Full Boar FBAST-100 User manual

KNOW YOUR PRODUCT
WARNING: Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future reference.
0721
AUTOMOTIVE
DIAGNOSTIC
SCANNER
• OBD2 CODE READER
•SUITS MOST VEHICLES
FROM 1996 ONWARDS
• READ & CLEAR
DIAGNOSTIC TROUBLE
CODES
INSTRUCTION MANUAL

2
OBDII / EOBD
AUTO SCAN TOOL
OBD/EOBD Ready Test
Setup About
CHECK
Support: OBD2 Compliant vehicles
Input: 8 to 18V
Display: 2.0" TFT Colour screen (220 x 176 dpi)
Operating temp.: 0°C to 50°C
Storage temp.: -20°C to 70°C
Weight: 0.21 kg
SPECIFICATIONS - MODEL NO. FBAST-100
KNOW YOUR PRODUCT
2
4
5
6
3
7
1
8

3
1. TFT Colour screen
Indicates setup, scan, menu options and test results.
2. Red LED
Indicates there is a problem in one or more of the vehicle’s systems. The red LED
is also used to show that DTCs are present. DTCs are shown on the Scan Tool’s
screen. In this case, the MIL lamp on the vehicle’s instrument panel will light steady
on.
3. Yellow LED
Indicates there is a possible problem. A “Pending” DTC is present and/or some of
the vehicle’s emission monitors have not run their diagnostic testing.
4. Green LED
Indicates that engine systems are running normally (The number of monitors
on the vehicle which are active and performing their diagnostic testing is in the
allowed limit, and no DTCs are present).
5. Enter/exit button
Confirms a selection (or action) from a menu. Or returns to previous menu.
6. OBD2, 16-Pin connector
Connects the scan tool to the vehicle’s Data Link Connector (DLC).
7. Scroll button
Scrolls down through menu items.
8. Quick-test function button
Shortcut for four quick functions including I/M readiness status, read code, usual
datastream and all datastream.
KNOW YOUR PRODUCT (cont.)

4
TABLE OF CONTENTS
SPECIFICATIONS.......................................................Page 02
KNOW YOUR PRODUCT...........................................Page 02
INTRODUCTION.......................................................Page 05
SAFETY INSTRUCTIONS...........................................Page 06
GENERAL INFORMATION........................................Page 07
MENU........................................................................Page 10
OPERATION..............................................................Page 12
TROUBLESHOOTING...............................................Page 25
MAINTENANCE........................................................Page 26
DESCRIPTION OF SYMBOLS....................................Page 27
CONTENTS...............................................................Page 27
WARRANTY...............................................................Page 28

5
Congratulations on purchasing a Full Boar Automotive
Diagnostic Scanner. The Full Boar Automotive Diagnostic
Scanner FBAST-100 is designed for troubleshooting most
cars and light trucks from 1996 onwards.
Use this Automotive Diagnostic Scanner to diagnose
and erase faults relating to spark plugs, valves and many
more, whilst the live data feature allows for more precise
diagnosis of faults. Read and understand the Owner’s
Manual before operating the Automotive Diagnostic
Scanner. Failure to do so could result in personal injury or
equipment damage.
INTRODUCTION

6
- This appliance is not intended for use by young or infirm persons unless supervised by a
responsible person to ensure that they can use the appliance safely.
- Young children should be supervised to ensure that they do not play with the appliance.
- The warnings, cautions and instructions discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
- Common sense and caution are factors that cannot be built into this product but must be
supplied by the operator.
- Wear safety eye protection that meets AS/NZS standards.
- Always perform automotive testing in a safe environment.
- Keep clothing, hair, hands, tools, test equipment, etc away from all moving or hot engine
parts.
- Operate the vehicle in a well-ventilated work area. Exhaust gases are poisonous.
- Operate in a safe work environment. Keep your work area clean and well lit.
- Always lock up tools and keep them out of the reach of children.
- Do not expose OBD2 automotive diagnostic scanner to rain, snow or wet conditions.
- Keep the OBD2 automotive diagnostic scanner dry, clean and free from oil, water and
grease.
- Stay clear of hot engine and car parts.
- Keep a fire extinguisher suitable for gasoline/chemical/electrical fires nearby.
- Use this product in accordance with these instructions, taking into account the working
conditions and the work to be performed. Use of this product for operations different from
those intended could result in a hazardous situation.
- This product is not a toy. Keep it out of reach of children.
- Maintain labels and nameplates on the unit. These carry important safety information.
- Don’t connect or disconnect any test equipment with ignition on or engine running.
- Ensure automatic vehicles are in park with the hand brake engaged before starting the
engine.
- Ensure manual vehicles are in neutral with the hand brake engaged before starting the
engine.
- Put blocks on drive wheels and never leave car unattended while running tests.
- Road Safety Road Rules 2009 penalty code 2135, it is illegal to leave “motor vehicle
unattended with keys in ignition, motor running, brakes not secured or doors unlocked.
- Use extreme caution when working around the ignition coil, distributor cap, ignition wires
and spark plugs. These components create hazardous voltages when the engine is running.
SAFETY INSTRUCTIONS
WARNING! Save all warnings and instructions for future reference.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.

7
GENERAL INFORMATION
OBD2 Readiness monitors
An important part of a vehicle’s OBD2 system is the Readiness Monitors, which are
indicators used to find out if all of the emissions components have been evaluated
by the OBD2 system. They are running periodic tests on specific systems and
components to ensure that they are performing within allowable limits.
Currently, there are eleven OBD2 Readiness Monitors (or I/M Monitors) defined by
the U.S. Environmental Protection Agency (EPA). Not all monitors are supported by
all vehicles and the exact number of monitors in any vehicle depends on the motor
vehicle manufacturer’s emissions control strategy.
• Continuous monitors – Some of the vehicle components or systems are
continuously tested by the vehicle’s OBD2 system, while others are tested
only under specific vehicle operating conditions. The continuously monitored
components listed below are always ready:
1. Misfire
2. Fuel System
3. Comprehensive Components (CCM)
Once the vehicle is running, the OBD2 system is continuously checking the above
components, monitoring key engine sensors, watching for engine misfire, and
monitoring fuel demands.
• Non-continuous monitors – Unlike the continuous monitors, many emissions
and engine system components require the vehicle to be operated under specific
conditions before the monitor is ready. These monitors are termed non-continuous
monitors and are listed below:
1. EGR System 2. O2 Sensors
3. Catalyst 4. Evaporative System
5. O2 Sensor Heater 6. Secondary air
7. Heated Catalyst 8. A/C system

8
GENERAL INFORMATION (cont.)
OBD2 Monitor readiness status
OBD2 systems must indicate whether or not the vehicle’s PCM’s monitor system
has completed testing on each component. Components that have been tested
will be reported as “Ready”, or “Complete”, meaning they have been tested by
the OBD2 system. The purpose of recording readiness status is to allow inspectors
to determine if the vehicle’s OBD2 system has tested all the components and/or
systems.
The power-train control module (PCM) sets a monitor to “Ready” or “Complete”
after an appropriate drive cycle has been performed. The drive cycle that enables
a monitor and sets readiness codes to “Ready” varies for each individual monitor.
Once a monitor is set as “Ready” or “Complete”, it will remain in this state. A
number of factors, including erasing of diagnostic trouble codes (DTCs) with a
scan tool or a disconnected battery, can result in Readiness Monitors being set
to “Not Ready”. Since the three continuous monitors are constantly evaluating,
they will be reported as “Ready” all of the time. If testing of a particular supported
noncontinuous monitor has not been completed, the monitor status will be
reported as “Not Complete” or “Not Ready”.
In order for the OBD monitor system to become ready, the vehicle should be
driven under normal operating conditions. These operating conditions may
include a mix of highway driving and stop and go, city type driving, and at least
one overnight-off period. For specific information on getting your vehicle’s OBD
monitor system ready, please consult your vehicle owner’s manual.
Audio tone
The audio tone could be configured according to the I/M Readiness Status. This
function is invaluable when working in bright areas where LED illumination alone is
not sufficient.
It is recommended to set the audio tone to Beep ON. For detailed setup
information, please refer to Key Beep Set in Menu Setup.
Note: The following audio tone description only works in Scan Tool mode.
Different audio tone with different LEDs will indicates different I/M Readiness
Status.
LED Audio Tone Beep Interval
Green LED Beep Off
Yellow LED Two short beeps 0.5 seconds
Red LED Two short beeps 0.5 seconds

9
GENERAL INFORMATION (cont.)
OBD2 Definitions
• Power-train control module (PCM) – OBD2 terminology for the on-board
computer that controls engine and drive train.
• Malfunction indicator light (MIL) – Malfunction Indicator Light (Service Engine
Soon, Check Engine) is a term used for the light on the instrument panel. It is to
alert the driver and/or the repair technician that there is a problem with one or
more of vehicle’s systems and may cause emissions to exceed federal standards.
If the MIL illuminates with a steady light, it indicates that a problem has been
detected and the vehicle should be serviced as soon as possible. Under certain
conditions, the dashboard light will blink or flash. This indicates a severe problem
and flashing is intended to discourage vehicle operation. The vehicle on-board
diagnostic system can not turn the MIL off until necessary repairs are completed or
the condition no longer exists.
• DTC – Diagnostic Trouble Codes (DTC) that identify which section of the
emission control system has malfunctioned.
• Enabling criteria – Also termed Enabling Conditions. They are the vehicle-
specific events or conditions that must occur within the engine before the various
monitors will set, or run. Some monitors require the vehicle to follow a prescribed
“drive cycle” routine as part of the enabling criteria. Drive cycles vary among
vehicles and for each monitor in any particular vehicle.
• OBD2 Drive cycle – A specific mode of vehicle operation that provides
conditions required to set all the readiness monitors applicable to the vehicle to
the “ready” condition. The purpose of completing an OBD2 drive cycle is to force
the vehicle to run its onboard diagnostics. Some form of a drive cycle needs to
be performed after DTCs have been erased from the PCM’s memory or after the
battery has been disconnected. Running through a vehicle’s complete drive cycle
will set the readiness monitors so that future faults can be detected. Drive cycles
vary depending on the vehicle and the monitor that needs to be reset. For vehicle
specific drive cycle, consult the vehicle’s Owner’s Manual.
• Freeze frame data – When an emissions related fault occurs, the OBD2
system not only sets a code but also records a snapshot of the vehicle operating
parameters to help in identifying the problem. This set of values is referred to as
Freeze Frame Data and may include important engine parameters such as engine
RPM, vehicle speed, air flow, engine load, fuel pressure, fuel trim value, engine
coolant temperature, ignition timing advance, or closed loop status.

10
KNOW YOUR PRODUCTMENU
WARNING! Read and understand the warnings before setup.
The Automotive Diagnostic Scanner is used to check engine of most OBD2
compliant vehicles from 1996 onwards with standard sized 16-Pin Data Link
Connector (DLC).
Your DLC is usually located near centre under the instrument panel (dash), under
or around the driver’s side of most vehicles
(fig. 1). Do not force OBD2 Connector into the
DLC, ensure the connector is in the correct
orientation to the DLC to avoid damaging the
pins.
Note: Refer to your vehicle’s service manual
for the location if the DLC cannot be found.
Fig. 1
Function description
• Dual-system diagnostic, optional engine and transmission.
• Quickly indicate engine faults, with green / yellow / red LED indicators as fault
lights.
• Read and clear the engine fault code and view Diagnostic Trouble Codes (DTC)
definitions.
• Display of sensor data stream information such as vehicle revolutions per minute
(rpm), engine coolant temperature in real time.
• View freeze frame data and I/M (readiness monitor status information.
• Read vehicle information:
vehicle identification number (VIN).
calibration identification numbers (CINs).
calibration verification number (CVNs).
• Multi-language.

11
MENU (cont.)
Diagnostic trouble codes (DTC)
OBD2 Diagnostic Trouble Codes are codes that are stored by the on-board
computer diagnostic system in response to a problem found in the vehicle. These
codes identify a particular problem area and are intended to provide you with a
guide as to where a fault might be occurring within a vehicle. OBD2 Diagnostic
Trouble Codes consist of a five-digit alphanumeric code. The first character, a
letter, identifies which control system sets the code. The other four characters, all
numbers, provide additional information on where the DTC originated and the
operating conditions that caused it to set. See below example (fig. 2) to illustrate
the structure of digits:
1. System
B = Body
C = Chassis
P = Power train
U = Network
2. Code type
Generic = 0
Manufacturer Specific = 1
OBDII EOBD
AUTO SCAN TOOL
P0115
1 2 3 4
Stored Codes
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Fig. 2
3. Sub-systems
1 = Fuel and Air Metering
2 = Fuel and Air Metering
3 = Ignition System or Engine Misfire
4 = Auxiliary Emission Controls
5 = Vehicle Speed Control and Idle Controls
6 = Computer Output Circuits
7 = Transmission Controls
8 = Transmission Controls
4. Identifying specific
malfunctioning section of
the systems.

12
OPERATION
WARNING! Do not connect or disconnect scan tool with ignition on or
engine running.
Setup menu
1. Connect OBD2 16-pin connector (6) into the DLC.
2. Turn the ignition on. Setup can be done
with engine off or engine running. When
the scan tool is powered on, it displays a
home screen (fig. 3)
3. From the home screen, press the Scroll
button (7) to select the Setup interface,
and press Enter/Exit button (5). Follow
the instructions to make adjustments and
settings as described in the following setup
options.
• Language: The default language from the
factory is English, many other languages can
be manually selected.
1. From the Tool Setup screen (fig. 4), use the
Scroll button (7) to select Language and
press the Enter/Exit button (5).
2. From Language screen, use the Scroll
button (7) to select the desired language
(fig. 5).
3. Press the Enter/Exit button (5) to save your
selection and return to previous menu.
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 3
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 4
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 5

13
• Unit of measure: The default units from the factory is Metric, English (imperial)
can me manually selected.
1. From the Tool Setup screen (fig. 4), use the Scroll button (7) to select Unit of
Measure and press the Enter/Exit button
(5).
2. From Unit of Measure screen, use the Scroll
button (7) to select the desired unit of
measure (fig. 6).
3. Press the Enter/Exit button (5) to save your
selection and return to previous menu.
• Key beep set: The default setting from the factory is Beep On, turn On or Off
the built-in speaker button-press beep .
1. From the Tool Setup screen (fig. 4), use the Scroll button (7) to select Key Beep
Set and press the Enter/Exit button (5).
2. From Key Beep Set screen, use the Scroll
button (7) to select beep ON or beep OFF
to turn on/off the beep (fig. 7).
3. Press the Enter/Exit button (5) to save your
selection and return to previous menu.
• Status beep set: Turns On or Off the built-in speaker for the LED's in I/M
Readiness diagnostic testing. A different audio tone corresponds to each LED.
1. From the Tool Setup screen (fig. 4), use the Scroll button (7) to select Status
Beep Set and press the Enter/Exit button (5).
2. From Status Beep Set screen, use the Scroll
button (7) to select beep ON or beep OFF
to turn on/off the beep (fig. 8).
3. Press the Enter/Exit button (5) to save your
selection and return to previous menu.
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 8
OPERATION (cont.)
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 6
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 7

14
• Fn key set: For setting the Quick-test function button (8) including I/M readiness
status, trouble code, default live data and all datastream.
1. From the Tool Setup screen (fig. 4), use the
Scroll button (7) to select Fn Key Set and
press the Enter/Exit button (5).
2. From Fn Key Set screen, use the Scroll
button (7) to select one of four Fn settings
(fig. 9) for the Quick-test function button (8).
During the operation in any menu or interface
of the tool, one press of the Quick-test
function button (8) that mode will be selected.
3. Press the Enter/Exit button (5) to save your
selection and return to previous menu.
—Usual datastream mode
In this mode, the tool has recommend some datastream as important datasteam
for the user reference, during the vehicle's monitors have run and completed their
diagnosis and testing.
—All datastream mode
In this mode, after the vehicle's monitors have run and completed their diagnosis
and testing, the scan tool will return to check all data-stream. So it is mostly used
to check the monitors' status.
—I/M Readiness mode
This is the default work mode. In this mode, after the vehicle's monitors have
run and completed their diagnosis and testing, the scan tool will turn to OBD2
diagnostic procedures.
—Read codes mode
This is the basic work mode. In this mode, after the vehicle's monitors have run
and completed their diagnosis and testing, the scan tool will read the trouble
codes.
4. To exit the Setup menu, use the Scroll button (7) to select Previous Menu and
press the Enter/Exit button (5) to return to the home screen (fig. 3).
OPERATION (cont.)
OBD/EOBD Ready Test
Setup About
CHECK
Tool Setup 1/6
Language
Unit of measure
Key Beep Set
Status Beep Set
Fn key set
Previous Menu
Language 1/8
Nederlands
English
Francais
Espanol
Deutsch
Unit of Measure 1/2
Metric
English
Key Beep Set 1/2
OFF
ON
Status Beep Set 1/2
OFF
ON
Fn Key Set 1/4
Usual Datastream
All Datastream
I/M Readiness
Read Codes
Fig. 9

15
OPERATION (cont.)
About menu
This function allows viewing of some important information such as serial number
and software version number of the scanner.
1. From the home screen (fig. 10), use the
Scroll button (7) to select the About
interface , and press Enter/Exit button (5).
2. The scan tool information will appear on
the TFT colour screen (1) (fig. 11).
3. To return to the home screen, press any
button.
OBD/EOBD Ready Test
Setup About
CHECK
Tool Information
Software Version
All Datastream
Hardware Version
V#.##
Serial Number
DT#########
Fig. 10
OBD/EOBD Ready Test
Setup About
CHECK
Tool Information
Software Version
All Datastream
Hardware Version
V#.##
Serial Number
DT#########
Fig. 11

16
OPERATION (cont.)
Diagnostic menu - OBD2 test
When more than one vehicle control module is detected by the scan tool, you will
be prompted to select the module where the data may be retrieved. The most
often to be selected are the Power train Control Module [PCM] and Transmission
Control Module [TCM].
WARNING! Do not connect or disconnect scan tool with ignition on or
engine running.
1. With the ignition off connect OBD2 16-pin connector (6) into the DLC.
2. Turn the ignition on. The scan can be done
with engine off or engine running. When
the tool is powered on, it displays a home
screen (fig. 12).
3. From the home screen, press the Scroll
button (7) to select the Diagnostic OBD/
EOBD interface and press Enter/Exit button
(5) to confirm.
4. Wait for the menu to appear. A sequence of messages displaying the OBD2
protocols will be observed on the TFT colour screen (1).
Note: If the scan tool fails to communicate with the vehicle’s ECU (Engine Control
Unit) more than three times, a "LINKING ERROR!" message will show on the TFT
colour screen (1).
a) You will need to verify that the ignition is ON;
b) Check if the tool’s OBD2 16-pin connector (6) is securely connected to the
vehicle‘s DLC.
c) Verify that the vehicle is OBD2 compliant;
d) Turn the ignition off and wait for about 10 seconds. Turn the ignition back to on
and repeat the procedure from step 3.
If the “LINKING ERROR” message does not go away, then there might be
problems for the tool to communicate with the vehicle. Contact TB Imports
customer service department for assistance.
WARNING! Operate vehicle in a well-ventilated area, exhaust gasses are
poisonous.
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 12

17
OPERATION (cont.)
5. View a summary of the system status (MIL
status, DTC counts, Monitor status) on the
TFT colour screen (1) (fig. 13).
6. Press any button for Diagnostic Menu. If
more than one module is detected, you
will prompted to select a module before
testing.
7. Use the Scroll button (7) to select a control
module and press Enter/Exit button (5) to
confirm (fig. 14).
Diagnostic menu - Read codes: Reading Codes can be done with the ignition
on engine off or with the engine running. Stored Codes are also known as
“hard codes” or “permanent codes”. These codes cause the control module to
illuminate the malfunction indicator light (MIL) when emission-related fault occurs.
Pending Codes are also referred to as “maturing codes” or “continuous monitor
codes”. They indicate problems that the control module has detected during the
current or last driving cycle but are not considered serious yet. Pending Codes will
not turn on the malfunction indicator lamp (MIL). If the fault does not occur within
a certain number of warm-up cycles, the code clears from memory.
1. Use the Scroll button (7) to select Read
Codes and press Enter/Exit button (5) to
confirm (fig. 15).
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 13
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 14
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 15

18
OPERATION (cont.)
2. Use the Scroll button (7) to select Stored
Codes or Pending Codes and press Enter/
Exit button (5) to confirm (fig. 16).
If there is not any Diagnostic Trouble Code
(DTC), the display indicates “No (pending)
codes are stored in the module!” Wait a few
seconds or press any button to return to
previous screen.
Note: Permanent Codes function is available
for vehicles supporting the CAN protocols.
Stored DTC codes- Are generated by
the current hardware failure. The current fault code(s) for the hardware failure
are generated by a continuous fault and can only be cleared if the hardware is
repaired.
Pending DTC codes- They indicate problems that the control module has
detected during the current or last driving cycle but are not considered serious
yet. Pending Codes will not turn on the malfunction indicator lamp (MIL) unless
the same problem is detected again. If the fault does not occur within a certain
number of warm-up cycles, the code clears from memory.
Permanent DTC codes- These codes cause the control module to illuminate the
malfunction indicator light (MIL) when emission-related fault occurs. These DTCs
cannot be cleared until it is confirmed that the problem is fixed.
3. View the DTCs and their definitions on the
TFT colour screen (1) (fig. 17). Press Enter/
Exit button (5) to return to previous screen.
Note: The control module number, sequence
of the DTCs, total number of codes detected
and type of codes (Generic or Manufacturer
specific, Stored or Pending codes) will be
observed on the upper right hand corner of
the display.
4. If more than one DTCs is found press the
Scroll button (7) to check all the codes.
5. Select Previous Menu from the Read Codes menu and press Enter/Exit button
(5) to return to previous menu.
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 16
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 17

19
OPERATION (cont.)
Diagnostic menu - Erase codes: This module can be used to clear DTCs in the
system. Erasing the Diagnostic Trouble Codes may allow the automotive scan
tool to delete not only the codes from the vehicle’s on-board computer, but also
“Freeze Frame” data and manufacturer specific enhanced data. Furthermore, the
I/M Readiness Monitor Status for all vehicle monitors is reset to Not Ready or Not
Complete status.
Note: Erasing codes does not mean that trouble codes in ECU have been
eliminated completely. As long as there is fault with the vehicle, the trouble codes
keeps on presenting. Ignition on engine off. Do not start the engine.
1. Use the Scroll button (7) to select Erase Codes and press Enter/Exit button (5) to
confirm (fig. 18).
2. If you do not want to proceed with erasing codes, use the Scroll button (7) to
select NO to exit (fig. 19). A message of "Command Cancelled!" appears. Wait
a few seconds or press any button to return to Diagnostic Menu.
WARNING! Do not erase the codes before the system has been checked
completely by a technician.
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 18
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 19
3. To erase codes, select YES and Press Enter/Exit button (5) to confirm. If the
codes are cleared successfully, an “Erase Done!” confirmation message shows
on the TFT colour screen (1) (fig. 20).
4. If the codes are not cleared, then an "Erase Failure. Turn Key on with Engine
off!” message appears (fig. 21).
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 20
OBD/EOBD Ready Test
Setup About
CHECK
Monitor Status
MIL status
Codes found
Monitors N/A
Monitors OK
Monitors INC
Control Module 1/2
Engine
A/T
OFF
6
3
3
5
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Read Codes 1/3
Stored Codes
Pending Codes
Permanent Codes
Previous Menu
Stored Codes
1/3
P0115 1/3
Engine Coolant Temperature Sensor 1
Circuit
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Erase Codes
Read Codes
Erase trouble codes!
Are you sure?
YES NO
Erase Codes
Erase done!
Press any button to con.
Erase Codes
Erase Failure.
Turn key on with Engine Off!
Press any button to con.
Fig. 21

20
OPERATION (cont.)
All Datastream 1/17
Fuelsys1
Fuelsys2
Load_PCT
ECT
Shrtfi1
CL
....
45.5%
98
-64.8%
Fig. 22
Diagnostic menu - Date stream: Allows viewing of live or real time PID data
of vehicle’s computer module(s). For the vehicles with more ECUs, more live
datas will be found and showed. The max live datas arrive at 300 for some cars.
However, the live data real quantity depend on each car ECU. Please check this
function as real vehicle status on the vehicle. This can be done with the ignition on
engine off or with the engine running, engine running will provide live data.
1. Use the Scroll button (7) to select Data Stream and press Enter/Exit button (5) to
confirm.
2. Wait a few seconds while the automotive
scan tool validates the Performance
Information Data (PID) (fig. 22).
Note: The number to the right of the TFT
colour screen (1) indicates sequence of
highlighted item.
3. If retrieved information covers more than
one screen, use the Scroll button (7), as
necessary, until all the data is displayed.
Note: If there is no data found, an advisory
message " No Data Stream!" will display on
the TFT colour screen (1).
4. Press Enter/Exit button (5) to return to previous menu.
Diagnostic menu - View freeze frame data: Records the vehicle operation,
status information (fault code, vehicle speed, RPM, water temperature, etc.) at
the moment when a DTC is detected. This information can aid the technician by
allowing the parameters to be duplicated for diagnostic and repair purposes. This
data will only exist when there is a fault code.
1. To view freeze frame data, use the Scroll
button (7) to select View Freeze Frame
from the Diagnostic Menu and press Enter/
Exit button (5) to confirm (fig. 23).
2. Wait a few seconds while the automotive
scan tool validates the PID.
Freeze Frame 1/5
DTCFRZF
FUELSYS2
LOAD_PCT (%)
ECT(C)
SHRTFT1 (%)
P1633
--
0.0
-40
99.2
Diagnostic Menu 1/7
Read Codes
Erase Codes
View Freeze Frame
I/M Readiness
Vehicle Information
Fig. 23
