example.
1
2

18 Options Guide U41617-J-Z156-1-76
Opening the server Preparation
Figure 3: Loosening the screws
ÊUnlock the top cover by removing the knurled screw at the rear side.
ÊPush the top cover approxiate 2 cm frontward.
ÊRemove the top cover.

U41617-J-Z156-1-76 Options Guide 19
5Mainmemory
VCAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 11
et seqq. .
The system board supports up to 4 Gbytes of main memory. Four slots (2 slots
form a memory bank) are provided for the main memory. Each memory bank
can be equipped with 512 Mbyte, 1 Gbyte or 2 Gbyte unbuffered PC2-533
(PC2-4200) DDR2 SDRAM memory modules.
5.1 Equipping rules
Figure 4: Structure of the main memory in memory banks and memory modules
– Mix of memory is permitted.
– For the dual-channel configuration: install identical memory modules in
DIMM_1A and DIMM_1B and identical memory modules in DIMM_2A and
DIMM_2B.
CPU Front Side Bus (FSB) DDR2 SDRAM Type
533 MHz (Celeron) PC2-533 (PC2-4200)
800 MHz PC2-533 (PC2-4200)
DIMM2B
DIMM1B
DIMM2A
DIMM1A
IDE 1
CN16
CN21
CN20 CN22
CN17

20 Options Guide U41617-J-Z156-1-76
Equipping rules Main memory
The table below shows the order in which the memory banks must be equipped:
Single-channel configuration
Dual-channel configuration
Basic configuration DIMM_1A
(black)
DIMM_2A
(blue)
DIMM_1B
(black)
DIMM_2B
(blue)
Basic configuration
with 1x memory
module K968-Vxxx
X- - -
Additional memory module F3000 -
1x memory module:
E513
E514
E515
Already
populated by
basic configu-
ration
-X-
2x memory module:
E513
E514
E515
Already
populated by
basic configu-
ration
XX -
3x memory module:
E513
E514
E515
Already
populated by
basic configu-
ration
XXX
Basic configuration DIMM_1A
(black)
DIMM_2A
(blue)
DIMM_1B
(black)
DIMM_2B
(blue)
Basic configuration
with 2x memory
module K968-Vxxx
X- X -
Additional memory module F3000 -
2x memory module:
E513
E514
E515
Already
populated by
basic configu-
ration
X Already
populated by
basic configu-
ration
X
