Fujitsu PRIMERGY TX300 S5 User manual

PRIMERGY TX300 S5
Options Guide
Edition July 2009

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
email: [email protected].
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4327-002.fm
Copyright © 2009 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability. The right to technical modification is reserved.
All hardware and software names used are trade names and/or trademarks of their respective
manufacturers.

TX300 S5 Options Guide
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 7
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 8
1.3 Expansions and conversions . . . . . . . . . . . . . . . . . . 9
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 13
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 17
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 23
4.1.2 Removing the front cover . . . . . . . . . . . . . . . . . . . . 24
4.1.3 Removing the server feet . . . . . . . . . . . . . . . . . . . . 28
4.2 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.2 Removing the rack front cover . . . . . . . . . . . . . . . . . . 32
4.3 Removing the fan bracket . . . . . . . . . . . . . . . . . . . 33
5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1.1 Independent Channel Mode / Performance Mode . . . . . . . . 36
5.1.2 Mirrored Channel Mode . . . . . . . . . . . . . . . . . . . . . 37
5.1.3 Spare Channel Mode . . . . . . . . . . . . . . . . . . . . . . 38
5.2 Extending/replacing the main memory . . . . . . . . . . . . 39

OptionsGuide TX300 S5
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4328-002.fm
6 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . . 41
6.1 Equipping of the bays . . . . . . . . . . . . . . . . . . . . . . 41
6.2 Accessible 5.25-inch drive . . . . . . . . . . . . . . . . . . . 43
6.2.1 Removing the dummy cover . . . . . . . . . . . . . . . . . . . 43
6.2.2 Installing an accessible 5.25-inch drive . . . . . . . . . . . . . . 45
6.3 Multibay 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.3.1 Equipping Multibay 1 . . . . . . . . . . . . . . . . . . . . . . . 47
6.3.1.1 Installing LSP or LSD . . . . . . . . . . . . . . . . . . . . . 47
6.3.1.2 Installing a DVD drive . . . . . . . . . . . . . . . . . . . . . 50
6.3.2 Installing Multibay 1 . . . . . . . . . . . . . . . . . . . . . . . . 54
6.4 HDD extension box . . . . . . . . . . . . . . . . . . . . . . . 58
6.4.1 Multibay 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
6.4.1.1 Installing Multibay 2 . . . . . . . . . . . . . . . . . . . . . . 60
6.4.2 2.5-inch HDD extension box . . . . . . . . . . . . . . . . . . . 61
6.4.2.1 Installing 2.5 inch HDD extension box . . . . . . . . . . . . . 62
7 Expansion cards . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.1 Installing an expansion card . . . . . . . . . . . . . . . . . . 66
8 Battery Backup Unit . . . . . . . . . . . . . . . . . . . . . . . 69
9 Trusted Platform Module (TPM) . . . . . . . . . . . . . . . . . 83
10 SAS/SATA RAID controller . . . . . . . . . . . . . . . . . . . 87
10.1 Inserting the RAID key . . . . . . . . . . . . . . . . . . . . . 87
11 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
11.1 Installing a second processor . . . . . . . . . . . . . . . . . 89
11.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . 95
11.3 Replacing the heat sink . . . . . . . . . . . . . . . . . . . . 100

TX300 S5 Options Guide
Contents
12 Conversion from a floorstand model to a rack model . . . . 101
12.1 Removing the right-hand side cover . . . . . . . . . . . . . 101
12.2 Removing the server feet . . . . . . . . . . . . . . . . . . . 102
12.3 Removing the foot mounting rail . . . . . . . . . . . . . . . 103
12.4 Accessible drives and operating panel module . . . . . . . 103
12.5 Installing the ID Card holder . . . . . . . . . . . . . . . . . . 105
12.5.1 Server with 3.5-inch hard disk drives . . . . . . . . . . . . . . 106
12.5.2 Server with 2.5-inch hard disk drives . . . . . . . . . . . . . . 114
12.6 Final steps . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
13 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
13.1 Installing the fan bracket . . . . . . . . . . . . . . . . . . . . 123
13.2 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 125
13.2.1 Mounting the server feet . . . . . . . . . . . . . . . . . . . . . 125
13.2.2 Attaching the front cover . . . . . . . . . . . . . . . . . . . . . 126
13.2.3 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 128
13.3 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
13.3.1 Attaching the rack front cover . . . . . . . . . . . . . . . . . . 130
13.3.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 131
14 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
14.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4328-002.fm

TX300 S5 Options Guide 7
1 Preface
With top dual processor performance, the PRIMERGY TX300 S5 tower server
is an all-purpose server for medium sized companies and branches of large
enterprises. The system is ideal for use as a versatile business server for
business critical applications and dedicated tasks. Thanks to internal SAS/SATA
hard disk capacity of up to 6 or 8 TB, the PRIMERGY TX300 S5 is also suitable
for use as a platform for highly data intensive solutions. Furthermore, it is the
ideal solution for smaller mySAP installations and directory or cache services in
medium sized and large companies.
The PRIMERGY TX300 S5 offers a balanced architecture that incorporates
next generation main memory (DDR3) and I/O technologies (PCIe Gen2). The
HDD backplane is already provided for SAS 2.0 and 6 Gbit/s SAS and the
chipset prepared for the next generation of 6-core processors. High
performance, scalability, impressive reliability and excellent extension options
are combined in a powerful design.
The Cool-safe™ cooling concept with improved air flow cooling technology
(comb design) ensures the highest possible performance of the processors at
work; at the same time, the system is extremely reliable thanks to the reduced
heat dissipation.
The new PRIMERGY TX300 S5 can also be converted quickly and easily into a
space-saving rack system that only takes up 4 height units (HU).
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.

8 OptionsGuide TX300 S5
Documentation overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4329-002.fm
1.2 Documentation overview
More information on your PRIMERGY TX300 S5 can be found in the following
documents:
– "Quick Start Hardware - PRIMERGY TX300 S5" leaflet (only included as a
printed copy)
– "Quick Start Software - Quick Installation Guide" DVD booklet (only included
with the PRIMERGY ServerView Suite as a printed copy)
– "Safety notes and other important information" manual
– "Warranty" manual
– "PRIMERGY ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual
– "Helpdesk" leaflet
– Technical manual for the system board D2619
– "PRIMERGY TX300 S5 Server Operating Manual"
– "PRIMERGY TX300 S5 Server Options Guide"
– "D2619 BIOS Setup Utility for PRIMERGY RX300 S5 and TX300 S5"
manual
IPRIMERGY manuals are available in PDF format on the PRIMERGY
ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is
part of the PRIMERGY ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289.
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL:
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.

TX300 S5 Options Guide 9
Preface Expansions and conversions
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the PRIMERGY
ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system
1.3 Expansions and conversions
Customer Self Service (CSS)
The Fujitsu Technology Solutions Customer Self Service (CSS) concept
enables you to identify and replace the affected component yourself in the case
of certain error scenarios.
In the CSS concept, you can replace the following components yourself in the
event of an error:
– Hot-plug hard disk drives
– Hot-plug power supply units
– Memory modules
– Hot-plug system fan
– Expansion cards
CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises (for more information on the
behavior of these indicators, see the operating manual and the "PRIMERGY
ServerView Suite Local Service Concept - LSC" manual on the PRIMERGY
ServerView Suite DVD 2).
You can also fit your server with a ServerView Local Service Panel, which
enables you to identify the type of component affected by the error directly on
the server (for more information, see the "PRIMERGY ServerView Suite Local
Service Concept - LSC" manual on the PRIMERGY ServerView Suite DVD 2).
In addition, CSS errors are displayed in the ServerView Operations Manager -
the server management software from Fujitsu Technology Solutions.

10 OptionsGuide TX300 S5
Expansions and conversions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4329-002.fm
In the event of errors, the ServerView Operations Manager refers you directly to
the affected component and its order information in the Illustrated Spares
catalog of the server in question.
Second processor
The system board can be upgraded with a second processor. Only processors
of the same type may be used on the system board. That means the number of
the internal processor cores as well as the primary clock and the FSB frequency
have to be the same. For dual operation, use a suitable multiprocessor
operating system.
Main memory expansion
The system board has 18 slots for memory modules. 9 memory slots can be
used in mono processor configurations.
ECC with memory scrubbing and the Single Device Data Correction (SDDC)
function is standard.
There are three modes of operation for the main memory:
– Independent Channel Mode / Performance Mode (recommended)
– Mirrored Channel Mode
– Spare Channel Mode
Depending on the mode of operation there are different population
requirements.

TX300 S5 Options Guide 11
Preface Expansions and conversions
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the BIOS system (for more information, refer to the
Fujitsu Technology Solutions BIOS manual).
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.
Additional accessible drives
The server has three 3.5-inch bays.
You can use these bays as follows:
– You can equip the individual bays with DVD drives or magnetic tape drives.
– You can install the Multibay 1 in the bottom bay. The Multibay 1 has bays for
a Slimline DVD drive and the ServerView Local Service Panel (LSP) or the
ServerView Local Service Display (LSD).
– In the two lower bays, you can install the Multibay 2. The Multibay 2 has bays
for two additional 3.5-inch hard disk drives, a Slimline DVD drive and the
ServerView Local Service Panel (LSP) or the ServerView Local Service
Display (LSD).
– You can install the Multibay 1 in the bottom bay (see above) and the
expansion box for 2.5-inch SAS hard disk drives in the two upper bays.

12 OptionsGuide TX300 S5
Expansions and conversions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4329-002.fm
Additional expansion cards in the PCI Express slots
The system board has seven PCI Express slots. Slots 1-5 are connected as x4
interfaces, whereby slots 3 and 5 are used as x8 interfaces if slots 2 and 4 are
empty. Slots 6 and 7 are connected as x8 interfaces.
ISlot 1 is the preferred slot for the SAS/SATA RAID controller (bootable).
Slots 5 and 7 allow the mechanical installation of x16 PCIe expansion
cards. The bus width is restricted to 8 lanes.
RAID key
The SATA SW RAID 5 functionality will be activated by installing a license key
(RAID key) on the SAS/SATA controller.
Battery Backup Unit
A Battery Backup Unit (BBU) backs up the memory contents of the SAS/SATA
RAID controller in the event of a power failure. One BBU can be installed for
each SAS/SATA RAID controller. A maximum of three BBUs can be installed for
each system.
Conversion from a floorstand model to a rack model
The floorstand model can be converted into a space-saving rack system that
only takes up 4 height units (HU). The server can thus be installed in any typical
rack systems.
ServerView Local Service Panel or Display
The system board supports the CSS (Customer Self Service) functionality (see
the operating manual and the "PRIMERGY ServerView Suite Local Service
Concept - LSC" manual). You can install a ServerView Local Service Panel
(LSP) or a ServerView Local Service Display (LSD) for an easier identification
of the defective components.

TX300 S5 Options Guide 13
Preface Notational conventions
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4329-002.fm

TX300 S5 Options Guide 15
2Procedure
VCAUTION!
●The actions described in this manual should only be performed by
technical specialists.
●Repairs to the device that do not relate to CSS failures must only be
carried out by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
IProcedures which are identical for the floorstand and rack models are
only described for the floorstand model.
ÊFirst of all, carefully read the safety instructions in the "Safety instructions"
on page 17.
ÊMake sure that all necessary manuals (see the section "Documentation
overview" on page 8) are available; print the PDF files if required. Most
importantly, you will need the operating manual for the server and the
technical manual for the system board.
ÊShut the server down correctly, switch it off, disconnect the power plugs and
open the server as described in the chapter "Preparation" on page 23.
ÊCarry out the expansion or upgrade of your server as described in the
pertinent chapter.
IInstallation and removal of the hot-plug components are described in
the operating manual.
ÊClose the server, connect it to the power outlet, and switch it on as described
in the chapter "Completion" on page 123.
ÊStart the operating system and make the appropriate configuration if
necessary (see the operating manual).

© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4330-002.fm

TX300 S5 Options Guide 17
3 Safety instructions
IThe following safety instructions are also provided in the manual "Safety
notes and other important information".
This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.
VCAUTION!
●The actions described in this manual should only be performed by
technical specialists.
●Repairs to the device that do not relate to CSS failures must only be
carried out by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.

18 OptionsGuide TX300 S5
Safety instructions
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4331-002.fm
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.
Installation and operation
VCAUTION!
●This unit should not be operated in ambient temperatures above
35 °C.
●If the unit is integrated into an installation that draws power from an
industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for non-
industrial power supply networks for type A connectors.
●The unit automatically adjusts itself to a mains voltage in a range of
100 V - 240 V. Ensure that the local mains voltage lies within these
limits.
●This device must only be connected to properly grounded shock-
proof sockets or insulated sockets of the rack's internal power supply
with tested and approved power cables.
●Ensure that the device is connected to a grounded shockproof socket
close to the device.

TX300 S5 Options Guide 19
Safety instructions
VCAUTION!
●Ensure that the power sockets on the device and the grounded
shockproof sockets are freely accessible.
●The On/Off button or the main power switch (if present) does not
isolate the device from the mains power supply. To disconnect it
completely from the mains power supply, unplug all network power
plugs from the grounded shockproof sockets.
●Always connect the server and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
the server is still running but a peripheral device (e.g. memory
subsystem) fails during a power outage.
●Data cables must be adequately shielded.
●The EN 50173 and EN 50174-1/2 standards apply for LAN cabling.
The minimum requirement is the use of a category 5 screened LAN
cable for 10/100 Mbit/s Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements from the ISO/IEC 11801 specification
must also be met.
●Route the cables in such a way that they do not create a potential
hazard (make sure no-one can trip over them) and that they cannot
be damaged. When connecting the server, refer to the relevant
instructions in this manual.
●Never connect or disconnect data transmission lines during a storm
(risk of lightning strike).
●Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids can
get inside the server (risk of electric shock, short circuit).
●In emergencies (e.g. damaged casing, controls or cables, penetration
of liquids or foreign bodies), switch off the server immediately, remove
all power plugs and contact your sales outlet or customer service
team.

20 OptionsGuide TX300 S5
Safety instructions
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\JESUS\OBJ_DOKU-4331-002.fm
VCAUTION!
●Proper operation of the system (in accordance with IEC 60950-1/
EN 60950-1) is only ensured if the casing is completely assembled
and the rear covers for the installation slots have been fitted (electric
shock, cooling, fire protection, interference suppression).
●Only install system expansions that satisfy the requirements and
rules governing safety and electromagnetic compatibility and those
relating to telecommunication terminals. If you install other
expansions, they may damage the system or violate the safety
regulations. Information on which system expansions are approved
for installation can be obtained from our customer service center or
your sales outlet.
●The components marked with a warning notice (e.g. lightning symbol)
may only be opened, removed or exchanged by authorized, qualified
personnel. Exception: CCS components can be replaced.
●The warranty is void if the server is damaged during installation or
replacement of system expansions.
●Only set screen resolutions and refresh rates that are specified in the
operating manual for the monitor. Otherwise, you may damage your
monitor. If you are in any doubt, contact your sales outlet or customer
service center.
Batteries
VCAUTION!
●Incorrect replacement of batteries may result in a risk of explosion.
The batteries may only be replaced with identical batteries or with a
type recommended by the manufacturer (see the technical manual for
the system board).
●Replace the lithium-battery on the system board in accordance with
the instructions in the technical manual for the system board.
