PRIMERGY RX100 S4 Server
Operating manual
Edition November 200

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2006 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

RX100 S4 Operating manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . 7
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 14
1.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Installation steps: Overview . . . . . . . . . . . . . . . . . . 17
3 Important information . . . . . . . . . . . . . . . . . . . . . 19
3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 26
3.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 29
3.5 Rack installation instructions . . . . . . . . . . . . . . . . . 30
3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 31
4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 33
4.1 Installation steps . . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 34
4.3 Installing/removing the server in/from the rack . . . . . . . 35
4.3.1 Rack requirements . . . . . . . . . . . . . . . . . . . . . . . . 36
4.3.2 Installation in PRIMECENTER/DataCenter Rack . . . . . . . . 39
4.3.3 Installation in 3rd party racks . . . . . . . . . . . . . . . . . . 42
4.3.4 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 43
4.4 Connecting devices to the server . . . . . . . . . . . . . . . 45
4.4.1 Connecting the monitor . . . . . . . . . . . . . . . . . . . . . 46
4.5 Connecting the server to the mains . . . . . . . . . . . . . . 46
4.6 Instructions for connecting/disconnecting cables . . . . . . 47

Operating manual RX100 S4
Contents
5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 49
5.1 Controls and displays . . . . . . . . . . . . . . . . . . . . . . 49
5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5.2 Switching the server on and off . . . . . . . . . . . . . . . . 55
5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 57
5.3.1 Hard disk drive write cache . . . . . . . . . . . . . . . . . . . . 57
5.3.2 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 58
5.3.3 Configuration without ServerStart . . . . . . . . . . . . . . . . . 60
5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 61
6 Property and data protection . . . . . . . . . . . . . . . . . . 63
6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 63
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 65
7.1 Power on indicator remains unlit . . . . . . . . . . . . . . . . 65
7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 66
7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 66
7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 67
7.5 No screen display or display drifts . . . . . . . . . . . . . . . 67
7.6 No mouse pointer displayed on screen . . . . . . . . . . . . 67
7.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 68
7.8 System will not boot . . . . . . . . . . . . . . . . . . . . . . . 68
7.9 Error message on screen . . . . . . . . . . . . . . . . . . . . 68
8 Hot pluggable hard disk drives . . . . . . . . . . . . . . . . . 69
8.1 Handling HDD modules . . . . . . . . . . . . . . . . . . . . . 70
8.1.1 Installing/removing HDD/dummy unit . . . . . . . . . . . . . . . 72

RX100 S4 Operating manual
Contents
Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

RX100 S4 Operating manual 7
1Introduction
The PRIMERGY RX100 S4 server is an Intel-based server for small and
medium-sized networks and can be used in the rack systems made by Fujitsu
Siemens Computers GmbH and in current standard rack systems made by
various other manufacturers.
Thanks to its highly developed hardware and software components, the
PRIMERGY RX100 S4 server offers a high level of data security and availability.
These include the ServerView server management software, Prefailure
Detection and Analysing (PDA) and Automatic Server Reconfiguration and
Restart (ASR&R).
Security functions in the BIOS Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
lockable rack door.
The server occupies 1 height unit in the rack.
1.1 Documentation overview
IPRIMERGY manuals are available in PDF format on the ServerBooks
DVD, which is part of the ServerView Suite provided with each server
system.
These PDF files can also be downloaded from the Internet free of
charge: At http://manuals.fujitsu-siemens.com you will find an overview
page showing the online documentation available on the Internet. You
can go to the PRIMERGY Server documentation by clicking on industry
standard servers.
Concept and target groups for this manual
This operating manual describes how to install, set up and operate your server.
This manual is intended for those people responsible for installing the hardware
and ensuring that the system runs smoothly. The manual contains all the infor-
mation required to install and operate your PRIMERGY RX100 S4.
A knowledge of hardware and data transmission, as well as basic knowledge of
the operating system used, is necessary to fully understand the various
expansion options. You should also have a good working knowledge of the
English language.

8 Operating manual RX100 S4
Documentation overview Introduction
Additional server documentation
The PRIMERGY RX100 S4 documentation also includes:
– “Quick Start Hardware - PRIMERGY RX100 S4” (leaflet)
– “Quick Start Software - PRIMERGY ServerView Suite” (leaflet)
– “Warranty” manual (print version supplied with the system, PDF file available
on the ServerBooks DVD supplied)
– “Safety notes and other important information” manual (print version
supplied with the system, PDF file available on the ServerBooks DVD
supplied)
– “Ergonomics” manual (PDF file available on the ServerBooks DVD supplied)
– “Returning used devices” manual (PDF file available on the ServerBooks DVD
supplied)
– “Helpdesk” (leaflet with worldwide helpdesk telephone numbers)
– “PRIMERGY RX100 S4 Server System Options Guide” (PDF file available
on the ServerBooks DVD supplied)
– Technical Manual for the D2532 system board (PDF file available on the
ServerBooks DVD supplied)
– “BIOS Setup” (PDF file available on the ServerBooks DVD supplied)
– "ServerView Suite" includes the ServerStart Disc, the ServerBooks DVD and
the print version of the "Primergy ServerView Suite - ServerStart" manual.
The PDF file of the manual is also available on the ServerBooks DVD.
IIf you need a replacement copy of the ServerBooksCD send the details
of your server to the following e-mail address:
[email protected]
– “Global Array Manager Client Software User’s Guide” (PDF file available on
the ServerBooks DVD supplied)
– “Global Array Manager Server Software User’s Guide” (PDF file available on
the ServerBooks DVD supplied)
– “LSI SATA Software RAID User’s Guide” (PDF file available on the
ServerBooks DVD supplied)

RX100 S4 Operating manual 9
Introduction Features
Further sources of information:
– Technical Manual for the relevant rack
– Manual for the monitor
– Manual on ServerView Server Management
– Manual for the remote testing and diagnostic system RemoteView
– Documentation for boards and drives
– Documentation for your operating system
– Information files on your operating system
(See also “Literature” on page 77.)
1.2 Features
System board
The features of the system board are described in the technical manual for the
system board D2532 for the hardware and in the “BIOS Setup” for the firmware
(see “Literature” on page 77).
Hard disk drives
Two basic versions of the server are available, fitted with either SATA or SAS
hard disk drives.
SAS server version:
The server has a drive cage in which one or two SAS hard disk drive modules
can be inserted. Each hard disk drive (HDD) module can accept an SAS hard
disk drive with a maximum height of 1 inch. The module is connected to the SAS
backplane without cables via the SAS interface. This allows hard disk drive
modules to be easily plugged in or removed. If the server has a corresponding
RAID configuration, defective HDD modules can also be replaced during
operation.
SATA server version:
With the standard design, the server has a drive cage in which up to two SATA
hard disk drives with an "easy change" drive frame and a maximum height of
1 inch are fitted. There is a wire connection to the controller. Defective HDD
modules cannot be replaced during operation.

10 Operating manual RX100 S4
Features Introduction
The server can optionally be upgraded with a SATA backplane. The SATA hard
disk drive modules then have a wireless connection via the SATA interface. This
allows hard disk drive modules to be easily plugged in or removed. If the server
has a corresponding RAID configuration, defective HDD modules can also be
replaced during operation.
Onboard SAS controller with Integrated Mirroring Enhanced functionality
An 8-channel SAS controller with "Integrated Mirroring Enhanced" (IME)
functionality is fitted to operate the two hard drives. IME also provides RAID
functionality for configuring the internal hard drives (RAID level 0, 1, 1E).
IA separate utility is available to the controller for IME configuration.
Further information can be found in the "Integrated RAID for SAS User’s
Guide" (on the ServerBooks DVD under "Controllers").
Onboard SATA controller
A 2-channel SATA controller is fitted to operate the two hard drives. LSI SATA
Software RAID supports RAID level 0 and 1.
IThe controller has its own configuration utility. Further information can be
found in the "Embedded SATA Software RAID for ICH7R User’s Guide"
(on the ServerBooks DVD under "Controllers").
Accessible drives
An installation slot is provided for a slimline CD/DVD drive (optional). The
accessible drive installed here cannot be replaced during operation.
Power supply
The server has a built-in power supply unit, which automatically sets itself to a
mains voltage in the range 100 V - 127 V or 200 V - 240 V.

RX100 S4 Operating manual 11
Introduction Features
High level of availability and data security
When memory data is accessed, 1-bit errors in the main memory are identified
and automatically corrected with the ECC (Error Correcting Code) method.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
case of an error and automatically “hides” the defective system components.
The PDA (Prefailure Detection and Analyzing) technology from Fujitsu Siemens
Computers analyzes and monitors all components that are critical for system
reliability.
Server management
Server management is implemented using the ServerView software supplied
combined with PDA (Prefailure Detection and Analyzing) technology from
Fujitsu Siemens. PDA reports the threat of a system error or overload at an early
stage, allowing preventive measures to be taken.
ServerView enables all PRIMERGY servers in the network to be managed from
a central console. ServerView supports the following functions:
●Round-the-clock monitoring, regardless of server status
●High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128 bit)
●Remote storage via USB
●Remote power on (Wake On LAN)
●Intrusion detection
●Temperature monitoring of the CPU and the surrounding area
●Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event of failure of memory modules or processors
●Power monitoring
●End-of-life monitoring of fans with prompt notification before failure
●Watchdog timer for operating system monitoring and application monitoring
with ASR&R
Further information about ServerView server management is provided in the
associated documentation (see “Literature” on page 77).

12 Operating manual RX100 S4
Features Introduction
ServerStart
The ServerStart software supplied allows you to configure your PRIMERGY
server quickly and precisely. User-guided menus are available for installing the
server operating system.
Service and support
PRIMERGY servers are service-friendly and modular, enabling quick and easy
maintenance.
The handles and locks (touch point) on the different hot pluggable components
are colored green to ensure simple and immediate recognition.
In order to avoid damage to components by incorrect handling when they are
being installed and removed, green highlighting also identifies the areas of all
components that can be touched without causing damage to the respective
component.
The Flash EPROM program supplied with the Fujitsu Siemens Computers
utilities supports a fast BIOS update.
With the iRMC (integrated Remote Management Controller) on the system
board and the optional remote testing and diagnostic system RemoteView, the
PRIMERGY RX100 S4 server can also be maintained and serviced remotely.
This enables remote diagnosis for system analysis, remote configuration and
remote restart should the operating system or hardware fail.

RX100 S4 Operating manual 13
Introduction Features
RemoteView
RemoteView is the remote management solution from Fujitsu Siemens
Computers for Intel-based PRIMERGY systems. RemoteView and the relevant
hardware components integrated on the system board allow remote monitoring
and maintenance as well as fast restoration of operation in the event of errors.
Remote monitoring and maintenance avoids time-consuming and costly on-site
repairs and reduces service costs. This leads to a reduction in the total cost of
ownership and an excellent return on investment for the remote management
solution.
LAN port 1 is used as the management interface and is set up for operation with
RemoteView. The management system shares the LAN connection with the
standard operating system.
The administrator can access all system information and information from the
sensors such as fan speeds, voltages etc. via a Web interface (iRMC Web
interface). He can also start the text-based or graphical console bypass
(Advanced Video Redirection, AVR) and obtain information about remote
storage.
RemoteView helps
●switch on/off the system remotely
●monitor systems and analyze the cause of faults
●prepare error resolution or to have this process initiated independently
where possible
●identify potential sources of error
●configure the system
●adjust system settings and initiate system restarts from a remote location

14 Operating manual RX100 S4
Notational conventions Introduction
1.3 Notational conventions
The following notational conventions are used in this manual:
Italics indicate commands, menu items or software programs.
“Quotation marks” indicate names of chapters and terms that need to be
emphasized.
Êindicates activities that must be performed in the order
given.
VATTENTION! indicates that, if you ignore the information given at this
point, your health, the correct functioning of your
system or the security of your data may be at risk.
IIndicates supplementary information, remarks and tips.

RX100 S4 Operating manual 15
Introduction Technical data
1.4 Technical data
Electrical data
Compliance with regulations and standards
Rated voltage range 100 V - 127 V or 200 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current with basic configuration 100 V - 240 V / 1.94 A - 0.96 A
Max. rated current 100 V - 240 V / 4 A - 2 A
Effective power 234 W
Apparent power 249 VA
Heat dissipation 842 kJ/h (798 btu/h)
Main power fuse 16 A (6.3 A)
Protection class I
Product safety and ergonomics IEC 60950 / EN 60950, UL/CSA 60950,
CAN/CSA 22.2 No. 60950 3rd. Ed.
Electromagnetic Compatibility
(standard power supply)
FCC class A
VCCI class A
AS/NZS CISPR 22 class A
CNS 13438 class A
Interference emissions EN 55022
Harmonic current EN 6100-3-2 JEIDA
Flicker EN 61000-3-3
Interference immunity EN 55024
CE marking to EU directives Low Voltage Directive 73/23/EEC
Electromagnetic Compatibility 89/336/EEC

16 Operating manual RX100 S4
Technical data Introduction
Mechanical values
Weight
Approx. 12 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear
Environmental conditions
Condensation must be avoided during operation.
Noise level
Width 430 mm
Depth 560 mm
Height 42.5 mm or 1 HU
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Section 3-3
EN 60721 / IEC 721 Section 3-2
Temperature:
Operation (3K2)
Transport (2K2)
10 °C ... 35 °C
-25 °C ... 60 °C
Humidity 10% ... 85%
Sound power level LWAd (ISO 9296) < 5.5 B (standby)
<6.1 B (operation)
Sound pressure level at adjacent workstation
LpAm (ISO 9296)
< 49.6 dB (A) (standby)
<55.5 dB (A) (operation)

RX100 S4 Operating manual 17
2 Installation steps: Overview
This chapter contains an overview of the steps necessary to install your server.
Links guide you to sections where you can find more detailed information on the
individual steps:
ÊFirst of all, it is essential that you familiarize yourself with the safety infor-
mation in chapter “Important information” on page 19.
ÊUnpack the system, check the contents of the package for visible transport
damage and check whether the items delivered correspond to the details on
the delivery note (see section “Unpacking the server” on page 34).
ÊTransport the server to the place where you want to install it
ÊMake sure that all necessary manuals (see “Additional server documen-
tation” on page 8) are available; print out the PDF files if required.
ÊFitting the server in the rack (see section “Installing/removing the server
in/from the rack” on page 35).
ÊWire the server. Follow the instructions in sections “Connecting devices to
the server” on page 45 and “Instructions for connecting/disconnecting
cables” on page 47.
ÊConnect the server to the mains (see section “Connecting the server to the
mains” on page 46).
ÊFamiliarize yourself with the controls and displays on the front and rear of
the server (see section “Controls and displays” on page 49).

18 Operating manual RX100 S4
Installation steps: Overview
ÊConfigure the server and install the desired operating system and applica-
tions. The following options are available:
– Remote configuration and installation with ServerStart:
The ServerStart Disc supplied allows you to conveniently configure the
server and install the operating system.
Details on how to operate ServerStart, as well as some additional infor-
mation, can be found in the “PRIMERGY ServerView Suite - ServerStart”
manual supplied as a PDF file.
Configuration information can also be found in section “Configuration
with ServerStart” on page 58.
– Local configuration and installation with or without ServerStart (see
section “Configuration with ServerStart” on page 58 or “Configuration
without ServerStart” on page 60).

RX100 S4 Operating manual 19
3 Important information
In this chapter you will find essential information regarding safety when working
on your server.
3.1 Safety
IThe following safety instructions are also provided in the manual “Safety
notes and other important information”.
This device meets the relevant safety regulations for IT equipment.
If you have any questions about whether you can install the server in the
intended surroundings, contact your sales outlet or our customer service team.
VCAUTION!
The activities described in these instructions may only be performed by
specialist technical personnel. Repairs to the server may only be carried
out by authorized specialist personnel. Any unauthorized opening and
improper repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) and could also damage the equipment. Please
note that any unauthorized opening of the server will void the warranty
and exempt the manufacturer from all liability.

20 Operating manual RX100 S4
Safety Important information
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see section
“Technical data” on page 15).
●If the server has been moved from a cold environment, condensation
may form both inside and on the outside of the machine.
Wait until the server has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the server if this requirement is not met.
●Only transport the server in the original packaging or in packaging
that protects it from impacts and jolts.
Installation and operation
VCAUTION!
●If the unit is integrated into an installation that draws power from an
industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for non-
industrial power supply networks for type A connectors.
●The device automatically adjusts itself to a mains voltage between
100 V and 240 V. Ensure that the local mains voltage lies within these
limits.
●This device must only be connected to a properly grounded shock-
proof socket using tested and approved power cables.
●Ensure that the power sockets on the device and the grounded
shockproof sockets are freely accessible.
●The On/Off button or the main power switch (if present) does not
isolate the device from the mains power supply. To disconnect it
completely from the mains power supply, unplug all network power
plugs from the grounded shockproof sockets.
