Fujitsu ETERNUS AF250 S2 Technical manual

FUJITSU Storage
ETERNUS AF250 S2,
ETERNUS AF250
All-Flash Arrays
Site Planning Guide
Requirements for transportation/installation
P3AG-1812-06ENZ0

Table of Contents
1. ETERNUS AF Installation 7
Installation Specifications............................................................................................................... 7
ETERNUS AF250 S2..................................................................................................................................................7
ETERNUS AF250.......................................................................................................................................................9
Storage System Dimensions.......................................................................................................... 11
Compliance Standards .................................................................................................................. 13
Package Size ................................................................................................................................. 14
Installation Area ........................................................................................................................... 15
Installation Environment .............................................................................................................. 16
Installation of the ETERNUS AF in High Altitude Locations ....................................................................................16
Air Conditioning ....................................................................................................................................................16
Installation Methods.............................................................................................................................................17
Load Bearing Capacity for Floors ...........................................................................................................................17
Outlet/Socket Specifications.......................................................................................................... 17
Specifications for Optional Power Supply Products ................................................................................................18
Required Number of Outlets/Sockets.....................................................................................................................23
Circuit Protectors ...................................................................................................................................................23
Input Power Supply Lines ......................................................................................................................................28
2. Rack Installation Specifications 31
Rack Installation Requirements .................................................................................................... 31
Placement in the Rack ..........................................................................................................................................31
Cable Connection ..................................................................................................................................................32
Installable Racks........................................................................................................................... 35
Fujitsu Racks .........................................................................................................................................................35
Non-Fujitsu Racks .................................................................................................................................................35
2
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

List of Figures
Figure 1 Controller Enclosure Dimensions..............................................................................................................11
Figure 2 Drive Enclosure Dimensions .....................................................................................................................12
Figure 3 Installation Area and Service Area............................................................................................................15
Figure 4 Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets) ..........................................................20
Figure 5 Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet)..........................................................20
Figure 6 Power Distribution Units (2U) ..................................................................................................................21
Figure 7 Power Distribution Units (2U) ..................................................................................................................22
Figure 8 Breaking Characteristics of Distribution Board Circuit Protectors ..............................................................24
Figure 9 Example of a Power Supply Connection When a Power Distribution Unit (1U) Is Used .............................25
Figure 10 Example of a Power Supply Connection When a Power Distribution Unit (2U) Is Used .............................26
Figure 11 Example of a Power Supply Connection When a Power Distribution Unit Is Not Used...............................28
Figure 12 Dual-Line Power Supply (When Connecting to Power Sockets).................................................................28
Figure 13 Dual-Line Power Supply (When Connecting to a UPS Unit).......................................................................29
Figure 14 Single-Line Power Supply (When Connecting to Power Sockets) ..............................................................29
Figure 15 Single-Line Power Supply (When Connecting to a UPS Unit) ....................................................................29
Figure 16 Single-Line Power Supply (When Connecting to a Power Socket and a UPS Unit).....................................29
Figure 17 Distance between Each Enclosure and the Power Distribution Unit (Example) ........................................32
Figure 18 AC Cable Connection.................................................................................................................................33
Figure 19 Unit Installation Area ...............................................................................................................................36
3
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

List of Tables
Table 1 ETERNUS AF250 S2 Installation Specifications............................................................................................7
Table 2 Efficiency and Power Factor of the Power Supply Unit (ETERNUS AF250 S2)...............................................8
Table 3 ETERNUS AF250 Installation Specifications.................................................................................................9
Table 4 Package Size (for Regions other than the EMEIA, Central American, and Caribbean Regions) .................14
Table 5 Current Consumption of Each Power Cord.................................................................................................17
Table 6 Specifications for AC200V Power Cords (for the EMEIA, Central American, and Caribbean Regions) .........18
Table 7 Specifications for AC200V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)..........................................................................................................................................18
Table 8 Specifications for AC125V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)..........................................................................................................................................19
Table 9 Specifications for AC100V and AC200V Power Cords (for Regions other than the EMEIA, Central American,
and Caribbean Regions)...........................................................................................................................19
Table 10 Specifications for Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets)...............................20
Table 11 Specifications for Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet) ..............................20
Table 12 Power Distribution Unit (AC200-240V, 2U, 12 Outlets) Specifications ......................................................21
Table 13 Power Distribution Unit (AC200-240V, 2U, 16 Outlets) Specifications ......................................................21
Table 14 Power Distribution Unit (AC16A/200-240V, 2U, 16 Outlets) Specifications ...............................................22
Table 15 Power Distribution Unit (AC24A/200-240V, 2U, 16 Outlets) Specifications ...............................................22
Table 16 Required Conditions for Distribution Board Circuit Protectors...................................................................23
Table 17 Enclosure Installation Order .....................................................................................................................31
Table 18 Cable Lengths When Connecting Each Enclosure to the Power Distribution Unit......................................32
Table 19 Usage of Cables for Connecting Enclosures...............................................................................................34
Table 20 Specifications for the Unit Installation Area .............................................................................................36
4
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Preface
Fujitsu would like to thank you for purchasing the FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 (herein-
after referred to as ETERNUS AF).
The ETERNUS AF is designed to be connected to Fujitsu servers (Fujitsu SPARC Servers, PRIMEQUEST, PRIMERGY,
and other servers) or non-Fujitsu servers.
This manual describes the environmental requirements that are necessary to install and use the ETERNUS AF.
This manual is intended for use of the ETERNUS AF in regions other than Japan.
Please carefully review the information outlined in this manual.
Sixth Edition
June 2021
Trademarks
Third-party trademark information related to this product is available at:
https://www.fujitsu.com/global/products/computing/storage/eternus/trademarks.html
About This Manual
Intended Audience
This manual is intended for managers of facilities where the ETERNUS AF is installed.
Related Information and Documents
The latest version of this manual and the latest information for your model are available at:
https://www.fujitsu.com/global/support/products/computing/storage/manuals-list.html
Document Conventions
■Third-Party Product Names
•Oracle Solaris may be referred to as "Solaris", "Solaris Operating System", or "Solaris OS".
•Microsoft® Windows Server® may be referred to as "Windows Server".
■Notice Symbols
The following notice symbols are used in this manual:
Indicates information that you need to observe when using the ETERNUS storage system.
Make sure to read the information.
Indicates information and suggestions that supplement the descriptions included in this
manual.
5
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Warning Signs
Warning signs are shown throughout this manual in order to prevent injury to the user and/or material damage.
These signs are composed of a symbol and a message describing the recommended level of caution. The follow-
ing explains the symbol, its level of caution, and its meaning as used in this manual.
This symbol indicates the possibility of serious or fatal injury if the ETERNUS AF is not used
properly.
This symbol indicates the possibility of minor or moderate personal injury, as well as dam-
age to the ETERNUS AF and/or to other users and their property, if the ETERNUS AF is not
used properly.
This symbol indicates IMPORTANT information for the user to note when using the ETERNUS
AF.
The following symbols are used to indicate the type of warnings or cautions being described.
The triangle emphasizes the urgency of the WARNING and CAUTION contents. Inside the
triangle and above it are details concerning the symbol (e.g. Electrical Shock).
The barred "Do Not..." circle warns against certain actions. The action which must be
avoided is both illustrated inside the barred circle and written above it (e.g. No Disassem-
bly).
The black "Must Do..." circle indicates actions that must be taken. The required action is
both illustrated inside the black disk and written above it (e.g. Unplug).
How Warnings are Presented in This Manual
A message is written beside the symbol indicating the caution level. This message is marked with a vertical rib-
bon in the left margin, to distinguish this warning from ordinary descriptions.
A display example is shown here.
Warning level indicator
Warning type indicator
Warning details
•To avoid damaging the ETERNUS storage system, pay attention to the
following points when cleaning the ETERNUS storage system:
Warning layout ribbon
Example warning
- Make sure to disconnect the power when cleaning.
- Be careful that no liquid seeps into the ETERNUS storage system
when using cleaners, etc.
- Do not use alcohol or other solvents to clean the ETERNUS storage system.
CAUTION Do
Preface
6
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

1. ETERNUS AF Installation
This chapter provides the installation specification of the ETERNUS AF.
Installation Specifications
ETERNUS AF250 S2
Table 1 shows the installation specifications of the ETERNUS AF250 S2 and Table 2 shows the efficiency and the
power factor of the power supply unit.
Table 1 ETERNUS AF250 S2 Installation Specifications
Item ETERNUS AF250 S2
Dimensions
(W ´ D ´ H)
Controller enclosure 482 ´ 645 ´ 88mm (2U)
Drive enclosure 482 ´ 540 ´ 88mm (2U)
Power distribution unit
(*1)
1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight (*7) Controller enclosure 35kg
Drive enclosure 35kg
Power distribution unit
(*1)
1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power con-
sumption (*7)
Controller enclosure AC 100 – 120V 850W (860VA)
AC 200 – 240V 850W (860VA)
Drive enclosure AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
Maximum heat genera-
tion (*7)
Controller enclosure AC 100 – 120V 3,100kJ/h
AC 200 – 240V 3,100kJ/h
Drive enclosure AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
Maximum amount of ex-
haust air
Controller enclosure 4.0m3/min
Drive enclosure 4.0m3/min
7
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Item ETERNUS AF250 S2
Environmental conditions Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less, NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the ETERNUS AF is installed on the ocean or
premises within 0.5km from the coast, neces-
sary measures must be taken to prevent salt
corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission (*8) Sound pressure level 47dB (A)
Sound power level 6.5B
*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 18).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each enclosure when 24 drives are installed.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
Table 2 Efficiency and Power Factor of the Power Supply Unit (ETERNUS AF250 S2)
Component name 80PLUS®Efficiency Power fac-
tor Output
20% (*1) 50% (*1) 100% (*1) 50% (*1)
Controller enclosure GOLD (*2) 89.3% 92.5% 90.2% 0.975 Multiple output
Drive enclosure 89.3% 92.5% 90.2% 0.975
*1: Indicates the rated load against the rated output of the PSU.
1. ETERNUS AF Installation
Installation Specifications
8
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

*2: 80PLUS® GOLD certified power supply units are used. 80PLUS® is a power saving program for electrical
equipment promoted by the 80PLUS® program.
ETERNUS AF250
The following table shows the installation specifications of the ETERNUS AF250.
Table 3 ETERNUS AF250 Installation Specifications
Item ETERNUS AF250
Dimensions
(W ´ D ´ H)
Controller enclosure 482 ´ 645 ´ 88mm (2U)
Drive enclosure 482 ´ 540 ´ 88mm (2U)
Power distribution unit
(*1)
1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight (*7) Controller enclosure 35kg
Drive enclosure 35kg
Power distribution unit
(*1)
1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power con-
sumption (*7)
Controller enclosure AC 100 – 120V 810W (820VA)
AC 200 – 240V 810W (820VA)
Drive enclosure AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
Maximum heat genera-
tion (*7)
Controller enclosure AC 100 – 120V 3,000kJ/h
AC 200 – 240V 3,000kJ/h
Drive enclosure AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
Maximum amount of ex-
haust air
Controller enclosure 4.0m3/min
Drive enclosure 4.0m3/min
1. ETERNUS AF Installation
Installation Specifications
9
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Item ETERNUS AF250
Environmental conditions Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less, NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the ETERNUS AF is installed on the ocean or
premises within 0.5km from the coast, neces-
sary measures must be taken to prevent salt
corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission (*8) Sound pressure level 47dB (A)
Sound power level 6.5B
*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 18).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each enclosure when 24 drives are installed.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
1. ETERNUS AF Installation
Installation Specifications
10
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Storage System Dimensions
■Controller Enclosure Dimensions
The following diagrams show the dimensions of a controller enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 1 Controller Enclosure Dimensions
645mm88mm
482mm
Top
Front
Side
1. ETERNUS AF Installation
Storage System Dimensions
11
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

■Drive Enclosure Dimensions
The diagrams below show the dimensions of a drive enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 2 Drive Enclosure Dimensions
540mm
88mm
482mm
Top
Front
Side
1. ETERNUS AF Installation
Storage System Dimensions
12
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Compliance Standards
●About Compliance Standards
•Product safety
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
IEC 60950-1:2005, 2nd Edition + A1:2009 + A2:2013
ANSI/UL 60950-1:2014
CAN/CSA-C22.2 No 60950-1-07, + A1:2011 + A2:2014
CNS 14336-1:2010
IS 13252(Part 1):2010
TP TC 004/2011
•CE marking
2014/35/EU, Low Voltage Directive
2014/30/EU, Electromagnetic Compatibility Directive
2009/125/EC, Regulation (EU) 019/424 Erp Directive (*1)
2011/65/EU, (EU) 2015/863 as amended, Restriction of Hazardous Substances (RoHS) Directive
•Electromagnetic Compatibility (EMC)
EN 55032 Class A
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3:2013
FCC Part-15 Subpart B Class A
ICES-003 Class A
VCCI Class A
JIS C 61000-3-2
CNS 13438:2006
AS/NZS CISPR 32 Class A 2015
TP TC 020/2011
KN32 Class A
KN35
•Environmental compliance
2011/65/EU, (EU) 2015/863 as amended, Restriction of Hazardous Substances (RoHS) Directive
WEEE-compliant (waste electrical and electronic equipment)
•Power conversion efficiency
80PLUS® GOLD
*1: The target ETERNUS AF is the ETERNUS AF250 S2.
1. ETERNUS AF Installation
Compliance Standards
13
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Package Size
The ETERNUS AF is shipped in cardboard boxes. These boxes may not fit through some doorways or elevators. To
make sure that the ETERNUS AF can be moved to the installation site, carefully check the transport route infor-
mation.
The following table shows the package size and the maximum package weight of each component for regions
other than the EMEIA, Central American, and Caribbean regions.
Table 4 Package Size (for Regions other than the EMEIA, Central American, and Caribbean Regions)
Component Package size (W ´ D ´ H) Maximum weight
Controller enclosure 600 ´ 760 ´ 240mm Approximately 40kg
Drive enclosure 600 ´ 660 ´ 240mm Approximately 40kg
Drive (*1) 160 ´ 278 ´ 106mm Approximately 0.5kg
Power distribution unit (*2) 1U 570 ´ 710 ´ 160mm (*3),
540 ´ 380 ´ 310mm (*4)
Approximately 4kg (*3),
Approximately 5kg (*4)
2U (390 ´ 590 ´ 180mm) ´ 2
(*5),
(540 ´ 380 ´ 310mm) ´ 2 (*6)
(Approximately 7kg) ´ 2 (*5),
(Approximately 10kg) ´ 2 (*6)
*1: When an order for optional drives to be installed in the factory is placed, enclosures are shipped with the
drives preinstalled.
When optional drives are ordered without preinstallation, each drive is shipped in an individual package.
*2: For power distribution units, there are multiple types of exteriors.
*3: These values are for product ID ETFP4BU-L.
*4: These values are for product ID ETFP4DU-L.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
1. ETERNUS AF Installation
Package Size
14
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Installation Area
This section explains the installation areas and the service areas that are required for an ETERNUS AF that is
installed in a Fujitsu 19-inch rack.
Secure service areas that are 850mm or more in the front and rear of the ETERNUS AF.
Figure 3 Installation Area and Service Area
850mm or more
850mm or more
ETERNUS AF
Rear service area
Front service area
1. ETERNUS AF Installation
Installation Area
15
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Installation Environment
Sufficient consideration of the installation environment should be taken to ensure proper use of the ETERNUS
AF. Using the ETERNUS AF in an environment that does not satisfy the installation environment requirements
may cause a failure to occur with the ETERNUS AF.
Installation of the ETERNUS AF in High Altitude Locations
When the ETERNUS AF is used at high altitudes (1,800m or higher above sea level), "Highland Mode" must be
enabled. When "Highland Mode" is enabled, the fans rotate at high speed to maintain the cooling effect of the
fans.
•To set "Highland Mode", perform the subsystem parameter settings for each ETERNUS AF. The Maintenance
Operation policy is required to perform this setting.
•The "Highland Mode" setting cannot be changed during a host access.
•After the setting is changed, the ETERNUS AF needs to be turned off and on again.
Air Conditioning
It is important to consider the flows of cooling air (intake air and exhaust air) for the installation location of the
ETERNUS AF. The temperature in some ETERNUS AF storage systems may rise by taking in air exhausted from
other storage systems depending on how they are installed near each other. In addition, check if the ambient
temperature in the installation location always satisfies the usage environment temperature by taking into con-
sideration the room size, whether other storage systems are installed, and how many people are present in the
room.
When installing air conditioning, consider the following:
●Ambient Temperature
An ETERNUS AF is cooled by taking in air through the front intakes and pushing out the exhaust air through the
rear of the ETERNUS AF. If the intake air temperature does not meet the ambient environment conditions, a
temperature error occurs and the power of the ETERNUS AF is shut down.
•Front intake air temperature
Make sure that the front intake air temperature is between 10 and 40°C.
•Rear exhaust air temperature
For example, when the intake air temperature is 40°C, the exhaust air temperature is 50°C or higher.
The necessary cooling capacity of air conditioning must be determined by taking the exhaust air cooling into
consideration.
Estimate the amount of heat in the exhaust air from the ETERNUS AF by using the heat generation amount
and exhaust air amount that are listed in "Installation Specifications" (page 7).
1. ETERNUS AF Installation
Installation Environment
16
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Installation Methods
•Perform one of the following rack installation methods to ensure the safe use of an ETERNUS AF that is instal-
led in a rack:
-To secure a rack, use a rack without stabilizers and secure it to the building with the leveling feet.
-If a rack is not to be secured, make sure to use a rack with stabilizers and use these stabilizers to prevent the
rack from toppling over.
•Which installation method should be used depends on the installation location, the floor conditions, and the
type of racks that are to be used. Contact your installation contractor for more details regarding installation
and how the installation should actually be performed.
Load Bearing Capacity for Floors
Make sure that the following relationship between the load bearing capacity of the floor and the weight of the
ETERNUS AF is maintained.
(Load bearing capacity of the floor) > (ETERNUS AF weight ¸ Installation area that includes service areas)
If the condition above is not satisfied, additional measures are required to ensure sufficient load bearing capaci-
ty.
Contact your installation contractor for details about the necessary measures that must be taken.
Outlet/Socket Specifications
This section explains the power connection specifications of the ETERNUS AF storage systems.
■Power Supply Units
Power can be supplied from two power sources in the ETERNUS AF because each enclosure has two power supply
units.
During normal operation, each of the power sources supplies half of the necessary power.
When one of the power supply lines fails, all of the necessary power is supplied from only one power source.
Using the same power supply condition for all of the power supply units is recommended so that different power
supply conditions (input voltage) are not used for the ETERNUS AF.
■Current Consumption
The following table shows the current consumption (guideline) of each power cord that is used for the connec-
tions to each type of enclosure.
Table 5 Current Consumption of Each Power Cord
Component name Voltage
AC100V AC200V
Controller enclosure 8.2A 4.1A
Drive enclosure 4.4A 2.2A
When using power distribution units, make sure that the current capacity totaling the current consumption val-
ue of power cords that connect to the enclosures does not exceed the actual usage rating of the power distribu-
tion unit.
1. ETERNUS AF Installation
Outlet/Socket Specifications
17
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

Specifications for Optional Power Supply Products
This section explains the specifications of optional power cords and power related optional products.
For power distribution units, the number of outlets that are required to connect the controller enclosure and
drive enclosures should be taken into consideration, and the most appropriate power distribution units should
then be selected.
When an existing power socket is used, make sure that the plug type of the power distribution unit fits the exist-
ing power socket and that the power supply facility is able to provide sufficient power to the system. If the plug
type does not fit the power socket, electrical work to change the power socket is required. This electrical work
must be performed in compliance with the electrical codes of the nation, the municipality, or the region.
■AC200V Power Cords (for the EMEIA, Central American, and Caribbean Regions)
AC200V power cords are used to connect devices to the IEC60320 C13 power socket type. These power cords can
be used if the specifications of the connection device allow AC200V.
Table 6 Specifications for AC200V Power Cords (for the EMEIA, Central American, and Caribbean Regions)
Usage Plug type Socket type
(Socket) Cable length Voltage rating/current
rating
Used for connection be-
tween the ETERNUS AF
and the socket
(IEC60320 C13 n
IEC60320 C14G)
IEC60320 C14G IEC60320 C13 1.5m 250V 10A
■AC200V Power Cords (for Regions other than the EMEIA, Central American, and Caribbean
Regions)
AC200V power cords are used to connect devices to the NEMA L6-15R power socket type. These power cords can
be used if the specifications of the connection device allow AC200V.
Table 7 Specifications for AC200V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)
Usage Plug type Socket type
(Socket) Cable length Voltage rating/current
rating
Used for connection be-
tween the ETERNUS AF
and the socket
(IEC60320 C13 n NEMA
L6-15P)
NEMA L6-15P NEMA L6-15R 4.0m Rating: 250V 10A
(Normal usage rating:
8A)
1. ETERNUS AF Installation
Outlet/Socket Specifications
18
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

■AC125V Power Cords (for Regions other than the EMEIA, Central American, and Caribbean
Regions)
AC125V power cords are used to connect devices to the NEMA 5-15R power socket type. These power cords can
be used if the specifications of the connection device allow AC100V.
Table 8 Specifications for AC125V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)
Usage Plug type Socket type
(Socket) Cable length Voltage rating/current
rating
Used for connection be-
tween the ETERNUS AF
and the socket
(IEC60320 C13 n NEMA
5-15P)
NEMA 5-15P NEMA 5-15R 3.0m Rating: 125V 13A
(Normal usage rating:
10A)
■AC100V and AC200V Power Cords (for Regions other than the EMEIA, Central American, and
Caribbean Regions)
AC100V/200V power cords are used to connect devices to the IEC60320 C13 power socket type. These power
cords can be used to connect devices with the AC100V and AC200V specifications.
Table 9 Specifications for AC100V and AC200V Power Cords (for Regions other than the EMEIA, Central American,
and Caribbean Regions)
Usage Plug type Socket type
(Socket) Cable length Voltage rating/current
rating
Used for connection be-
tween the ETERNUS AF
and the socket
(IEC60320 C13 n
IEC60320 C14)
IEC60320 C14 IEC60320 C13 0.5m
1.0m
1.5m
3.0m
Rating: 250V 10A
(Normal usage rating:
8A)
1. ETERNUS AF Installation
Outlet/Socket Specifications
19
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0

■Power Distribution Units (1U) (Only for Regions other than the EMEIA, Central American,
and Caribbean Regions)
Two types (Figure 4 and Figure 5) of 1U power distribution units with different specifications are provided.
•Power distribution unit (AC8A/200-240V, 1U, 4 outlets, 2 inlets)
There are four outlets and two inlets.
Figure 4 Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets)
Two inlets
Four outlets
Table 10 Specifications for Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets)
Outlet Inlet
Voltage rating/current
rating
Socket type
(Socket) Plug type Socket type
(Socket) Cable length
IEC60320 C13 NEMA L6-15P NEMA L6-15R 4.0m Rating: 250V 10A
(Normal usage rating:
8A)
•Power distribution unit (AC24A/200-240V, 1U, 4 outlets, 1 inlet)
There are four outlets and one inlet.
Figure 5 Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet)
One inlet
Four outlets
Table 11 Specifications for Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet)
Outlet Inlet
Voltage rating/current
rating
Socket type
(Socket) Plug type Socket type
(Socket) Cable length
IEC60320 C13 NEMA L6-30P NEMA L6-30R 4.4m Rating: 250V 30A
(Normal usage rating:
24A)
1. ETERNUS AF Installation
Outlet/Socket Specifications
20
FUJITSU Storage ETERNUS AF250 S2, ETERNUS AF250 All-Flash Arrays Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AG-1812-06ENZ0
