Fujitsu Tablet DOCK ST5100 Series Use and care manual

Stylistic®ST5100 Series
Tablet PC
(Windows Vista OS)
Technical
Reference
Guide

Copyright and Trademark Information
Fujitsu Computer Systems Corporation has made every effort to
ensure the accuracy and completeness of this document. Because
ongoing development efforts are made to continually improve
the capabilities of our products, however, the data contained
herein represents Fujitsu design objectives and is provided for
comparative purposes; actual results may vary based on a variety
of factors. This product data does not constitute a warranty.
Specifications are subject to change without knowledge.
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu
Limited. Stylistic is a registered trademark of Fujitsu Computer
Systems Corporation.
Softex and OmniPass are trademarks or registered trademarks of
Softex, Inc.
PCMCIA and CardBus are registered trademarks of the Personal
Computer Memory Card International Association.
Intel and Core are trademarks or registered trademarks of Intel
Corporation.
Microsoft, Windows, and Windows Vista are trademarks or
registered trademarks of Microsoft Corporation.
All other products are trademarks or registered trademarks of
their respective companies.
Copyright 2007 - Fujitsu Computer Systems Corporation. All
rights reserved. No part of this publication may be copied,
reproduced, or translated, without the prior written consent of
Fujitsu Computer Systems Corporation. No part of this
publication may be stored or transmitted in any electronic form
without the prior consent of Fujitsu Computer Systems
Corporation.
FPC58-1696-01
For more detailed information about the FCC rules and their applicability to the Stylistic ST5100 Series Tablet PC, refer to
“Agency Notices” on page 68 of this document.
Warning
Handling the cord on this product will expose you to
lead, a chemical known to the State of California to
cause birth defects or other reproductive harm.
Wash hands after handling.
DECLARATION OF CONFORMITY
according to FCC Part 15
Responsible Party Name: Fujitsu Computer Systems Corporation
Address: 1250 E. Arques Avenue, Sunnyvale, CA 94085
Telephone: [phone]
Declares that product: Model: Stylistic ST5100 Series Tablet PC
Complies with Part 15 of the FCC Rules
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and, (2) This device must accept any interference received, including interference that may
cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS
■This unit requires an AC adapter to operate. Use only UL
Listed Class 2 Adapters with an output rating of 16 VDC, with
a current of 3.75A minimum.
AC Adapter output polarity:
■When using your notebook equipment, basic safety precau-
tions should always be followed to reduce the risk of fire, elec-
tric shock and injury to persons, including the following:
■Do not use this product near water for example, near a
bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
■Avoid using the modem during an electrical storm. There
may be a remote risk of electric shock from lightning.
■Do not use the modem to report a gas leak in the vicinity of
the leak.
■Use only the power cord and batteries indicated in this
manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal
instructions.
■To reduce the risk of fire, use only No. 26 AWG or larger UL
Listed or CSA Certified Telecommunication Line Cord
■For TV Tuner Models: To protect from overvoltages and tran-
sients on the Cable Distribution System, make sure that the
outer shield of the coaxial cable is connected to earth
(grounded) at the building premises as close to the point of
cable entrance as practicable, as required per NEC Article
820.93, ANSI/NFPA 70: 2005. If you have questions about
your CATV installation, contact your service provider.
SAVE THESE INSTRUCTIONS
For Authorized Repair Technicians Only
System Disposal
+
Danger of explosion if Lithium (clock) battery is
incorrectly replaced. Replace only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries according
to the manufacturer’s instruction.
For continued protection against risk of fire,
replace only with the same type and rating fuse.
Hg
LAMP(S) INSIDE THIS PRODUCT
CONTAIN MERCURY AND MUST
BE RECYCLED OR DISPOSED OF
ACCORDING TO LOCAL, STATE, OR
FEDERAL LAWS.

Table of Contents
Copyright and Trademark Information ......................................................................................... 2
About This Guide .............................................................................................................................. 1
Organization....................................................................................................................................................... 1
Related Documentation...................................................................................................................................... 2
Chapter 1
Stylistic ST5100 Tablet PC Features ............................................................................................... 3
Hardware Features............................................................................................................................................. 3
PC Card Support.................................................................................................................................... 3
Internal Modem...................................................................................................................................... 3
Internal LAN.......................................................................................................................................... 3
ACPI Support......................................................................................................................................... 4
DMI Support.......................................................................................................................................... 4
USB 2.0 Support.................................................................................................................................... 4
Smart Card Support ............................................................................................................................... 4
SD Card/Memory Stick Support............................................................................................................ 4
Infrared Support..................................................................................................................................... 4
IEEE 1394 Support................................................................................................................................ 4
Software Features .............................................................................................................................................. 4
Supported Operating Systems................................................................................................................ 4
Pen Support............................................................................................................................................ 5
Fujitsu Menu.......................................................................................................................................... 5
Chapter 2
Configuring the Stylistic ST5100 Tablet PC BIOS ........................................................................ 6
Permanent and Current BIOS Settings .............................................................................................................. 6
BIOS Setup Utility............................................................................................................................................. 6
Starting BIOS Setup............................................................................................................................... 6
Using BIOS Setup.................................................................................................................................. 7
Exiting BIOS Setup ............................................................................................................................... 8
BIOS Setup Main Menu Options........................................................................................................... 9
Drive0 Submenu Options....................................................................................................................... 10
Advanced Menu Options....................................................................................................................... 11
IrDA Port Configuration Submenu Options.......................................................................................... 12
Keyboard Features Submenu Options ................................................................................................... 13
Video Submenu Options........................................................................................................................ 14
Internal Device Configurations Submenu.............................................................................................. 15
CPU Features Submenu......................................................................................................................... 16
USB Features Submenu......................................................................................................................... 18
Miscellaneous Configurations Submenu............................................................................................... 19
Event Logging Submenu ....................................................................................................................... 20
Security Menu Options.......................................................................................................................... 21
Hard Disk Security Submenu ................................................................................................................ 23
Owner Information Submenu ................................................................................................................ 24
Security Chip Setting Submenu............................................................................................................. 25
Boot Menu Options................................................................................................................................ 26
Boot Device Priority Submenu.............................................................................................................. 27
Info Menu .............................................................................................................................................. 28
Exit Menu Options................................................................................................................................. 29

Chapter 3
Hardware Specifications .................................................................................................................. 30
General Specifications....................................................................................................................................... 30
Digitizer Specifications...................................................................................................................................... 31
External Video Capabilities............................................................................................................................... 31
Display Specifications ....................................................................................................................................... 32
Environmental Specifications............................................................................................................................ 32
Peripheral Interface Specifications.................................................................................................................... 33
Physical Specifications ...................................................................................................................................... 33
Power System Specifications............................................................................................................................. 34
Internal Modem Specifications.......................................................................................................................... 35
Internal LAN Specifications.............................................................................................................................. 35
Agency Approval Specifications ....................................................................................................................... 36
Tablet Dock Specifications................................................................................................................................ 36
Chapter 4
Peripheral Interfaces ........................................................................................................................ 37
DC Power Input ................................................................................................................................................ 37
Universal Serial Bus Port................................................................................................................................... 38
IrDA Port ........................................................................................................................................................... 38
Tablet Dock Interface Port................................................................................................................................. 39
Audio Jacks........................................................................................................................................................ 43
PC Card Port...................................................................................................................................................... 44
Hard Drive Port.................................................................................................................................................. 46
RJ-45 LAN Port................................................................................................................................................. 47
IEEE 1394 Port.................................................................................................................................................. 47
Chapter 5
System Power .................................................................................................................................... 49
System Power Hardware.................................................................................................................................... 49
Battery Pack........................................................................................................................................... 49
DC Power Inputs.................................................................................................................................... 50
Chapter 6
Installing Hardware Options ........................................................................................................... 51
Installing/Removing a DIMM Module.............................................................................................................. 51
Installing a Memory Module ................................................................................................................. 51
Removing a Memory Module................................................................................................................ 52
Replacing/Installing a Wireless LAN Module.................................................................................................. 53
Removing a Wireless LAN Module ...................................................................................................... 53
Installing a Wireless LAN Module....................................................................................................... 54
Replacing the IDE Hard Drive........................................................................................................................... 54
Removing the Hard Drive...................................................................................................................... 54
Installing the Hard Drive ....................................................................................................................... 54
AT Command Set ............................................................................................................................. 55
AT Commands Table......................................................................................................................................... 56
AT Data Commands .............................................................................................................................. 56
AT Fax (Class1) Commands.................................................................................................................. 61
V.25ter AT Commands.......................................................................................................................... 62
S Register Table................................................................................................................................................. 63
Result Codes Summary...................................................................................................................................... 66
Agency Notices .................................................................................................................................. 68
Wireless LAN Agency Notices.......................................................................................................................... 70

1
About This Guide
This guide provides technical information on the Fujitsu Stylistic ST5100 Tablet PC for technicians, hardware
developers, and software developers.
Organization 0
This guide is organized as follows:
•Chapter 1: Tablet PC Features
This chapter discusses some of the system’s main features and technology.
•Chapter 2: Configuring the Stylistic ST5100 Tablet PC BIOS
This chapter provides details on using BIOS Setup Utility for the Stylistic ST5100 Tablet PC. BIOS configuration
options are explained in detail.
•Chapter 3: Hardware Specifications
This chapter gives hardware specifications on the Tablet PC system. Industry standards supported by the Stylistic
ST5100 Tablet PC are listed.
•Chapter 4: Peripheral Interfaces
This chapter provides details on peripheral interfaces provided by the Stylistic ST5100 Tablet PC and the Stylistic
ST5100 Tablet Dock.
•Chapter 5: System Power
This chapter provides information on the Tablet PC’s system power hardware.
•Chapter 6: Installing Hardware Options
This chapter gives detailed instructions on installing hardware options such as PCMCIA, DIMM, and WLAN
cards, as well as the IDE Hard Drive.
•Appendix A: AT Command Set
This appendix provides a detailed list of AT commands used by the Tablet PC’s modem, including AT
Commands, S Register Table, and Result Codes Summary information.
•Appendix B: Agency Notices
This appendix states notices required by regulatory agencies in the United States and Canada that apply to the
Stylistic ST5100.

Related Documentation 2
Related Documentation 0
Documentation relating to the Stylistic ST5100 Tablet PC is listed below. Refer to these documents for details on
topics not covered in this guide.
Stylistic ST5100 User’s Guide
This guide provides an introduction to the Stylistic ST5100 Tablet PC’s basic functions for the end user.
Stylistic ST5100 Tablet Dock User’s Guide
This guide gives instructions on using the Stylistic ST5100 Tablet Dock.
The following resources contain information on software development tools for Windows:
Microsoft Developer’s Network
The Microsoft Developer’s Network web site provides links to information on application programming
interfaces (APIs) used with Microsoft Windows. The site address is <MSDN.Microsoft.com>.
The following documents provide information on industry standards supported by the Stylistic ST5100 Tablet PC.
Advanced Configuration and Power Interface (ACPI) Specification
The ACPI specification was developed by Microsoft, Intel, and Toshiba to manage device control in order to
conserve power. The specification and additional detailed information is available at the ACPI web site,
<www.acpi.info>.
PC Card Standards
The Stylistic ST5100 Tablet PC and supporting system software comply with PCMCIA and PC Card standards
specifications up to and including the PC Card Standard February 1995 (also referred to as PC Card Standard
Release 3.0 in this document and other related documentation). PC Card standards are published by: Personal
Computer Memory Card International Association, 2635 North First Street, Suite 209, San Jose, CA 95134,
<http://www.pcmcia.org/>, (408) 433-CARD (2273).
IrDA Standards
The IrDA port on the Stylistic ST5100 Tablet PC is compliant with IrDA (Infrared Data Association) Standard
Version 1.1 published by: Infrared Data Association, <http://www.irda.org>.
Universal Serial Bus Specification
The Universal Serial Bus (USB) ports on the Stylistic ST5100 Tablet PC and docking peripherals are compliant
with the Universal Serial Bus Specification Version 2.0. Refer to this specification for USB details including: cable
requirements, topology, and USB power distribution. This specification and other technical documents regarding
USB are available on the Universal Serial Bus Implementer’s Forum home page at <http://www.usb.org/>.

3
Chapter 1
Stylistic ST5100 Tablet PC Features
This chapter provides an introduction to the Stylistic ST5100 Tablet PC system hardware and software and gives an
overview of some of the Tablet PC’s features. Detailed specifications on the features discussed in this chapter are
given in other chapters of this guide.
This model of the Stylistic ST5100 computer is designed for the Microsoft Windows Vista. The system uses an active
digitizer and conforms to the Windows Tablet PC standards.
The Stylistic ST5100 Tablet PC system has been tested by Windows Hardware Quality Labs (WHQL) at Microsoft
Corporation and is compliant with PC2001 system design guidelines.
Hardware Features 1
PC Card Support 1
The Stylistic ST5100 Tablet PC is equipped with a PC Card slot that allows you to install a Type I or II PC Card. The
PC Card slot is compliant with PC CardBus Standard Release 3.0 and provides support for the following PC Card
features:
• Multivoltage 3.3/5 V PC Cards (detected automatically)
• CardBus (PCI bridge) type PC Cards
• Supports PCIC (PC Card I/O Card) protocol
• Backward compatibility with previous PC Card Standard Release level PC Cards
Among the types of PC Cards supported by this slot are:
• Wireless LAN cards
• Bluetooth cards
• ISDN cards
• Communications cards
• LAN cards
• SCSI cards
Internal Modem 1
The Stylistic ST5100 Tablet PCs are equipped with an internal 56 Kbps* modem.
* The 56 Kbps rate is nominal; due to FCC restrictions, actual rates are limited to 53 Kbps.
For details on the built-in modem, see “Internal Modem Specifications” on page 35.
Internal LAN 1
The Stylistic ST5100 Tablet PCs are equipped with an internal wired 10/100/1000* Base-T/Tx Ethernet LAN.
*1000 Mbps, commonly referred to as Gigabit Ethernet.
The first time you initialize your Windows Vista system, the screen will be blank for approximately
two minutes. This is normal. After initialization, a “Set Up Windows” dialog box will appear.
Important: During the setup procedure, do not disconnect the power supply, press any buttons, or use
any peripheral devices such as a mouse, keyboard, or remote control.

Software Features 4
ACPI Support 1
The Stylistic ST5100 Tablet PC supports the Advanced Configuration and Power Interface (ACPI) Specification in all
system configurations. With ACPI, power management features are controlled and configured primarily by the BIOS
and BIOS settings. The ACPI specifications allow for additional control over power management features such as
state transitions and device timeouts. Refer to the ACPI specifications and the documentation for your operating
system regarding power management with ACPI.
DMI Support 1
The Stylistic ST5100 supports the Desktop Management Interface (DMI). DMI provides a framework for managing
the variety of components within the Tablet PC. The Event Logging menu in the BIOS allows you to configure the
DMI event logging options (see “Event Logging Submenu” on page 20).
USB 2.0 Support 1
The Universal Serial Bus (USB) 2.0 design is the primary interface for your tablet PC. The Stylistic ST5100 USB ports
are compliant with Universal Serial Bus Specification 2.0, and are backward-compatible with USB 1.1 devices. For
more information on the USB interface, refer to “Universal Serial Bus Port” on page 38.
Smart Card Support 1
The dedicated Smart Card slot allows you to insert a Smart Card, on which you can store information such as
medical records or electronic “cash”.
SD Card/Memory Stick Support 1
The Secure Digital (SD)/Memory Stick (MS) card slot allows you to install a flash memory card for data storage.
Infrared Support 1
There are three infrared ports on your Stylistic ST5100 Tablet PC, two infrared keyboard/mouse ports and an IrDA/
FIR port. The keyboard/mouse ports are used for receiving communications from an infrared keyboard or mouse.
(Note that the infrared keyboard/mouse ports are receive-only, one-direction serial ports.) The IrDA/FIR port is
used for communications compliant with IrDA Standard Revision 1.1.
IEEE 1394 Support 1
The Institute of Electrical and Electronics Engineers, Inc. (IEEE) standard 1394 architecture supports a fast external
bus that allows transfer rates of up to 400 Mbps. IEEE 1394 (also known as “Firewire” or “iLink” by other vendors)
allows connection of the tablet PC with peripherals such as digital video cameras, providing for fast transfer of the
large files. For more information on the IEEE 1394 port, refer to “IEEE 1394 Port” on page 47.
Software Features 1
Supported Operating Systems 1
The Stylistic ST5100 Tablet PC is distributed with Microsoft Windows Vista Business pre-installed.
Licensing and user documentation for the operating system installed on your system is also included with the Tablet
PC. For details on the operating system, refer to the documentation provided, or refer to the documents listed in
“Related Documentation” in the About This Manual section of this guide.

Software Features 5
Pen Support 1
The Stylistic ST5100 Tablet PC has an active digitizer and employs the Microsoft Windows Vista Business as its
operating system. As such, the on-screen keyboard, handwriting recognition, and pen utilities are part of the Tablet
PC operating system.
There are three ways to access the pen utilities:
• Position the pen over the “Tablet PC Input Panel” on your desktop. It is located along the edge of the screen, and
looks like a tab. When you touch it with the pen, it opens slightly more to reveal a tablet and pen icon. When you
click on that icon, the input panel opens fully. When the pad is open, click on Tools for a full menu of utilities, or,
• Select Start -> Control Panel -> Mobile PC -> Pen and Input Devices or,
• Click on the Fujitsu Menu icon in the system tray (or press the [Fn] button twice in quick succession), and select
Tablet PC Input Panel from the menu.When the panel is open, click on Tools for a full menu of utilities.
To display the on-screen keyboard:
• Click the Tablet PC Input Panel icon located on the edge of the screen, then click the keyboard icon, or,
• Click on the Fujitsu Menu icon in the system tray (or press the [Fn] button twice in quick succession), and select
Tablet PC Input Panelfrom the menu, then click the keyboard icon.
Fujitsu Menu 1
The Fujitsu Menu provides a handy list of shortcuts to commonly-used utilities. To open the Fujitsu Menu, click on
the Fujitsu Menu icon in the system tray at the bottom right of the screen or press the [Fn] button twice in quick
succession.
The following utilities can be accessed directly from the Fujitsu Menu:
• Control Panel
• Tablet PC Input Panel
• Tablet PC Settings
• Fujitsu Tablet Controls
• Sound
• Capture Screen
• Capture Window
• Organize Favorites
• Power Options
•Printers
• LCD Brightness Min.
• LCD Brightness Max.
• Enable/Disable Button Panel
• Windows Mobility Center
• Fujitsu Menu Settings
Any of these utilities can be added or deleted from the Fujitsu Menu by clicking on the Fujitsu Menu Settings button
and checking or unchecking the utility then applying your changes. Additionally, any new applications can be added
to the menu by clicking Fujitsu Menu Settings -> [Add], then browsing to the application you want to add.

Permanent and Current BIOS Settings 6
Chapter 2
Configuring the Stylistic ST5100 Tablet PC BIOS
This chapter provides instructions on how to use the Setup Utility to configure the Stylistic ST5100 Tablet PC BIOS.
Permanent and Current BIOS Settings 2
Some BIOS configuration utilities allow you to select permanent and/or current settings when configuring BIOS options.
When you change a permanent setting, BIOS parameters stored in CMOS memory are changed and the new setting is
applied after the system is restarted. When you change a current setting, BIOS parameters stored in dynamic memory are
changed and the new setting is applied for the current session.
BIOS data resides in the system’s CMOS memory. When the system is powered on, BIOS data is copied or “shadowed”
into the system’s dynamic memory and the system runs using BIOS parameters stored in dynamic memory.
BIOS Setup Utility 2
The BIOS Setup Utility is a configuration utility that you can use to change your system’s permanent BIOS settings. The
BIOS Setup Utility application is stored in the BIOS flash ROM. (BIOS Setup values or settings are stored in CMOS
memory.) Instructions for starting and running BIOS Setup are given in the following discussions.
Starting BIOS Setup 2
To start BIOS Setup, restart your system and when the message “Tap, Click, or Enter for System Utilities” is displayed in
the status bar at the bottom of the screen, tap anywhere on the screen with your tablet pen. Select “BIOS Setup” from the
pop-up menu that appears. You can also press the [Alt] button (the button closest to the corner of the display), or press
[F2] on an external keyboard to launch BIOS Setup.
The system starts the BIOS Setup Utility and the BIOS Setup Main menu is displayed.
Options and settings for menus in BIOS Setup are described in tables appearing later in this chapter.

BIOS Setup Utility 7
Using BIOS Setup 2
Once the BIOS Setup Utility is started, you can use BIOS Setup to change your system BIOS settings. The BIOS Setup
screen consists of a menu bar, menu items, a command bar, and a window for item-specific help as shown below.
Figure 2-1 BIOS Setup Screen
Instructions for selecting and changing BIOS options and navigating BIOS Setup menus:
If you want to... Do one of these...
Select a BIOS
Setup menu from
the menu bar
To move left and right to highlight the menu and display a list of menu options, do one of the following:
• Press either side of the lower navigation button (the one that is farthest from the application buttons)
• Tap on the menu name in the menu bar
• Tap on the right or left side of the Select Menu field in the command bar
• Use the right or left arrow keys on an external keyboard
Select a BIOS
option
To highlight an option in the list of items for a given menu, do one of the following:
• Press either side of the upper navigation button (the one that is closest to the application buttons)
• Tap on the setting field for the option
• Tap on the right or left side of the Select Item field in the Command Bar
• Use the up and down arrow keys on an external keyboard
System Time: [02:34:56]
System Date: [02/28/2007]
Drive0 [FUJITSU MHV2060BH PL]
Language: [English (US)]
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Main Advanced Security Boot Info Exit
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
▲
BIOS Configuration Options BIOS Configuration Settings Item-Specific Help Window
Menu Bar
(Triangle symbol
indicates that a
submenu is
available)
Command Bar
Highlighted text indicates equivalent keyboard command

BIOS Setup Utility 8
Exiting BIOS Setup 2
Once you have finished making changes in BIOS Setup, you must exit BIOS Setup and allow the system to boot to apply
your configuration changes. You can exit BIOS Setup by selecting options in the Exit menu. The Exit menu includes
options that allow you to load default BIOS settings, load previous settings, discard your changes, save your changes, and
exit BIOS Setup. For details on Exit menu options, see “Exit Menu Options” on page 29.
Change the setting
of a selected BIOS
option
To cycle through the list of possible settings, do one of the following:
• Tap directly on the setting field
• Tap on the highlighted commands to the right or left of Change Values in the command bar
• Use the -, +, and space keys on an external keyboard
• Press the Display Orientation button (third button from the right)
Access a pop-up
menu with a list all
possible settings
for a given BIOS
option
Tap on the [option], then press the [Ent] application button. Tap on the setting of your choice to select it.
You can also hold the pen barrel button while tapping to bring up the pop-up menu.
Select and enter a
submenu
To select and enter a submenu, do one of the following:
• Tap on the submenu name, then tap again to activate it.
• Select the submenu using the up and down arrow keys on an external keyboard and press Enter, or
press the [Ent] application button.
View Item-Specific
Help for a BIOS
option
Select the option. Item-specific help is displayed in the Item Specific Help panel on the right-hand side of
the screen.
View General Help
for BIOS Setup
Tap on Help in the command bar or press F1 on your external keyboard. The BIOS Setup help screen is
displayed giving general instructions for using BIOS Setup
Exit BIOS Setup To exit the BIOS Setup Utility, do one of the following:
• Choose the appropriate option from the Exit menu
• Tap Save and Exit in the command bar
• Press F10 on an external keyboard.
Load factory
default settings for
all BIOS options
To load the factory BIOS default settings, do one of the following:
• Press F9 on an external keyboard
• Select Setup Defaults from the command bar
• Select Load Setup Defaults from the Exit menu
If you want to... Do one of these...

BIOS Setup Utility 9
BIOS Setup Main Menu Options 2
BIOS Setup Main menu options are given in Table 2-1. (Options and settings for other BIOS Setup menus are described
in the tables that follow.) The default setting for each option is listed in bold type when applicable.
Table 2-1. BIOS Setup Main Menu Options
Menu Field Options Default Description
System Time 00:00:00 to 23:59:59 ___ Real Time Clock (RTC) setting in hours, minutes,
and seconds. Note that the system time option
uses a 24 hour format.
System Date 01/01/1980 to 12/31/
2099
___ RTC calendar setting in month/day/year format.
Drive0 Submenu ___ ___ Select this field to access the primary disk drive
submenu. (See “Drive0 Options” later in this
section.)
Language • English
• Japanese
[English] Select the display language for the BIOS.
System Time: [02:34:56]
System Date: [02/28/2007]
Drive0 [FUJITSU MHV2060BH PL]
Language: [English (US)]
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Main Advanced Security Boot Info Exit
Item Specific Help
Adjust calendar clock.
<Tab>, <Shift-Tab>, or
<Enter> selects field.
▲

BIOS Setup Utility 10
Drive0 Submenu Options 2
Options and settings for the Drive0 Submenu are given in Table 2-2.
Table 2-2. the Primary Master Submenu of the Main Menu
Menu Field Options Default Description
Type: • Auto
•None
[Auto] Selects the Serial ATA/IDE device type. Select Auto to have the type
automatically identified by the BIOS at POST. If None is selected, all of the
following Set-up items do not appear.
LBA Format Logical Block Addressing (LBA)
Total Sectors: --- --- The total number of sectors on your hard disk
Maximum
Capacity:
--- --- The maximum capacity of your hard disk
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Item Specific Help
Select Serial ATA/IDE
drive installed here.
[Auto]
The BIOS auto-types the
drive on boot time.
[None]
The drive is disabled.
Exit Submenu
Drive0 [FUJITSU MHV2120BH PL]
Type: [Auto]
LBA Format
Total Sectors: 234441648
Maximum Capacity: 120GB SATA1

BIOS Setup Utility 11
Advanced Menu Options 2
Options in the Advanced menu are described in Table 2-3.
Table 2-3. BIOS Setup Advanced Menu Options
Option Description
IrDA Port Configurations
Submenu
Enter this submenu to configure the infrared port features. (See “IrDA Port Configuration
Submenu Options” on page 12 for details.)
Keyboard Features Submenu Enter this submenu to configure the system keyboard. (See “Keyboard Features Submenu
Options” on page 13 for details).
Video Features Submenu Enter this submenu to select system resources for the video controller. (See “Video Features
Submenu Options” on page 14 for details.)
Internal Device Configurations
Submenu
Enter this menu to configure additional device controllers. (See “Internal Device
Configurations Submenu Options” on page 15 for details.)
CPU Features Submenu Enter this submenu to change CPU features. (See “CPU Features Submenu Options” on
page 16 for details).
USB Features Submenu Enter this submenu to change USB features. (See “USB Features Submenu Options” on page
18 for details).
Miscellaneous Configurations
Submenu
Enter this submenu to change several miscellaneous features, such as Wake Up On LAN.
(See “Miscellaneous Configurations Submenu Options” on page 19 for details).
Event Logging Submenu Enter this submenu to view the Event Log features. (See “Event Logging Submenu Options”
on page 20 for details).
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Main Advanced Security Boot Info Exit
Item Specific Help
Configures IrDA ports.
▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲
IrDA Port Configurations
Keyboard Features
Video Features
Internal Device Configurations
CPU Features
USB Features
Miscellaneous Configurations
Event Logging

BIOS Setup Utility 12
IrDA Port Configuration Submenu Options 2
Configuration options for the IrDA Port Configuration submenu are given in Table 2-4.
Table 2-4. IrDA Port Configurations Submenu
Menu Field Options Default Description
Infrared
Port:
• Disabled
• Enabled
•Auto
[Enabled] Determines whether the infrared port is active and the method used to
configure the infrared port.
• Select [Auto] to allow the BIOS or operating system to configure the
port automatically.
• Select [Enabled] to configure the I/O Address and Interrupt options
manually in BIOS setup.
• Select [Disabled] to turn off the infrared port.
Mode: • IrDA
•FIR
[FIR] Determines which physical interface the infrared port is assigned to. Select
IrDA to use the IrDA port in Standard IR (SIR) mode (115 Kbps). Select FIR
to use the IrDA port in Fast IR mode (4 Mbps). Note: The Infrared port
option must be Enabled before this setting can be changed.
I/O
Address
• 3F8 - 3FF
• 2F8 - 2FF
• 3E8 - 3EF
• 2E8 - 2EF
[2E8 - 2EF] Determines the base I/O address and interrupt request level used for the
infrared port. The Infrared Port option must be set to [Enabled] before this
setting can be changed.
Interrupt: • IRQ 3
•IRQ6
•IRQ10
•IRQ11
[IRQ 6] Determines the interrupt number for the infrared port. Note: The Infrared
port option must be Enabled before this setting can be changed.
DMA
Channel
•DMA1
•DMA3
[DMA 3] Determines the DMA channel assigned to the infrared port when using Fast
IR mode. This option is only selectable when the Infrared Port Mode setting
is FIR.
PhoenixBIOS Setup Utility
F1 Help
ESC Exit
Select Item
Select Menu
- Change Values Space
Enter Select Sub-Menu
F9 Setup Defaults
F10 Save and Exit
▲
Item Specific Help
[Disabled]
The port is disabled.
[Enabled]
The port is enabled
with user configuration.
[Auto]
Plug & Play OS
configure the port.
Exit Submenu
IrDA Port Configurations
Infrared Port: [Enabled]
Mode: [FIR]
I/O Address: [2E8-2EF]
Interrupt: [IRQ 6]
DMA Channel: [DMA 3]

BIOS Setup Utility 13
Keyboard Features Submenu Options 2
Configuration options for the Keyboard Features submenu are given in Table 2-5.
Table 2-5. Keyboard Features Submenu Options
Menu Field Options Default Description
Numlock • On
•Off
[Off] This option determines the state of the NumLock key when the system is powered
on.
F1 Help
ESC Exit
Select Item
Select Menu
-
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Exit Submenu
Item Specific Help
PhoenixBIOS Setup Utility
Select power-on state
for Numlock.
Keyboard Features
Numlock: [Off]
Space

BIOS Setup Utility 14
Video Submenu Options 2
Options for the Video Features submenu are given in Table 2-6.
Table 2-6. Video Features Submenu Options
Menu Field Options Default Description
Display: • Internal Flat Panel
• External
•Auto
[Auto] Selects where the video signal will be routed. Note that once the
system boots up, the settings for the Windows video driver take
precedence over this setting.
Display: [Auto]]
F1 Help
ESC Exit
Select Item
Select Menu
-
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific Help
Select display terminal.
* This setting is not
effective after
operating system
starts up.
Video Features
PhoenixBIOS Setup Utility
Exit Submenu
Space

BIOS Setup Utility 15
Internal Device Configurations Submenu 2
Options for the Internal Device Configurations submenu are given in Table 2-7.
Table 2-7. Internal Device Configurations Submenu Options
Menu Field Options Default Description
Serial ATA
Controller:
• Disabled
• Enabled
[Enabled] When [Enabled] is selected, the Serial ATA port is enabled.
When [Disabled] is selected, the Serial ATA port is disabled.
AHCI
Configuration:
• Disabled
• Enabled
[Enabled] When [Enabled] is selected, the Advanced Host Controller Interface
(AHCI) is enabled.
When [Disabled] is selected, the AHCI is disabled.
Bluetooth(R): • Disabled
• Enabled
[Enabled] When [Enabled] is selected, the Bluetooth device is enabled.
When [Disabled] is selected, the Bluetooth device is disabled.
LAN Controller: • Disabled
• Enabled
[Enabled] When [Enabled] is selected, the LAN device is enabled.
When [Disabled] is selected, the LAN device is disabled.
Wireless LAN: • Disabled
• Enabled
[Enabled] When [Enabled] is selected, the wireless LAN is enabled.
When [Disabled] is selected, the wireless LAN is disabled.
IEEE1394
Controller:
• Disabled
• Enabled
[Enabled] When [Enabled] is selected, the IEEE 1394 (Firewire) device is enabled.
When [Disabled] is selected, the IEEE 1394 (Firewire) device is
disabled.
F1 Help
ESC Exit
Select Item
Select Menu
-
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values Space
Select Sub-Menu
▲
Item Specific Help
[Disabled]
Serial ATA port is
disabled.
[Enabled]
Serial ATA port is
enabled.
Internal Device Configurations
PhoenixBIOS Setup Utility
Serial ATA Controller: [Enabled]
AHCI Configuration: [Enabled]
Bluetooth(R): [Enabled]
LAN Controller: [Enabled]
Wireless LAN: [Enabled]
IEEE1394 Controller: [Enabled]
Exit Submenu
