TEXA TMD2 User manual

ENGLISH...............................................................5 en

2

SUMMARY
Introduction........................................................................................5
1 LEGEND OF THE SYMBOLS USED...........................................6
2 GENERAL SAFETY REGULATIONS..........................................7
2.1 Glossary..........................................................................................7
2.2 Operator Safety Regulations...........................................................7
2.2.1 General Safety Regulations................................................................7
2.2.2 Risk of Asphyxiation............................................................................7
2.2.3 Risk of Impact and Crushing...............................................................8
2.2.4 Hazards Caused by Moving Parts......................................................8
2.2.5 Risk of Burning or Scalding................................................................8
2.2.6 Fire and Explosion Hazard.................................................................9
2.2.7 Noise Hazard......................................................................................9
2.2.8 High Voltage Hazard...........................................................................9
2.2.9 Poisoning Hazard.............................................................................10
2.3 General User and Maintenance Warnings....................................11
3 SPECIFIC SAFETY RULES FOR INSTALLING TMD2.............12
3.1 Glossary........................................................................................12
3.2 General Rules...............................................................................12
3.3 Operator Safety.............................................................................13
3.4 Device Safety................................................................................14
3.5 Safety during the Installation.........................................................15
4 ENVIRONMENTAL INFORMATION..........................................17
5 OPERATION OF THE TOOL'S RADIO DEVICES.....................18
6 NORMATIVE INFORMATION....................................................19
7 DESCRIPTION...........................................................................20
7.1 Image of the device.......................................................................21
7.2 Technical Features........................................................................22
7.3 Flash codes...................................................................................23
7.3.1 Flashings of LED - [a] and of LED - [b].............................................23
3
en

7.3.2 Flashings of LED - [c] with instrument panel on ..............................23
8 INSTALLATION..........................................................................25
8.1 Suggestions for a Correct Installation...........................................26
8.2 External GPS Antenna Positioning (Optional)...............................27
8.3 Connection of the External GPS Antenna to TMD2......................28
8.4 Positioning of TMD2......................................................................30
8.5 Power Supply Connections...........................................................35
8.6 Checking the Installation...............................................................36
9 CONFIGURATION.....................................................................37
9.1 Configuration through TMDStarter................................................37
9.2 Configuration through the Portal...................................................38
10 MAINTENANCE.......................................................................39
11 INDICATIONS IN CASE THE VEHCILE IS NOT USED FOR A
LONG TIME.....................................................................................40
12 LEGAL NOTICES.....................................................................41
4

TMD2 INSTALLATION MANUAL
Introduction
Dear Installer,
Please read through the instructions in this manual carefully and keep it for
future reference.
Reading and understanding the following manual will help you to avoid
damage or personal injury caused by improper use of the product to which
it refers.
TEXA S.p.A reserves the right to make any changes deemed necessary
to improve the manual for any technical or marketing requirement; the
company may do so at any time without prior notice.
This manual should be considered an integral part of the product to which
it refers. In the case it is resold the original buyer is therefore required to
forward the manual to the new owner.
Reproduction, whole or in part, of this manual in any form whatsoever
without written authorization from the producer is strictly forbidden.
© copyright and database rights 2010. The material contained in this
documentisprotectedbycopyrightanddatabaserights.Allrightsreserved
according to law and international agreements.
5
en

1 LEGEND OF THE SYMBOLS USED
The symbols used in the manual are described in this chapter.
Asphyxiation Risk
Explosion Risk
High Voltage Hazard
Fire / Burn risk
Poisoning Hazard
Corrosive Substances Risk
Noise Hazard
Moving Parts Risk
Crushing Risk
General Risk
Important information
6

2 GENERAL SAFETY REGULATIONS
2.1 Glossary
•Operator: qualified person responsible for installing the tool.
•Device: the purchased product.
•Workplace: the place where the operator must carry out her/his work.
2.2 Operator Safety Regulations
2.2.1 General Safety Regulations
•The operator must be completely clear-headed and sober when using the
device; taking drugs or alcohol before or while operating the device is strictly
forbidden.
•The operator must not smoke during device operation.
•The operator must carefully read all the information and instructions in the
technical documents provided with the tool.
•The operator must follow all the instructions provided in the technical
documents.
•The operator must make sure she/he is working in an environment which is
suitable for the operations that must be carried out.
•The operator must report any faults or potentially hazardous situation in
connection with the workplace or the device.
•The operator must carefully follow the safety regulations required for the
workplace in which she/he is working in and for the operations she/he has
been asked to carry out.
2.2.2 Risk of Asphyxiation
Exhaust gases from internal combustion engines, whether petrol
or diesel, are hazardous to your health and can cause serious
harm to your body.
Safety Precautions:
•The workplace must be equipped with an appropriate ventilation and air
extraction system and must be in compliance with standards according to
current national laws.
•Always activate the air extraction system when working in closed
environments.
7
en

2.2.3 Risk of Impact and Crushing
The vehicles which are undergoing A/C system recharging
operations and the devices must be properly blocked during
service, using the specific mechanical brakes.
Safety Precautions:
•Alwaysmakesurethat thevehicle isin neutralgear (orthat itis setin parking
position in case of a vehicle equipped with automatic transmission).
•Always activate the hand brake or parking brake on the vehicle.
•Always block the wheels on the vehicle with the specific mechanical brakes.
•Make sure the device is stable, on a flat surface and that the wheels are
locked with the specific brakes.
2.2.4 Hazards Caused by Moving Parts
Vehicle engines include parts that move, both while running and
when off (ex: the cooling fan is controlled by a thermal switch in
connection with the coolant temperature and can be activated
even when the vehicle is off), that can injure the operator.
Safety Precautions:
•Keep hands away from moving parts.
•Disconnect the engine cooling fan each time the engine you are working on
is still hot. This will avoid the fan from being unexpectedly activated even
when the engine is off.
•Do not wear ties, loose clothes, wrist jewellery or watches when working on
a vehicle.
•Keep connection cables, probes and similar devices away from the moving
parts of the engine.
2.2.5 Risk of Burning or Scalding
The parts that are exposed to high temperatures in engines that
are running or have just stopped could burn the operator.
Remember that catalytic mufflers reach very high temperatures,
able to cause serious burns or even start fires.
Acid in the vehicle batteries is another potential hazard.
Safety Precautions:
•Protect your face, hands, and feet by using suitable protection.
•Avoid contact with hot surfaces, such as spark plugs, exhaust pipes,
radiators and connections within the cooling system.
8

•Make sure there are no oil stains, rags, paper or other inflammable material
near the muffler.
•Avoid splashing electrolyte on skin, eyes and clothes, as it is a corrosive and
highly toxic compound.
2.2.6 Fire and Explosion Hazard
The following are potential fires and/or explosion hazards:
•The types of fuel used by the vehicle and the vapours released by
these fuels.
•The refrigerants used by the A/C system.
•The acid in the vehicle batteries.
Safety Precautions:
•Let the engine cool.
•Do NOT smoke near the vehicle.
•Do NOT expose the vehicle to open flames.
•Make sure that the electrical connections are all well insulated.
•Collect any fuel that might have spilled.
•Collect any refrigerant that might have spilled.
•Make sure you are always working in an environment equipped with a good
ventilation and air extraction system.
•Always activate the air extraction system when working in closed
environments.
•Cover the openings of the batteries with a wet cloth in order to stifle the
explosive gases before proceeding in testing or recharging.
•Avoid causing sparks when connecting cables to the battery.
2.2.7 Noise Hazard
Loudnoisesthatmayoccurwithintheworkplace,especiallyduring
service operations, may damage the operator's hearing.
Safety Precautions:
•Protect your ears with suitable protective ear wear.
2.2.8 High Voltage Hazard
The voltage supply from the mains that powers the devices in the
workplace and the voltage within the vehicle starter system are a
potential shock hazard to the operator.
9
en

Safety Precautions:
•Make sure the electrical system in the workplace is compliant to current
national standards.
•Make sure the device being used is connected to ground.
•Cut off the power supply voltage before connecting or disconnecting cables.
•Do NOT touch the high voltage cables when the engine is on.
•Operate in conditions of insulation from ground.
•Work with dry hands only.
•Keep conductive liquids away from the engine while working.
•Never leave tools on the battery in order to avoid accidental contacts.
2.2.9 Poisoning Hazard
The hoses used to extract the gases can release toxic gases,
dangerous to the operator if exposed to temperatures higher than
250 °C or in case of a fire.
Safety Precautions:
•Contact a doctor immediately should you inhale these gases.
•Use neoprene or PVC gloves when eliminating combustion deposits.
10

2.3 General User and Maintenance Warnings
When using the device or carrying out scheduled maintenance (ex.: fuse
replacement) on the device, carefully follow the information provided
below.
•Do not remove or damage the labels and the warnings on the device; do
NOT in any case make them illegible.
•Donot removeor blockanysafetydevicethe purchasedproduct isequipped
with.
•Only use original spare parts or spare parts approved by the manufacturer.
•Contact your retailer for any non-scheduled maintenance.
•Periodically check the electrical connections of the device, making sure they
are in good condition and replacing any damaged cables.
•Periodically check parts that are subject to wear and replace them if
necessary.
•Do not open or disassemble the device.
11
en

3 SPECIFIC SAFETY RULES FOR INSTALLING TMD2
The technology used for the design and the production inspection of the
TMD2 devices and related accessories, make them reliable, simple and
safe to install and use.
Thepersonnelqualifiedtoinstalltelediagnosticdevicesisrequiredtofollow
the general safety rules, to employ the TMD2 devices and related
accessories for their intended use only. and to preserve the correctly, as
described in this manual.
3.1 Glossary
Operator: a qualified person responsible for installing the telediagnostic
device.
Device: any TMD2 device.
Wiring: specific electric cables needed to connect TMD2 to its
accessories, to the power supply, to the antenna, etc.
3.2 General Rules
•The operator must have basic knowledge of mechanics, automotive
industry, car repairs and of the potential dangers that can occur during
installation operations.
•The operator must carefully read and understand the information and the
instructions in the technical documents provided with the device.
12

3.3 Operator Safety
The airbags inflate with great force and a device placed in their
expansion area may be projected towards the occupants of the
vehicle causing serious harm and injuries.
Safety Measures:
•Do not place the device in the expansion areas of any airbag.
Thedevicewasmanufactured tobeelectricallysafeandinsulated.
It is however necessary to reduce the risk of electric shock.
Safety Measures:
•Make sure the electric power supply devices (auxiliary batteries) are
disconnected and that they remain so during the entire installation before
proceeding with the installation itself.
•Do not touch the device, the accessories and the wiring with wet hands.
•If liquid should penetrate inside the device, immediately disconnect the
power supply wiring and contact technical assistance.
The device's antenna was manufactured to result be electrically
safe and mechanically resistant.
However,if the antenna is damagedin some way, the contactwith
skin could cause light burns.
Safety Measures:
•Do not use the accessory device if the antenna is damaged.
•Do not touch the antenna with bare hands.
•Immediately contact technical assistance.
13
en

3.4 Device Safety
The device was manufactured to be mechanically resistant.
Careless use and excessive mechanical stress could compromise
its efficiency.
Safety Measures:
•Do not drop, shake or knock the device.
•Do not place objects over the cables and do not bend them at a right angle.
•Do not perform any type of intervention that could damage the device.
•Do not open or disassemble the device.
•Do not fold the device's antenna.
•Use the device only with the provided antenna or with one authorized by the
device's manufacturer.
•Make sure the device and the accessories connected to it are firmly secured
before moving the vehicle they are installed on.
The device was manufactured to be electrically safe and to work
with specific power supply voltage levels.
The failure to comply with the specifications related to the power
supply may compromise its efficiency.
Safety Measures:
•Do not wet the device with water or other liquids.
•If not otherwise specified, use the device on vehicles with a 12/24 V DC
power supply and the chassis connected to the negative pole.
•The device's power supply must always be connected following the
indications provided in this manual.
•Do not use an external batteries to supply the device.
Electromagnetic compatibility tests on the device guarantee that it
canbeadaptedtothetechnologiesnormallyusedonvehicles(ex.:
engine check, ABS, airbag, etc.). Nevertheless, if there are
malfunctions, contact the vehicle dealer.
In particular, the correct functioning of the device could be
compromised by covering the antenna with shielding objects and/
or materials.
Such materials force the device to work with more power than
normal.
Safety Measures:
•Do not cover the antenna with shielding objects or materials.
14

3.5 Safety during the Installation
Thedevicewasmanufacturedtobeusedinspecificenvironmental
conditions.
The installation and use of the device in environments with
temperature and humidity features different from those specified
could compromise its efficiency.
Safety Measures:
•Store the device in a dry area and away from dust.
•Do not expose or install the device near sources of heat.
•Position the device in order to guarantee its proper ventilation.
•Do not use corrosive chemicals, solvents or harsh detergents to clean the
device.
The installation of the device was carefully tested by qualified
personnel in TEXA.
You must follow some indications provided by the vehicle
manufacturer in order to install the device correctly.
Safety Measures:
•Follow the indications provided in the vehicle's manual carefully to
disassemble the plastic parts and the access to the compartments.
•Respect the safety distances from the systems with the following functions:
•airbag;
•ABS;
•speed limiter;
•seat belt pretensioners.
Theinstallation of the devicerequires a connectionto the vehicle's
electrical system.
Perform the connection to the vehicle's electrical system making
sure not to compromise the safety and its correct functioning.
Safety Measures:
•Insulate each of the device's connections to the vehicle's electrical system.
•Equip the openings crossed by cables with fairleads.
•Do not compromise in any way the quality of the electrical and mechanical
OEM wiring.
•Make sure the electric cables, the wiring in general, the fuel hydraulic pipes
and the safety pneumatic devices of the vehicle are not damaged during the
installation. 15
en

•Make sure the installation does not compromise the correct functioning of
the vehicle's controls, in particular the brakes and, in general, the safety
devices.
•Donotconnect to theelectriccircuits ofsystemswith the followingfunctions:
•airbag;
•ABS;
•speed limiter;
•seat belt pretensioners.
•Do not change the current flow of an OEM circuit by cutting it off, increasing
it or mechanically changing it cables if not permitted by the vehicle
manufacturer.
The device must be installed so that it works correctly and safely.
Safety Measures:
•Avoid contact between the device and vibrating parts of the vehicle.
•Do not spread out the wiring with the cables stretched.
•Do not spread out the wiring in walkable areas or in areas that are subject
to friction without the necessary protections.
•For the installation you must use only the wiring and the components
provided with the device.
•Put the antenna at a minimum distance of 20 cm from the positions of the
vehicle's passengers.
At the end of the installation, you must restore the initial conditions
of the vehicle.
Safety Measures:
•Restore each OEM electrical connection.
•Restore each OEM device (ex.: compartment covers).
•Replace the fastening elements that are damaged.
•Restore any OEM anti-corrosion systems.
16

4 ENVIRONMENTAL INFORMATION
For information regarding the disposal of this product please
see the pamphlet supplied.
17
en

5 OPERATION OF THE TOOL'S RADIO DEVICES
Wireless connection with Bluetooth, WiFi and HSUPA technology
Wireless connectivity through Bluetooth, WiFi and HSUPA is a technology
that supplies a standard, reliable method for exchanging information
betweendifferent devices using radio waves.Manyother products besides
those built by TEXA use this technology, such as mobile phones, portable
devices, Computers, printers, cameras, Pocket PCs etc.
The Bluetooth, WiFi and HSUPA interfaces search for compatible
electronic devices based on the radio signals they emit and establish a
connection. TEXA tools only select and prompt compatible TEXA devices.
This does not exclude the presence of other sources of communication or
disturbance.
THE EFFICIENCY AND QUALITY OF BLUETOOTH, WiFi AND HSUPA
COMMUNICATIONMAYBEAFFECTEDBYTHEPRESENCEOFRADIO
DISTURBANCE.THECOMMUNICATIONPROTOCOLISDESIGNEDTO
MANAGE THESE TYPES OF ERRORS; HOWEVER, IN SUCH CASES
COMMUNICATION MAY BE DIFFICULT AND CONNECTION MAY
REQUIRE SEVERAL ATTEMPTS.
SHOULD THE WIRELESS CONNECTION ENCOUNTER SERIOUS
PROBLEMS AND COMPROMISE REGULAR COMMUNICATION, THE
SOURCE OF THE ENVIRONMENTAL ELECTROMAGNETIC
DISTURBANCEMUSTBEIDENTIFIED ANDITSINTENSITYREDUCED.
Position the tool so that the radio devices it is equipped with can work
properly.Inparticular,donotcoveritwithanyshieldingormetallicmaterials
in general.
18

6 NORMATIVE INFORMATION
Declaration of Conformity
TEXA S.p.A. hereby declares that the TMD2 complies with the
essentialrequirementsandwithallfurtherprovisions as defined
by the 1999/5/EC regulation.
A copy of the complete Declaration of Conformity can be obtained at:
TEXA S.p.A., Via 1 Maggio 9, 31050 Monastier di Treviso (TV), Italy
Antennas
This product was designed and tested to work with the provided antennas.
In order to guarantee the compliance with the above mentioned
regulations,usetheapplianceonlywiththeprovidedantennasorwithother
antennas authorized by TEXA S.p.A.
19
en

7 DESCRIPTION
TMD2 is a GPS localization device able to communicate via Bluetooth with
other diagnosis devices.
The TMD2 Kit includes:
•TMD2.
•External GPS antenna (optional).
•Wiring for the electrical connection.
•Installation Manual.
20
