Fujitsu STYLISTIC Q704 User manual

System
Operating Manual
FUJITSU Tablet STYLISTIC Q704

Contact address in North America
FUJITSU AMERICA INC:
1250 East Arques Avenue Sunnyvale
CA 94085-3470, U.S.A.
Telephone: [phone] or 408 746 6000
"http://solutions.us.fujitsu.com"
"http://solutions.us.fujitsu.com/contact"
Have a question? Email us at: "AskFujits[email protected]jitsu.com"
Copyright
©2015 Fujitsu America, Inc. All rights reserved.
B5FK-2461-03ENZ0

FUJITSU Tablet STYLISTIC Q704
Operating Manual
Fujitsu Contact Information 7
Notational conventions 8
Ports and controls 9
Important notes 12
First-time setup of your device 17
WorkingwiththeTabletPC 21
Accessories for your Tablet PC
(optional) 43
Security functions 61
Connecting external devices 68
Settings in BIOS Setup Utility 72
Troubleshooting and tips 75
Technical data 82
Manufacturer’s notes 88
Appendix 94
Index 109

Copyright and Trademark Information
Fujitsu America, Incorporated has made every effort to ensure the accuracy and completeness
of this document; however, as ongoing development efforts are continually improving the
capabilities of our products, we cannot guarantee the accuracy of the contents of this
document. We disclaim liability for errors, omissions, or future changes.
Fujitsu, the Fujitsu logo and STYLISTIC are registered trademarks of Fujitsu Limited
or its subsidiaries in the United States and other countries.
Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or
its subsidiaries in the United States and other countries.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
The ExpressCard word mark and logo are owned by the Personal Computer
Memory Card International Association (PCMCIA) and any use of such marks by
Fujitsu America, Incorporated is under license.
Google is a trademark or registered trademark of Google Incorporated.
Bluetooth is a trademark of Bluetooth SIG, Inc., USA.
OmniPass is a trademark of Softex, Inc.
Roxio is a trademark of Roxio, a division of Sonic Solutions.
PowerDirector, PowerDVD, YouCam, and MakeDisc are trademarks of CyberLink Corp.
Adobe, Acrobat, and Adobe Reader are either a reg istered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
Made under license from DTS Licensing Limited. DTS and the symbol are registered trademarks and
& DTS Boost is a trademark of DTS, Inc. Product contains software. © DTS, Inc. All rights reserved.
The DVD player found in some models of the LIFEBOOK notebook incorporates copyright
protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights users. Use
of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
All other trademarks specified here are the property of their respective owners.

Contents
Contents
FujitsuContact Information ............................................................ 7
Notationalconventions ................................................................ 8
Portsandcontrols ..................................................................... 9
Important notes ........................................................................ 12
Safetyinstructions ...................................................................... 12
Additional safety notes for devices with wireless components . . ............................. 13
Protecting the display screen ............................................................ 13
Energysaving .......................................................................... 13
Energy saving under Windows ....................................................... 13
Traveling with your Tablet PC ............................................................ 13
Before youtravel ................................................................... 14
Transporting the Tablet PC ........................................................... 15
Storing your TabletPC .................................................................. 15
Cleaning the TabletPC .................................................................. 16
First-timesetup ofyour device ......................................................... 17
Unpacking and checking the device . . . ................................................... 17
Choose a location . ...................................................................... 18
Connecting the AC adapter . . . ........................................................... 18
Switching on the device for the firsttime .................................................. 19
Installing Bonus Apps . . . . . ........................................................... 20
Working with theTablet PC ............................................................ 21
Status indicators ........................................................................ 21
Switching theTabletPC on .............................................................. 22
Programing the ON/OFF button ...................................................... 22
Switching theTabletPC off .............................................................. 23
Handwriting recognition .................................................................. 23
Touchscreen ............................................................................ 24
Select display orientation (portraitorlandscapeformat) .................................... 25
Using fingers ........................................................................... 25
Calibrate the Dual Digitizer for finger-based operation of the device. ..................... 25
Actions with one finger (Windows 8.1 Pro) . ............................................ 26
Actions with one finger (Windows 7 / Windows 8.1 Desktop) . . . ......................... 28
Actions with two fingers (Windows 7 / Windows 8.1 Desktop) . . ......................... 29
Using thestylus ......................................................................... 31
Stylus location ...................................................................... 32
Adjustingthestylus .................................................................. 32
Calibratingthestylus ................................................................ 33
Installingastylus tether .............................................................. 33
Tabletbuttons .......................................................................... 34
Webcam ............................................................................... 34
Rechargeable battery ................................................................... 35
Charging andmaintainingthebattery ................................................. 35
Using the energy saving functions . ....................................................... 36
Memory cards .......................................................................... 37
Supportedformats .................................................................. 37
Insertingthememory card ........................................................... 37
Removingthe memory card .......................................................... 38
Fujitsu 3

Contents
SIM card ............................................................................... 39
Inserting aSIM card ................................................................. 39
Removing a SIM card ............................................................... 40
Wireless LAN/Bluetooth/4G/NFC wireless components . . . .................................. 40
Switching the wireless components on and off ......................................... 40
Furtherinformation on WLANand Bluetooth ........................................... 41
Accessvia WirelessWAN ............................................................ 41
NFC ............................................................................... 41
Ethernet and LAN (only with performance docking cradle or keyboard docking station) . . . . .... 41
GPS ................................................................................... 42
Accessories for your Tablet PC (optional) . ............................................. 43
Your performance docking cradle (optional) . . ............................................. 44
Cradle components . . ................................................................ 44
Setting up thecradle ................................................................ 45
Connecting the Tablet PC to the cradle . . ............................................. 45
Disconnecting the Tablet PC from the cradle . ......................................... 47
Keyboard cover (optional) . . . ............................................................ 48
Keyboard cover components . ........................................................ 48
Connecting the Tablet PC to the keyboard cover . . . . . .................................. 49
Separating the Tablet PC from the keyboard cover . . .................................. 50
Keyboard docking station (optional) . . . . . . ................................................. 51
Ports on the keyboard docking station . . . ............................................. 51
Connecting the Tablet PC to the keyboard docking station .............................. 53
Separating the Tablet PC from the keyboard docking station . . .......................... 54
VESA mounting attachment (optional) . . . ................................................. 55
Hand strap (optional) . . . . ................................................................ 56
Shoulder strap (optional) ................................................................ 57
Folio case (optional) . . . . . ................................................................ 58
MicroUSB adapters ..................................................................... 59
Security functions ..................................................................... 61
Configuring the fingerprint sensor ........................................................ 62
Configuringpasswordprotectionin BIOSSetupUtility ...................................... 63
Protecting BIOS Setup Utility (supervisor HDD password and user HDD password) . . . .... 63
Password protection for booting the operating system .................................. 64
Passwordprotectionfor the harddisk ................................................. 65
Smart Card reader (optional) . ............................................................ 66
Inserting theSmartCard ............................................................. 66
Trusted Platform Module - TPM (device dependent) . . . . . . .................................. 67
Enabling TPM ....................................................................... 67
Disabling TPM ...................................................................... 67
Connecting externaldevices ........................................................... 68
Connecting an external monitor . . ........................................................ 69
HDMI port(onlyperformancedocking cradle andkeyboarddocking station) .............. 69
External monitor port (VGA) (only performance docking cradle and keyboard docking
station) ............................................................................. 69
Connecting USB devices ................................................................ 70
How toremove USBdevicescorrectly ................................................ 70
Headphones port ....................................................................... 71
Settings in BIOS Setup Utility . . ........................................................ 72
Starting theBIOS Setup Utility ........................................................... 72
4Fujitsu

Contents
BIOS Setup Utilityoperation ............................................................. 73
Exiting BIOSSetup Utility ................................................................ 74
Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 74
Exit Discarding Changes - Reject changes and exit BIOS Setup Utility . . . . . .............. 74
Load Setup Defaults – load default values . ............................................ 74
Discard Changes - Discard Changes without exiting BIOS Setup Utility . . . . .............. 74
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 74
Save changesand poweroff ........................................................ 74
Troubleshooting andtips .............................................................. 75
Help ifproblems occur ................................................................... 75
Recoveringyour FactoryImage ...................................................... 75
The Tablet PC’sdate ortime isincorrect .................................................. 76
Battery indicator does not illuminate . . . ................................................... 76
The Tablet PC’stouchscreen remains dark ................................................ 76
The display on the Tablet PC’s touchscreen is difficult to read. . ............................. 76
The externalmonitorremains blank ...................................................... 77
The externalmonitoris blank orthe imageis unstable ..................................... 77
The cursor does not correctly follow the stylus movements . . . . ............................. 77
Stylusinputnot working ................................................................. 78
The Tablet PCdoesnotstartafterswitchon ............................................... 78
The Tablet PCstops working ............................................................. 78
The printer does not print . . . . . ........................................................... 79
The wireless connection to a network does not work . . . .................................... 79
The battery discharges tooquickly ........................................................ 79
Smart Card reader is not recognized . . . ................................................... 80
Acoustic warning ........................................................................ 80
Errormessageson thescreen ........................................................... 80
Technicaldata ......................................................................... 82
Tablet PC .............................................................................. 82
WLAN specifications .................................................................... 84
Rechargeablebattery ................................................................... 84
AC adapter (65 W) ...................................................................... 85
Performance docking cradle (optional) . ................................................... 85
Keyboard cover(optional) ............................................................... 86
Keyboard docking station (optional) ....................................................... 86
VESA mounting attachment (optional) . ................................................... 87
Hand strap (optional) . . .................................................................. 87
Shoulder strap (optional) . . . . . ........................................................... 87
Micro USB adapters (optional) ........................................................... 87
Manufacturer’snotes .................................................................. 88
Disposal andrecycling .................................................................. 88
Recycling your battery ............................................................... 88
DOC (IndustryCANADA)Notices ........................................................ 88
UL Notice ........................................................................... 89
ENERGY STARCompliance ............................................................. 90
Declarationsof Conformity ............................................................... 90
FCC andICRegulatoryInformation ...................................................... 90
Regulatory Notes and Statements . ................................................... 91
Appendix .............................................................................. 94
Before Using the Optional Wireless LAN . . . . . . ............................................ 94
Fujitsu 5

Contents
Wireless LANDevicesCoveredby this Document ...................................... 94
CharacteristicsoftheWLAN Device .................................................. 94
Wireless LAN Modes Using this Device . . ............................................. 95
Deactivating/DisconnectingtheWLAN Device ......................................... 96
Configuringthe WirelessLAN ............................................................ 97
Connection to the network . . . ........................................................ 97
Troubleshooting the WLAN ........................................................... 98
Image Backup and Recovery Procedures ................................................. 100
Creating a Backup ofBootable Diskand RecoveryImage .............................. 100
RECOVERYOUR SYSTEMWHENTHE HARDDRIVE ISSTILLACCESSIBLE ............. 101
Usingthe Recovery andUtility Tools .................................................. 101
Restore the Recovery Image from Hidden Partition . . . .................................. 103
RECOVERYOUR SYSTEMWHENTHE HARDDRIVE ISNOT BOOTABLE ................ 104
RestoretheRecoveryImagefor FullHardDrive ....................................... 104
Recovering Your Recovery Image Using Recovery and Utility (for new hard drive or
non-bootableharddrive) ............................................................. 105
Installingthe Softwareafterthe RecoveryImage isRestored ............................ 106
Index .................................................................................. 109
6Fujitsu

Fujitsu Contact Information
Fujitsu Contact Information
Service and Support
You can contact Fujitsu Service and Support in the following ways:
• Toll free phone: 1-800-Fujitsu (1-800-838-5487)
• Website: "http://solutions.us.fujitsu.com/www/content/support/contact/index.php"
Before you place the call, you should have the following information ready so that the
customer support representative can provide you with the fastest possible solution:
• Product name
• Product configuration number
• Product serial number
• Purchase date
• Conditions under which the problem occurred
• Any error messages that have occurred
• Type of device connected, if any
Fujitsu Shopping Online
Please go to "http://www.shopfujitsu.com/store/ ".
Maintaining Latest Configuration
To ensure that you always have the most current driver updates related to your system, you should
occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is
available from the Fujitsu Support site. FSDM will allow you to view a list of the most current
drivers, utilities, and applications to determine whether you have the latest versions. If you have a
Windows 7 or Windows 8/8.1 operating system, you will need to go to the Support Site to download
the FSDM Utility: "http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS".
Limited Warranty
Your LIFEBOOK notebook is backed by a Fujitsu International Limited Warranty. Check the service
kit that came with your notebook for the Limited Warranty period and terms and conditions.
Fujitsu 7

Notational conventions
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device, or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed.
Indicates a result.
This font Indicates data entered using the keyboard in a program dialog or at the
command line, e.g. your password (Name123)oracommandusedtostart
a program (start.exe)
This font Indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font Indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programsorfiles, e.g. Windows or setup.exe.
"This font" Indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://solutions.us.fujitsu.com/"
• names of CDs, DVDs and titles or designations for other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety/Regulations" manual
Key Indicates a key on the keyboard, e.g: F10 .
This font Indicates terms and texts that are emphasized or highlighted, e.g.: Do
not switch off the device.
8Fujitsu

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives an
overview of the indicators and connections of the device. Please familiarize yourself
with these items before you start to work with the device.
Front
1
23
5
6
4
7
56
7
8
8
1 = Touchscreen
2 = Webcam
3 = Webcam LED
4 = Ambient light sensor
5 = Speaker
6 = Mechanical mounting for keyboard docking
station / keyboard cover / cradle
7 = Docking port
8 = Air inlet
Fujitsu 9

Ports and controls
Left-hand side
1 2 3 4 5 6 7
1 = DC jack (DC IN, protected by cover)
2 = ON/OFF button
3 = Increase volume button
4 = Decrease volume button
5 = Shortcut button
6 = Power-on indicator
7 = Battery charging indicator
Right-hand side
12 34 567
1=SIM
card slot (format: micro SIM,
protected by cover)
2 = Storage card slot (format: micro SD,
protected by cover)
3=M
icro USB port (protected by cover)
4=USB
port (USB 3.0, protected by cover)
5 = Headphones port
6=St
ylus holder
7 = Eyelet for stylus cord
10 Fujitsu

Ports and controls
Back (2 variants: standard shell and smart card shell)
432
1
6
5
5
5
5
432
1
7
7
1 = Fingerprint sensor
2 = Camera light
3 = Webcam
4 = Webcam LED
5 = Screw holes (device-dependent) for
securing accessories
6 = Smart Card reader (device dependent)
7 = NFC (Near Field Communication)
(device-dependent)
Fujitsu 11

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed when working
with your Tablet PC. The other notes provide useful information about your Tablet PC.
Safety instructions
SafetyinformationInform ation,
Please follow the safety notes provided in the "Safety/Regulations" manual
as well as the safety notes given below.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in the "Technical data", Page 82 chapter
and the information in the "First-time setup of your device", Page 17 chapter before
preparing your Tablet PC for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the section .
Pay attention to the additional safety notes for devices with wireless components
provided in the "Safety/Regulations" manual.
When handling this device, you come into contact with lead, a chemical which in
California is held to be a possible cause of birth defects and other damage to fertility.
Wash your hands after using the device.
This Tablet PC complies with the relevant safety regulations for data processing equipment. If
you have questions as to whether you can set up the Tablet PC in the intended environment,
please contact your sales outlet or our hotline/service desk.
12 Fujitsu

Important notes
Additional safety notes for devices with
wireless components
wirelesscomponentsWirelessLANBluetooth,Safetynotes
If a wireless component (Wireless LAN, Bluetooth, 4G) is integrated in your Tablet PC, you must
be sure to observe the following safety precautions when using your Tablet PC:
• Switch off the wireless components when you are in an aircraft or driving in a car.
• Switch off the wireless components when you are in a hospital, an operating
room or near a medical electronics system. The transmitted radio waves
can impair the operation of medical devices.
• Switch off the wireless components, when you let the device get near flammable
gases or into hazardous environments (e.g. gas station, paint stores), as the
transmitted radio waves can cause an explosion or a fire.
For further information on how to switch the wireless components on and off,
refer to "Switching the wireless components on and off", Page 40.
Protecting the display screen
Depending on your device configuration, where applicable your device is not waterproof.
In this event, do not pour liquids onto the device and do not wash it with a wet cloth.
Do not place items on the top of the display, or damage may occur.
During normal use of the device, small particles from the environment
can become embedded in the stylus tip and scratch the screen. The
warranty does not cover a scratched screen.
Energy saving
NotesEnergyEnergysaving
If you will not be using your Tablet PC, switch it off. Switch off any connected external devices when
they are not in use. If you use the energy-saving functions, the Tablet PC uses less power. If you do
this, you will be able to work longer with the Tablet PC before having to recharge the battery.
The energy efficiency is increased and environmental pollution is reduced.
You save money and help protect the environment.
Energy saving under Windows
►Make use of the available energy saving functions as described in chapter
"Using the energy saving functions", Page 36.
Traveling with your Tablet PC
MobileoperationNotesTrans portTabletPC
Please follow the instructions below when traveling with your Tablet PC.
Fujitsu 13

Important notes
Before you travel
►Back up important data stored on your hard disk.
NotebookTraveling,notebook
►Switch off the wireless component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorized third parties to receive data.
Information on activating data encryption is provided in the documentation
for your wireless component.
►If you want to use your Tablet PC during a flight, ask the flight attendants to see it is safe to use it.
When traveling in other countries
►If you are traveling abroad, check that the AC adapter can be operated with the
local AC voltage. If this is not the case, obtain the appropriate AC adapter for
your Tablet PC. Do not use any other voltage converter!
►Check whether the local AC voltage and the AC cable are compatible. If this is not
the case, buy an AC cable that suits the local conditions.
►Enquire with the appropriate government office of the country you will be traveling in as to
whether you may there operate the wireless component integrated in your Tablet PC.
►Take the necessary travel adapters with you when traveling abroad. Check in the following
table for which travel adapters you will need, or ask your travel organizer.
Power connection Travel destination
United States, Canada, Mexico, parts of Latin
America, Japan, Korea, Philippines, Taiwan
Russia and the Commonwealth of Independent
States (CIS), much of Europe, parts of Latin
America, the Middle East, parts of Africa, Hong
Kong, India, much of south-east Asia
United Kingdom, Ireland, Malaya, Singapore,
parts of Africa
China, Australia, New Zealand
14 Fujitsu

Important notes
Transporting the Tablet PC
Protect the Tablet PC from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
• Do not transport your Tablet PC while it is turned on.
• Carry your Tablet PC with you while traveling, rather than checking it in as baggage.
• Never put your Tablet PC through a metal detector; have it hand-inspected by
security personnel. You can however, put your Tablet PC through a properly
tuned X-ray machine. To avoid problems, place it close to the entrance of
the machine and remove it as soon as possible or have it hand-inspected
by security personnel. Security officials may require you to turn your Tablet
PC on, so make sure you have a charged battery on hand.
►Switch the Tablet PC off.
►Unplug the AC plug of the AC adapter and all external devices from the power outlets.
►Disconnect the AC adapter cable and the data cables for all external devices.
►To protect against damaging jolts and bumps, use a suitable Tablet PC
carrying case to transport your Tablet PC.
Storing your Tablet PC
• If storing your Tablet PC for a month or longer, turn it off, fully charge the battery,
then remove and store all Lithium Polymer batteries.
• Store your Tablet PC in a cool, dry location. Temperatures should remain
between 13ºF / -25ºC and 140ºF / 60ºC.
• Store your Tablet PC and batteries separately. If you store your Tablet PC with
a battery installed, the battery will discharge, and battery life will be reduced. In
addition, a faulty battery might damage your Tablet PC.
• Always power off the Tablet PC before transporting and/or packaging it.
After shutting down the Tablet PC, wait until the status led panel indicates
power off condition (i.e., no lights are illuminated).
• It is possible that the Tablet PC may not automatically go to power-off or hibernate
mode when you close the lid. This situation may occur due to pre-operating system
boot password security settings or some other application running on the Tablet PC.
• Attempting to transport the Tablet PC while power is on may damage
the Tablet PC due to shock or overheating.
Fujitsu 15

Important notes
Cleaning the Tablet PC
• Use of incorrect cleaners can result in optical impairment of the LCD and / or
damage to the computer. Always refer to the cleaner manufacturer’s guidelines and
material safety data sheets fo proper handling and use of the products.
• Never use ammonia, acidic, or alkaline cleaners or organic chemicals
such as paint thinner, acetone or kerosene. It may damage surface
finishes and the coating of the LCD screen.
• Never use compressed air for cleaning your computer.
• If your Tablet PC has a Smart Card slot, be very careful to avoid any
liquid entering the slot as this can damage the unit.
Cleaning guidelines using recommended off-the-shelf cleaners: Computer exterior
To clean the exterior, use one of the following off-the-shelf products:
•Office Depot® #154-616 b Cleaning Kit
• Meridrew Enterprises Klear Screen® Wipes
• 3M CL563 Cleaner Wipes
After cleaning with one of these products, gently polish with a dry, soft,
lint-free cloth until the solution is no longer visible.
Disinfecting STYLISTIC computers
Wipe the surface with a soft cloth wipe and a 50% ethanol solution or use another ethanol-based
germicide which has been registered as a hospital disinfectant by the EPA.
16 Fujitsu

First-time setup of your device
First-time setup of your device
First- timese tupGettingstarted
Please read the chapter "Important notes", Page 12.
If your device is equipped with a Windows operating system, the necessary
hardware drivers and supplied software are already pre-installed.
Before switching it on for the first time, connect the device to the AC voltage using
the AC adapter, see "Connecting the AC adapter", Page 18. The AC adapter must
remain connected during the whole of the installation process.
A system test is performed when your device is first switched on. Various messages
can appear. The display may remain dark for a short time or may flicker.
Please follow the instructions on the screen.
NEVER switch off your device during the first-time setup process.
The battery must be charged if you want to operate your device using the battery.
When used on the move, the built-in battery provides the device with the necessary power. You
can increase the operating time by using the available energy-saving functions.
For instructions on how to connect external devices (e.g. mouse, printer) to your Tablet
PC, please refer to the operating manual for your device.
Unpacking and checking the device
If you find that damage has occurred during transport, please notify
your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTransport
►Check your device for any visible damage which may have occurred during transportation.
You may need to reuse the packaging in future, for example if you
need to transport your device.
Fujitsu 17

First-time setup of your device
Choose a location
ChoosealocationSetupACadapter
Choose a suitable location for the device before setting it up. In doing
so, please follow these instructions:
• Never place the device or the AC adapter on a heat-sensitive surface.
The surface could be damaged as a result.
• Never place the device on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can result in damage caused by overheating.
• The underside of the device heats up during normal operation. Prolonged
contact with skin can become unpleasant or even result in burns.
• Place the device on a stable, flat, non-slippery surface. Please note that the
rubber feet of the device may mark certain types of delicate surfaces.
• Keep other objects at least 100 mm / 4 inches away from the device
and its AC adapter to ensure adequate ventilation.
• Do not expose the device to extreme environmental conditions. Protect
the device against dust, humidity and heat.
Connecting the AC adapter
MakingreadytouseACadapter
Observe the safety notes in the enclosed "Safety/Regulations" manual.
ThesuppliedACc
able conforms to the requirements of the country in which
you purchased your device. Make sure that the AC cable is approved for
use in the country in which you intend to use it.
2
►Open the cover of the DC jack
socket (DC IN).
►Connect the AC cable (1) to the AC adapter.
►Plug the AC cable (2) into a power outlet.
►Connect the AC adapter cable (3) to the
DC jack socket (DC IN) of the device.
18 Fujitsu
