Fujitsu PRIMERGY RX800 S2 User manual

Produktfamilie
PRIMERGY RX800 S2/S3 Server
Options Guide
Joachim Pichol
Fujitsu Siemens Computers GmbH Paderborn
33094 Paderborn
e-mail: email: [email protected]
Tel.: [phone]
Fax: (++49) 700 / 372 00001
Sprachen: En
Edition March 2007

This manual is printed on
paper treated with
chlorine-free bleach.
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.vor
Copyright © 2007 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 3
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . . 6
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Environmental Protection . . . . . . . . . . . . . . . . . . . . 15
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1 Removing the server from the rack . . . . . . . . . . . . . . . 19
4.2 Opening the cover . . . . . . . . . . . . . . . . . . . . . . . . 21
4.3 Removing the bezel . . . . . . . . . . . . . . . . . . . . . . . 23
5Mainmemory. . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.1 Fitting rules . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.2 Upgrading/exchanging main memory . . . . . . . . . . . . . . 28
5.3 Installing a memory card . . . . . . . . . . . . . . . . . . . . . 29
6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.1 Installing additional processors . . . . . . . . . . . . . . . . . 32
6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . . 38
7Adapters. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.1 Installing adapters . . . . . . . . . . . . . . . . . . . . . . . . 42
7.2 Installing a ServeRAID-8i adapter . . . . . . . . . . . . . . . . 42
8Completion. . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2 Mounting the server in the rack . . . . . . . . . . . . . . . . . 46
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

1
1 Preface
The PRIMERGY RX800 S2/S3 server system offers unique performance
density by packing up to four Intel®Xeon™ MP dual-core processors into a 3-
height (3U) building block (node).
Each node offers 6 PCI-X 2.0 slots and is equipped with a CD/DVD drive and
up to 6x2,5" hot-plug SAS hard disks. Full redundancy for power supplies and
fans as well as phase redundancy for AC line input is supported. Hard disks,
memory cards, fans units, power supply units, and PCI adapters are hot-
pluggable. All hot-plug operations are described in the Operating Manual.
Each node is either a base unit or an extension unit. Both units can be
combined to form an 8-way (6U) configuration. By combining two 8-way config-
urations, a 16-way (12U) configuration with four nodes can be assembled. The
assembly procedure is described in the Operating Manual.
Generally speaking, base unit and extension unit upgrade and conversion is
done in the same way. However, there are exceptions to this rule which are
explained in the appropriate chapter(s).
1.1 Documentation overview
IPRIMERGY manuals are available in PDF format on the ServerBooks CD,
which is part of the PRIMERGY ServerView Suite provided with each
server system.
The PDF files for the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found via the URL:
http://manuals.fujitsu-siemens.com (choose: industry standard servers).
Concept and target groups
This Options Guide shows you how to expand and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
specialist personnel with technical training.

2
Documentation overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k01
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server. This applies to memory
cards, hard disk drives, system fans, power supply units, and PCI boards.
Additional components of the system documentation
The PRIMERGY RX800 S2/S3 documentation comprises the following
documentation:
– “Warranty” manual (printed copy always supplied with the server, and
available as a PDF file on the ServerBooks CD supplied)
– “Safety” manual (printed copy always supplied with the server, and available
as a PDF file on the ServerBooks CD supplied)
– “Ergonomics” manual (PDF file available on the ServerBooks CD supplied)
– Operating Manual for PRIMERGY RX800 S3 (PDF file available on the
ServerBooks CD supplied)
– Service Supplement for PRIMERGY RX800 S2/S3 (PDF file available on the
ServerBooks CD supplied)
– "RemoteView Management Board RSA-II User Manual" (PDF file available
on the ServerBooks CD supplied)
– "ServeRAID-8i HDD Controller User Manual" (PDF file available on the
ServerBooks CD supplied)
– "ServerView Suite" includes the ServerStart CD, the ServerBooks CD and the
ServerSupport CDs. The PDF version of the user manual "PRIMERGY -
ServerView Suite - ServerStart" is also available on the ServerBooks CD.
IYou can order a supplementary ServerBooks CD by sending an e-mail
to the following address, quoting your server data:
Reklamat-PC-LO[email protected]
Further sources of information:
– Technical Manual for the relevant rack
– Manual for the monitor
– Manual on ServerView Server Management
– Manual on the RemoteView Remote Test and Diagnostics System
– Documentation for your operating system
– Information files on your operating system
(see also chapter “Related publications” on page 55)

3
Preface Extensions and conversions
1.2 Extensions and conversions
Main memory
In the basic configuration (base/extension unit), two memory cards are supplied
with either 2 GB or 4 GB of memory installed in memory card A.
The system board offers four hot-plug memory cards (A to D) slots, each of
which can accommodate up to four DIMMs (in two memory banks each). The
slots are suitable for DDR RAM PC2-3200 ECC DIMMs with 2 GB or 4 GB
capacity, depending on the type of memory. Thus, each node supports up to 32
GB (64 GB) of system memory.
No mixing of DIMM types is allowed within one memory bank. Memory mirroring
is only possible if DIMM types are identical between mirrored memory banks.
Memory upgrade/exchange with the server switched off is described in chapter
“Main memory” on page 25.
IThe hot-plug memory card exchange and upgrade procedure is
described in the Operating Manual.
Processors
In the basic configuration (base/extension unit), the system comes with two
microprocessors. You can install up to four microprocessors to further enhance
performance and symmetric multiprocessing (SMP) capability.
You may only use processors of the same type on the system board. All
processors must have the same frequency and cache size.
Processor upgrade/exchange is described in chapter “Processors” on page 31.
Accessible drives
The basic configuration (base/extension unit) includes a CD/DVD drive.
However, this drive is disabled in the extension unit of an 8-way configuration.
IIn 16-way configuration, only one CD/DVD drive is operable.
No built-in accessible drives are available. Therefore, additional drives must be
plugged in via the USB port. This can be done while the system is up and
running.

4
Extensions and conversions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k01
Adapters in PCI slots
The server is equipped with six PCI-X 2.0 slots, all offering 64-bit support,
operating at 266 MHz, and supporting hot-plug functionality.
The following adapter types are available:
●PCI adapters for external SCSI storage system
If you want to connect additional external SCSI devices, up to two 1-channel
PCI SCSI adapters may optionally be installed per scalable partition.
●PCI adapters for external disk arrays
If you want to connect additional external disk arrays, up to four 2-channel
PCI RAID adapters may optionally be installed per scalable partition.
●PCI Fibre Channel adapters
Up to four 1-channel Fibre Channel PCI adapters for subsystems and SAN
(Storage Area Network) may optionally be installed per scalable partition.
●Single-port or dual-port PCI LAN adapters
The server comes with an integrated Broadcom dual-port LAN adapter.
Up to four single-port PCI LAN adapters may optionally be installed per
scalable partition
Up to three dual-port PCI LAN adapters may optionally be installed per
scalable partition.
PCI card upgrade with the server switched off is described in chapter “Adapters”
on page 41.
IInstallation of hot-plug adapters is described in the Operating Manual.

5
Preface Extensions and conversions
SAS/RAID adapters
In addition to the six standard PCI slots, a dedicated PCI slot is reserved for the
ServerRAID-8i RoMB adapter (controller).
By default, the base unit has a ServeRAID-8i adapter installed to handle up to
six hard disk drives. This adapter works in conjunction with the onboard SAS
controller.
In the extension unit, a ServeRAID-8i adapter is optionally available. However,
in a multi-node configuration, a maximum of two adapters is allowed to handle
up to 12 hard disk drives.
IIn a 16-way configuration, a ServeRAID-8i adapter is installed in both
base units. Consequently, no more optional adapters are allowed for any
of the two extension units.
ServeRAID-8i upgrade is described in chapter “Adapters” on page 41.
IAn BBU (Battery Backup Unit) is integrated in the ServeRAID-8-i adapter
to protect its memory contents in the event of a power failure. Lithium
battery exchange is described in the Service Supplement.

6
Notational conventions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k01
1.3 Notational conventions
The following notational conventions are used in this manual:
Italics indicate commands, menu items or software programs.
“Quotation marks” indicate names of chapters and terms that need to be
emphasized.
Êindicates an activity that must be performed.
VCAUTION! indicates that, if you ignore the information given at this
point, your health, the correct functioning of your
system or the security of your data may be at risk.
Iindicates supplementary information, remarks and tips.
Table 1: Notational conventions

7
2Procedure
VCAUTION!
●The actions described in this manual should only be performed by
engineers, service personnel or technical specialists.
●Equipment repairs should only be performed by qualified staff.
●Any failure to observe the guidelines in this manual, and any unautho-
rized opening or improper repairs could endager the user (through
electric shock, fire hazards) or damage the equipment.
●Please note that any unauthorized opening of the device will result in
the invalidation of the warranty and exclusion from all liability.
ÊFirst of all please familiarize yourself with the safety instructions in the
chapter “Important notes” on page 9ff.
ÊMake sure that all the manuals you need (see “Documentation overview” on
page 1) are available, printing out the PDF files if necessary.
You will definitely need the Operating Manual for the server.
ÊShut down the server correctly, switch it off, unplug all connectors, remove
the server from the rack and open the server as described in the chapter
“Preparation” on page 19ff.
ÊExtend or upgrade your server as described in the relevant chapter.
IThe installation and removal of the hot-plug components is described
in the Operating Manual supplied with the server.
ÊClose the server, connect all peripherals, plug in the power plugs, and switch
on the server as described in the chapter “Completion” on page 45ff.
ÊStart the operating system and, if necessary, configure it as required (see
the Operating Manual).

9
3 Important notes
This chapter provides safety instructions which you must observe when
handling your server.
3.1 Notes on safety
IThe following safety instructions can also be found in the manual entitled
“Safety”.
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office
environment.
If you have any questions as to whether you can set up the device in your
particular environment, please contact your sales outlet or our customer service
center.
VCAUTION!
The activities described in this manual may only be performed by
specialist technical personnel. Equipment repairs must only be
performed by qualified staff. Any unauthorized opening or improper
repairs could endanger the user (through electric shock, energy hazard,
fire hazard) or damage the equipment. Please note that any unautho-
rized opening of the device will result in the invalidation of the warranty
and exclusion from all liability.

10
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k03
Before setting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see
Operating Manual).
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Before operating the device, wait until it is absolutely dry and has
reached approximately the same temperature as the installation site.
Failure to observe these guidelines can lead to material damage of
the device.
●Transport the device only in its original packaging or in packaging
which protects it from knocks and jolts.
Installation and operation
VCAUTION!
●If the rack model is integrated in an installation that receives power
from an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial power supply networks for the
type A connector.
●The server automatically adjusts to a mains voltage range of 100 to
120 V and from 200 to 240 V. Make sure that the local mains voltage
is neither above nor below this range.
●This device has safety-tested power cables and must only be
connected to properly grounded power outlets.
●Make sure that the power sockets on the device or the grounded
mains outlets are freely accessible.
●The power switch does not disconnect the device from the mains
voltage. To completely disconnect it from the mains voltage, you must
remove the power plugs from the power outlets.

11
Important notes Notes on safety
VCAUTION!
●Always connect the device and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
a power outage occurs and the central processing unit is still running
but the peripheral device (e.g. a storage subsystem) has failed.
●Data cables must be adequately shielded to avoid interference.
●For the LAN wiring, the requirements according to standards EN
50173 and EN 50174-1/2 apply. The minimum requirement is the use
of a protected LAN line of category 5 for 10/100 Mbps Ethernet,
and/or of category 5e for Gigabit Ethernet. The requirements of the
specification ISO/IEC 11801 must also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the Operating Manual.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
●Be careful to ensure that no objects (e.g. jewelry, paper clips etc.) or
liquids get inside the device (electric shock, short circuit).
●In emergencies (e.g. damaged casing, control elements or cable,
penetration of liquids or foreign bodies), switch off the device immedi-
ately, unplug it from the grounded power outlet, and contact your
customer service center.
●Proper operation of the device (in accordance with IEC 60950-1/EN
60950-1) is only ensured if the casing is completely assembled and
the rear covers for the installation openings are in place (electric
shock, cooling, fire protection, interference suppression).

12
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k03
VCAUTION!
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
●If you install other extensions, you may damage the system or violate
these safety regulations.
●Information on which system extensions are suitable can be obtained
from the customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed, or exchanged by authorized, qualified
personnel.
Exception: You may exchange hot-plug power supply units.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
●You may only set the resolutions and refresh rates specified in the
Operating Manual for your monitor.
Otherwise, you may damage the monitor. If you are in any doubt,
contact your sales outlet or customer service center.
Batteries
VCAUTION!
●Incorrect replacement of batteries may lead to risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer.
●When replacing the lithium battery on the system board or on the
ServeRAID-8i adapter, always follow the instructions in the Service
Supplement.

13
Important notes Notes on safety
Notes on handling CDs/DVDs in CD/DVD drives
VCAUTION!
●To prevent data loss, damage to the device, or injuries, you should
use only CDs/DVDs in good condition in the CD/DVD drive of your
server.
●Therefore, check each CD/DVD for damage, cracks, breakage etc.
before inserting it in the drive.
Please note that any additional labels applied may change the
mechanical properties of a CD/DVD and cause imbalance.
Damaged and imbalanced CDs/DVDs can break at high drive speeds
(data loss).
Under certain conditions, sharp-edged pieces of broken CDs/DVDs
can penetrate the cover of the drive (cause damage to the device)
and be thrown out of the device (therefore causing injury to
uncovered body parts, particularly the face or neck).
ITo protect the CD/DVD drive and prevent mechanical damage as well as
premature wearing of the CDs/DVDs, you should observe the following
advice:
– Only insert the CDs/DVDs in the drive when needed and remove
them after use.
– Store the CDs/DVDs in suitable sleeves.
– Protect the CDs/DVDs from exposure to heat and direct sunlight.
Note on the laser
The CD/DVD drive is classified as Laser Class 1, according to IEC 60825-1.
VCAUTION!
The CD/DVD drive contains a light-emitting diode (LED) which may
generate a stronger laser beam than laser class 1. It is dangerous to look
directly into the beam.
Never remove any parts of the housing of the CD/DVD drive!

14
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k03
Components with electrostatic-sensitive devices:
Components with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, you must always observe the
following points:
●Pull out the power plugs before installing or uninstalling components.
●You must always discharge static build-up (e.g. by touching a grounded
object) before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Wear a suitable grounding cable that connects you to the external chassis of
the system unit.
●Always hold components with ESDs at the edges or at the points marked
green (touch points).
●Do not touch any connectors or conduction paths on an ESD.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1, ANSI/ESD
S20.20).

15
Important notes Environmental Protection
3.2 Environmental Protection
Environmentally Friendly Product Design and Development
This product has been designed in accordance with the Fujitsu Siemens
Computers standards for ”environmentally friendly product design and devel-
opment“. This means that the designers have taken into account important
criteria such as durability, selection of materials and coding, emissions,
packaging, the ease with which the product can be dismantled and the extent to
which it can be recycled.
This saves resources and thus reduces the harm done to the environment.
Notes on Saving Energy
Devices that do not have to be on permanently should not be switched on until
they need to be used and should be switched off during long breaks and on
completion of work
Notes on Dealing with Consumables
Please dispose of printer consumables and batteries in accordance with local
government regulations.
Do not throw batteries and accumulators into the household waste. They must
be disposed of in accordance with local regulations concerning special waste
(see also “Returning Batteries” on page 17).
Notes on Labeling Plastic Housing Parts
Please avoid attaching your own labels to plastic housing parts wherever
possible, since this makes it difficult to recycle them.

16
Environmental Protection Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX800S3\og_rx800s3_us\RX800S2uS3_og_us.k03
Returning Used Electrical and Electronic Devices in EU Countries
●Separate collection
Users of electrical and electronic devices are obligated to collect used
devices separately. Electrical (electronic) used devices may not be disposed
of together with unsorted household refuse. The separate collection is a
condition for reuse, recycling and utilisation of used electrical (electronic)
devices, which ensures the protection of resources.
●Return and collection systems
Electrical (electronic) used devices from private households can be returned
free of charge. To return your used device, please use the country-specific
return and collection systems available to you (see “Local Contacts” on
page 17).
The return of used devices which pose a health or safety risk for human
beings due to soiling during use may be refused.
●Reuse, recycling and utilisation
By actively using the offered return and collection systems, you make your
contribution to the reuse, recycling and utilisation of electrical (electronic)
devices.
●Effects on the environment and human health
Electrical (electronic) used devices contain parts which must be handled
selectively according to the EU directive. Separate collection and selective
treatment are the basis for environment-friendly disposal and the protection
of human health.
●Meaning of the symbol "Crossed out rubbish bin on wheels"
Electrical (electronic) devices which are marked with one of the following
symbols may not be disposed of with household refuse in accordance with
the EU directive.
Figure 2: Symbols for electrical (electronic) devices
